Yealink VCM36-W User manual

VCM36-WVCM36-W
IntroductionIntroduction
The Yealink VCM36-W is an innovative wireless video conferencing microphone designed to accommodate various
meeting room needs. With a built-in 3-microphone array, the VCM36-W has a 20ft (6m) and 360° voice pickup range.
It features Yealink’s high-quality echo cancellation technology and noise cancellation, effectively filtering out up
to 90dB of ambient noise to provide a high-quality audio experience during full-duplex calls.
The VCM36-W’s high-quality pickup technology provides a full range of audio coverage for all conference room
sizes.
The VCM36-W is easy to use with a single pairing, with up to 12 hours of battery life in conference mode and 7 days
of standby time. The VCM36-W WIFI microphone is equipped with a charging dock that allows you to charge the
microphone wirelessly, and you can change its deployment position at any time while using it to suit your needs.
Key features and benefitsKey features and benefits
HD Hi-Fi Wifi Microphone
Yealink Full Duplex Technology
Dual-band 2.4GHz/5GHz wireless networks
6m-360° voice pickup range
12 hours battery life of conference
WPA2，AES128 Encryption Technology
SpecificationsSpecifications
SpecificationsSpecifications DescriptionDescription
VCM36-W
1

Microphone Features
• Optimal HD Audio
• Yealink Full Duplex Technology
• Yealink Acoustic Echo Canceling
• Yealink Noise Proof Technology
• 6 m voice pickup range
• Muting the microphone with touchpad
• Can be used as an expansion microphone
• Built-in 2450 mAh battery
• Up to 12 hours of use time
• Up to 7 days standby time
Wi-Fi
• Standard：802.11 b/g/n/ac
• Frequency: 2.4GHz/5GHz
• Security: WPA-PSK/WPA2-PSK
Physical Features
• Dimension (W D H):
Microphone: 100 x 16.5 mm
Charge Cradle: 100 x 10.5 mm
• Operating humidity: 10% - 90%
• Storage temperature: 0℃ - 40℃ (+32℉ - 104℉)
Package Contents
• 1x VCM36-W Video Conference Microphone
• 1x Charger Cradle
• 1x 1.2 m USB-C Cable
• 1x USB Adapter
• Double-sided adhesive
• Quick Start Guide
Package Features
• Qty/CTN: 20 PCS
• N.W/CTN: 8.068 kg
• G.W/CTN: 8.678 kg
• Giftbox size: 184 x 112 x 60 mm
• Carton Meas: 635 x *237 x 200 mm
Device CompatibilityDevice Compatibility
The maximum number of VCM36-W microphones supported by the conferencing room endpoint is as follows:
Device NameDevice Name Max. number of VCM36-W supportedMax. number of VCM36-W supported
MeetingBar A10 ×
NOTENOTE
Since the microphones do not support mixed-use, the kits with this microphone or MSpeech do not
support other microphones by default. For which kits contain microphones or MSpeech, please refer to
datasheet.
The MVC840-BASE KIT/MVC860-BASE KIT refers to kits without the VCM34 microphone.
VCM36-W
2

MeetingBar A20 1 (A20 version requires 133.320.0.2 and later)
MeetingBar A30 2 (A30 version requires 133.320.0.2 and later)
MVC960, MVC940, MVC900 ×
MVC860, MVC840, MVC660, MVC640-AI ×
MVC860-BASE KIT, MVC840-BASE KIT, MVC640-
Wireless, ZVC860, ZVC840
4 (UVC86 version requires 151.431.0.5 and later, UVC84
version requires 262.431.0.5 and later)
MVC400, ZVC400 ×
MVC320 ×
MeetingBoard 65, MeetingBoard 86 2 (MeetingBoard 65&86 version requires 155.15.0.46 and
later)
DeskVision A24 ×
MeetingEye 500 2
How to UseHow to Use
VCM36-W has different features when used with different video conferencing endpoints. For more information,
please refer to the corresponding documents.
Teams VerisonTeams Verison:
Connect the VCM36-W to MeetingBar A20/A30: VCM36-W Wireless Microphone
Connect the VCM36-W to MVC System: VCM36-W Wireless Microphone
Connect the VCM36-W to MeetingBoard 65/86: VCM36-W Wireless Microphone
Zoom VersionZoom Version:
Connect the VCM36-W to MeetingBar A20/A30: VCM36-W Wireless Microphone
Connect the VCM36-W to ZVC System: VCM36-W Wireless Microphone
Connect the VCM36-W to MeetingBoard 65/86: VCM36-W Wireless Microphone
Connect the VCM36-W to MeetingEye 500: VCM36-W Wireless Microphone
BlueJeans VersionBlueJeans Version:
Connect the VCM36-W to MeetingBar A20/A30: VCM36-W Wireless Microphone
RingCentral VersionRingCentral Version:
Connect the VCM36-W to MeetingBar A20/A30: VCM36-W Wireless Microphone
LED IndicatorLED Indicator
Charging LED Indicator:
LED Indicator StatusLED Indicator Status DescriptionDescription
Solid red Charging
Solid green The VCM36-W is fully charged
Flash red slowly Low battery(lower than 20%), and please charge
VCM36-W
3

Flash red 3 times and
then off The battery is too low to power on
Solid green for 3 seconds
and then off Standby
Solid green for one
second and then off Power on
Off If you tap the mute button and the Charge indicator LED on the VCM36-W is still
off, it means the VCM36-W is powered off
Mute LED Indicator:
LED Indicator StatusLED Indicator Status DescriptionDescription
Solid red The system is muted
Solid green The system can pick voice
Slowly flashing yellow The VCM36-W is searching for signal
Off The system is in the idle state
Hardware IntroductionHardware Introduction
ChargeCharge
VCM36-W
4

Power On and OffPower On and Off
1. Press and hold the MuteMute button for 5 seconds.
The charging LED indicator turns green and then turns off during startup.
2. Press and hold the MuteMute button for 15 seconds.
The charging LED indicator turns red and then turns off. If the device does not respond after pressing the MuteMute
button, it is powered off.
Mute/Unmute MicrophoneMute/Unmute Microphone
1. Press the MuteMute button on the VCM36-W to mute the microphone. If the muting LED indicator is solid red, the
microphone is mute.
2. Press the MuteMute button again to unmute the microphone.
