Fitting Instructions
YewdaleDefiant® roller blinds
(R20, Fascia, R20C, R20D, R20S, R20W)
yewdale.co.uk
Fitting Instructions
YewdaleDefiant®roller blinds
(R20, Fascia, R20C, R20D, R20S, R20W)
Part no: 936

YewdaleDefiant® fitting instructions Part no: 9362
Safety Instructions:
1.Loops in pull cords, chains, tapes and inner cords that operate the product
can cause strangulation
2. To avoid strangulation and entanglement, keep cords out of the reach of
young children. Cords may become wrapped around a child’s neck
3.Move beds, cots and furniture away from window covering cords
4. Do not tie cords together. Make sure cords do not twist and create a loop R20
Sidewinder control
N.B. For more information and child safety device fitting instructions, see Point
7 on Page 5 & 6.
Fitting Instructions
YewdaleDefiant®roller blinds (R20, Fascia, R20C, R20D, R20S, R20W)

Call: [phone] Fax: [phone] Email: [email protected] Visit: www.yewdale.co.uk 3
R20 Sidewinder control:
N.B. This blind should be installed by a person competent in DIY. If in doubt
please consult a professional.
1.The standard universal metal brackets supplied with the blind may be top,
face or side-fixed.
2.Check that the blind fits correctly. The pin-end is sprung for easy fitting, but
the pin should be depressed once in place. The fabric should roll o the back
of the barrel, unless ordered reverse-roll.
3.Fix the control-end bracket using appropriate screws/plugs.
4. Locate the blind in the control-end bracket, and mark the position of the
pin-end bracket.
5.Remove blind and fix pin-end bracket using appropriate screws/plugs.
NB. Fix the control-end bracket using appropriate screws/plugs.
6. Insert the pin in the pin-end of blind into the bracket. Press the blind
against the bracket to depress sprung pin, and insert the lug on the control-
end into its bracket until it drops into place.

YewdaleDefiant® fitting instructions Part no: 9364
7. Ensure the relevant child safety device is used to comply with BS
EN13120:2009+A1:2014, BS EN16433:2014 and BS EN16434:2014 as follows:
*You will have been provided with either a chain tidy or easy break chain
connector (also see page 8 & 11)
Chain Tidy
The chain tidy will be attached to the chain when the blind arrives. The chain
tidy should be at a maximum distance from the control mechanism, keeping
the chain taut (not under excessive tension however as this could negatively
aect the longevity and operation of the blind). Put the retaining device on
the wall, mark fixing holes with a pencil, drill the holes and screw the device
to the wall with suitable fixings.
Fitting Instructions
YewdaleDefiant®roller blinds (R20, Fascia, R20C, R20D, R20S, R20W)

Call: [phone] Fax: [phone] Email: [email protected] Visit: www.yewdale.co.uk 5
Easy Break Chain Connectors
Two easy break chain connectors are connected to the operating chain
200mm apart. This ensures that at least one of them will be in the vertical
position ensuring they perform as required. If excessive weight is applied
within the loop a connector will come apart. If a connector comes apart
and is undamaged then it will need to be re-connected by inserting the
last ball on the end of the chain into the hole in the connector and pushed
into place.
8. Check that the blind operates correctly.
NB. Large blinds are heavy and it is important that the correct fixings are
used. If unsure, seek expert advice.

YewdaleDefiant® fitting instructions Part no: 9366
R20 Sidewinder control:
933019W
Bracket cover 32mm
933029W
Bracket cover 40mm
933039W
Bracket cover 45mm
918003S
Wire
918011
Wire clamp
918008
Side guiding bezel
OPTIONAL
938311W/B/S Tear drop bottom bar
938312W/B/S Endcap
938313W/B/S Side guiding adapter
938021 Barrel 32mm
938024 Barrel 40mm
938027 Barrel 45mm
938120W
Bottom bar plastic
933015W/G/BL/BR
Universal end set 32mm
933025W
Universal end set 40mm
933035W
Universal end set 45mm
(available in black, brown,
grey and white in 32mm)
938170W
Bottom bar
end cap
913680S
Metal chain
938280
P-clip
913680S
Metal chain
926325W
Back bar top fix bracket
933016W
Control bracket
32mm (back bar)
933026W
Control bracket
40mm (back bar)
933036W
Control bracket
45mm (back bar)
933010W
Back bar screw
926325W
Back bar top fix bracket
938031W
Aluminium back bar
OPTIONAL
OPTIONAL
938311W/B/S
Tear drop bottom bar
938312W/B/S
Endcap
938314W
Lug
6200W
Aluminium
Channel
Fitting Instructions
YewdaleDefiant®roller blinds (R20, Fascia, R20C, R20D, R20S, R20W)

Call: [phone] Fax: [phone] Email: [email protected] Visit: www.yewdale.co.uk 7
R20 with Fascia:
N.B. This blind should be installed by a person competent in DIY. If in doubt
please consult a professional.
1.If the blind is top fix, fix through the fascia profile using the indent to
position the screws. If face fix, use the brackets supplied to fix the brackets
securely to the wall. Once secured, fix the fascia to the brackets using the
threaded screw provided.
2.Remove the chain guide from the transition plate.
3.Lifting the blind into position, secure into the transition plates.
4. Thread the chain through the chain guide and secure the chain guide in
place using the screws provided.
N.B. For child safety device fitting instructions, see Point 7 on Page 5.

