Uplus Lighting 200 MZ-SPOT PR User manual

(Manual zoom 15-50°)
User manual
200 MZ-SPOT PR
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions……………………………………………………………………………3
2.Technical Specifications………………………………………………………………………4
3.Descriptions………………………………………………………………………………………5
4.Unpacking…………………………………………………………………………………………5
5.Control Menu ……………………………………………………………………………………6-7
6.DMX Channels ……………………………………………………………………………………7
7.Dimension …………………………………………………………………………………………8
8.LUX Date ……………………………………………………………………………………………8
9.Trouble Shooting…………………………………………………………………………………9
10.Fixture Cleaning………………………………………………………… ………………………9
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also
receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power requirements of the
unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent surfaces. Be sure
that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always by taking its
base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher than this Unit
surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand during its operation. Turn off
the power and allow about 15 minutes for the unit to cool down before replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit by yourself.
Repairs carried out by unskilled people can lead to damage or malfunction. Please contact the nearest
authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any repairs yourself.
In the unlikely event your unit may require service, please contact your nearest dealer.
Installation:
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly fixed to
avoid vibration and slipping while operating. And make sure that the structure to which you are attaching the unit
is secure and is able to support a weight of 10 times of the unit’s weight. Also always use a safety cable that can
hold 12 times of the weight of the unit when installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the touch of
people.

4
2.Technical Specifications
Light Source:
LED POWER: 200W
Cool White 5600K or Warm White 3200K (200W) COB LED
Led Lamp: Imported LED
Color Rendering Index(CRI): Ra≥90
LED Life Time: over 50,000 hours
Power supply:
Voltage: AC100-240V
Max.power: 200W
Optics:
Zooming Scale: 15-50°
Manual zoom
Soft and even field of light
Features:
House Material: Aluminum Alloy
House Color: Black
Strobe :1-25times/sec
Control:
Control System: DMX, Auto run and Master/Slave
Manual zoom: 1/3CH
Working Environment :
Environment Temperature: -30°C~40°C
Cooling system : No noise fan of Pccooler
IP Grade: IP20
Package :
Dimensions: 397(D)*211(W)*378(H)mm
Net weight: 8.5kgs
Gross weight: 11kgs
Packing Size: 58x32.5x32cm (1pc/carton)

5
3.Descriptions
·· Works perfectly on conventional dimmers or constant power with DMX
·Motorized zoom angle between 15° to 50°, manually
·Ultra smooth 16-bit dimming of master dimmer
·Soft and even field of light
·Simple and complex DMX channel profiles for programming versatility
·Warm white and cool white Fresnel-style lighting fixture
·Virtually silent operation for use in studio and theatre applications
4.Unpacking
Thank you for choosing our 200 MZ-SPOT PR. For your own safety, please read this manual before installing the
device. This manual covers the important information on installation and applications. Please install and operate
the fixture with following instructions. Meanwhile, please keep this manual well for future needs.
The 200 MZ-SPOT PR is made of a new type of high temperature strength of cast aluminum casing with nice
outlook. The fixture is designed and manufactured strictly following CE&RoHS standards, complying with
international standard DMX512 protocol. It's available independently controlled and linkable with each other for
operation. And it is applicable for large-scale live performances, theater, studio, nightclubs and discos.
The 200 MZ-SPOT PR adopts 1PCS 200W COB LED (available for CW Or WW) which features high brightness
and stability. Please carefully unpack it when you receive the fixture and check whether it is damaged during the
transportation. And please check whether the following items are included inside the box:

6
5.Control Menu
.
Menu
State
Operation
Remark
Main
Menu
Vice Menu
No vice menu
A: advance
UP/DOW
N
adjust ID adress
disconnect the controller
and connect the master
light, then it will follow the
master light.
It will flicker if no signal.
External
control mode
(standard
channel
model)
ENTER
save the ID address
No vice menu
d: dmx
UP/DOW
N
adjust ID address
External
control mode
(Basic
channel
model)
ENTER
Save the ID address
two vice menu
StAt: static
ENTER
enter vice menu
Static model
C: Color
UP/DOW
N
change value of
color
Menu：
The first list is the main menu (press MENU to exchange), the
second list is submenu (press ENTER to get in or exchange)
If the menu include the decimal point, that’s the data, and it can be
set by the Key of Up/Down.
Key operation：
Key of “MENU” (Press it and can save the data)
If it’s the main menu, it will exchange to next main menu.
If it’s the submenu , it will back to main menu.
Key of “ENTER” (Press it and can save the data)
If it’s the main menu and it have submenu, it will enter the submenu.
If it’s the submenu, it will exchange to the next submenu
Key of “UP/DOWN”
It’s no function if the menu not include the decimal point.
If the menu include the decimal point, it can set the data after the
decimal point. And it need to press “ENTER” to save the data.

7
Set the color
ENTER
save the data
change to the vice
menu
St: strobe
UP/DOW
N
change value of
strobe
strobe and its
speed
ENTER
save and exchange
two vice menu
tEMp:
temperature
ENTER
enter the vice menu
temperature
control
current
temperature
ENTER
change to vice menu
t: top
UP/DOW
N
change the data of
temperature protect
set the protect
temperature
ENTER
save and change
No vice menu
diSP: display
ENTER
reverse the display
set to show
reverse
display
No vice menu
rESt: reset
ENTER
enter the interface of
key
the password is “UP
DONW UP DOWN”
return Initial
State
return Initial
State
6.DMX Channels
Model – CH3
channel
data
function
Mark
1
0~255
dimmer
2
0~10
default delay of dimmer
11~15
no dimmer
16~255
Choose delay of dimmer
16 is the shortest delay time, increase gradually....
255 is the longest delay time
3
0~10
no strobe
11~255
speed of strobe (255 is fastest)
Model – CH1
channel
data
function
1
0~255
dimmer

8
7.Dimension
Size of the fixture: 379(D)*211(W)*378(H)mm
8.LUX Date

9
9.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X
p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
10.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates:
damp, smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
