ACME Sunrise User manual

CONTENTS
1. Safety Instructions ................................................................................................. 2
2. Technical Specifications.......................................................................................... 6
3. Control Panel ......................................................................................................... 8
4. Effect Wheels ......................................................................................................... 9
5. How To Set The Unit............................................................................................... 9
5.1 Main Function .................................................................................................. 9
5.2 Home Position Adjustment............................................................................. 17
6. Control By Universal DMX Controller.................................................................... 22
6.1 DMX512 Connection ...................................................................................... 22
6.2 Address Setting .............................................................................................. 23
6.3 DMX512 Configuration................................................................................... 23
7. Error Information ................................................................................................. 28
8. Troubleshooting ................................................................................................... 32
9. Fixture Cleaning ................................................................................................... 32
1D

1. Safety Instructions
WARNING
Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that
they also receive this instruction manual.
Important:
Damages caused by the disregard of this user manual are not subject to warranty. The dealer will
not accept liability for any resulting defects or problems.
Unpack and check carefully to ensure that there is no transportation damage before using the
unit.
This product is for indoor use only. Use only in a dry location.
DO install and operate by qualified operator.
DO NOT allow children to operate the fixture.
Use safety chain when fixing the unit. Handle the unit by carrying its base instead of head only.
The unit must be installed in a location with adequate ventilation, at least 50cm from adjacent
surfaces.
Be sure that no ventilation slots is blocked, otherwise the unit will be overheated.
Before operation, ensure that you are connecting this product to the proper voltage in
accordance with the specifications in this manual or on the product’s specification label.
It’s important to ground the yellow/green conductor to earth in order to avoid electric shock.
Minimum ambient temperature TA: 0℃. Maximum ambient temperature TA: 40℃.Do not
operate this product at a lower or higher temperature.
DO NOT connect the device to any dimmer pack.
Keep flammable materials away from the fixture while operating to avoid fire hazard.
Make sure the power cord is not crimped or damaged; replace it immediately if damaged.
Unit’s surface temperature may reach up to 75℃. DO NOT touch the housing bare-handed
during its operation.
Avoid any flammable liquids, water or metal from entering the unit. Once it happens, cut off
the mains power immediately.
Please read the instruction carefully which includes important information about
the installation, usage and maintenance.
2D

DO NOT operate in a dirty or dusty environment. DO clean the fixture regularly.
DO NOT touch any wire during operation as there might be a hazard of electric shock.
Avoid entanglement of the power cord with other wires.
The minimum distance to objects/surface must be more than 3 meters.
In the event of serious operating problem, stop using the unit immediately.
Never turn on and off the unit time after time.
The housing, the lenses, or the ultraviolet filter must be replaced if they are visibly damaged.
DO NOT open the housing as there are no user serviceable parts inside.
DO NOT attempt to operate this unit if it becomes damaged. DO NOT attempt any repairs
yourself. Repairs carried out by unskilled people can lead to damage or malfunction. Please
contact the nearest authorized technical assistance center if needed.
Disconnect this product from its power source before servicing.
DO use the original packaging if the device is to be transported.
Avoid direct eye exposure to the light source while the product is on.
DO NOT operate this product if you see damage on the housing, shields, or cables. Have the
damaged parts replaced by an authorized technician at once.
Installation:
The fixture should be fixed on the clamp. Always ensure that the unit is firmly fixed to avoid
vibration and slipping off during operation. Ensure that the trussing or area of installation must be
able to hold 10 times the weight without any deformation. Always install a safety cable that can
hold at least 12 times the weight of the fixture when installing.
DO install and operate by qualified operator. It must be installed in a place where there is out of the
reach of people.
3D

