WIKA PASCAL ET-P User manual

Multichannel Calibrator PASCAL ET, ET-P, ET/IS, ET-P/IS
GB
Documenting Multivariable Multichannel Calibrator PASCAL ET, ET-P, ET/IS, ET-P/IS
Operating instructions

2 WIKA Operating Instruction, Pascal ET, ET-P, ET/IS, ET-P/IS
GB
Operating instructions ET, ET-P, ET/IS, ET-P/IS
Page
5 - 84
Rev. 10 –October 2017.
© 2017 WIKA Alexander Wiegand SE & Co. KG
All rights reserved.
WIKA® is a registered trademark in various countries.
Prior to starting any work, read the operating instructions!
Keep for later use!

Contents
WIKA Operating Instruction, Model Pascal ET, ET-P, ET/IS, ET-P/IS 3
GB
1General Information...........................................................................................................5
2Safety .................................................................................................................................6
2.1 Intended use..........................................................................................................................................7
2.2 Personnel qualification...........................................................................................................................7
2.3 Additional safety instructions for instruments with ATEX approval only Pascal ET/IS.........................8
2.4 Special hazards .....................................................................................................................................9
2.5 Labelling / safety marks.......................................................................................................................10
3Specifications..................................................................................................................11
4Design and Function.......................................................................................................16
4.1 Description...........................................................................................................................................16
4.2 Scope of delivery .................................................................................................................................17
4.3 Power supply .......................................................................................................................................17
5Transport, packaging and storage................................................................................. 18
5.1 Transport..............................................................................................................................................18
5.2 Packaging ............................................................................................................................................18
5.3 Storage ................................................................................................................................................18
6Commissioning, operation..............................................................................................19
6.1 Commissioning ....................................................................................................................................19
6.1.1 Instrument overview.............................................................................................................................19
6.1.2 Functional Modules..............................................................................................................................19
6.1.2.1 Input module for electrical/temperature signals.................................................................................. 20
6.1.2.2 Output module for electrical/temperature signals............................................................................... 20
6.1.2.3 Pressure module................................................................................................................................. 21
6.1.2.4 HART module ..................................................................................................................................... 21
6.1.2.5 Environmental parameters module (optional)..................................................................................... 24
6.2 Electrical ..............................................................................................................................................24
6.2.1 Electrical measurements......................................................................................................................25
6.2.2 Thermocouple measurements.............................................................................................................26
6.2.3 Thermoresistance measurements.......................................................................................................27
6.2.4 Generation of electrical parameters.....................................................................................................28
6.2.5 Thermocouple simulation.....................................................................................................................28
6.2.6 Thermoresistance simulation...............................................................................................................29
6.3 User Interface ......................................................................................................................................30
6.3.1 Channel configuration..........................................................................................................................32
6.3.2 Other assignments...............................................................................................................................38
6.3.2.1 Pressure measurement....................................................................................................................... 38
6.3.2.2 Thermocouple signal measurement ................................................................................................... 41
6.3.2.3 Electrical parameter measurement..................................................................................................... 44
6.3.2.4 Temperature Simulation...................................................................................................................... 46
6.3.2.5 Electrical parameter generation.......................................................................................................... 46
6.3.2.6 Channel C or D –mathematic functions............................................................................................. 47
6.3.2.7 HART channel assignment................................................................................................................. 51
6.3.2.8 HART trimmer calibration.................................................................................................................... 54
6.3.2.9 HART scale adjust .............................................................................................................................. 56
6.4 Setting channel, function, instrument...................................................................................................57
6.4.1 Channel setting....................................................................................................................................57
6.4.2 Functions setting..................................................................................................................................60
6.4.3 Instrument setting ................................................................................................................................61
6.4.3.1 Setting the “F“ key of the keyboard..................................................................................................... 62
6.5 Channel settings..................................................................................................................................63
6.5.1 Offset On –Offset Off..........................................................................................................................63
6.5.2 Scaling .................................................................................................................................................64
6.5.3 Hold On –Hold Off...............................................................................................................................65
6.5.4 Modification of the generation/simulation value...................................................................................65
6.6 Report ..................................................................................................................................................66
6.6.1 Report of Tc/Rtd with dry well calibrator or dry block management....................................................71
6.7 Data Logger .........................................................................................................................................77

