Ballard Designs MS096 User manual

PRODUCTS ARE NOT INTENDED
FOR COMMERCIAL USE.
UPDATED: 8-19-2019 Page 1 of 4
PRODUCT NAME: Wynn Demilune
ITEM NUMBER: MS096
ASSEMBLED DIMENSIONS : 32”H x 38”W x 14”D
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
MADE IN CHINA

Customer Service: 800-367-2810
Online: www.ballarddesigns.com Page 2 of 4
Ltr.
A 3
B 4
Qty. Hardware Included
Ltr.
D
E
1
1
Qty. Components
REQUIRED TOOLS:
-Phillips Screwdriver
-Two person assembly suggested.
Remove all parts, hardware and
protective packaging from carton
and carefully arrange on a clean,
level, padded surface.
NOTE: To avoid accidentally
discarding small parts or hardware,
retain all carton contents until
assembly and installation are complete.
Shelf Support
Anti-Tip Hardware
Kit
(See Page 4)
Shelf
Cabinet
Hardware Packet
Shelf

Page 3 of 4
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
IMPORTANT:
For items with levelers, if doors are not even, adjust levelers
until doors become even.
Cleaning & Care:
DO NOT use alcohol based products or spray polisher as finish damage may result.
Dust with a soft cloth.
STEP 1: Gently insert Shelf Supports (A) into pre-drilled holes inside Cabinet (E). Fit Shelf (D) into
Cabinet and lay upon supports.
NOTE: Cabinet is equipped with Rotary Levelers located under each Leg. Gently lift Cabinet and
turn Levelers clockwise/counterclockwise until level. If doors are not aligned, adjust Levelers.
(A)
(E)
(D)

Page 4 of 4
Customer Service: 800-367-2810
Online: www.ballarddesigns.com
Ltr.
A2 Small Screw
Retention Belt
Qty. Hardware Included
WALL ANCHORING INSTALLATION:
B2 Large Screw
C4 Bracket
D2
NOTE: Assemble the Bookshelf in desired location for use.
1. Locate and mark a Wall Stud behind Demilune at location for installation.
2. Corresponding to Stud location, attach one Bracket (C) to back of Demilune using Small Screw (B).
3. To keep hardware out of view after installation, attach remaining Bracket (C) INTO WALL STUD
with Large Screw (A) 2 inches below Bracket attached to back of Demilune.
4. Move Demilune into place, align Brackets then connect both using Retention Belt (D).
5. Confirm Belt is securely laced and locked.
Wall Stud
Serious or fatal crushing injuries can occur from a furniture tip-over
WARNING
Tip-Over Hazard
WALL BRACKET MUST BE ATTACHED TO WALL STUD
Prevent tipping accidents. Anchor your furniture.