1. Consignes de sécurité
ATTENTION
Veuillez conserver ce guide de l'utilisateur pour une consultation future. Si vous vendez l'appareil à
un autre utilisateur, assurez-vous qu'il reçoive également ce manuel d'instructions.
Important:
Les dommages causés par le non-respect de ce manuel d'utilisation ne sont pas couverts par la
garantie. Le revendeur n'acceptera aucune responsabilité pour les défauts ou problèmes qui en
résultent.
Déballez et vérifiez soigneusement qu'il n'y a pas de dommages dus au transport avant
d'utiliser l'appareil.
Ce produit est destiné à un usage intérieur uniquement. Il doit donc être utilisé uniquement
dans un endroit sec.
L’installation et la mise en fonctionnement doit être effectué par un opérateur qualifié.
NE PAS permettre aux enfants d'utiliser l'appareil.
Utilisez une chaîne de sécurité lors de la fixation de l'unité. Manipulez l'appareil en portant sa
base au lieu de la tête uniquement.
L'unité doit être installée dans un endroit avec une ventilation adéquate, à au moins 50cm des
surfaces adjacentes.
Assurez-vous qu'aucune fente d'aération du luminaire n'est obstruée, sinon il risque de
surchauffer.
Avant toute utilisation, assurez-vous que vous connectez ce luminaire à la tension appropriée
conformément aux spécifications que vous trouverez dans ce manuel ou sur l'étiquette des
spécifications collée sur la base du luminaire.
Il est important de relier le file jaune/vert à la terre afin d'éviter tout choc électrique.
Température ambiante minimale TA: 0. Température ambiante maximale TA: 40. N'utilisez pas
ce luminaire à des températures inférieures ou supérieures.
NE PAS connecter le luminaire à un pack de gradateurs.
Gardez les matériaux inflammables à l'écart du luminaire pendant le fonctionnement pour
éviter tout risque d'incendie.
Veuillez lire attentivement les instructions qui contiennent des informations
importantes sur l'installation, l'utilisation et l'entretien.
4D

Assurez-vous que le cordon d'alimentation n'est pas pincé ou endommagé; remplacez-le
immédiatement s'il est endommagé.
La température de surface de l'unité peut atteindre 75℃. NE PAS toucher les capots à mains
nues pendant son fonctionnement.
Évitez que des liquides inflammables, de l'eau ou du métal ne pénètrent dans l'appareil. Si cela
se produit, coupez immédiatement l'alimentation secteur.
NE PAS utiliser le luminaire dans un environnement sale ou poussiéreux. Cette appareil doit
être nettoyer régulièrement.
NE touchez AUCUN file pendant le fonctionnement car il pourrait y avoir un risque de choc
électrique.
Évitez l'enchevêtrement du cordon d'alimentation avec d'autres fils.
La distance minimale de projection sur des objets ou sur des surfaces doit être supérieure à 3
mètres.
En cas de problème de fonctionnement grave, arrêtez immédiatement d'utiliser l'appareil.
N'allumez et n'éteignez jamais ce luminaire à maintes reprises.
Le boîtier, les lentilles ou le filtre ultraviolet doivent être remplacés s'ils sont visiblement
endommagés.
NE PAS ouvrir le boîtier car il ne contient aucune pièce réparable par l'utilisateur.
NE PAS mettre ce luminaire en fonctionnement s'il est endommagé. N'effectuez pas de
réparations vous-même. Les réparations ne doivent être effectuées par des personnes non
qualifiées, cela peut entraîner des dommages ou des dysfonctionnements. Veuillez contacter le
centre d'assistance technique agréé le plus proche si nécessaire.
Débranchez ce produit du secteur avant de procéder à l'entretien.
Utiliser l'emballage d'origine si l'appareil doit être transporté.
Évitez une exposition directe des yeux à la source lumineuse lorsque le produit est allumé.
N'utilisez PAS ce produit si vous constatez des dommages sur le boîtier, les blindages ou les
câbles. Faites remplacer immédiatement les pièces endommagées par un technicien agréé.
5D

Installation:
Le luminaire doit être fixé à l’aide de crochets. Assurez-vous toujours que l'appareil est fermement
fixé pour éviter les vibrations et le glissement pendant le fonctionnement. Assurez-vous que la
structure ou la zone d'installation peut supporter au moins 10 fois le poids de cet appareil sans
aucune déformation. Installez toujours un câble de sécurité pouvant supporter au moins 12 fois le
poids du luminaire lors de l'installation.
L’installation et l’utilisation de ce luminaire doit être effectué par un opérateur qualifié. Il doit être
installé dans un endroit hors de portée des personnes.
2. Technical Specifications
Power Voltage:
100-240V~ 50/60Hz
Power Consumption:
1535W
Light Source:
SSL1050AC
Color Temperature:
6500K
Zoom Range:
5°~72°
Movement:
Pan: 540°
Tilt: 270°
Pan/Tilt Resolution: 16 bit
Fixation: Pan/Tilt lock
Color Wheel:
Color Wheel 1: 5 colors plus open and soft filter with rainbow effect
Color Wheel 2: 6 colors plus open with rainbow effect
6D

