Yealink VC110 Video Conferencing Endpoint Quick Start Guide
Applies to 50.10.0.6 firmware version or laterV10.6

1
2
4
5
9
8
12
7
Cable Hub Connection Diagram
Table of Contents
Remote Control and Cable
Ties Installation
VC110-All-in-one Unit Installation
Packaging Contents
VC110-All-in-one Unit Connection
Troubleshooting
Main Screen
Network Deployment
Diagram

Packaging Contents
1
Please use the Yealink-customized DVI cable (only for VC110)
Quick Start Guide
AAA Batteries 2
+
Remote Control
DVI Cable VGA Cable (2m)
Ethernet Cable
HDMI Cable 1
+
+
+
4
+
2
VC110 All-in-one Unit
Cable Hub
Power Adapter Cable Ties 5
+
VCM30
Microphone Array Package
Wireless Microphone Package
Velcro 2
+
Video Conferencing Phone Package
Quick Start
USB CableDongle
VCM60 Power
Adapter
VCP40
Guide
VC110 Installation Accessories
Ethernet Cable
(7.5m)
Ethernet Cable
(7.5m)
VC110 all-in-one unit can work with the VCM60, VCP40 or VCM30. You can purchase
any combination according to your needs.

VC110 All-in-one Unit Connection Diagram
Please connect to Display1 port in blue color if you have only one display device
HDMI CableDVI Cable
2
Display 2
+
Cable Hub
The Back of the VC110

3
For more information, refer to Yealink VCM60 Video Conferencing Wireless Microphone Quick Start Guide
The VCM60 video conferencing wireless microphone and dongle are automatically ”paired” at the factory. All you need
to do is connect the dongle to one of the USB ports on the VC110 all-in-one unit. After the VCM60 is turned on, the VCM60
will register with the dongle automatically.
VCM60 Video Conferencing
Wireless Microphone
Dongle
The Right Side of the VC110

Remote Control and Cable Ties Installation
Fasten the cables with the cable tie
Install batteries
4

VC110 All-in-one Unit Installation
Hanging Mode
Adjust the bracket to ensure close adhesion to the back of the TV.
Lock the all-in-one unit Remove the protection of the Velcro
1
5
Please choose the following installation mode when the thickness of the TV is between 35-120mm.
TV
4
1
3
2
Make sure the back of
Steps: 2Install bracket
the TV is clean, and then adjust the bracket to ensure close adhesion to the back of the TV with Velcro
34

The recommended height for VC110 all-in-one unit positioning is 1.5m-1.8m
Wall-mount Mode
Hole diameter: 6mm
Hole depth: 30mm
Steps：Punch holes & Insert expansion bolts Drive screws Adjust the screw position and manually
lock it Insert screws to lock the bracket to the wall Connect DVI cable Lock the camera
12 3
4 5 6
Screw specification: M3 8
6
50mm
100mm 4
5 6
13
2
+
Screw specification: T4 30
+

DVI Cable
7
Wall Mount Method for the Cable Hub
DVI
83mm
Cable Hub Connection Diagram
To hang the cable hub on the wall, you need to purchase the screws (specification: T4 30) separately.
+
Connect to a VCP40 or VCM30 audio device
VGA Cable
(2m)
Ethernet Cable
(7.5m)
Ethernet Cable
VCP40
Power Adapter
VCM30
PC
The cable hub can also be powered from a PoE-compliant switch or hub.
The VC110 video conferencing endpoint should be used with Yealink original power adapter (12V/2A) only.

Main Screen
Time and date Site name Status icon Endpoint IP address and
account information
8
