Assa Abloy Union CodeGUARD 5 Assembly instructions

ASSA ABLOY, the global leader
in door opening solutions
CodeGUARD Fitting Guide
UNION recommend that you read this guide to installing, using and maintaining
CodeGUARD before beginning any work, and that it is kept in a safe place for future use.
English Version 1.0
BS8607:2014
+A1:2016
Lic.KM 690973

Important information about the UNION CodeGUARD 5 product:
• FullytestedtoBS8607:2014+A1:2016
• KitemarkedtoGrade5–LicenceNo690973
• CodeGUARD5hasbeensuccessfullyretestedtoBSEN1634-1:2014
• 30and60minutetimberredoors.SpecialNote:ifinstallingCodeGUARDon 
 timberredoorspleaseusetheapprovedintumescentkitJ8607CG5-IK
• 240minutemetalredoors
• Fullytestedto(latchonly)EN12209:2003classicationcode2|M|4|1|0|F|6|B|H|1|0
CodeGUARD:
• Isintendedforuseonsingleswinghingeddoors
• Isdesignedforthesecuritylatchtobemorticedwithinthedoor
• Pushbuttondeviceissecuredtotheexternalfacetoprovideaccesswhenthe
correct code is entered
• Internalleveronbackplateallowskeylessegressatalltimes
• Mustbeinstalledwithallofthecomponentsprovidedwhichcannotbemodiedor
 changedasthiswillinvalidatethekitemark,warrantyandcouldreducethesecurity
 provided
• Issuitableforuseonexternaldoors
• Issuppliedwithxingsfortimberandmetaldoors45mmand55mmthick
Advisory security note to maintain the security of this lock, please observe the
following recommendations:
• Changethefactory-setcodetoyourowncode
• Keepthekeypadcleansowearmarksdonotindicatethebuttonsinuse
• Changethecodewhenanemployee/userleaves,oryoubelievethecodehasbeen
shared with unauthorsized people
• Pleaseensurethatthedoorandframeissuitableforsecurityrequirementofthe 
doorset
Important Information
2

3
Contents
1 Before you begin page 4
2 Pack contents page 5
3 Before you start page 6
4 Determining the hand of the door page 6
5 Re-handing of the latch page 6
6 Preparing the door and mortice page 7
7 Fitting the latch page 7
8 Assembling the keypad page 8
9 Removing the transit pin from the latch page 8
10 Fitting the keypad (external face of door) page 9
11 Fitting the backplate (internal face of door) page 10
12 Fitting the lever handles page 10
13 Preparing the frame and strike page 11
Section 2
14 How to change your code number page 12
15 Exploded view of assembly page 14
16 Operating the unit page 14
17 Troubleshooting and maintenance page 15

1 Before you begin…
Pleasereadtheseinstructionscarefully.
Followingthestepsintherightorderwillmaketheinstallationmucheasierandhelp
makesurethenewlockisttedproperly.
Give yourself time…
Pleaseensureyougiveyourselfplentyoftimetoinstallthisproductcorrectlyand
adjustifrequired.
Please Note
If at any point you feel you can not successfully complete the installation you can call
ourcustomerservicehelpline08452232124.
After Installation
Ensureenduserhasthisdocumentforfuturereferenceandre-coding.
4

