Zte ZXHN H3601 Programming manual

ZXHN H3601
Home Gateway
Maintenance Management Guide
Version:V1.0
ZTE CORPORATION
No. 55, Hi-tech Road South, ShenZhen, P.R.China
Postcode: 518057
Tel: [phone]
URL: http://support.zte.com.cn
E-mail: [email protected]

LEGAL INFORMATION
Copyright 2020 ZTE CORPORATION.
The contents of this document are protected by copyright laws and international treaties. Any reproduction
or distribution of this document or any portion of this document, in any form by any means, without the
prior written consent of ZTE CORPORATION is prohibited. Additionally, the contents of this document
are protected by contractual confidentiality obligations.
All company, brand and product names are trade or service marks, or registered trade or service marks,
of ZTE CORPORATION or of their respective owners.
This document is provided as is, and all express, implied, or statutory warranties, representations or
conditions are disclaimed, including without limitation any implied warranty of merchantability, fitness for
a particular purpose, title or non-infringement. ZTE CORPORATION and its licensors shall not be liable
for damages resulting from the use of or reliance on the information contained herein.
ZTE CORPORATION or its licensors may have current or pending intellectual property rights or
applications covering the subject matter of this document. Except as expressly provided in any written
license between ZTE CORPORATION and its licensee, the user of this document shall not acquire any
license to the subject matter herein.
ZTE CORPORATION reserves the right to upgrade or make technical change to this product without
further notice.
Users may visit the ZTE technical support website http://support.zte.com.cn to inquire for related
information.
The ultimate right to interpret this product resides in ZTE CORPORATION.
Revision History
Revision No. Revision Date Revision Reason
R1.0 2020-07-23 First edition
Serial Number: SJ-20200429083356-004
Publishing Date: 2020-07-23(R1.0)

Contents
1 Safety Precautions....................................................................................1-1
2 Product Overview......................................................................................2-1
2.1 Package Check..................................................................................................... 2-1
2.2 Product Specifications...........................................................................................2-1
2.3 Hardware Description............................................................................................2-2
2.4 Hardware Connection........................................................................................... 2-4
3 Topology.....................................................................................................3-1
4 Configuration Preparation........................................................................4-1
4.1 Configure TCP/IP.................................................................................................. 4-1
4.2 Login......................................................................................................................4-2
5 Configure the Internet.............................................................................. 5-1
5.1 Check the Status.................................................................................................. 5-1
5.1.1 Check the Ethernet Interface Information................................................ 5-1
5.1.2 Check the Ethernet Connection Status....................................................5-2
5.1.3 Check the 3G/4G Status..........................................................................5-2
5.2 Configure the WAN............................................................................................... 5-3
5.2.1 Configure the Ethernet Connection..........................................................5-3
5.2.2 Configure the 3G/4G................................................................................5-6
5.3 Configure the QoS................................................................................................ 5-9
5.3.1 Configure the QoS Global Parameters.................................................... 5-9
5.3.2 Configure the QoS Classification............................................................. 5-9
5.4 Configure the Security........................................................................................ 5-11
5.4.1 Configure the Firewall Level.................................................................. 5-11
5.4.2 Configure the Filter Criteria....................................................................5-13
5.4.3 Configure the Local Service Control...................................................... 5-16
5.4.4 Configure the ALG................................................................................. 5-19
5.4.5 Configure the DMZ.................................................................................5-19
5.4.6 Configure the Port Forwarding...............................................................5-20
5.5 Configure the Parental Controls......................................................................... 5-21
5.6 Configure the DDNS........................................................................................... 5-22
5.7 Configure the SNTP............................................................................................5-24
5.8 Configure the Port Binding..................................................................................5-25
5.9 Configure the Mulitcast....................................................................................... 5-25
I

