Yale YRD210 Technical specifications

Yale Real Living™ Push Button Deadbolt
Installation and Programming Instructions
For Technical Assistance call Yale at 1-800-810-WIRE (9473)
NOTE TO INSTALLER
FAILURE TO FOLLOW THESE INSTRUCTIONS
COULD RESULT IN DAMAGE TO THE PRODUCT
AND VOID THE FACTORY WARRANTY
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
This document is available on our website in printed Spanish and French. Go to www.yalerealliving.com.
Click “Product Information & Documentation” and then “Installation Instructions”.
Este documento está disponible en español en nuestra página de internet. Vaya a www.yalerealliving.com.
Presione “Información del Producto y Documentación” y luego “Instrucciones de Instalación”.
Ce document est disponible sur notre site Web dans le français imprimé. Allez à www.yalerealliving.com.
Cliquez sur le “ ; Information sur le produit et Documentation” et puis “Installation Instructions”.

2
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
Warnings ..................................................................................................................... 2-3
Introduction .....................................................................................................................3
Installation
Components and Tools .............................................................................................4
Prepare Lock for Installation .....................................................................................5
Install Lock ............................................................................................................ 6-7
Programming
Programming Features-Menus-Keys-Definitions ................................................. 8-9
Lock Operation ................................................................................................. 10-11
Miscellaneous Information
Return Lock to Programming Defaults ...................................................................12
Hardware Troubleshooting ......................................................................................12
Programming Troubleshooting ...............................................................................13
Replace/Install Cylinder ..........................................................................................14
Sample Pin Code Management Sheets ........................................................... 15-16
TABLE OF CONTENTS
WARNINGS
IMPORTANT: The accuracy of the door preparation is critical for the proper functioning and
security of this product. Misalignment can cause performance degradation and a lessening of
security.
Finish Care: This lockset is designed to provide the highest standard of product quality and
performance. Care should be taken to ensure a long-lasting finish. When cleaning is required
use a soft, damp cloth. Using lacquer thinner, caustic soaps, abrasive cleaners or polishes
could damage the coating and result in tarnishing.
CAUTION: Changes or modifications to this unit will void the the warranty.
FCC:
FCC ID: U4A-YRHCPZW0 (Z-Wave); U4A-YRHCPZB0 (Zigbee)
Model(s): YRD210, YRD220, YRT210 or YRT220
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful Interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced radio/TV technician for help.

3
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
Industry Canada:
Canadian ID: 6982A-YRHCPZW0 (Z-Wave); 6982A-YRHCPZB0 (Zigbee)
Model(s): YRD210, YRD220, YRT210 or YRT220
This Class B digital apparatus meets all requirements of the Canadian Interference Causing
Equipment Regulations. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation.
Cet appareillage numérique de la classe B répond à toutes les exigences de l’interférence
canadienne causant des règlements d’équipement. L’opération est sujette aux deux conditions
suivantes: (1) ce dispositif peut ne pas causer l’interférence nocive, et (2) ce dispositif
doit accepter n’importe quelle interférence reçue, y compris l’interférence qui peut causer
l’opération peu désirée.
“This equipment complies with FCC radiation exposure limits set forth for an uncontrolled
environment. This equipment should be installed and operated with minimum distance 20cm
between the radiator and your body. This transmitter must not be co-located or operating in
conjunction with any other antenna or transmitter.”
Section 7.1.2 of RSS-GEN Under Industry Canada regulations, this radio transmitter may only
operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter
by Industry Canada. To reduce potential radio interference to other users, the antenna type
and its gain should be so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not
more than that necessary for successful communication.
Section 7.1.3 of RSS-GEN This Device complies with Industry Canada License-exempt RSS
standard(s). Operation is subject to the following two conditions: 1) this device may not cause
interference, and 2) this device must accept any interference, inclusing interference that may
cause undesired operation of the device.
INTRODUCTION
The Yale Real Living™ Stand-alone Touchscreen Deadbolt Lock combines a robust lockset with a
contemporary electronic aesthetic.
Users benefit from an interactive touchscreen that makes day-to-day access effortless, as well as
offering voice-guided programming for simple updates to user information in the event of staffing
changes or security breaches. Yale Real Living™ is engineered for quick and easy installation and
fits in place of a standard deadbolt lock door prep (ANSI/BHMA A156.115).
If this is an RF-enabled network lock, it needs to be located within 50 - 100 feet of another network
controller. That distance is influenced by objects between the lock and the controller and may be
expanded depending on proximity to other RF network devices. Also, if the lock is connected to a
network controller, it is recommended that it is programmed through the centralized user interface
(PC or hand-held device) to ensure communication between the lock and the controller unit.

