Uplus Lighting BAR 6 LASER User manual

User manual
BAR 6 LASER
Please read the instructions carefully before use

2
TABLE OF CONTENTS
1. Safety Instructions……………………………………………………………………………3-4
Technical Specifications…………………………………………………………………………4
Control Menu ………………………………………………………………………………………5-6
DMX Channels ………………………………………………………………………………………7
Trouble Shooting……………………………………………………………………………………8
Fixture Cleaning………………………………………………………… …………………………8
STATEMENT
The product has well capability and intact packing when leave factory. All of the user should
comply with warning item and manual, any misuse cause of the damages are not included in our
guarantee, and also can not be responsible for any malfunction & problem owing to ignore the
manual.

3
1.Safety Instructions
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction booklet.
•Unpack and check carefully there is no transportation damage before using the unit.
•Before operating, ensure that the voltage and frequency of power supply match the power
requirements of the unit.
•It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
•The unit is for indoor use only. Use only in a dry location.
•The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces. Be sure that no ventilation slots are blocked.
•Disconnect main power before replacement or servicing.
•Make sure there are no flammable materials close to the unit while operating as it is fire hazard.
•Use safety cable when fixes this unit. DO NOT handle the unit by taking its head only, but always
by taking its base.
•Maximum ambient temperature is Ta: 40℃. DO NOT operate it where the temperature is higher
than this Unit surface temperature may reach up to 85℃. DO NOT touch the housing bare-hand
during its operation. Turn off the power and allow about 15 minutes for the unit to cool down before
replacing or serving.
•the event of serious operating problem, stop using the unit immediately.Never try to repair the unit
by yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center. Always use the same type spare parts.
•DO NOT touch any wire during operation as high voltage might be causing electric shock.
Warning:
•To prevent or reduce the risk of electrical shock or fire, do not expose the unit to rain or moisture.
•The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
Caution:
•There are no user serviceable parts inside the unit. DO NOT open the housing or attempt any
repairs yourself. In the unlikely event your unit may require service, please contact your nearest
dealer.
Installation:
•The unit should be mounted via its screw holes on the bracket. Always ensure that the unit is firmly

4
fixed to avoid vibration and slipping while operating. And make sure that the structure to which you
are attaching the unit is secure and is able to support a weight of 10 times of the unit’s weight. Also
always use a safety cable that can hold 12 times of the weight of the unit when installing the fixture.
•The equipment must be fixed by professionals. And it must be fixed at a place where is out of the
touch of people.
2.Technical Specifications
Input Voltage: 100-240V,50/60Hz
Light Source: 6x2W RGB 3in1 Color (Red: 638 nm Green: 520 nm blue: 447 NM)
Laser Patterns: 128 Laser Animation Patterns (Built-in: Geometric Lines and Dotting Effect 2
Patterns)
Light source life: 50000 hours
Power:180W
Modulation signal:TTL modulation
Laser color:RGB full color Scanner:15KPPS*6pcs
Dimmer:0-100%(16bit)
Strobe:1-20Hz
DMX Channels: 12/62/60(10*6)CH
Control mode:DMX512, voice control, self-walking
Fixture Size:99*22*25; NW: 12 KG

5
3.Control Menu
MENU
Secondary menu
tertiary menu
1、DMX-512 Mode
DMX-512 Mode/
Address/
Channel/ Expert/
Address Setup/
Channel Setup/
Normal Mode/
Expert Mode/
2、Auto Mode
Auto Mode/
Effect/ Mix/
AutoSpeed/ 50%
Auto Effect/
Mix Show/
Lines Show/
Beams Show/
Auto Speed/self-propelled speed
50%
3、Music Mode
Music Mode/
Effect Mix/
MusicSpeed / 50%
Music Effect/
Mix Show/
Lines Show/
Beams Show/
Music Speed/
50%
4、Laser Light
Laser Light/
Scanner/20KPPS
Color/ RGB
Laser/ Analog
Invert/ Normal
Image Size X Y
Position/ X Y
Scan Rate/
15KPPS
Color Setup/
Single/
RGY
RBP
GBC
RGB

