Ballard Designs Miles Redd MR Shell MS050 User manual

PRODUCT NAME: MR Shell Console
ITEM NUMBER: MS050
DIMENSIONS OF ITEM ASSEMBLED: 33.5” H x 54” W x 20” D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 6/5/2017 Page 1 of 5
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN INDONESIA

Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 2 of 5
TOOLS NEEDED:
- Assembly may require
2 people
- Requires a screwdriver
NOTE: When unpacking, lay
the parts on a padded
surface such as the
packaging provided
Ltr.
A
B
4
C 6
D 6
E 1
F 2
Small Allen Bolts
2Large Allen Bolts
Lock Washers
Flat Washers
Allen Wrench
Anti-Tip Kits
Qty. Hardware Included
Ltr.
G 1
H 1
I
Table Top (G)
Post (H)
Base (I)
1
Qty. Components
Part A: Console Assembly

Page 3 of 5
STEP 1: Turn the Table Top (G) onto a smooth surface such as a carpeted floor or the packaging
provided.
(G)
(H)
(G)
(A)
(E)
(C)(D)
(D)
(E)
(C)(B)
STEP 2: Insert the top of the Post (H) into the slot in the Table Top (G). Insert a Lock Washer (C)
and a Flat Washer (D) onto the Large Allen Bolts (B) and two of the Small Allen Bolts (A).
Attach the Large Allen Bolts (B) into the front of the Post (H) and tighten with the Allen
Wrench (E). Then attach the Small Allen Bolts (A) into the sides of the Post (H) and tighten
with the Allen Wrench (E).
Customer Service: 800-367-2810
Online: www.ballarddesigns.com

Page 4 of 5
STEP 3: Align the pre-drilled holes in the Base (I) with the holes in the bottom of the Post (H).
Insert a Lock Washer (C) and a Flat Washer (D) onto the remaining Small Allen Bolts (A)
and attach them into the Base. Tighten with the Allen Wrench (E).
STEP 4: If the floor is uneven adjust the Levelers located on the underside of the Base (I). To adjust
the Levelers, lift up the side of the Console that needs to be elevated and turn the levelers
clockwise or counterclockwise until the Console is Level.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
(E)
(A)
(C)
(D)
(I)
(H)
(G)
(I)

Cleaning & Care:
DO NOT use alcohol based products or spray polisher as they can damage the finish.
Dust with soft cloth. One to two times monthly apply beeswax polish as needed.
Finish can be affected by heat or extended contact with oils or wine.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 5 of 5
Part F: Anti-Tip Installation
Ltr.
J
K
4
L 4
M 2
Small Screws
4Large Screws
Brackets
Retention Belt
Qty. Hardware Included
STEP 1: Attach two Brackets (L) horizontally to the back of the top of the Console using the Small
Screws (J). Attach the remaining Brackets vertically into a wall stud 1 inch below the
Brackets attached to the Console using the Large Screws (K). Align the brackets and
string in the Retention Belt (M). Confirm that the Belt is securely laced and locked.
(K)
(J)
(M)
(L)