4
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
Lock Installation
#2 Phillips screwdriver
Door Prep
2-1/8" (54mm) hole saw
1" (26mm) boring bit
7/64" (2.5mm) drill bit
Chisel & hammer
Parts Illustrations
Tools Needed
Quick Start Guide
Installation Instructions
Door Marker
Outside Escutcheon
Bolt
Strike Plate
Screw Pack
Keys
Included in the box. . .
COMPONENTS AND TOOLS
Inside Escutcheon
Inside Mounting Plate
Battery Cover
4 AA Alkaline Batteries
INSTALLATION
Outside
Escutcheon
Inside
Escutcheon
4 AA Alkaline
Batteries
(2) Through
bolts
(4) screws
Keys
Battery Cover
Bolt
Strike Plate
Inside
Mounting
Plate
(3) Mounting
screws

5
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
PREPARE LOCK FOR INSTALLATION
Unpack the Lock
The lock is packed representative of how it will install on
the door.
Before installing the lock on the door:
A. Inside escutcheon
1. Loosen the screw (Phillips #2) holding the battery
cover . (The screw remains attached to battery
cover)
2. Slide the battery cover up and out (note the two tabs
at bottom of battery cover).
3. Remove the inside mounting plate (with gasket) from
the back (door side) of the inside escutcheon.
Battery Cover
Inside Escutcheon
C. The outside escutcheon (with gasket) remains assembled.
B. Bolt
Note: Bolt ships with backset in 2-3/4" posi-
tion. If required, press small black button
on underside of bolt and push to shorten to
2-3/8" backset position.
Inside Escutcheon & Mounting Plate
(with gasket)
Outside Escutcheon
Image (Fig. 3B) shows proper orientation
when installing the bolt.
1
2
3
a. Ensure that gasket
on Inside Mounting
Plate is properly
fitted. Note the
positioning of the
gasket's five rubber
nubs (Figure 3A) .
Figure 3A
Figure 3B

6
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
1. Install bolt in door.
NOTE: The bolt must be in a retracted (unlocked) position
when installing the lockset.
Attach with (2) M4 x 25.4mm [8-32 x 1"] screws supplied.
2. Install strike on the door frame, making sure to allow
for the bolt to be centered in the strike.
3. Install outside escutcheon.
As you position the outside escutcheon, route the
cable through 2-1/8" diameter hole (Figure 3A).
NOTE: Cable goes under bolt and through.
Ensure that the tailpiece is oriented correctly
(see arrows Fig. 3B).
INSTALL LOCK
Figure 4B
Figure 4A
Figure 3B
Figure 3A
“Tongue“
4. Holding the outside escutcheon flush to the door,
position the inside mounting plate by first routing
the cable and connector through the mounting
plate's 1/2" hole (Fig. 4A) and then inserting the
mounting plate “tongue“ into the bottom slot of the
outside escutcheon (Fig. 4B).
(2) M4 x 25.4mm
[8-32 x 1"]
Flat Head
Combination Screws
(2) M4 x 25.4mm
[8-32 x 1"]
Flat Head
Combination Screws
1
2

7
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
5. Secure both assemblies using (2) M6 x 59.5mm
pan head machine screws, making sure that
outside escutcheon is vertically aligned.
Hand-tighten until snug. Do not over-tighten.
7. Install inside escutcheon on inside mounting
plate. Note the horizontal orientation of the tail-
piece (Fig. 7A) as you insert the inside escutcheon
(thumb turn should be vertical).
8. Install and secure using (3) M4 x 8mm [8-32 x 5/16"]
pan head screws through the inside escutcheon into
the mounting plate.
IMPORTANT: Before installing the batteries, test
the mechanical operation of the lock by using
both thumb turn and the key. The movement of the
bolt should be smooth and unobstructed. If
operation is not smooth, review the previous steps
to ensure proper installation.
9. Insert four (4) AA alkaline batteries. Lock responds
with a series of beeps, red/blue flash and a quick
flash of all keypad LEDs.
Note: Refer to programming instructions prior to
completion of step 10.
10. Install battery cover and tighten Phillips head
screw.
6. Attach cable assembly to the inside escutcheon
PC board by lining up notches on top of cable
connector to slots on PCB connector (Fig. 6B).
Note that connector should be pressed in firmly us-
ing thumbs until completely seated (proper position
indicated by arrows on PCB as in Fig. 6A & 6B ) .
Figure 6B
Figure 7A
Figure 6A
CAUTION:
Use care when assembling to ensure that
the cable lies against the back recessed
area of the inside escutcheon (Fig. 6A).
Position and bend cable, using the harness
clip as shown in Fig. 6A to prevent binding
when installing the escutcheon over the
mounting plate.
Harness
clip

