Universal Space FUNFAIR BASH User manual

Operation Manual
www.universal-space.com

Rev1.0
1
Non-technical personnel who do not have technical knowledge and
Expertise should refrain from performing such work that this manual
require or perform tasks which are not explained in this manual.
Failing to comply can cause severe accidents such as electric shock or
other serious injuries. All repairs must be performed to original
manufacturer specifications.
WARNING: To reduce the risk of fire, electric shock or personal injury,
unplug or disconnect the machine from the power supply before
servicing.
CONTENT
IMPORTANT SAFETY INSTRUCTIONS .............................................................. 2
1. SPECIFICATIONS ......................................................................................... 4
2. PACKAGE CONTENTS .................................................................................. 5
3. PART NAME ................................................................................................. 6
4. SET UP & INSTALLATION ............................................................................ 7
5. HOW TO PLAY ............................................................................................ 10
6. GAME OPTIONS ......................................................................................... 12
7. ERROR MESSAGE AND RECOVERY .......................................................... 14
8. MAINTENANCE, INSPECTION .................................................................... 15
9. OVERALL CONSTRUCTION ........................................................................ 16
10. DECAL ...................................................................................................... 37

Rev. 1.0
2
Thank you for purchasing Fun Fair Bash. We hope you enjoy the product.
This manual contains valuable information about how to operate and maintain your game
machine properly and safely. It is intended for the owner and/or personnel in charge of product
operation. Carefully read and understand the instructions.
If you need any help during installation and setup please utilize this manual and
troubleshooting guide. If the product fails to function properly, non-technical personnel should
under no circumstance attempt to service the machine. Contact your distributor or
manufacturer for help.
Before use, please read IMPORTANT SAFETY INSTRUCTIONS.
IMPORTANT SAFETY INSTRUCTIONS
To ensure the safe usage of this product, carefully read and
understand these instructions before operating your game.
Save these instructions for future reference.
Use this product only as described in this manual. Other uses not recommended may cause
fire, electric shock or personal injury. Unplug the game from the outlet when not in use, when
moving from one location to another, and before cleaning/servicing.
Explanations which require special attention are indicated by signs of warning. Depending on
the potential hazardous degree, the terms: NOTE, NOTICE, and WARNING are used.
NOTE: A NOTE indicates useful hints or information about product usage.
NOTICE: A NOTICE indicates potential damage to product and how to avoid the problem.
WARNING: A WARNING indicates a potential for product damage or serious personal Injury.
It is important to understand the meaning of the following HAZARD SIGNS before continuing:
High Voltage and Shock Hazard:
High voltage can cause electric shock.
Turn off/unplug power before servicing.
High Temperature Hazard:
This part may cause scalding.
Do not touch. Surface may be hot.
No Touching Hazard:
This part may be hot or can cause electric shock.
Do not touch.
Use the following safety guidelines to help ensure your own personal safety and to help protect
your equipment and surrounding environment from potential damage.

Rev1.0
3
This product is an indoor game machine. Do not install outdoors.
Avoid installing in the following places to prevent fire, electric shock, injury and/or
machine malfunctioning:
 Places subject to rain/moisture, or places subject to high humidity.
 Places subject to direct sunlight, or places subject to extremely hot or cold temperatures to
ensure that it is used within the specified operating range.
 Places where inflammable gas may be present or in the vicinity of highly
inflammable/volatile chemicals or items that can easily catch fire
 On unstable or sloped surfaces. The machine may topple or cause unforeseen accidents.
 Vicinity of fire exits, fire extinguishers etc that may block/prevent safety measures
IMPORTANT NOTE:
ALL REPAIRS MUST BE DONE TO ORIGINAL MANUFACTURER SPECIFICATIONS.
FAILURE TO DO SO VOID ALL WARRANTIES AND OPERATOR ASSUMES ALL
RISKS.
Note: The contents of this manual may be updated without notice.

Rev. 1.0
4
1. SPECIFICATIONS
Rated power supply: AC110V 50/60Hz
Min. Power consumption: 400W
Max. Power consumption：450W
Dimensions： W803×D2102×H2518 (mm)
Weight： Approximately 250.5kg
NOTICE: After turning off the game, please wait at least 1 minute before
restarting again.
Note: Game parameters are subject to change without notice.
2518
2102
803

Rev1.0
5
2. PACKAGE CONTENTS
Open the package and make sure all the items are included:
 1 x Body Assembly
 Following accessories
No. Part No. Code Name Spec. Qty Picture
1 F126-428-000 23301000001 Power cord 10A/250V 1.8m 1
2 F126-434-000 21901000013 Fuse T5A/250V
Φ5-20mm 1
3 F126-727-000 41441205001 Manual 中文 1
4 F126-832-000 25300171002 Key 171 2
5 F126-833-000 25302222002 Key 2222 2
6 F126-835-000 41300000003 USB Lenovo 2G 1
7 F126-836-000 41000000114 Ball VBS75 50
Total
58
If any items are found to be missing, please contact your sales representative
for help immediately.
NOTE: Part models are subject to change without notice.