5.9.1 Configure the IGMP............................................................................... 5-25
5.9.2 Configure the MLD.................................................................................5-26
6 Configure the Local Network...................................................................6-1
6.1 Check the Local Network Status.......................................................................... 6-1
6.2 Configure the WLAN............................................................................................. 6-2
6.2.1 Configure the Basic Parameters of the WLAN........................................ 6-2
6.2.2 Configure the Advanced Parameters of the WLAN................................. 6-5
6.3 Configure the LAN................................................................................................ 6-7
6.3.1 Configure the LAN (IPv4).........................................................................6-7
6.3.2 Configure the LAN (IPv6).......................................................................6-10
6.4 Configure the Route............................................................................................6-15
6.4.1 Configure the Routing(IPv4)...................................................................6-15
6.4.2 Configure the Routing(IPv6)...................................................................6-18
6.5 Configure the FTP Server Feature..................................................................... 6-20
6.6 Configure the UPnP............................................................................................ 6-21
6.7 Configure the DMS/DLNA...................................................................................6-21
6.8 Configure the Samba Service.............................................................................6-23
6.9 Configure the DNS..............................................................................................6-24
6.10 Configure the NetSphere.................................................................................. 6-25
7 Configure the Management and Diagnosis............................................ 7-1
7.1 Check the Device Status...................................................................................... 7-1
7.2 Configure the Account Management.................................................................... 7-2
7.3 Configure the Login Timeout................................................................................ 7-3
7.4 Configure the System Management..................................................................... 7-4
7.4.1 Configure the Device Management......................................................... 7-4
7.4.2 Upgrade Software.................................................................................... 7-5
7.4.3 Manage the User Configuration...............................................................7-5
7.5 Configure the Mirror function................................................................................ 7-6
7.6 Configure the TR069 function...............................................................................7-7
7.7 Manage the Log..................................................................................................7-10
7.8 Network Diagnosis.............................................................................................. 7-13
7.9 Check the ARP Table......................................................................................... 7-15
7.10 Check the MAC Table.......................................................................................7-15
7.11 Configure the IPv6 Switch.................................................................................7-16
8 Troubleshooting........................................................................................ 8-1
II

Chapter 1
Safety Precautions
Note
Before using the device, read the following safety precautions. ZTE bears no liability to
the consequences incurred by violation of the safety instructions.
Usage Cautions
Read all the safety cautions carefully before using the device.
Only use the accessories included in the package, such as power supply adapter
and battery.
Do not extend the power cord, otherwise the device will not work.
The power supply voltage must meet the requirements of the device input voltage (
The voltage fluctuation range is less than 10%).
Keep the power plug clean and dry to prevent any risk of electric shock or other
dangers.
Disconnect all the cables during a lightning storm to prevent the device from
damage.
Power off and unplug the power plug when the device is not in use for a long time.
Do not attempt to open the covers of the device. It is dangerous to do so when the
device is powered ON.
Power off and stop using the device under the conditions such as, abnormal sound,
smoke, and strange smell. Contact the service provider for maintenance if the device
is faulty.
Environment Requirements
Ensure proper ventilation to the device. Place the device away from direct sunlight.
Keep the device ventilated and dry. Never spill any liquid on the device.
Do not place any object on the device to prevent any deformation or damage to the
device.
SJ-20200429083356-004 | 2020-07-23(R1.0) 1-1

ZXHN H3601 Maintenance Management Guide
Do not place the device near any source of heat or water.
Keep the device away from any household appliances with strong magnetic or
electric fields, such as microwave oven and refrigerator.
Cleaning Requirements
Before cleaning, power off the device, and unplug all the cables connected to the
device, such as power cable, optical fiber, and Ethernet cable.
Do not use any liquid or spray to clean the device. Use a soft dry cloth.
Environment Protection
Do not dispose the device or battery improperly.
Observe the local regulations about the equipment disposal or treatment.
Restrictions in the 5 GHz Band
According to Article 10(10) of Directive 2014/53/EU, the packaging shows that this radio
equipment will be subject to some restrictions when placed on the market in Belgium(
BE), Bulgaria(BG), the Czech Republic(CZ), Denmark(DK), Germany(DE), Estonia(
EE), Ireland(IE), Greece(EL),Spain(ES), France(FR), Croatia(HR), Italy(IT),Cyprus(CY),
Latvia(LV), Lithuania(LT), Luxembourg(LU), Hungary(HU), Malta(MT), Netherlands(
NL), Austria(AT), Poland(PL), Portugal(PT), Romania(RO), Slovenia(SI), Slovakia(
SK), Finland(FI), Sweden(SE), the United Kingdom(UK), Turkey(TR), Norway(NO),
Switzerland(CH), Iceland(IS), and Liechtenstein(LI).
The WLAN function for this device is restricted to indoor use only when operating in the
5150 to 5350 MHz frequency range.
RF Exposure Information
The Maximum Permissible Exposure (MPE) level is calculated based on a distance of
d=20 cm between the device and the human body. To maintain compliance with the
RF exposure requirement, a separation distance of 20 cm between the device and the
human should be maintained.
EU Declaration of Conformity
Hereby, ZTE Corporation declares that the radio equipment type ZXHN H3601 is in
compliance with Directive 2014/53/EU, The full text of the EU declaration of conformity
is available at the following Internet address:
http://support.zte.com.cn/support/cer/EU
1-2 SJ-20200429083356-004 | 2020-07-23(R1.0)

