Yealink MVC Series: MVC800 User manual

Yealink Network Technology CO., LTD
Yealink MVC800&MVC500&MVC300 for Microsoft Teams Rooms System
Quick Start Guide(V1.5)
V32.35
English | 简体中文

Mini-PC Package (Mini-PC and Mini-PC Box)
1
Package Contents
MVC800 Package
UVC80 2.5m
USB Cable
Power Adapter
48V/0.7A
Mounting Bracket
and Accessories
UVC80
Quick Start Guide
Cable Tie×5
VESA Accessory
(1/4”-20 UNC screw)
(T4×30 screw)
(M3×8 screw)
7.5m
Ethernet Cable
Velcro×2
MShare 3M
Cable Tie Mounting Base×2
Cable Ties×2
×4
1.2m HDMI Cable and
1.2m Mini-DP Cable
7m
USB Cable (for content sharing)
Velcro×2 MShare
Quick Start Guide
UVC80 Package (Camera)
MShare Package (Screen Sharing)
Machine Screw×27m USB CableMTouch
MSpeaker
MSpeaker
Quick Start Guide
Expansion screws and Self-tapping screws
2m AUX Cable
+
+
2
2
Power Cable
VCM34 Silicone Pad VCM34
Quick Start Guide
3m
Ethernet Cable
Mini-PC Upper Cover Bracket
1.8M
HDMI Cable×2
Velcro×2
Machine Screw×6
Expansion screws and
Self-tapping screws
+
+
2
2
MTouch
Quick Start Guide
MTouch Package (Touch Console) VCM34 Package×2 (Microphone)
MSpeaker Package (Soundbar)
(One Velcro is on the bracket)
Mini-PC
Camera Lens
Privacy cover

MVC500 Package
UVC50 2.5m
USB Cable
Power Adapter
48V/0.7A
VESA Accessory Mounting Bracket
and Accessories
UVC50
Quick Start Guide
Cable Tie×5
(1/4”-20 UNC screw)
(T4×30 screw)
(M3×8 screw)
7.5m
Ethernet Cable
Velcro×2
UVC50 Package (Camera)
(One Velcro is on the bracket)
DD10 USB Dongle
Charging Cradle
1.8m Micro USB Cable Power Adapter
CPW90 Wireless Mic×2
CPW90
Quick Start Guide
Machine Screw×2
7m USB CableMTouch
MSpeaker
MSpeaker
Quick Start Guide
Expansion screws and Self-tapping screws
2m AUX Cable
+
+
2
2
Power Cable
MTouch
Quick Start Guide
MTouch Package (Touch Console) CPW90 Package (Microphone)
MSpeaker Package (Soundbar)
Mini-PC Package (Mini-PC and Mini-PC Box)
Mini-PC Upper Cover Bracket
1.8M
HDMI Cable×2
Velcro×2
Machine Screw×6
Expansion screws and
Self-tapping screws
+
+
2
2
Mini-PC
2
Camera Lens
Privacy cover
MShare 3M
Cable Tie Mounting Base×2
Cable Ties×2
×4
1.2m HDMI Cable and
1.2m Mini-DP Cable
7m
USB Cable (for content sharing)
Velcro×2 MShare
Quick Start Guide
MShare Package (Screen Sharing)

We recommend that you use the accessories provided or approved by Yealink. The use of
unapproved third-party accessories may result in poor performance.
3
MVC300 Package
UVC30 Room UVC30 Room
Quick Start Guide
UVC30 Room Package (Camera)
Camera Lens
Privacy Cover
CP900 CP900
Quick Start Guide
Carrying Case
CP900 Package (Microphone)
Mini-PC Package (Mini-PC and Mini-PC Box)
Mini-PC Upper Cover Bracket
1.8M
HDMI Cable×2
Velcro×2
Machine Screw×6
Expansion screws and
Self-tapping screws
+
+
2
2
Mini-PC
Machine Screw×2
7m USB CableMTouch MTouch
Quick Start Guide
MTouch Package (Touch Console)
5m
USB Extension Cable
MShare 3M
Cable Tie Mounting Base×2
Cable Ties×2
×4
1.2m HDMI Cable and
1.2m Mini-DP Cable
7m
USB Cable (for content sharing)
Velcro×2 MShare
Quick Start Guide
MShare Package (Screen Sharing)