Rev. 1.0
6
灯箱组件
3. PART NAME
Gate assy.
Control
panel assy.
Ticket dispenser
Coin
mech.
Side window
Monitor assy.
Wooden box
assy.
Marquee assy.

Rev1.0
7
4. SET UP & INSTALLATION
This product is an indoor game machine. Do not install outdoors.
 Refer to IMPORTANT SAFETY INSTRUCTIONS (Pg. 2) for places to avoid
 Place the unit on a dry level surface
 Ventilation openings in the back of the unit must not be obstructed by objects or by wall.
4.1 Play Zone
This machine requires space for playing and for maintenance as shown below.
Leave space around the game upon installation:
Service Area: 500mm
Play Area: 500mm

Rev. 1.0
8
4.2 Level Adjustment
Install this machine on a flat surface. Adjust levers to lift casters off the ground to level the
game. If the game is installed on an unsuitable floor, it could cause game malfunction.
To secure the game, adjust the Leveler down until it touches the floor, lifting the casters off the
ground by 5mm. Repeat the same for all levelers.
4.3 Transporting the Machine
If you need to move the game, adjust the levelers back to an “up” position so the casters touch
the ground.
NOTICE
 Be careful not to damage the machine during transport.
 The machine should be handled with care when bringing it down from a higher level.
 Always unplug the game before moving.
 Keep the machine in upright position during transport.
 For longer distance transport, package the game properly to prevent damages.
Leveler
Caster
Move
About 5 mm
Fix
Make sure the machine is level with the ground and all the
adjustable legs should stick to the floor closely.
NOTICE
Leveler Caster
Fix

Rev1.0
9
4.4 Connecting Power
WARNING: Check the voltage rating before you connect the equipment to an
electrical outlet to ensure that the required voltage and frequency match the
available power source. Please refer the label of the machine.
 Do not plug the equipment power cables into an electrical outlet if the power cable is
damaged.
 Avoid putting many loads on one electrical outlet as it could generate heat and fire
resulting from overload.
 Connect the grounding conductor to the earth terminal (GND):
WARNING
Ensure no heavy objects rest on the power cord. Check to make sure the game cabinet does
not sit on the power cord as this could damage the cord and become hazardous.
To disconnect the game, grip the plug and pull it from the wall outlet. Never pull by the cord.
To prevent electric shock, do not touch the power plug when hand is wet.
Ensure that nothing rests on the power cord and that it is not located where it can be stepped
on or tripped over.
Power socket
Power outlet
Power plug
Power cord
Power plug

Rev. 1.0
10
5. HOW TO PLAY
5.1 Game Interface
5.2 How to play
Stage 1: Stage 2:
Knock’Em over Clown Tumbler
Knock off all the milk bottles from the table. Hit down all the tumblers!
Tip: Aim at the bottom of the tumblers
A: Display game remaining time
B: Game rules
C1:Balls
C2::Hit target
D: Game time
E: Target
F: How many targets have hit

Rev1.0
11
Stage 3: Stage 4:
Rolling barrels Clown pins
Break all the barrels! Knock out all the BOWLING PINS!!
Tip: Aim at the target signs!
Stage 5:
Clown Wheel
Hit all four targets behind the clown!
Tip: Do not hit the clown!

Rev. 1.0
12
6. GAME OPTIONS
6.1 Button Distribution:
You can see setting button after you open the coin
door under orange fishing mechanism. Press test
button, and enter to setting menu.
6.2 Main Menu Options
Main Menu Item settings (default)
Game Mode
Free Play OFF/ON (ON)
Ticket Out
OFF/ON (OFF)
Attract Mode
OFF/ON (OFF)
Save Coin
OFF/ON (ON)
Volume
1-10 (10)
Coin Per Game
1-10 (2)
Game 01 Time
5-50 seconds (30)
Game 02 Time
5-50 seconds (25)
Game 03 Time
5-50 seconds (20)
Game 04 Time
5-50 seconds (20)
Game 05 Time
5-50 seconds (15)
Tickets/Prizes
Ticket/Prizes (ticket)
Payout
1-50 ticket/coin (10)
MercyTickets
1-15 tickets (2)
------
Level
Easy/normal/Hard (normal)
Game 1 Prize
1-1000 tickets (20)
Game 2 Prize
1-1000 tickets (30)
Game 3 Prize
1-1000 tickets (50)
Game 4 Prize
1-1000 tickets (100)
Game 5
Prize
1-1000 tickets (200)
Continue
OFF/ON (ON)
Back
Input Test
Coin1 OFF/ON (ON)
1#TestRest
OFF/ON (ON)
ServerCoin0 OFF/ON (ON)
1#Vol-
OFF/ON (ON)
1#Vol+
OFF/ON (ON)
ScreenTest0 OFF/ON (ON)
BallCounter0
OFF/ON (ON)
Output Test
1#Send Ball OFF/ON (ON)
Back

