Wren Kitchens FI.PK.FIT.004 Assembly instructions

FITTING GUIDE
Appliance
Housing
For Internal Use: FI.PK.FIT.004_50-WKIN00004_AppHousing_Rev3.indd
FI.PK.FIT.004
(H) x4 1 1/4” Screws
(B) x22 5/8”Screws
(J) x2 L Bracket Small
(K) x2 L Bracket Large
(R) x2 Dummy Fixing Clip
Step 2.
Screw up through the front rail into
your worktop to secure it in place, then
also through the back rail into your
wall. Screws for attaching to the
wall are not supplied as these vary
depending on your wall material and
construction. Ensure appropriate
xings for wall construction are
used.
(G) x2 13/16”Screws
Step 1.
Use 2 x 5/8” screws (B) to secure each
of the L brackets LGE (K) to the
cabinets at either side.
Then screw up through into the
worktop as shown.
Sample Cabinet Shown
HEIGHT: 34 1/2”
WIDTH: 24” - 30”
DEPTH: 24” - 25”
Screws for attaching to walls and worktop are not provided as these vary depending on
materials, thickness and construction. Ensure appropriate xings for wall and worktop
construction are used. Please refer to the specialist worktop supplier if these are
required for solid surface worktops.
H
BB
K
Bottom Filler
Top Filler
Step 3.
Screw into any adjacent cabinets
using 1 1/4” screws (H) provided to
secure the cabinet. Screw at the top
and bottom of the left and right
sides of the cabinet. Place a cover
cap on the head to conceal it.

FITTING GUIDE
Appliance
Housing
For Internal Use: FI.PK.FIT.004_50-WKIN00004_AppHousing_Rev3.indd
Step 4.
Secure L bracket SML (J) onto the inside face of the Top
Filler, 11/16” from the side edges and 15/16” from the top edge
of the ller (as shown below) using 2 x 5/8” screws (B). Align
so ller is in line with adjacent frontals.
11/16” from side 11/16”from side
Step 6.
Secure both dummy xing clip parts (Rii)
onto both end panels using
2 x 5/8” screws (B) each, as shown.
The centre hole is to be positioned
1 15/16” from the bottom of the panel and
1 3/8” from the front of the panel.
115/16”
INSIDE FACE
from bottom
Front
(Ri)
Bottom
Filler
Top
Filler from sides
Sample Cabinet Shown
J
B
B
J
15/16” from top
Step 5.
Secure the top ller with L bracket SML (J) to
top of rail with 2 x 5/8” screws (B) as shown.
13/8” from front
(Rii)
INSIDE FACE
1 1/8”from sides
115/16”
from top
(Ri) (Ri)
Step 7.
Secure dummy xing clip (Ri) onto the inside
face of the bottom ller,1 1/8” from the side
edges and 1 15/16” from the top edge, using
2x 13/16” screws (G).
G
15/16” from top
115/16”
from top
11/8”