1 Safety Precautions
Environmental Information
The equipment you purchased has required the extraction and use of natural resources
for its production. It may contain substances that are hazardous to people’s health
and to the environment. To avoid putting such substances into our environment and to
reduce pressure on our natural resources, we ask that you reuse or recycle your end-of-
life equipment by using an accredited electronics take-back system.
The symbols below indicate that this product should be reused or recycled and not
simply discarded. Please locate and use an appropriate reuse and recycling site.
If you need more information on collection, reuse and recycling systems, contact your
local or regional waste administration. You may also contact your equipment provider for
more information on the environmental performances of these products.
SJ-20200429083356-004 | 2020-07-23(R1.0) 1-3

ZXHN H3601 Maintenance Management Guide
1-4 SJ-20200429083356-004 | 2020-07-23(R1.0)

Chapter 2
Product Overview
Table of Contents
Package Check.............................................................................................................. 2-1
Product Specifications....................................................................................................2-1
Hardware Description.....................................................................................................2-2
Hardware Connection.................................................................................................... 2-4
2.1 Package Check
After unpacking the product, check that the following items are complete.
Name Quantity
ZXHN H3601 One
AC-DC power supply adapter One
RJ-45 Ethernet cable One
User manual One
Note
The list is only for reference. The actual contents may vary from the list.
If any item is found to be wrong, missing, or damaged, contact your service provider.
Keep the package and all the items in good condition if you want to replace the product.
2.2 Product Specifications
Technical Specifications
Dimension 128 mm × 79 mm × 180mm
(Width × Depth × Height)
Certification CE Certification and Wi-Fi Certification
Power adapter Input: AC 100 V – 240 V, 50 Hz/60 Hz
Output: DC 12 V, 1.5 A
SJ-20200429083356-004 | 2020-07-23(R1.0) 2-1

ZXHN H3601 Maintenance Management Guide
Technical Specifications
Environment Requirements
Operation temperature 0 °C – 40 °C (32 °F – 104 °F)
Operation humidity 5% – 95% (non-condensing)
Wi-Fi Radio Specifications
Radio Frequencies Maximum Output Power
Wi-Fi 2.4 GHz band: 2400 – 2483.5
MHz
EIRP: 19 ± 1 dBm
Wi-Fi 5 GHz band: 5150 – 5250
MHz
EIRP: 22 ± 1 dBm
Wi-Fi 5 GHz band 5250 – 5350MHz EIRP: 19 ± 1 dBm
Wi-Fi 5 GHz band 5470 – 5725MHz EIRP: 26 ± 1 dBm
2.3 Hardware Description
Front panel
Figure 2-1 shows the front panel of the ZXHN H3601.
Figure 2-1 The Front Panel
2-2 SJ-20200429083356-004 | 2020-07-23(R1.0)

2 Product Overview
LED Color Status Description
Off The power supply is not connected or is faulty.
Red On Steady on: The system is performing self-detection or the self-
detection fails.
Flashing: Uplink connection failed or configuration synchronization
failed in agent mode.
Green On Steady on: The uplink connection is normal.
Or the connection is successful in agent mode and the configuration
is synchronized successfully.
Or the wireless uplink signal is strong in agent mode.
Flashing: WLAN terminal is in WPS accessing process.
Or the wireless uplink signal is weak in agent mode.
Green + Red On Flashing: Software upgrade progress.
Rear panel
Figure 2-2 shows the interfaces and buttons on the rear panel of the ZXHN H3601.
Figure 2-2 The Rear Panel
Interface/Button Function
USB USB 2.0 host port: Used for the USB storage device, printer or Dongle connection
SJ-20200429083356-004 | 2020-07-23(R1.0) 2-3

ZXHN H3601 Maintenance Management Guide
Interface/Button Function
LAN1-LAN3 RJ-45 port: Used to connect the modem to PCs, STBs or other network devices
LAN1/LAN2 RJ-45 port, it is used to connect to the uplink access network.
Power Power supply socket: Used to connect to the power adapter
Reset Reset pinhole: During power ON period, hold on this button for more than 5
seconds to reset the current settings to the factory default.
WPS WPS Push Button
2.4 Hardware Connection
Figure 2-3 shows the devices that are connected to interfaces of the ZXHN H3601.
Figure 2-3 Cable Connection
The factors affecting the wireless network coverage range include the location of the
product, distance between the product and a wireless terminal, number of obstacles,
obstacle material and density, and interference source. It is recommended that you
place the product in accordance with the following principles to maximize the strength of
wireless signals.
The product should be far away from the objects affecting wireless signal
propagation, for example, an object with a high reflectivity such as a metallic object
or a mirror.
2-4 SJ-20200429083356-004 | 2020-07-23(R1.0)