Control:
DMX Channel: 27/18 channels
Control Mode: DMX512, RDM, Art-Net, sACN
Firmware Upgrade via DMX link or USB disk
Construction:
Display: LCD display
Battery backup for user setup without mains connection
Data In/Out: 3-pin and 5-pin XLR, RJ45
Power In/Out: Power Connector in/out
Protection Rating: IP20
Features:
Standard mode Ra>70
High CRI mode Ra>90
Switch to high CRI mode with high CRI filter
Linear CMY color mixing
Variable CTO
The patented design frost filters, made of brand new material can achieve 0-100% linear softening
and make the spot larger and more uniform
4 x fast and smooth framing shutters, the position and the angel of each shutter blade can be
controlled individually; the framing module can be rotated at ± 45 degrees
2 x fixed clamps for 50mm truss, and 2 x screw holes for removable clamps for 70mm truss
Dimension/Weight:
465x352x848.4mm, 44.5kgs
18.3"x13.9"x33.4"in, 98lbs
7D

Photometric Diagram:
3. Control Panel
1. Display: To show the various menus and the selected function
2. Button:
MENU
To enter into move backward or leave the menu
UP
To go backward to move up in the menu
DOWN
To go forward to move down in the menu
ENTER
To perform the desired functions
3. BATTERY DISPLAY
4. ETHERNET: Transfers fixture’s information to a main controller
4. DMX IN:For DMX512 operation, use 3/5-pin XLR cable to link the unit and DMX controller
5. DMX OUT: For DMX512 operation, use 3/5 -pin XLR cable to link the next units
7. POWERCON IN: To connect to supply power
8.POWERCON OUT: To connect to the next fixture
9. POWER SWITCH: Turns on/off the power
10. FIRMWARE UPGRADE: Used to upgrade fixture’s firmware
8D

4.Effect Wheels
DANGER!
Install the color wheels with the device switched off only.
Unplug from mains before changing the color wheels!
5.How To Set The Unit
5.1 Main Function
Turn on the unit, press the MENU button into menu mode, and press the UP/DOWN button until
the required function is shown on the monitor. Select the function by pressing the ENTER button.
Use the UP/DOWN button to choose the submenu, press the ENTER button to store and
automatically return to the last menu. Press the MENU button or let the unit idle 30 seconds to exit
menu mode.
The main functions are shown below:
9D

10D

DMX Settings
To select DMX Settings, press the ENTER button to confirm, use the UP/DOWN button to select
DMX Address, DMX Channel Mode, Connect Option, No DMX Status, Network, Art-Net, sACN,
Repeat On DMX or View DMX Value.
DMX Address
To select DMX Address, press the ENTER button to confirm. Use the UP/DOWN button to adjust the
address from 1to 486/495, press the ENTER button to store. Press the MENU button back to the
last menu or let the unit idle 30 seconds to exit menu mode.
DMX Channel Mode
To select DMX Channel Mode, press the ENTER button to confirm. Use the UP/DOWN button to
select (27)F-Wash or (18)Wash, press the ENTER button to store. Press the MENU button back to
the last menu or let the unit idle 30 seconds to exit menu mode.
Connect Option
To select Connect Option, press the ENTER button to confirm. Use the UP/DOWN button to select
Auto, DMX,Art-Net or sACN, press the ENTER button to store. Press the MENU button back to the
last menu or let the unit idle 30 seconds to exit menu mode.
11D

No DMX Status
To select No DMX Status, press the ENTER button to confirm. Use the UP/DOWN button to select
Hold or Blackout, press the ENTER button to store. Press the MENU button back to the last menu or
let the unit idle 30 seconds to exit menu mode.
Network
To select Network, press the ENTER button to confirm. Use the UP/DOWN button to select Manual
or DHCP, press the ENTER button to store. To select Manual, press the ENTER button to confirm.
Use the UP/DOWN button to select IP Address, Subnet Mask or Gateway, press the ENTER button
to store. Press the MENU button back to the last menu or let the unit idle 30 seconds to exit menu
mode.
Art-Net
To select Art-Net, press the ENTER button to confirm. Use the UP/DOWN button to select Net,
Sub-Net or Universe, press the ENTER button to store. Press the MENU button back to the last
menu or let the unit idle 30 seconds to exit menu mode.
sACN
To select sACN, press the ENTER button to confirm. Use the UP/DOWN button to select Universe or
Priority, press the ENTER button to store. Press the MENU button back to the last menu or let the
unit idle 30 seconds to exit menu mode.
Repeat On DMX
To select Repeat On DMX, press the ENTER button to confirm. Use the UP/DOWN button to select
No or Yes, press the ENTER button to store. Press the MENU button back to the last menu or let the
unit idle 30 seconds to exit menu mode.
View DMX Value
To select View DMX Value, press the ENTER button to confirm. Use the UP/DOWN button to view
the DMX channel value. Press the MENU button back to the last menu or let the unit idle 30
seconds to exit menu mode.
Fixture Settings
To select Fixture Settings, press the ENTER button to confirm, use the UP/DOWN button to select
Pan Invert, Tilt Invert, P/T Feedback, Dimmer Speed, Dimmer Curve, Power Mode or Soften
Mode.
12D

