Ballard Designs Hutton MO569 COR User manual

PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 5-4-2020 Page 1 of 7
PRODUCT NAME: Hutton *Corner Work Surface
ITEM NUMBER: MO569 COR
ASSEMBLED DIMENSIONS : 29.75”H x 24.75”L x 30.75”D
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN INDONESIA
*Corner Work Surface requires use of additional Hutton Base Cabinets and Work Surface Tops (sold separately).

Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 2 of 7
Ltr.
A 16
B 12
Qty. Hardware Included
Ltr.
I
J
1
1
Qty. Components
C 28
REQUIRED TOOLS:
Phillips Screwdriver
-Two person assembly suggested.
Remove all parts, hardware and
protective packaging from carton
and carefully arrange on a clean,
level, padded surface.
NOTE: To avoid accidentally
discarding small parts or hardware,
retain all carton contents until
assembly and installation are complete.
K
1
D
E
F
G
H
28
4
2
1
Long Screws (35mm)
Short Screws (15mm)
Flat Washers
Lock Washers
*Top Connector Brackets
*Corner Brackets
(Left & Right)
Wall Anchoring
(Anti-tip) Kit
See page 7
Serious or fatal crushing injuries can occur from a furniture tip-over
Tip-Over Hazard
Prevent tipping accidents. Anchor your furniture.
WARNING
ANCHORING HARDWARE INCLUDED
*For use for joining required Hutton Work Surfaces and Base Cabinets (sold separately)
Wood Dowels
2
L
1Middle Leg (J)
Right Leg (L)
Left Leg (K)
Top (I)
Assemble in location for intended use.

Page 3 of 7
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
STEP 1: Attach Left Leg (K) and Right Leg (L) to Middle Leg (J) using 8 Long Screws (A) with Flat
Washer (C) and Lock Washer (D) as illustrated below. Do not fully tighten until Step 2 is completed.
(L)
(J)
STEP 2: First, insert Wood Dowels (E) into pre-drilled holes located at outer top edge of each Side Panel.
Next, carefully place Top (I) onto Leg Assembly, align holes along edge then insert remaining 8 Long
Screws (A) with Lock Washer (D) and Flat Washer (C). Fully and firmly tighten all Screws from Steps 1
and 2.
(E)
(A)
(K)
(A)
(C)
(D)
(A) (A)
(I)
(A)
(D)
(C)

Page 4 of 7
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
STEP 3: Corner Work Surface is equipped with Rotary Levelers under each Leg. If necessary, Unit may
be adjusted by carefully lifting applicable corner and turning Leveler clockwise/counterclockwise.
(F)
(B)
(C)
(D)
STEP 4: Invert Hutton Work Surface and locate embedded T-nut along side edge. Using Short Screw (B),
Lock Washer (D) and Flat Washer (C) attach Top Connector Bracket (F) as illustrated. Firmly tighten and
secure.
STEPS 4 through STEP 8 illustrate and explain connecting required Hutton Work Surface
and Cabinet Base Units. While selected Units may vary from these illustrations, the
mechanical and hardware connections are the same. (These Units sold separately)
Work Surface

Page 5 of 7
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
STEP 5: Place Base Cabinets onto their backs and attach Corner Brackets (G) to bottom back edge of
Base Cabinet for left side and Base Cabinet for right side. Use Short Screw (B) with Lock Washer (D)
and Flat Washer (C). Firmly tighten.
(C)
(B)
STEP 6: Turn Base Cabinets upright and place Work Surface onto top with Top Connector Brackets (F)
oriented toward Corner Work Surface.
(D)
(C)
(B) (D)
(G)
(F)
(G)

Page 6 of 7
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
STEP 7: Slide Left and Right Base Cabinets up to each end of Corner Work Surface. Align Top
Connector Brackets and Corner Brackets with embedded T-nuts in Top and Legs.
(F)
(B)
(G)
(C)
(D)
STEP 8: Secure Work Surface Top Connector Brackets (F) and each Corner Bracket (G) by inserting
Short Screw (B) with Lock Washer (D) and Flat Washer (C) into T-nut and fully tightening.
(B)
(C)
(D)

Page 7 of 7
(A)
(D)
(B)
(C)
W
A
LLS
T
U
D
WALL BRACKET MUST BE ATTACHED TO WALL STUD
WALL ANCHORING HARDWARE (ANTI-TIP)
Serious or fatal crushing injuries can occur from a furniture tip-over
Tip-Over Hazard
Prevent tipping accidents. Anchor your furniture.
WARNING
Ltr.
A 2 Small Screw
Retention Belt
Qty. Hardware Included
B2Large Screw
C2Bracket
D1
1. Place Desk against wall at desired location then locate and mark a Wall Stud behind unit.
2. Corresponding to Stud location, attach one Bracket (C) into WOOD BANDING on back of Cabinet
using Small Screws (A). If Screw is not driven into wood it may pull out during a tip-over.
*NOTE: Assemble and connect side Cabinets BEFORE installing bracket onto Desk back.
3. To keep hardware out of view after installation, attach remaining Bracket (C) INTO WALL STUD
with Large Screws (B) 2 inches below Bracket attached to back of unit.
4. Move unit into place, align Brackets then connect both using Retention Belt (D).
5. Confirm Belt is securely laced and locked.
Cleaning & Care
Do not use alcohol based products or spray polisher as finish damage may result.
Periodically dust with a soft, dry cloth.
Anchor Desk into
corner WALL STUD
IMPORTANT
*Be certain connecting
Work Surface Tops
will fit and lay level:
Install Tops BEFORE attaching
Coner unit to wall.