6
WYPC
Laser Type/
TTL /TTL
Analog/
Normal /
invert X /
invert Y /
invert XY/
Image Size/size setting
Size X /Size X
Size Y/SizeY
Position Setup/
position X/
position Y/
5、Settings
Settings/
Reset Default/
SafetyProtected/
Master Setup/
Back Light/
Language/
Display Setup/
About System/
Reset Default/
Yes/
No/
SafetyProtected/
Turn ON/
Turn OFF/
Master Setup/
Turn ON/
Turn OFF/
Back Light/
Normally ON/
Delay 15S OFF/
Language/
Chinese/
English/
Display Setup/
Rotate 180deg/
NormalDisplay/
LaserSystem2.9/
Software/
Version 1.0/Ver1.0
YM:20190301001

7
4.DMX Channels
12 CH Mode
Channel
value
Function
CH1
dimmer
0～255
dimmer 0~100%
CH2
red
0～255
Red 0~100%
CH3
green
0～255
Green 0~100%
CH4
blue
0～255
Blue 0~100%
CH5
Animation selection
0～255
One animation each 3 value
CH6
horizontal position
1～255
horizontal position selection
CH7
vertical position
1～255
vertical position selection
CH8
Pattern size
0～255
Pattern size selection
CH9
Line scan speed
0～127
Line scan speed
dot scan speed
128～255
dot scan speed
CH10
strobe
1～127
Strobe speed
Gradient
128～255
Gradient position
CH11
Pattern
0～127
Line effect
128～255
Dot effect
CH12
Mode select
0～26
Manual control mode
27～127
Built-in self-propelled mode speed selection
128～255
Built-in voice control mode speed selection
62 CH Mode
Channel
value
Function
CH61
Pattern
0～127
Line effect
128～255
Dot effect
CH62
Mode select
0～26
Manual control mode
27～127
Built-in self-propelled mode speed selection
128～255
Built-in voice control mode speed selection
60 CH Mode 10*6CH
Channel
value
Function
CH1
dimmer
0～255
dimmer 0~100%
CH2
red
0～255
Red 0~100%
CH3
green
0～255
Green 0~100%
CH4
blue
0～255
Blue 0~100%
CH5
Animation selection
0～255
One animation each 3 value
CH6
horizontal position
1～255
horizontal position selection
CH7
vertical position
1～255
vertical position selection
CH8
Pattern size
0～255
Pattern size selection
CH9
Line scan speed
0～127
Line scan speed
dot scan speed
128～255
dot scan speed
CH10
strobe
1～127
Strobe speed
Gradient
128～255
Gradient position

8
5.Trouble Shooting
F ollo w ing a r e a few c o mm on p r oble m s th a t m a y occu r d uring ope r a tion . He r e a r e s o m e s ug g es tion s fo r
ea s y tr ou b leshooting :
A. The un it does no t work , no li ght a n d t he f a n d o es no t w o r k
1. Check th e c on nect ion of p owe r a nd m a in fu s e .
2. M eas ure th e m a ins volt a ge on th e m a i n co nn e ct o r .
3. Check th e pow er on LED .
B. N o t responding t o D MX c on t ro ll er
1. D M X LED s h ou ld b e on. If no t, che ck D M X co n nectors, ca b l es to s ee if link p r ope r ly .
2. If th e D M X LE D i s on a nd no r espons e t o th e c h a nn el, che ck th e a dd r ess s etti ng s a nd D M X p ol a r ity .
3. If y ou h a ve i nter m ittent D M X s ig n a l p r oble m s , che ck th e p ins on c onn ecto r s or on
PCB of th e u nit or the p r ev iou s on e.
4. Tr y to us e a no th er D M X co ntroller .
5. Check if th e D M X ca b le s r un ne a r or run a lon g s id e t o h ig h volta ge c a b les th a t m a y c a us e d a m a ge or
in terfer ence to D M X inter face circui t.
C . One of the cha nn el s is no t w o r k ing w el l
1. Th e s tep p er moto r m ig h t b e dam a g ed or the c a b le c on nect ed to th e PCB is b r oken.
2. Th e m oto r ’ s d r ive IC on th e PCB m ig h t b e o ut of co ndition
6.Fixture Cleaning
The cleaning of internal and external optical lenses and/or mirrors must be carried out periodically to
optimize light output. Cleaning frequency depends on the environment in which the fixture operates: damp,
smoky or particularly dirty surrounding can cause greater accumulation of dirt on the unit’s optics.
Clean with soft cloth using normal glass cleaning fluid.
Always dry the parts carefully.
Clean the external optics at least every 20 days. Clean the internal optics at least every 30/60 days.