Pan Invert
To select Pan Invert, press the ENTER button to confirm. Use the UP/DOWN button to select No or
Yes, press the ENTER button to store. Press the MENU button back to the last menu or let the unit
idle 30 seconds to exit menu mode.
Tilt Invert
To select Tilt Invert, press the ENTERbutton to confirm. Use the UP/DOWN button to select No or
Yes, press the ENTER button to store. Press the MENU button back to the last menu or let the unit
idle 30 seconds to exit menu mode.
P/T Feedback
To select P/T Feedback, press the ENTER button to confirm. Use the UP/DOWN button to select No
(Pan or tilt’s position will not feedback while out of step) or Yes (Feedback while pan/tilt out of step),
press the ENTER button to store. Press the MENU button back to the last menu or let the unit idle
30 seconds to exit menu mode.
Dimmer Speed
To select Dimmer Speed, press the ENTER button to confirm. Use the DOWN/UP button to select
Fast or Smooth, press the ENTER button to store. Press the MENU button back to the last menu or
let the unit idle 30 seconds to exit menu mode.
Dimmer Curve
To select Dimmer Curve, press the ENTER button to confirm. Use the DOWN/UP button to select
Square Law, Inv SQ Law, Linear or S Curve,press the ENTER button to store. Press the MENU
button back to the last menu or let the unit idle 30 seconds to exit menu mode.
Square Law: Light intensity control is finer at low levels and coarser at high levels.
Inv SQ Law: Light intensity control is coarser at low levels and finger at high levels.
Linear: The increase in light intensity appears to be linear as DMX value is increased.
S Curve: Light intensity control is finger at low levels and high levels and coarser at medium levels.
13D

Power Mode
To select Power Mode, press the ENTER button to confirm. Use the UP/DOWN button to select
Standard or Quiet, press the ENTER button to store. Press the MENU button back to the last menu
or let the unit idle 30 seconds to exit menu mode.
Soften Mode
To select Soften Mode, press the ENTER button to confirm. Use the UP/DOWN button to select No
or Yes, press the ENTER button to store. Press the MENU button back to the last menu or let the
unit idle 30 seconds to exit menu mode.
Display Settings
To select Display Settings, press the ENTER button to confirm, use the UP/DOWN button to select
Display Invert, Backlight Intensity or Temperature Unit.
Display Invert
Select Display Invert, press the ENTER button to confirm, present mode will blink on the display, use
the UP/DOWN button to select No (normal display) or Yes (invert display), press the ENTER button
to store. Press the MENU button back to the last menu or let the unit idle 30 seconds to exit menu
mode.
Backlight Intensity
Select Backlight Intensity, press the ENTER button to confirm, present mode will blink on the
display, use the UP/DOWN button to adjust value from 1to 10, press the ENTER button to store.
Press the MENU button back to the last menu or let the unit idle 30 seconds to exit menu mode.
Temperature Unit
Select Temperature Unit, press the ENTER button to confirm, present mode will blink on the display,
use the UP/DOWN button to select
℃
or
℉
, press the ENTER button to store. Press the MENU
button back to the last menu or let the unit idle 30 seconds to exit menu mode.
F ixture Test
To select F ix ture Test , press the ENTER button to confirm, use the UP/DOWN button to select Auto
Test or Manual Mode.
14D

Auto Test
Select Auto Test, press the ENTER button to confirm, the unit will run built-in programs to
automatically test pan, tilt, color, focus, zoom, shutter, dimmer, special function, etc. Press the
MENU button back to the last menu or exit menu mode after auto test.
Manual Mode
Select Manual Mode, press the ENTER button to confirm, the present channel will show on the
display, use the UP/DOWN button to select channel, press the ENTER button to confirm, then use
the UP and DOWN button to adjust the value, press the ENTER button to store, the fixture will run
as the channel value indicates. Press the MENU button back to the last menu or exit menu mode
idling 30 seconds.
(All channels value will become 0 after exiting Manual Mode menu)
Fixture Information
To select Fixture Information, press the ENTER button to confirm, use the UP/DOWN button to
select Fixture Use Hour, Temperature, Fan State, Voltage, Upgrade Files or Firmware Version.
Fixture Use Hour
Select Fixture Use Hour, press the ENTER button to confirm, fixture use hour will show on the
display, press the MENU button to exit.
Temperature
Select Temperature, press the ENTER button to confirm, fixture temperature will show on the
display, press the MENU button to exit.
Fan State
Select Fan State, press the ENTER button to confirm, fan state will show on the display, press the
MENU button to exit.
Voltage
Select Voltage, press the ENTER button to confirm, fixture voltage will show on the display, press
the MENU button to exit.
Upgrade Files
Select Upgrade Files, press the ENTER button to confirm, fixture upgrade files will show on the
display, press the MENU button to exit.
15D

