Wren Kitchens FRONTALS INFINITY PLUS User manual

For Internal Use:50-WKIN00143_INFINITY+_DRAWER_ATTACHMENT_GUIDE_Rev3
FRONTALS
INFINITY PLUS
Attachment
Guide
Glass Side
Deep Drawer
Standard Drawer
INFINITY PLUS

For Internal Use:50-WKIN00143_INFINITY+_DRAWER_ATTACHMENT_GUIDE_Rev3Page 1
FRONTALS
INFINITY PLUS
Attachment
Guide
Frontal Fixings
Step 1.
Attach the frontal xings to the draw front
using 3 x ” screws (B) per bracket using
the spiked positions.
4 ⁄“ 4 ⁄“
2 ⁄“
2 ⁄“
2 ⁄“
2 ⁄“
Standard
Drawer
1 ⁄“1 ⁄“
Step 2.
Attach the draw front by pushing the
frontal onto the sides, aligning the
mechanism with the xings.
B
B
B
STANDARD DRAWER
DRAWER FRONTAL
ADJUSTMENT
DRAWER REAR
ADJUSTMENT
STANDARD DRAWER
Step 1.
Press in the xing clips half way, at
the bottom of the frontal where
they meet the runners on both
sides of the drawer.
Step 2.
Adjust the position of the drawer
frontal, left or right.
Step 3.
Release the frontal xing clips on
both sides of the drawer to secure
the frontal in the new position.
Loosen top screw. Turn bottom
screw to adjust drawer frontal
height, once in desired position
re-tighten the top screw.
Turn screw to adjust rear
elevation of drawer.
To Adjust the frontal horizontally

For Internal Use:50-WKIN00143_INFINITY+_DRAWER_ATTACHMENT_GUIDE_Rev3 Page 2
FRONTALS
INFINITY PLUS
Attachment
Guide
DRAWER FRONTAL
ADJUSTMENT
DRAWER REAR
ADJUSTMENT
Frontal Fixings
Step 1.
Attach the frontal xings to the draw front using 3 x ”
screws (B) per bottom bracket and 2 x ” screws (B) per top
bracket using the spiked positions.
Step 2.
Attach the draw front by pushing the
frontal onto the sides, aligning the
mechanism with the xings.
B
B
B
B
B
Deep Drawer
7 ⁄“
6 ⁄“
7 ⁄“
6 ⁄“
4 ⁄“
2 ⁄“
2 ⁄“
1 ⁄“
1 ⁄“
2 ⁄“
2 ⁄“
4 ⁄“
Loosen top 2 screws. Turn
bottom screw to adjust drawer
frontal height, once in desired
position re-tighten the top 2
screws.
Turn screw to adjust rear
elevation of drawer.
DEEP DRAWER
Step 1.
Press in the xing clips half way, at
the bottom of the frontal where
they meet the runners on both
sides of the drawer.
Step 2.
Adjust the position of the drawer
frontal, left or right.
Step 3.
Release the frontal xing clips on
both sides of the drawer to secure
the frontal in the new position.
To Adjust the frontal horizontally

For Internal Use:50-WKIN00143_INFINITY+_DRAWER_ATTACHMENT_GUIDE_Rev3Page 3
FRONTALS
INFINITY PLUS
Attachment
Guide
Frontal Fixings
Step 1.
Attach the frontal xings to the draw front using 3 x ” screws
(B) per bottom bracket and 2 x ” screws (B) per top bracket
using the spiked positions.
Step 2.
Attach the draw front by pushing the
frontal onto the sides, aligning the
mechanism with the xings.
DRAWER FRONTAL
ADJUSTMENT
DRAWER REAR
ADJUSTMENT
B
B
B
B
B
Glass sided
Drawer
Loosen top 2 screws. Turn bottom
screw to adjust drawer frontal
height, once in desired position
re-tighten the top screws.
Turn screw to adjust rear
elevation of drawer.
DEEP DRAWER
7 ⁄“
6 ⁄“
7 ⁄“
6 ⁄“
4 ⁄“
2 ⁄“
2 ⁄“
1 ⁄“
1 ⁄“
2 ⁄“
2 ⁄“
4 ⁄“
Step 1.
Press in the xing clips half way, at
the bottom of the frontal where
they meet the runners on both
sides of the drawer.
Step 2.
Adjust the position of the drawer
frontal, left or right.
Step 3.
Release the frontal xing clips on
both sides of the drawer to secure
the frontal in the new position.
To Adjust the frontal horizontally

For Internal Use:50-WKIN00143_INFINITY+_DRAWER_ATTACHMENT_GUIDE_Rev3 Page 4
FRONTALS
INFINITY PLUS
Attachment
Guide
GLASS OUT
Step 3.
Slide the glass forward into the front slot of the drawer
side, so that both ends of the glass are encapsulated
within the side panel.
Step 2.
Insert the glass into the rear slot of
the side panel and rotate the glass
parallel to the side of the drawer.
CLICK
A CLICK will be heard once the glass is
correctly located within the side panel
of the drawer.
GLASS REMOVAL:
To remove the glass, reverse the
installation process. Press the rear
xing clip in, then slide the glass
backwards, towards the rear of the
drawer. Once fully back the glass will
be free to slide out on an angle from
the side panel.
Step 1.
Fully press the rear xing clip in.
GLASS
REPLACEMENT