Contents
4 WIKA Operating Instruction, Pascal ET, ET-P, ET/IS, ET-P/IS
GB
6.8 Communication....................................................................................................................................78
6.9 Calibration Examples...........................................................................................................................79
6.9.1 Example 1 –Calibration of 2-wire pressure transmitters.....................................................................79
6.9.2 Example 2 –Calibration of PTZ gas volume converters .....................................................................80
6.9.3 Example 3 –Calibration of 4-wire RTD’s.............................................................................................80
6.9.4 Example 4 –Calibration of Thermocouples.........................................................................................82
7Maintenance, cleaning and servicing.............................................................................83
7.1 Maintenance ........................................................................................................................................83
7.2 Cleaning...............................................................................................................................................83
7.3 Recalibration........................................................................................................................................83
8Dismounting, return and disposal.................................................................................. 84
8.1 Dismounting.........................................................................................................................................84
8.2 Return ..................................................................................................................................................84
8.3 Disposal ...............................................................................................................................................84
Declarations of conformity can be found online at www.wika.com.

1 General Information
WIKA Operating Instruction, Model Pascal ET, ET-P, ET/IS, ET-P/IS 5
GB
1 General Information
■The Multichannel Calibrator model Pascal ET, ET-P, ET/IS, ET-P/IS described in the operating
instructions has been manufactured using state-of-the-art technology.
All components are subject to stringent quality and environmental criteria during production. Our
management systems are certified to ISO 9001 and ISO 14001.
■These operating instructions contain important information on handling the Multichannel
Calibrator model Pascal ET or Pascal ET/IS. Working safely requires that all safety instructions
and work instructions are observed.
■Observe the relevant local accident prevention regulations and general safety regulations for the
range of use of the Multichannel Calibrator model Pascal ET or Pascal ET/IS.
■The operating instructions are part of the instrument and must be kept in the immediate vicinity
of the Multichannel Calibrator model Pascal ET, ET-P, ET/IS, ET-P/IS and readily accessible to
skilled personnel at any time.
■Skilled personnel must have carefully read and understood the operating instructions, prior to
beginning any work.
■The manufacturer's liability is void in the case of any damage caused by using the product
contrary to its intended use, non-compliance with these operating instructions, assignment of
insufficiently qualified skilled personnel or unauthorized modifications to the Pascal ET or
Pascal ET/IS.
■The general terms and conditions, contained in the sales documentation, shall apply.
■Subject to technical modifications.
■Factory calibrations/DKD/DAkkS calibrations are carried out in accordance with international
standards.
■Further information:
- Internet address: www.wika.de / www.wika.com
- Relevant Data Sheet: CT 18.02
- Application consultant: Tel.: [phone]
Fax: [phone]
E-Mail:[e-mail]

1 General Information / 2 Safety
6 WIKA Operating Instruction, Pascal ET, ET-P, ET/IS, ET-P/IS
GB
Explanation of symbols
WARNING!
... indicates a potentially dangerous situation, which can result in serious
injury or death, if not avoided.
Information
... points out useful tips, recommendations and information for efficient and
trouble -free operation.
WARNING!
... indicates a potentially dangerous situation in a potentially explosive
atmosphere, resulting in serious injury or death, if not avoided.
2 Safety
WARNING!
Before installation, commissioning and operation, ensure that the appropriate
reference pressure sensor has been selected in terms of measuring range, design and
specific measuring conditions. Serious injuries and/or damage can occur should these
not be observed.
Further important safety instructions can be found in the individual chapters of these
operating instructions.