YewdaleDefiant® fitting instructions Part no: 9368
R20C Crank Control:
N.B. This blind should be installed by a person competent in DIY. If in doubt
please consult a professional.
1.The standard universal metal brackets supplied with the blind may be top,
face or side-fixed.
2.Check that the blind fits correctly. The pin-end is sprung for easy fitting, but
the pin should be depressed once in place. The fabric should roll o the back
of the barrel, unless ordered reverse-roll.
3.Fix the control-end bracket using appropriate screws/plugs.
4. Locate the blind in the control-end bracket, and mark the position of the
pin-end bracket.
5. Remove blind and fix the pin-end bracket using appropriate screws/plugs.
NB. To operate correctly, blind MUST be fixed level.
6. Insert the pin in the pin-end of the blind into the bracket. Press the blind
against the bracket to depress sprung pin, and insert the lug on the control-
end into its bracket until it drops into place.
7. Extra screw has been provided in the set to secure the crank control to the
square pin end if required (to stop the blind being pushed out of the bracket
when operating).
8. Check that blind operates correctly.
NB. Large blinds are heavy and it is important that the correct fixings are used.
If unsure, seek expert advice.
Fitting Instructions
YewdaleDefiant®roller blinds (R20, Fascia, R20C, R20D, R20S, R20W)

Call: [phone] Fax: [phone] Email: [email protected] Visit: www.yewdale.co.uk 9
R20C Crank Control:
OPTIONAL
938311W/B/S
Tear drop bottom bar
938312W/B/S
Endcap
938314W
Lug
6200W
Aluminium
Channel
938311W/B/S
Tear Drop Bottom Bar
938312W/B/S
Bottom Bar End Cap
938027
45mm Barrel
911769
End Plug with Square Pin
70401
Gear Box 1:5
933401
Crank support
set
810
Nut and Bolt
70422B/W
Pole Clip
911770
Fixing Clip
911771
Joint Fixing Clip
70723
Magnetic Adaptor
70722
Magnetic Universal Joint
146B/W
Control Rod
70421B/W
Crank
911770
Fixing Clip
70946
Bracket adaptor
933401
Crank support set
926325W
Back bar top fix bracket
933036W
Control bracket
45mm (back bar)
933010W
Back bar screw
926325W
Back bar top fix bracket
938031W
Aluminium back bar
OPTIONAL
918003S
Wire
918011
Wire clamp
918008
Side guiding
bezel
938312W/B/S Endcap
+ 938313W/B/S Side
guiding adapter
OPTIONAL
933039W
Bracket cover 45mm

YewdaleDefiant® fitting instructions Part no: 93610
Fitting Instructions
YewdaleDefiant®roller blinds (R20, Fascia, R20C, R20D, R20S, R20W)
R20D Double roller:
N.B. This blind should be installed by a person competent in DIY. If in doubt
please consult a professional.
1.The standard universal metal brackets supplied with the blind may be top or
face-fixed.
2.Check that the blind fits correctly. The pin-ends are sprung for easy fitting,
but the pins should be partially depressed once in place. The fabric should
roll o the back of the barrel, unless ordered reverse-roll.
3.Fix one of the brackets using appropriate screws/plugs.
4. Locate the blind in the control-end bracket, and mark the position of the
other bracket.
5.Remove blind and fix the bracket you’ve just marked out using appropriate
screws/plugs.
6. Insert the pin in the pin-end of blind into the bracket. Press the blind
against the bracket to depress sprung pin, and insert the lug on the control-
end into its bracket until it drops into place. Repeat for the second blind.
N.B. For child safety device fitting instructions, see Point 7 on Page 5.

Call: [phone] Fax: [phone] Email: [email protected] Visit: www.yewdale.co.uk 11
R20D Double roller:
933022W
Double bracket cover 40mm
933023W
40mm Double
bracket set
940025W
40mm control mechanism set
918003S
Wire
918011
Wire clamp
918008
Side guiding bezel
OPTIONAL
938311W/B/S Tear drop bottom bar
938312W/B/S Endcap
938313W/B/S Side guiding adapter
938024 Barrel 40mm
938120W
Bottom bar plastic
938170W
Bottom bar
end cap
913680S
Metal chain
938280
P-clip
OPTIONAL
938311W/B/S
Tear drop bottom bar
938312W/B/S
Endcap
938314W
Lug
6200W
Aluminium
Channel

