Yealink VC120 Video Conferencing Endpoint Quick Start Guide
Applies to firmware version 40.20.0.1 or later
V20.1
Yealink Network Technology CO., LTD

Table of Contents
Remote Control and Cable
Ties Installation
Bracket and Camera Installation
Packaging Contents 1
2
4
5
VC120 Connections
8
7
11
Troubleshooting
Main Screen
Network Deployment
VCM60 Connections 3

We recommend that you use the accessories provided or approved by Yealink. The use of unapproved
third-party accessories may result in reduced performance. 1
Packaging Contents
Power Adapter AAA Batteries 2
+
(2m) (7.5m)
1
VCC18 Camera VC120 Codec VCR10 Remote Control
DVI Cable VGA Cable Ethernet Cable Ethernet Cable
HDMI Cable
Please use the Yealink-customized DVI cable
VCM30
Microphone Array Package
Velcro 2
+
Ethernet Cable
(7.5m)
VC120 video conferencing endpoint can work with the VCM60, VCP40 or VCM30. You can purchase any
combination according to your needs.
Quick Start Guide
Camera Wall Mount Accessories
+
+
4
+
2
Cable Ties 5
+
Video Conferencing Phone Package
VCP40 Ethernet Cable
(7.5m)
Wireless Microphone Package
Quick Start
USB CableDongle
VCM60 Power
Adapter Guide

Please connect to the Display1 port if you only have one display device
The endpoint should be used with Yealink original power adapter (19V/3.42A) only. The use of the
third-party power adapter may cause the damage to the endpoint
VC120 Connections
VCC18 Camera Connects to a VCP40 or VCM30 audio device
VGA Cable HDMI Cable 2m Ethernet Cable Power Adapter
PC Display 2
DVI Cable
7.5m Ethernet Cable
+
VCP40 VCM30
2

For more information, refer to Yealink VCM60 Video Conferencing Wireless Microphone Quick Start Guide
The VCM60 video conferencing wireless microphone and dongle are automatically ”paired” at the
factory. All you need to do is connect the dongle to one of the USB ports on the VC120 Codec. After
the VCM60 is turned on, the VCM60 will register to the dongle automatically.
VCM60 Video Conferencing
Wireless Microphone
VCM60 Connections
3
Dongle

Remote Control and Cable Ties Installation
4
Fasten the cables with the cable tie
Install batteries

Bracket and Camera Installation
Please chose the following installation mode when the thickness of the TV is between 35-120mm
Hanging Mode
Adjust the bracket to ensure close adhesion to the back of the TV
TV
4
1
3
2
Lock the Camera Remove the protection of the Velcro
1
Make sure the back of the
Steps: Install bracket
TV is clean, and then adjust the bracket to ensure close adhesion to the back of the TV with Velcro
34
2
5

The recommended height for camera positioning is 1.5m-1.8m above the ground
Wall Mount Method
Hole diameter: 6mm
Hole depth: 30mm
50mm
100mm 4
5 6
1
3
2Screw specification: M3 8
+
Screw specification: T4 30
+
Steps：Punch holes & Insert expansion bolts Drive screws Adjust the screws position and manually lock them
Insert screws to lock the bracket to the wall Connect DVI cable Lock the camera
1
4
3
6
2
5
6

Main Screen
7
Time and date Site name Status icon Endpoint IP address and
account information
6

Network Deployment
To ensure that the VC120 works correctly, please configure it according to the conference role
that it plays. If it is in the head office, please make sure that it can be reached from the public
network. If it is in a branch office, please use an intelligent firewall to deploy it, or just follow the
same steps as for the head office
Head Office
At least one static public IP address is required in the head office to allow branch offices to
connect. The recommended endpoint configurations are as follows :
. To deploy the VC120 on a public network, you need to assign a static public IP address to the
VC120.
. To deploy the VC120 in an Intranet, you must assign a static private IP address behind the
firewall to the VC120. In the meantime, do port mapping on the firewall for VC120.
Configure a Static IP
Firstly, configure a static IP for the VC120
For example: you can use the remote control to configure the IP 10.3.20.12 to your VC120.
.
Menu->Advanced (Admin Password:0000)->LAN Configuration
. Turn off the 【DHCP】
.
Enter the IP address, subnet mask, gateway and DNS information in corresponding fields.
8

PortFunction
H.323 signal port
SIP（optional ）
Audio & Video media stream port
Web management port（optional ）
Protocol Type
UDP/TCP
5060
443
50000-50499
1719-1720
TCP/UDP
TCP/UDP
TCP
Configure Port Mapping
If the VC120 is deployed in an Intranet, you need to finish the following port mapping on the firewall:
8
9
. Press 【Save】to save the configuration, then the screen prompts【Reboot now】
. Press 【OK】
to reboot the endpoint.

8
10
Branch Office
If you are in a branch office, following two options are suggested:
Option1: Deploy the VC120 following the same steps as for the head office. In this way, both inbound
and outbound calls are available.
Option2: Deploy the VC120 using an intelligent firewall, which means that plug and play is possible
without any further firewall configuration, but only outbound calls are available.
Please note that when the VC120 is deployed with an intelligent firewall, you have to open ports (as shown
below) permission if they are restricted
PortFunction
H.323 signal port
SIP（optional ）
Audio & Video media stream port
Protocol Type
UDP/TCP
TCP/UDP
TCP/UDP
50000-50499
5060
1719-1720
It is recommended that you forward the web management port(443/TCP) to the public network, so that the
head office can remotely manage the branch office.

Video Resolution Recommended Bandwidth
Full HD 1080P 1.3Mb
People 1080P+Content 1080P 2.6Mb
Bandwidth Requirements
To ensure the best video conference performance , the recommended bandwidth for VC120 is as
below:
For more information on configurations, contact your system administrator.
The bandwidth mentioned above is based on a two-way conference. Head office bandwidth should be
increased in line with the growing number of connected branch offices.
11
Troubleshooting
After installation and deployment, you can test the VC120 by dialing the Yealink Demo Room. If
you can’t dial out successfully, please contact your IT administrator to check the internal network
configuration.
Assume that you are A in head office. Using the configuration method explained in "Head Office"
chapter on page 8, you find that you can call B in branch office or Yealink Demo, but that they
cannot call you. The most likely reason is that the firewall or gateway in the environment does
not support the H.323 ALG feature. In this situation, please take the following actions so that the

NAT feature on the VC120 can solve this problem. (Carry out each step via the remote control)
. Menu->Advanced(Admin Password:0000)->NAT/Firewall
. Select 【Auto】from the 【Type】pull-down list, the endpoint will obtain public IP address
automatically.
. If the endpoint does not obtain a public IP address automatically, select【Manual Settings】
from the 【Type】pull-down list, and then enter the public IP address in the 【Public IP Address】
field.
Yealink Test Room IP: 117.28.251.50、117.28.251.51
12