2 Safety
WIKA Operating Instruction, Model Pascal ET, ET-P, ET/IS, ET-P/IS 7
GB
2.1 Intended use
The Multichannel Calibrator model Pascal ET or Pascal ET IS gauge can be used as a calibration
instrument and also for any application which requires accuracy pressure measurement.
The Multichannel Calibrator model Pascal ET, ET-P, ET/IS, ET-P/IS has been designed and built
solely for the intended use described here, and may only be used accordingly.
The technical specifications contained in these operating instructions must be observed.
Improper handling or operation of the Multichannel Calibrator model Pascal ET, ET-P, ET/IS, ET-
P/IS outside of its technical specifications requires the instrument to be shut down immediately and
inspected by an authorized WIKA service engineer.
Handle electronic precision measuring instruments with the required care (protect from strong
magnetic fields, static electricity and extreme temperatures, do not insert any objects into the
instrument or its openings). Plugs and sockets must be protected from contamination.
If the Multichannel Calibrator model Pascal ET, ET-P, ET/IS, ET-P/IS are transported from a cold
into a warm environment, the formation of condensation may result in the instrument
malfunctioning. Before putting it back into operation, wait for the instrument temperature and the
room temperature to equalize.
The manufacturer shall not be liable for claims of any type based on operation contrary to the
intended use.
2.2 Personnel qualification
WARNING!
Risk of injury should qualification be insufficient!
Improper handling can result in considerable injury and damage to equipment.
■The activities described in these operating instructions may only be carried out by
skilled personnel who have the qualifications described below.
Skilled personnel
Skilled personnel are understood to be personnel who, based on their technical training,
knowledge of measurement and control technology and on their experience and knowledge of
country-specific regulations, current standards and directives, are capable of carrying out the work
described and independently recognizing potential hazards.
Special operating conditions require further appropriate knowledge, e.g. of aggressive media.

2 Safety
8 WIKA Operating Instruction, Pascal ET, ET-P, ET/IS, ET-P/IS
GB
2.3 Additional safety instructions for instruments with ATEX approval
only Pascal ET/IS
WARNING!
Non-observance of these instructions and their contents may result in the loss of
explosion protection.
■Battery operation:
Use only the rechargeable battery which is supplied by WIKA! Only charge the
battery outside of the hazardous area!
■Operation of the serial interface in the hazardous area is prohibited.
Further hazardous area safety instructions!
Observe the operating information and the relevant country-specific regulations
concerning use in hazardous areas (e.g. EN IEC 60079-14).
The Pascal ET/IS intrinsically safe multichannel calibrator has been designed for use
in Ex Hazardous Areas. These are areas where potentially flammable or explosive
vapors may occur. These areas are referred to as hazardous (classified) locations in
the United States, as Hazardous Locations in Canada, as Potentially Explosive
Atmospheres in Europe and as Explosive Gas Atmospheres by most of the rest of
the world. The Pascal ET/IS intrinsically safe multichannel calibrator is designed as
intrinsically safe. This means that connecting the Pascal ET/IS intrinsically safe
multichannel calibrator to equipment that is used within intrinsically safe circuits will
not cause an ignition capable arc as long as the entity parameters are suitably
matched.
Information/Approval for hazardous locations:
WARNING!
■Ex Hazardous Areas
An Ex-hazardous area as used in this manual refers to an area made hazardous
by the potential presence of flammable or explosive vapors. These areas are also
referred to as hazardous locations.
WARNING!
Only gauges powered by batteries are approved for use in hazardous locations.
Use only the rechargeable battery which is supplied by WIKA! Only charge the
battery outside of the hazardous area!
II 2G
Ex ib IIC T4 Gb - Tamb: -10°C / 50°C