YewdaleDefiant® fitting instructions Part no: 93612
R20S Spring Control:
N.B. This blind should be installed by a person competent in DIY. If in doubt
please consult a professional.
1.Fit as per the R20 Sidewinder instructions but please see parts diagram to
right (back bar is optional).
2.Spring must be on the right-hand side unless fabric is reverse rolled.
3.The spring would have been tensioned during the manufacturing process
but the tension can be increased or decreased if required. If the fabric does
not wind up completely when the blind is operated, greater spring tension
can be applied as follows:
a) Bring the blind down 250mm from its uppermost position.
b) Remove the blind from the brackets and roll the fabric by hand back onto
the barrel.
c) Replace the blind in the brackets.
d) If there is still not enough tension, repeat steps a to c.
e) If the tension is too much, follow the above but in reverse. Remove the
blind from the brackets and unroll the fabric by hand. Ensure the blind
is not over tensioned as it will result in the bottom bar crashing into
the blind and potentially jamming. If the blind is installed outside the
recess then adjusting the tension can be done without taking the blind
out of its brackets if preferred. Use a flat head screwdriver through the
hole in the bracket to either increase or decrease the tension as desired.
NB. If the blind has been fitted with a limit stop, this may need to be checked
prior to installation. Roll the blind up to the desired stop point and the limit
stop will be on the left (for reverse roll blinds, this will be on the right).
Turn the square centre pin counter-clockwise until it stops. (On a blind in a
back bar this is controlled by a cross head screw on the bracket.)
4. Attach the pull cord to the bottom bar.
Fitting Instructions
YewdaleDefiant®roller blinds (R20, Fascia, R20C, R20D, R20S, R20W)

Call: [phone] Fax: [phone] Email: [email protected] Visit: www.yewdale.co.uk 13
R20S Spring Control:
R20SBCS
Acorn pullcord accessory set
938311W/B/S
Tear Drop Bottom Bar
941001W
Braked Spring
Bracket Set
(Standard)
941001W
Braked Spring
Bracket Set
(Standard)
938021
Barrel 32mm
941006
Braked Spring
Control End
941003
Braked Spring (Short)
941004
Braked Spring (Medium)
941005
Braked Spring (Long)
938312W/B/S
Bottom Bar
End Cap
941010
Spring limit stop
962499
10mm Plastic Strip
with double sided tape
926325W
Back bar top fix bracket
941002W
Braced Spring
Bracket Set (Back Bar)
933010W
Back bar screw
926325W
Back bar top fix bracket
938031W
Aluminium back bar
OPTIONAL
941000
Braked Spring (Mini)
941007
941008
941009
Braked Spring (Narrow Strong)
Braked Spring (Wide)
Braked Spring (XL)

YewdaleDefiant® fitting instructions Part no: 93614
R20W Light Duty Crank Control:
N.B. This blind should be installed by a person competent in DIY. If in doubt
please consult a professional.
1.The standard universal metal brackets supplied with the blind may be top,
face or side-fixed.
2.Check that the blind fits correctly. The pin-end is sprung for easy fitting, but
the pin should be depressed once in place. The fabric should roll o the back
of the barrel, unless ordered reverse-roll.
3.Fix the control-end bracket using appropriate screws/plugs.
4.Locate the blind in the control-end bracket, and mark the position of the
pin-end bracket.
5.Remove blind and fix pin-end bracket using appropriate screws/plugs.
NB. To operate correctly, the blind MUST be fixed level.
6. Insert the pin in the pin-end of blind into bracket. Press the blind against
the bracket to depress the sprung pin, and insert the lug on the control-end
into its bracket until it drops into place.
7. Check that the blind operates correctly.
NB. Large blinds are heavy and it is important that the correct fixings are used.
If unsure, seek expert advice.
Fitting Instructions
YewdaleDefiant®roller blinds (R20, Fascia, R20C, R20D, R20S, R20W)

Call: [phone] Fax: [phone] Email: [email protected] Visit: www.yewdale.co.uk 15
R20W Light Duty Crank Control:
70422B/W
Pole Clip
911770
Fixing Clip
146B/W
Control Rod
70421B/W
Crank
911770
Fixing Clip
942003
Plastic Hook
938024
40mm Barrel
942004
Crank and bracket set
926325W
Back bar top fix bracket
933026W
Control bracket
40mm (back bar)
933010W
Back bar screw
926325W
Back bar top fix bracket
938031W
Aluminium back bar
OPTIONAL
918003S
Wire
918011
Wire clamp
918008
Side guiding bezel
938312W/B/S Endcap
+ 938313W/B/S Side
guiding adapter
OPTIONAL
942004
Crank and
bracket set
938120W
Bottom bar plastic
938170W
Bottom bar
end cap

Yewdale, Enterprise Way,
Wickford, Essex SS11 8DH
Call [phone]
Fax [phone]
Email [email protected]o.uk
Visit yewdale.co.uk
For more information on all
Yewdale products, please call
the sales department.
