IndraControl VEP30.2 40.2 and 50.2 System Presentation 1-1
DOK-SUPPL*-VEP**.2****-PR01-EN-P
1 System Presentation
1.1 Brief Description IndraControl VEP 30.2, VEP 40.2 and
VEP 50.2
The embedded terminals IndraControl VEP 30.2, VEP 40.2 and VEP 50.2
are PC-based machine operator terminals. Depending on the respective
application or configuration they can also perform control functionalities.
Depending on its type the IndraControl VEP devices are provided with up
to two PC104 slots for plug-in cards. All VEP devices are suitable for the
food industry.
Note: This documentation describes the embedded terminals
IndraControl VEP 30.2, VEP 40.2 and VEP 50.2. In this
documentation they are all called IndraControl VEP.
Information about the models IndraControl VEP 30.1,
VEP 40.1, VEP 50.1 and VEH 30.1 you will find in
documentation "Rexroth IndraControl VEP / VEH", DOK-
SUPPL*-VEH/VEP****-PR02-DE-P.
IndraControl VEP**.2
The embedded terminals IndraControl VEP are provided as different
variants. Principally, they differ in their display seize.
VEP 30.2CC VEP 30.2CG
Display 8.4" TFT
Touch screen Yes
Keys No Yes
Fig. 1-1: IndraControl VEP 30.2 –Front panel
VEP 40.2CE
Display 12.1" TFT
Touch screen Yes
Keys No
Fig. 1-2: IndraControl VEP 40.2 –Front panel
VEP 50.2CH
Display 15" TFT
Touch screen Yes
Keys No
Fig. 1-3: IndraControl VEP 50.2 –Front panel
All IndraControl VEP devices are equipped with an identical PC-Box.

1-2 System Presentation IndraControl VEP30.2 40.2 and 50.2
DOK-SUPPL*-VEP**.2****-PR01-EN-P
PC box
PC104 slots 2
Depending on the device type one or two
slots are equipped.
The VEP 30.2CG has only one slot.
Power supply 24 V DC
Short-time UPS Integrated charging circuit and buffer
capacitor board
Fig. 1-4: PC box of the VEP devices
Embedded Terminals with Keypad
The keypad consists of a chemical resistant polyester foil with embossed
keys.
Embedded Terminals with Touch Screen
The front panel with touch screen allows to operate the application
software via the touch-sensitive surface of the display without keyboard
and mouse.
Front Panel of the IndraControl VEP 30.2
VEP 30.2CC with Touch Screen
VEP_30_Front.FH9
Fig. 1-5: VEP 30.2CC –Front panel

IndraControl VEP30.2 40.2 and 50.2 System Presentation 1-3
DOK-SUPPL*-VEP**.2****-PR01-EN-P
VEP30.2CG with Touch Screen and 5 Keys
Fig. 1-6: VEP30.2CG –Front panel

1-4 System Presentation IndraControl VEP30.2 40.2 and 50.2
DOK-SUPPL*-VEP**.2****-PR01-EN-P
Front Panel of the IndraControl VEP 40.2
VEP 40.2CE with Touch Screen
VEP_40_Front.FH9
Fig. 1-7: VEP 40.2CE –Front panel