2 Safety
WIKA Operating Instruction, Model Pascal ET, ET-P, ET/IS, ET-P/IS 9
GB
2.4 Special hazards
WARNING!
■When measuring pressure, make sure that the process pressure line is shut off
and depressurized before it is connected to or disconnected from the pressure
module.
■Disconnect test leads before changing to another measurement or generation
function.
■Observe the working conditions in accordance with chapter "3. Specifications".
■Always operate the device within its overload limits.
■To ensure problem-free operation, only operate the Multichannel Calibrator
model Pascal ET, ET-P, ET/IS, ET-P/IS on battery power. Only use the mains
connection for charging the Hand-held pressure calibrators batteries.
■Do not apply a voltage greater than the specified voltage to the instrument.
See chapter "3. Specifications".
■Make sure that the test probes never contact a voltage source while the test
leads are connected to the current terminals.
■Do not use the calibrator if it is damaged. Before using the multichannel
calibrator, check that there are no cracks or missing plastic parts on the case.
Pay particular attention to the insulation of the connectors.
■Select the proper function and correct measuring range for the measurement.
■Inspect the test leads for damaged insulation or exposed metal. Check the
continuity of the test leads. Damaged test leads should be replaced before using
the multichannel calibrator.
■When using test probes keep fingers away from the test probe contacts. Keep
your fingers behind the test probes' finger guards.
■First connect the common lead, and then the live lead. When disconnecting,
remove the live test lead first.
■Do not use the multichannel calibrator if it is not working properly. The
instrument protection might be compromised. If in doubt, have the instrument
checked.
■Do not operate the calibrator in areas with explosive gases, vapours or dust.
■To avoid false readings, which could lead to possible electric shock or personal
injury, charge the rechargeable battery as soon as the battery indicator appears.
■In order to avoid any possible damage to the multichannel calibrator or the test
equipment, use the correct leads, the correct function and the correct range for the
measuring application.

2 Safety
10 WIKA Operating Instruction, Pascal ET, ET-P, ET/IS, ET-P/IS
GB
2.5 Labelling / safety marks
Explanation of symbols
Pascal ET and Pascal ET/IS
Before mounting and commissioning the Multichannel Calibrator model
Pascal ET or Pascal ET/IS, ensure you read the operating instructions!
CE, European Community
Instruments bearing this mark comply with the relevant European directives.
This marking on the instruments indicates that they must not be disposed of in
domestic waste. The disposal is carried out by return to the manufacturer or by
the corresponding municipal authorities. See Directive 2002/96/EC.
Only Pascal ET/IS
ATEX European Explosion Protection Directive
(Atmosphère = AT, explosible = Ex)
Instruments bearing this mark comply with the requirements of the European
Directive 94/9/CE (ATEX) on explosion protection.
IECEx for IEC 60079-0, IEC 60079-11

3 Specifications
WIKA Operating Instruction, Model Pascal ET, ET-P, ET/IS, ET-P/IS 11
GB
3 Specifications
1)

3 Specifications
12 WIKA Operating Instruction, Pascal ET, ET-P, ET/IS, ET-P/IS
GB

3 Specifications
WIKA Operating Instruction, Model Pascal ET, ET-P, ET/IS, ET-P/IS 13
GB

3 Specifications
14 WIKA Operating Instruction, Pascal ET, ET-P, ET/IS, ET-P/IS
GB

3 Specifications
WIKA Operating Instruction, Model Pascal ET, ET-P, ET/IS, ET-P/IS 15
GB
For further specifications see WIKA data sheet CT 18.02 and the order documentation.

