Ballard Designs UM013 User manual

PRODUCT NAME: Camden Daybed with & without Trundle
ITEM NUMBER: UM013; UM014
DIMENSIONS OF ITEM ASSEMBLED: 47 1/2”H x 79 1/4”W X 41 3/4”D
PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE. Page 1 of 4
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN USA

Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 2 of 4
TOOLS NEEDED:
-2 Person assembly.
-Screwdriver required.
Ltr.
A 4 Screws
Back (B)
Front (C)
Left Arm (D) Right Arm (E)
Spring Frame (F)
Qty. Hardware Included
Ltr.
B 1
F 1
D/E 2
C 1
Qty. Components
NOTE: It is best to put this bed together in the space where you will use it.

Page 3 of 4
STEP 1: Attach the Left Arm (D) and then the Right Arm (E) to the Back (B). Be sure the hook is fully
engaged before continuing with the assembly.
STEP 2: Attach the Front Rail (C) to the Left (D) and Right Arm (E). Push down on the Front Rail (C)
to fully lock it into place. Then Velcro the front apron to the side arms.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
(E)
(E)
(D)
(D)
(D)
(C)
(C)
(C)
(B)
(B) (B)
(A) (F)
NOTE: It is best to put this bed together in the space where you will use it.

Page 4 of 4
STEP 3: Place the Spring Frame (F) onto the ledges on inside of the Back (B) and Front Rail (C).
Then using a screwdriver and the Screws (A), attach the Spring Frame (F) to the
Back (B) and Front Rail (C) in all 4 corners.
CLEAN & CARE:
Spot cleaning is suggested. The method of cleaning is different
based on what upholstery fabric is used.
NOTE: The Trundle requires no assembly and simply slides underneath the bed.
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
(C)
(B)
(A)
(F)
(F)
NOTE: It is best to put this bed together in the space where you will use it.