Firmware Version
Select Firmware Version, press the ENTER button to confirm, firmware version will show on the
display, press the MENU button back to exit.
Reset Function
To select Reset Function, press the ENTER button to confirm, use the UP/DOWN button to select
Pan & Tilt Reset, Effect Reset or All Reset.
Pan & Tilt Reset
Select Pan & Tilt Reset, press the ENTER button to confirm, use the UP/DOWN button to select No
(normal) or Yes (the unit will run built-in program to reset pan and tilt to their home positions),
press the ENTER button to store. Press the MENU button to exit.
Effect Reset
Select Effect Reset,press the ENTER button to confirm, use the UP/DOWN button to select No or
Yes (the unit will run built-in program to reset effect to their home positions), press the ENTER
button to store. Press the MENU button to exit.
All Reset
Select All Reset,press the ENTER button to confirm, use the UP/DOWN button to select No or Yes
(the unit will run built-in program to reset all motors to their home positions), press ENTER button
to store. Press the MENU button to exit.
Special Function
Factory Restore
Select Factory Restore,press the ENTER button to confirm, use the UP/DOWN button to select No
(normal) or Yes (the fixture will reset to factory settings), press ENTER button to store. Press the
MENU button to exit.
16D

RDM FUNCTIONS
Select the MANUFACTURER menu to display the manufacturer of the fixture.
Select the SOFTWARE VERSION menu and the program version number of the fixture will be
displayed.
Select the DMX START ADDRESS menu to change the DMX 512 address (001-512).
Select the DEVICE MODEL DESCRIPTION menu to display the model of the fixture.
Select the DEVICE LABEL menu to change the model of the fixture.
Select the DMX PERSONALITY menu to set the channel mode of the fixture (2 7/1 8 channel).
Select the DMX PERSONALITY DESCRIPTION menu to display the current channel mode of the
fixture.
Select the DEVICE HOURS menu to display the running time of the fixture.
Select the PAN INVERT menu and the fixture will run the pan invert mode.
Select the TILT INVERT menu and the fixture will run the tilt invert mode.
Select the RESET DEVICE menu, the WARM RESET/COLD RESET option will be displayed. When
WARM RESET is selected, the fixture will start a warm reset, and exit when COLD RESET is selected.
5.2 Home Position Adjustment
Press the MENU button into menu mode, then press the ENTER button for about 3 seconds into
offset mode to adjust the home position. Select the function by pressing the ENTER button. Use the
UP/DOWN button to choose the submenu, press the ENTER button to store and automatically
return to the last menu. Press MENU button to exit.
17D

Dimming Start
Enter offset mode, Select Dimming Start, press the ENTER button to confirm, the present position
will blink on the display, use the UP/DOWN button to offset the value from 0 to 9999, press the
ENTER button to store. Press the MENU button to exit.
18D

LED Frequency(Hz)
Enter offset mode, Select LED Frequency(Hz), press the ENTER button to confirm, the present
position will blink on the display, use the UP/DOWN button to offset the value from 1072 to 1327,
press the ENTER button to store. Press the MENU button to exit.
Pan
Enter offset mode, Select Pan, press the ENTER button to confirm, the present position will blink on
the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button
to store. Press the MENU button to exit.
Tilt
Enter offset mode, Select Tilt, press the ENTER button to confirm, the present position will blink on
the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button
to store. Press the MENU button to exit.
Cyan
Enter offset mode, Select Cyan, press the ENTER button to confirm, the present position will blink
on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER
button to store. Press the MENU button to exit.
Magenta
Enter offset mode, Select Magenta, press the ENTER button to confirm, the present position will
blink on the display, use the UP/DOWN button to offset the value from -128 to 127, press the
ENTER button to store. Press the MENU button to exit.
Yellow
Enter offset mode, Select Yellow, press the ENTER button to confirm, the present position will blink
on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER
button to store. Press the MENU button to exit.
Cto
Enter offset mode, Select Cto, press the ENTER button to confirm, the present position will blink on
the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER button
to store. Press the MENU button to exit.
Color1
Enter offset mode, Select Color1, press the ENTER button to confirm, the present position will blink
on the display, use the UP/DOWN button to offset the value from -128 to 127, press the ENTER
button to store. Press the MENU button to exit.
19D