4 Design and Function
16 WIKA Operating Instruction, Pascal ET, ET-P, ET/IS, ET-P/IS
GB
4 Design and Function
4.1 Description
Pascal ET, ET-P, ET/IS, ET-P/IS are the Professional Advanced Superior Calibrators of latest
generation. User friendly interface by a wide display with an industrial touch screen through which
it is possible to manage the instrument completely.
The operations are simplified thanks to the touch screen: the display changes in a dynamic way
according to the user selections, following test by step the operator during the calibration process,
decreasing the learning time and the human errors.
The touch screen can be operated by nude or gloved hands: dirty parts can be easily removed with
a cloth or a sponge. The touch screen can be locked during the measurement process to avoid
unintentional pressing of keys.
The backlight illumination with LED guarantees a perfect view in case of low environmental
visibility. Five keys are present below the touch screen: turn on/off of the instrument, contrast
settings and backlight.
The electrical part of Pascal ET, ET-P, ET/IS, ET-P/IS consists from two until 4 electrical modules
to be selected between the available ones (2 inputs (IN) –2 outputs (OUT) –one HART module)
for measuring and generating mA, mV, V, Hz, Ohm, Pulse, TC/RTD.
The Pascal ET, ET-P, ET/IS, ET-P/IS consists of two parts: pressure part and electrical one.
The pressure part consists of one or two connectors for connecting the external pressure sensors:
■pneumatic distribution block
■internal manual vacuum/pressure generator with fine adjustment
■up to four internal pressure sensors with overpressure valves.
The electrical part consists of up to four electrical module (2 inputs (IN), 2 outputs (OUT) and a
HART module) for the measurement and generation of mA, mV, V, Hz, Ohm, Pulse, TC/RTD.
On the side panel of the instrument there are several connectors for:
■recharging the battery
■RS232 port
■Connection to the external pressure transducers
■Connection for the environment parameters
(temperature, humidity and atmospheric pressure)
Moreover there are the connections to provide 24 V d.c. power supply to the device under test.
The Pascal ET, ET-P, ET/IS, ET-P/IS is powered with an internal battery pack. The battery allows
6 hours of standard operation before recharging.
Operating Pascal ET, ET-P, ET/IS, ET-P/IS user is able to calibrate the whole industrial
instrumentation like for example:
■Electronic and pneumatic pressure/vacuum transmitter
■Electronic and pneumatic differential pressure transmitter
■Electronic and pneumatic temperature transmitter (thermocouple and RTD)
■Signal converter V, mV, mA, Hz, Pulse, ohm
■Signal converter I/P and P/I
■Signal isolator mA, mV
■Mathematical Device (adder, subtractor, multiplier, divider)
■Manometer, Pressure switch
■Temperature monitor switch
■Thermocouple and thermoresistance
■Compensation device (up to 4 in-out signals)
■Electronic and pneumatic receiver
■Electronic and pneumatic controller
■Electronic and pneumatic recorder
■Miscellaneous instrument

4 Design and Function
WIKA Operating Instruction, Model Pascal ET, ET-P, ET/IS, ET-P/IS 17
GB
Pascal ET, ET-P, ET/IS, ET-P/IS includes different modules and can be ordered with different
hardware configurations.
The hardware configuration depends on the installation of different functional modules:
■Two electrical/temperature IN modules (IN A & IN B)
■Two electrical/temperature OUT modules (OUT A & OUT B)
■One pressure module able to support up to two transducers (2 internal, 2 external or a
combination of both)
■One environment parameters module
(atmospheric pressure, ambient temperature and relative humidity)
■One power supply 24 V d.c.
■One RS-232 communication port
■One connection for recharging the battery
Battery Life
In order to preserve battery life is recommended to keep the battery charger
connected for no more than 36 hours
Functional module
A functional module is a hardware component that allows the Pascal ET or
Pascal ET/IS to perform some operations like for example measurement and
generation of electrical signals and pressure.
4.2 Scope of delivery
■Portable multifunction calibrator model Pascal ET or Pascal ET/IS
■Operating instructions
■AC adapter
■Pascal report software
■RS-232 interface cable
■RS-232 to USB adapter
■Electrical kit order no. 241076
■Pneumatic pressure kit order no. 241028 and 241029
(Depending on pressure range)
■3.1 calibration certificate per DIN EN 10204
Cross-check scope of delivery with delivery note.
4.3 Power supply
Charging
To avoid false measurements, charge the rechargeable batteries as soon as the battery indicator
appears. If the batteries run too low the Pascal ET, ET-P, ET/IS, ET-P/IS will automatically shut
down.
Use only the original AC/DC converter which is supplied by WIKA