Rev1.0
13
Reset Game Setting
Rest Game Setting
Rest to default
Delete All Record Clear all records
Clear Tickets clear owed ticket amount
Back
language
English Play in English
简体中文(Chinese) Play In Chinese
Date/Time Setting
Year
Current year
Month
Current month
Day
Current day
Ho
ur(24)
Current hour
Minute
Current minute
Second
Current second
Save&Back
Back
PC information
CPU: Intel(R) Pentum(R) Dual CPU E2180 @ 2.00GHz
MotherBoard Colorful Technology And Development Co.LTD
DiskDrive ST3160813AS ATA Device 149GB
Memory 307MB
Display Adapter NVDIA GoForce 9600 GSO
DisplayRAMSize 256MB
Bookkeeping
Player Coins Tickets Payout
1 4 0 0.00
2 0 0 0.00
Sum 4 0 0.00
Daily Record Date Weekday RunTime Coins Tickets payout
2013-4-1 Monday 00:30 5 4 0
Back(no)
Back(Yes)

Rev. 1.0
14
7. ERROR MESSAGE AND RECOVERY
7.1 Error Message
Symptom: Screen displays message “Communication ERROR” (there is communication
problem with the game)
Possible Causes & Fixes:
 Communication data wire is damaged  Replace the data wire.
 SCM is not working  Ask your technician to check and repair
 PC COM port has been used  Ask your technician to check and repair
Symptom: Screen displays ““PLEASE CALL ATTENDENT”, “TICKET ERROR” (there is problem in
the ticket payout function)
Possible Causes & Fixes:
No tickets in the game  Replenish tickets and then press the TICKET RESET button.
Ticket dispenser is damaged  Replace with a new ticket dispenser.
Faulty connection  Ask the technician to check and repair.
7.2 System Recovery Operation
1. Turn off the game. Insert the memory
stick into the USB port at the back of the
computer.
2. Restart PC to enter the system recovery
screen as shown.
3. The game will automatically start
recovery which will last about 5 minutes.
Please wait until process is complete.
WARNING: the USB flash drive should only be used to fix software errors. Using it for
other purposes may cause unexpected results and damages.
4. Once system recovery is finished (as shown on
the left), remove the USB flash drive from the
computer and turn off the PC. Wait at least 30
seconds before restarting the PC.

Rev1.0
15
8. MAINTENANCE, INSPECTION
8.1 Safety Check
Check the points listed before operating the machine. These checks are necessary for safe
machine operation:
1. Try to run the game before operation each day.
2. Conduct monthly routine checks of game components ensure good working condition
3. Check the machine regularly for dust and clean when necessary.
Note: Parts and components require preventative maintenance to be kept running smoothly.
8.2 Handling Precautions
When installing or inspecting the machine, be very careful of the following points and pay
attention to ensure that the player can enjoy the game safely.
Non-compliance with the following points or inappropriate handling running counter to the
cautionary matters herein stated can cause personal injury or damage to the machine.
• Before servicing the machine, be sure to turn power off. Servicing without turning the
power off can cause electric shock or short circuit.
• To avoid electric shock or short circuit, do not plug then unplug the power quickly
• Do not expose power cords and earth wires, these are susceptible to damage.
• Damaged cords and wires can cause electric shock or short circuit and should be
replaced immediately.
• When or after installing the product, avoid pulling the power cord to prevent
unnecessary wear and tear. Use the power button to disconnect power.
• In case the power cord is damaged, ask for replacement through where the product was
purchased from or replace locally. Continued usage of damaged cord can cause fire, electric
shock or leakage.
• Perform grounding appropriately. Inappropriate grounding can cause electric shock.
• Use fuses that meet specified rating. Fuses exceeding can cause an electric shock.
• Should a problem occur, turn off the power immediately and stop operating the machine.
Unplug the power cord of the service outlet. Operating the machine without correcting the
problem may cause a fire or injuries.
• Insert the power plug securely into the outlet. Poor contact may cause overheating,
resulting in fire or burns.
• To ensure the warning labels attached on the machine are visible and legible, install the
machine in a well-lit location, and keep the labels clean at all times. Make sure the labels
are not hidden behind other game machines.
WARNING