2 Product Overview
The product should be far away from an electrical appliance with a strong magnetic
or electric field, for example, a microwave oven, a refrigerator, a wireless router, a
cordless phone, or a Bluetooth product.
The product should be installed on the same floor as the applied area.
Do not put other objects on the product. Try to reduce the number of obstacles
between the product and a wireless terminal.
Horizontally place the product in the middle of the applied area and do not put it in a
corner.
Do not place the product at a high position while it is placed horizontally. The
recommended height is 1.2 to 1.5 meters.
SJ-20200429083356-004 | 2020-07-23(R1.0) 2-5

ZXHN H3601 Maintenance Management Guide
2-6 SJ-20200429083356-004 | 2020-07-23(R1.0)

Chapter 3
Topology
In the controller status and agent status, the corresponding topologies are different.
If ZXHN H3601 is set to controller, the corresponding topology diagram is shown in
Figure 3-1.
Figure 3-1 Controller
If ZXHN H3601 is set to agent, the corresponding topology diagram is shown in
Figure 3-2.
Figure 3-2 Agent
SJ-20200429083356-004 | 2020-07-23(R1.0) 3-1

ZXHN H3601 Maintenance Management Guide
3-2 SJ-20200429083356-004 | 2020-07-23(R1.0)

Chapter 4
Configuration
Preparation
Table of Contents
Configure TCP/IP........................................................................................................... 4-1
Login...............................................................................................................................4-2
This manual uses the Windows operating system as an example for describing how to
configure the ZXHN H3601. Before configuring the ZXHN H3601, you need to perform
the following operations:
Ensure that a crossover or straight-through Ethernet cable connects a computer to
the device.
Ensure that the TCP/IP configuration on the computer is correct.
Stop any firewall or other security software operating on the computer.
Disable the proxy setting of Internet Explorer.
4.1 Configure TCP/IP
To log in to the ZXHN H3601 on a computer, you need to set the IP address of the
computer to ensure that the IP address of the computer and the maintenance IP
address of the ZXHN H3601 are in the same network segment.
Context
The default maintenance IP address of the ZXHN H3601 is as follows:
IP address: 192.168.1.1
Subnet mask: 255.255.255.0
Default gateway: 192.168.1.1
Steps
1. Use an Ethernet cable to connect a local computer to the LAN interface of the ZXHN
H3601.
SJ-20200429083356-004 | 2020-07-23(R1.0) 4-1

ZXHN H3601 Maintenance Management Guide
2. On the local computer, double-click Local Area Connection and click Properties.
The Local Area Connection Properties dialog box is displayed.
3. Double-click Internet Protocol (TCP/IP). The Internet Protocol (TCP/IP)
Properties dialog box is displayed. Set the IP address to 192.168.1.200, subnet
mask to 255.255.255.0, and default gateway to 192.168.1.1.
4. Click OK.
Postrequisite
After the IP address of the computer is set, you can run the Ping command to ping the
IP address 192.168.1.1. If the ping operation is successful, it indicates that the TCP/IP
configuration is correct and the computer is properly connected to the ZXHN H3601.
4.2 Login
The ZXHN H3601 provides a Web-based configuration and management system. You
can enter a specified IP address in the address bar of Internet explorer to access the
system.
Prerequisite
A computer is directly connected to the ZXHN H3601, and their IP addresses are in the
same network segment.
Steps
1. Open Internet explorer, and enter http://192.168.1.1 (default maintenance IP address
of the ZXHN H3601) in the address field. Press the Enter key. The login page is
displayed, see Figure 4-1.
Figure 4-1 Login Page
4-2 SJ-20200429083356-004 | 2020-07-23(R1.0)

4 Configuration Preparation
2. Enter your username and password and click Login. The configuration page is
displayed, see Figure 4-2.
Figure 4-2 Configuration Page
SJ-20200429083356-004 | 2020-07-23(R1.0) 4-3

ZXHN H3601 Maintenance Management Guide
4-4 SJ-20200429083356-004 | 2020-07-23(R1.0)