2 Pack contents
Tools required
1xKeypad 1xInsidehandle
2xLeverhandles
2xSpindles
50mmand60mm
1xShield
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
Latch fixing pack
TimberDoorFixings
4xwoodscrews
MetalDoorFixings
2xM4x10mmCSK
2xM5x10mmCSK
2xSecuritypins
1
2
3
4
5
6
7
8
Keypad fixing pack
Allen key
Code changer tool
2xGromitsx2
2xHexsupportposts
2xGrubscrews
2xM4x40mmCSK
2xM4x50mmCSK
2xM4x60mmCSK
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
1
2
3
4
5
6 7
8
1
2
3
4
5
6 7
8
1
2
3
4
5
6 7
8
1
2
3
4
5
6 7
8
Code card
1
2
3
4
5
6
7
8
1
2
3
4
5
6
7
8
2xHandlewashers Shield fixing pack
2xwashers
8xM3xingscrews
Buttonheadbolt-through
xings
2xM6x40mm
2xM6x50mm
2xM6x60mm
1
2
3
4
5
6
7
8
1
2
3
4
5
6 7
8
1
2
3
4
5
6 7
8
1
2
3
4
5
6 7
8
1
2
3
4
5
6
7
8
Scissors
SteelRule
Pencil
MaskingTape
Bradawl/Point
CrossHeadScrewdriver
4mmAllenkey
12&25mmChisels
Mallet
10,16,20&25mmdiaspadedrills
5
1xLatchwithforend
1xStrike

Pleaseensurethatthereisa3-5mmgapontheleadingedge
ofthedoor–thisisrequiredtoensuretheproductfunctionscorrectly.
1 Pleasecheckthatallpartsareworkingcorrectly.
2 Fittheleverhandlestothekeypadandinsidehandle.
3 Enterthefactorypresetcodeasprintedonthecodecard.
4 Rotatetheleverhandleonthekeypaddownwards.
5 Re-enterthecodeandturnthehandleupwardsensuringthatthespindlefolloweronthebackofthekeypadrotateseachtime.
6 Aclickshouldbeheardeverytimeacorrectcodeisenteredastheleverhandleisturned.
Bothleverhandlesonthekeypadandinsidehandleshouldreturneasilyundertheirownspringpressure.
Pleasereferto‘ttingtheleverhandles’below.
Ifyouintendtochangethecodefromthefactorysettingpleasereferto‘howtochangeyourcodenumber’
instructions before installing the product.
4 Determining the hand of the door
Thehandofthedoorisdeterminedwiththedoorinitsclosedpositionfromtheexteriororkeypadsideof
the door, as shown in the diagram below
A)Righthanddoor–dooropens
inward(push),hingedonthe
right side.
C)Righthandinwardopening–
dooropensoutward(pull),hinged
on the right side.
B)Lefthanddoor–dooropens
inward(push),hingedonthe
left side.
D)Lefthandinwardopening–
dooropensoutward(pull),hinged
on the left side.
3 Before you start…
Insert4mmAllenkeyintolatchhead.
Loosenscrew.
Removelatchfromlockcaseandrotate
180degreesandinsertbackintocase.
Tighten screw in latch head using allen key.
5 Re-handing of the latch
Ifrequired,re-handthelatchtosuitthehandingofthedoorbyfollowingthediagramsbelow:
6
Leading
edge
5.1 5.2 5.3

Ø16
Ø10
Ø16
Ø10
Ø20
Ø10
60mm
Edge of door
Do not drill
through all.
Only drill into
the cavity
NOTE: Fit to external face of door
6 Preparing the door & mortice
Cutouttemplate.Markcentrelineofdoor
andframe.Atrequiredheightmark
horizontal line on door and frame.
Usingthecentrelineguideandttingheight
datum,tapetemplatetotheexternalface
where the push button key pad is being
tted.Markthecentresofallholeswitha
bradawlandremovetemplate.RETAINFOR
DRILLINSTRUCTION.
Using25mmdiaspadedrillto100mm
deepin2placesasperthemorticelock
template.
Chisel out remaining timber between drill
holes.Removedebris.Insertlatchinto
mortice. Ensure latch is orientated so snib
is below the latch.
Drawaroundfaceplate.Removelatchand
chiseloutmarkedareatoadepthof4.5mm.
Tape drill guide to side face of door using
ttingheightdatumforposition.Drillthrough
holes on side of door as per marked locations.
Ensure drill is kept at right angle to door face
at all times during drilling.
Insert latch into mortice and place faceplate
overthetop.Markholesforxings&
pilot drill. Securefaceplatewithxingssupplied.
7 Fitting the latch
Ø3
Pilot hole
Ø3
Pilot hole
4.5mm
Ø3
Align with centreline
of door
Pilothole
4.5mm
Ø3
Align with centreline
of door
Pilothole
4.5mm
Ø3
Align with centreline
of door
Pilothole
4.5mm
Ø3
Align with centreline
of door
Pilothole
7
Ø3
Pilot hole
6.1 6.2 6.3
6.4 6.5 6.6
7.1 7.2