5 Transport, packaging and storage
18 WIKA Operating Instruction, Pascal ET, ET-P, ET/IS, ET-P/IS
GB
5 Transport, packaging and storage
5.1 Transport
Check the Multichannel Calibrator model Pascal ET, ET-P, ET/IS, ET-P/IS for any damage that
may have been caused by transport. Obvious damage must be reported immediately.
5.2 Packaging
Do not remove packaging until just before mounting.
Keep the packaging as it will provide optimum protection during transport (e.g. sending for
calibration).
5.3 Storage
Permissible conditions at the place of storage:
■Storage temperature: -30 ... +80 °C
■Relative Humidity: 10 ... 90 % r. H. (non-condensing)
Avoid exposure to the following factors:
■Direct sunlight or proximity to hot objects
■Mechanical vibration, mechanical shock (putting it down hard)
■Soot, vapour, dust and corrosive gases
■Potentially explosive environments, flammable atmospheres
Store the instrument in its original packaging in a location that fulfills the conditions listed above. If
the original packaging is not available, pack and store the instrument as described below:
1. Wrap the instrument in an antistatic plastic film.
2. Place the instrument, along with shock-absorbent material, in the packaging.
3. If stored for a prolonged period of time (more than 30 days), place a bag, containing a
desiccant, inside the packaging.

6 Commissioning, operation
WIKA Operating Instruction, Model Pascal ET, ET-P, ET/IS, ET-P/IS 19
GB
6 Commissioning, operation
6.1 Commissioning
6.1.1 Instrument overview
1 RS-232 port
2 Connector for battery charger
3 Power ON
4 Power OFF
5 Changing the number of windows
6 Connectors for external P transducer
7 Programmable Function
8 Home
9 Environmental Parameter Connector
10 Loop power supply –24 V d.c.
11 IN electrical/temperature modules
12 OUT electrical/temperature modules
6.1.2 Functional Modules
The functional modules can be classified according to their assignments:

■Electrical and temperature signals measurement
■Pressure measurement, (2 different modules, up to 4 internal pressure sensors and 2
connectors for external pressure sensor)
■Electrical and temperature signals generation/simulation
■Pressure generation and regulation
■Environmental parameters measurement
Many different configurations are available according to the specific requirements of the user.
3
4
5
6
7
8
11
2
10
12
1
9

6 Commissioning, operation
20 WIKA Operating Instruction, Pascal ET, ET-P, ET/IS, ET-P/IS
GB
6.1.2.1 Input module for electrical/temperature signals
The input module for electrical/temperature parameters measurement is one of those modules
inserted from the instrument’s front panel; two slides drive the module into its position. It is possible
to have up to two input modules in the same instrument: IN A and IN B. This terminology is used
also by the software to carry out the connection between physical input IN and software channel.
For example: if you connect a thermoresistance Pt100 to module IN A, the temperature measured
by this thermoresistance can be displayed in any of the four available windows. The following
figure shows the pins connection in electrical/temperature IN module.
Figure 1 –Input panel module
6.1.2.2 Output module for electrical/temperature signals
The output module for electrical/temperature parameters generation or simulation is one of those
inserted from the instrument’s front panel; two slides drive the module into its position. It is possible
to have up to two output modules in the same instrument: OUT A and OUT B. This terminology is
used also by the software to carry out the connection between physical output OUT and software
channel. For example: if you connect a signal-receiver to module output OUT A, the current 4…20
mA generated can be displayed in any of the four available windows.
The following figure shows the output module for electrical/temperature parameters.
Figure 2 –Output panel module
The 2 INPUT cards and 2 OUTPUT cards are plug and play modules and can be installed by the
user himself.