8
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
PROGRAMMING FEATURES - MENUS - KEYS - DEFINITIONS
Phillips Screw
Network Module Slot
Alkaline Batteries
4 AA Type
Thumb Turn
Status Indicator
Battery Cover
Outside Inside
Status Indicator
Numbers
Privacy Mode Button
Menu and Icons Used in This Guide
Cylinder
Click the indicated number. Enter Master PIN code (4-8 digits in
length).
(Factory default: 12345678)
Press the Star key on the keypad to Enter
or Accept entry. Enter User PIN. Can be 4-8 digits in
length.
Press the Pound key on the keypad to
enter Menu mode.
User Number (1 - 25);
RF Controlled (1 - 250).
~M
U
Low Battery Warning
1 Lock-out Mode 2 Return to previous step 3
Status Indicators
RED RED &
BLUE
BLUE

9
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
All Code Lockout: This feature is enabled by the Master code. When enabled, it restricts
all user PIN code access. When attempting to enter a code while the unit is in Lockout,
the Status Indicator flashes RED and BLUE; the keypad flashes as well.
Low Battery: When battery power is low, the Status Indicator flashes RED. If battery
power is completely lost, use the key override.
Master PIN Code: The Master code is used for programming and for feature settings.
NOTE: The default Master Pin Code must be changed prior to programming the
lock. The Master code will also operate the lock.
Privacy Mode: This button located under the thumb turn on the inside escutcheon, acti-
vates and deactivates the sound and keypad and is indicated by a BLUE flash every ten
(10) seconds. It is also overridden by mechanically operating the thumb turn or key.
Auto Re-lock Time: After successful code entry and the unit unlocks, it will automatically
re-lock after a default of thirty (30) seconds. Re-lock time is adjustable from five (5) to
thirty (30) seconds.
One Touch Re-Lock: When the bolt is retracted electronically, activating the keypad will
extend the bolt (during Auto Re-Lock duration or when Auto Re-Lock is disabled).
Shutdown Time: The unit will shutdown for a default of sixty (60) seconds and not allow
operation after the wrong code entry limit has been met. When the unit is in Shutdown,
the Status Indicator flashes RED and BLUE; the keypad flashes as well.
Audio Mode: Choosing Disable (3) in Audio mode shuts off the code confirmation tone
playback for use in quiet areas. Audio mode is enabled or disabled through feature pro-
gramming by the Master code.
Status LED: Located on inside escutcheon.
User PIN Code: The User code operates the lock. Maximum number of user codes is
250 with Network Module; without Network Module, maximum is 25 user codes.
Wrong Code Entry Limit: After a specified number of unsuccessful attempts at entering
a valid PIN code the unit will shut down and not allow operation. Wrong code entry limit is
adjustable from three (3) to ten (10) times through feature settings (up to 5 times with no
RF network enabled - default is 5; 10 with RF network enabled).
Definitions
Settings Factory Defaults
Master Code 12345678
Auto Re-lock Enabled
Audio Enabled
Re-lock Time *30 Seconds
Wrong Code Entry Limit *5 Times
Shutdown Time *60 Seconds
Factory Defaults
*Adjustable with Network Module

10
An ASSA ABLOY Group brand
P/N AYRD210-INST-FUL Rev B
Lock Operation
1
Enter current Master PIN code,
followed by the key.
1
Enter '1' to change Master PIN code,
followed by the key.
2
Enter the new Master PIN code (4~8
digits), followed by the key.
3
1. Enter the 8-digit default Master PIN code (12345678) followed by the key.
2. Enter “1” followed by the key.
3. Enter new 4-8 digit Master PIN code followed by the key.
Change Default Master Code Before Programming*
User Codes can only be programmed through the Master Code.
1. Enter the 4-8 digit Master PIN code followed by the key.
2. Enter “2“ followed by the key.
3. Enter the User number to be registered (1-25) followed by the key.
4. Enter a 4-8 digit PIN code for the User number followed by the key.
Set Up User Codes
Note: When registering User codes, the code must be entered with in 20 seconds.
If time expires, no codes are registered and the process must be re-started.
PIN code structure
Maximum number of user codes is 250 with Network Module; without Network Module,
maximum is 25 user codes.
Lockout is a Menu feature that restricts Pin code access (except Master).
Privacy mode is set by pressing and holding the button (found below thumb turn) for a
duration of four beeps. This deactivates the keypad and sound, and because it is set from
the inside, provides a secure and silent lock for the convenience of the occupant(s).
Privacy Mode vs. All Code Lockout Mode
*Default Master PIN Code must be changed prior to programming the lock.