Rev. 1.0
16
9. OVERALL CONSTRUCTION
9.1 Mechanical Part
9.1.1 Castor, T-molding, coin door assy.
No. Part No. Code No. Name Material/Spec. Qty
1 F126-124-000 20211211022 Cabinet front T-molding t1.2 powder red 2
2 F126-171-000 26000008000 2.5” leveler M16X100
(zinc plating) 4
3 F126-125-000 20211211023 Cabinet side T-molding t1.2 powder red 2
4 F126-172-000 26000010000 2.5” castor bracket δ3(zinc plating) 4
5 F126-446-000 25501000056 2.5” castor 3-2689-52 4
6 F126-449-000 26000015000 Coin door Assembly
(powder black) 1
7 F126-200-000 20101040007
Hexagon socket button head
screws
M4×20 nickel
plating 14
8 F126-215-000 20102000014 Hexagon nut M16 4
9 F126-221-000 20104000021
Cross recessed hexagon bolt
with indentation
M6×25
GB/T29.2-1988 32
10 F126-186-000 20104010036 Cup head square neck bolts M5×25 black 8
11 F126-205-000 20102100030 Hexagon nut with flange M5 8

Rev1.0
17
9.1.2 Electric Assy.
No. Part No. K3 code Name Spec. Qty
1 F126-517-000 20311211016 Electrical base plate t15 1
2 F126-127-000 20211211025 Plate down glide slot t2 powder black 1
3 F126-126-000 20211211024 Terminal port board t1.5 1
4 F126-128-000 20211211026 Plate up glide slot t1.5 powder black 1
5 F126-167-000 20221004026 Power platen 1
6 F126-168-000 26000001000
SW power supply support
base δ1.2 1
7 F126-202-000 20101030187 Butterfly screw M5×25 white zinc 1
8 F126-232-000 20101020036
Cross recessed countersunk
head set screw M4×16 color zinc 7
9 F126-233-000 20101020159
Cross recessed countersunk
head set screw M3×12 color zinc 4
10 F126-234-000 20104010003 Cross recessed hexagon bolts M6×20 black 2

Rev. 1.0
18
9.1.3 Monitor Assy.
No. Part No. K3 code Name Spec. Qty
1 F126-129-000 20211211027 Monitor down fixed plate t2 powder black 1
2 F126-131-000 20611211004 Long sticker t3 single with tape 2
3 F126-132-000 20611211005 Short sticker t3 single with tape 2
4 F126-133-000 20611211020 Monitor glass t5 1
5 F126-134-000 20611211021 Touch screen long sticker t10 double with tape 2
6 F126-135-000 20611211023 Touch screen short sticker t10 double with tape 2
7 F126-411-000 21202046001 46” sensor touch screen F46WHOOU-02 1
8 F126-407-000 21201047001 47” LCD MT47W-2630 1
9 F126-130-000 20211211028 Monitor up fixed plate t2 powder black 1
10 F126-101-000 20211211001 Monitor fixed plate t2 2
11 F126-122-000 20211211020 Monitor down cant board t2 1
12 F126-197-000 20101020040
Cross recessed
countersunk head set
screw
M4×8 color zinc 6
13 F126-184-000 20101010043
Cross recessed
countersunk head set
screw
M5×20 black 7

Rev1.0
19
9.1.4 Marquee Assy.
No. Part No. K3 code Name Spec. Qty
1 F126-517-000 20311211017 Marquee bottom board 1
2 F126-139-000 20211211031 Vacuum foam fixed plate t1.5 7
3 F126-142-000 20611211008
Marquee R transparent
plate t10 1
4 F126-701-000 20511211001
Marquee vacuum foam
decal
830*730 silk-screen
printing
1
5 F126-138-000 20611211006
Marquee down transparent
plate t10 1
6 F126-141-000 20611211007
Marquee L transparent
plate t10 1
7 F126-140-000 20211211032 Light tube fixed plate t1 4
8 F126-137-000 20211211030 Marquee up fixed plate t1.5 powder black 1
9 F126-464-000 40814060001
Acetate cloth insulating
tape 10mmX30m 2.4
10 F126-136-000 20211211029 Marquee down fixed plate t2 2
11 F126-183-000 20101020036
Cross recessed pan head
set screw M4×16 color zinc 22
12 F126-195-000 20101107001
Hexagon socket
countersunk heat screws M4×20 10
13 F126-196-000 20101108018
Hexagon socket button
head screws M4×12 7
14 F126-184-000 20101010043
Cross recessed pan head
set screw M5×20 black 8
15 F126-512-000 20311211010 Marquee fixed board T15 MDF 1
