Ballard Designs Tuscan MV197 User manual

PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 8-7-2019 Page 1 of 4
PRODUCT NAME: Tuscan Corner Bookcase Left
ITEM NUMBER: MV197
ASSEMBLED DIMENSIONS : 81 3/4”H x 26 1/2”W x 15”D
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
IMPORTED

Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 2 of 4
Ltr.
A 12
C3
Qty. Hardware Included
Ltr.
D1
Qty. Components
REQUIRED TOOLS:
Phillips Scredriver
-Two person assembly suggested.
Remove all parts, hardware and
protective packaging from carton
and carefully arrange on a clean,
level, padded surface.
NOTE: To avoid accidentally
discarding small parts or hardware,
retain all carton contents until
assembly and installation are complete.
Shelves (C)
B2
Anti-Tip Kit
WARNING
Tip-Over Hazard
Prevent tipping accidents. Anchor your furniture.
ANCHORING HARDWARE INCLUDED
Shelf Supports
Hardware Packet
Shelves
Bookcase (D)

Page 3 of 4
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
STEP 2: Bookcase is equipped with Rotary Levelers under each bottom corner. If necessary, gently
lift corner and turn Leveler clockwise/counterclockwise to adjust.
STEP 1: Place Bookcase in desired location for use. Determine Shelf (C) placement then insert
Shelf Supports (A) into corresponding pre-drilled holes inside Bookcase. Gently place Shelf upon
Supports.

Page 4 of 4
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
Cleaning & Care:
DO NOT use alcohol based products or spray polisher as
they can damage the finish. Dust with soft cloth.
Ltr.
A
(B)
(A)
(C)
(C)
(D)
2 Small Screw
Retention Belt
Qty. Hardware Included
STEP 3: ANTI-TIP ANCHORING HARDWARE INSTALLATION
B2 Large Screw
C4 Bracket
D2
1. Locate and mark a Wall Stud behind Bookcase at location for installation.
2. Corresponding to Stud location, attach one Bracket (C) to back of Bookcase using Small Screw (B).
3. To keep hardware out of view after installation, attach remaining Bracket (C) INTO WALL STUD
with Large Screw (A) 2 inches below Bracket attached to back of Bookcase.
4. Move Bookcase into place, align Brackets then connect both using Retention Belt (D).
5. Confirm Belt is securely laced and locked.
WALL
STUD
WARNING
Tip-Over Hazard
WALL BRACKET MUST BE ATTACHED TO WALL STUD
Prevent tipping accidents. Anchor your furniture.