Locatethetransitscrewinthesideofthe
latchwhichwillbevisiblethroughthedoor
preparation.
8
8 Assembling the keypad
Pickthekeypad,shield,backplateandkey
padxingpackoutofthebox.
Take shield and place keypad face down
intotheapertureensuringtheleverfollower
is aligned with the hole in the shield.
If you wish to change the factory code set
forcodeGUARD,pleaseseethe‘howto
changeyourcodenumber’section.
Placethebackplateatontopoftheshield
ensuringthefollowerisvisblethroughthe
circular cut out.
Securebackplatetoshieldwiththe
8machinescrewssupplied.Ensurethatthe
screwssitushwiththefaceoftheback
plate.
Installhexsupportpostsintothetopand
bottom of the key pad for stability. Ensure
these are screwed all the way to the surface.
9 Removing the transit pin from the latch
STOP!
Undoscrewandremovefromlatchthrough
side of door preparation.
Ballbearingcavitywillnowbeexposedon
the side of the latch ready to insert security
pin.
8.1 8.2 8.3
8.4 8.5 8.6
9.1 9.2 9.3

9
10 Fitting the keypad (external face of door)
Pushthelatchfullyintothecasetoexpose
theballbearingcavityonthesideofthe
latch.
Whilst still holding the security pin in place,
carefully replace thumb with metal rule and
hold against surface of the door.
Take the assembled keypad and locate on
the door face. Ensure the metal rule and
security pin is kept in place.
Oncekeypadisrmlypushedagainstdoor,
carefully slide metal rule away allowing the
security pin to engage with the back plate.
Whilst still holding the keypad in place,
securewiththeM6buttonheadbolt
throughxingsandwashers.Select
appropriatexingstosuitdoorthickness.
Ie40mmfor44/45mmdoor.
Insert the spindle through the lock and into
the follower of the keypad. Ensure that the
flatendofthespindleispositioned
at‘5past 7’frominternalsideofdoor.
50mmSpindle–44/45mmdoors
60mmSpindle–55mmdoors
Selectthesecuritypinrequiredforthedoor
thickness.
44/45mmdoor
19mmpin 55mmdoor
24mmpin
1a-Insertthesmallerendofthesecurity
pinintotheballbearingcavity.
1b–fullydepressthepinintothelatchuntil
itisushwithfaceofthedoor
NOTE–pinisnowsprungloaded.
1a 1b
Ballbearingcavitywillnowbeexposedon
the side of the latch ready to insert security
pin.
10.1 10.2
10.4 10.5 10.6
10.7
10.3
10.8 10.9

11 Fitting the backplate (internal face of door)
Offer up the backplate to the internal door
face. Ensure spindle is located in follower
of backplate.
LocateM4CSKmachinescrewsthrough
top and bottom of body of backplate and
intothehexsupportposts.Tightenupfully.
Applyhandlewashersoverhandlespindles
tointernalandexternalsidesofthepush
button lock.
Fixhandlepointingawayfromedgeofthe
door. Insert grub screw and secure with
allen key supplied. Test the operation of the
handle. If the handle does not return under
its own spring pressure, loosen the grub
screw by ¼ of a turn until it springs back.
Repeat for other side of the door.
Oncehandlesaresecurelytted,push
rubbergrommetsovergrubscrews.
12 Fitting the lever handles
10
11.1 11.2
12.1 12.2 12.3