MVC800 & MVC500 & MVC300 Connection
The connection of MVC500 is almost the same as that of MVC800.
The following is an example of connecting MVC800.
You can use VCM34 or CPW90 as microphone.
For more information about the installation and deleployment of accessories (for example, the installation of mini-PC package or
UVC80 camera), refer to the Quick Start Guide of corresponding accessory.
When starting up the system for the first time, you need to connect a mouse to complete the initial configuration. We recommend
using the wireless mouse and keyboard kit.
4
VCM34
MTouch
MShare
Display
MSpeaker
3.5mm
CAT5e
USB2.0
USB2.0
USB2.0
HDMI
HDMI
HDMI HDMI
Display
Type-B
Ethernet Cable
VCM34
UVC80
The Back of Mini-PC The Front of Mini-PC
MVC800 & MVC500 Connection

Wireless Sharing
WPP20
Wireless Presentation Pod
PC
You can use Yealink WPP20 wireless presentation pod for wireless content sharing. WPP20 needs
to be purchased separately.
Make sure the MShare is connected to the mini-PC.
Procedure
1. Connect the WPP20 to the USB port of the MShare.
2. Wait for about 3 seconds, the WPP20 LED indicator glows
solid green.
The WPP20 is paired with the MShare successfully.
3. Connect the WPP20 to the PC.
MVC300 Connection
MShare
The Back of Mini-PC The Front of Mini-PC
Display Display
USB2.0
USB2.0 USB2.0
USB2.0
Type-B
HDMIHDMI
CP900
MTouch
HDMI HDMI
Ethernet Cable
UVC30 Room
5
For more information about the installation and deleployment of accessories (for example, the installation of mini-PC package or
UVC30 Room camera), refer to the Quick Start Guide of corresponding accessory.
When starting up the system for the first time, you need a USB hub to connect a mouse to complete the initial configuration.
We recommend using the wireless mouse and keyboard kit.

6
Upgrading System Software through Windows Update
Enabling Automatically Windows Update
Procedure
1. On the display screen, navigate to ->Settings.
2. Enter the administrator password (default: sfb) to access Setup screen.
3. Navigate to Windows Settings->Go to Admin Sign-in.
4. Select Administrator from the bottom-left corner and then enter the administrator password
(default: sfb).
5 . Tap the Start button, and then go to Settings->Upgrade & Security->Windows Update , and
select Advanced options .
6. Enable Automatically download updates, even over metered data connections
(charge may apply) .
The system software(including the Windows, the UVC80/UVC50/UVC30 Room, the MTouch and
the MShare) can be automatically upgraded via windows update by default. Otherwise, you can
enable automatically windows update or upgrade the devices manually.
The software upgrade is only supported by the operating system of 64-bit Windows 10.
Manually Windows Update
Procedure
1. On the display screen, navigate to ->Settings.
2. Enter the administrator password (default: sfb) to access Setup screen.
3. Navigate to Windows Settings->Go to Admin Sign-in.
4. Select Administrator from the bottom-left corner and then enter the administrator password
(default: sfb).
5. Do one of the following:
Long tap the Start button, and then select
Device Manager .
Select the desired device and then long tap the device to select Update driver .
Select a desired way to update.
Tap the Start button, and then n
avigate to Settings->Upgrade & Security->Windows Update ,
and select Check for updates .
Select the desired device and then complete the installation.

Resetting UVC80/UVC50/UVC30 Room Camera to Home Position
1. Tap to enter the Camera Control page.
2. Tap
Reset .
Procedure
Controlling UVC80/UVC50/UVC30 Room Camera Position
1. Tap to enter the Camera Control page.
2. Tap or to zoom camera in/out.
3. Tap / / / to pan/tilt the camera.
Procedure
If the auto-framing feature is enabled, you can not control the UVC30 Room camera.
Enabling/Disabling Auto-framing for UVC30 Room Camera
1. Tap to enter the Camera Control page.
2. Select .
3. Enable/Disable the Auto-framing.
Procedure
7
