Bosch Rexroth Indramat BTV30.2 Technical manual

Project Planning Manual
DOK-MTC200-BTV30.2****-PR02-EN-P
SYSTEM200
BTV30.2

About this Documentation BTV30.2
DOK-MTC200-BTV30.2****-PR02-EN-P
BTV30.2
Project Planning Manual
DOK-MTC200-BTV30.2****-PR02-EN-P
Document Number, 120-1700-B320-02/EN
This documentation describes …
•the hardware functions of the BTV30.2
•the connection and mounting
•the technical datas
Description Release
Date
Notes
109-1041-4134-01/EN 03.99 First issue
120-1700-B320-02/EN 11.01 Revision
2001 Rexroth Indramat GmbH
Copying this document, giving it to others and the use or communication
of the contents thereof without express authority, are forbidden. Offenders
are liable for the payment of damages. All rights are reserved in the event
of the grant of a patent or the registration of a utility model or design
(DIN 34-1).
The specified data is for product description purposes only and may not
be deemed to be guaranteed unless expressly confirmed in the contract.
All rights are reserved with respect to the content of this documentation
and the availability of the product.
Rexroth Indramat GmbH
Bgm.-Dr.-Nebel-Str. 2 •D-97816 Lohr a. Main
Telephone [phone] •Tx 68 94 21 •Fax [phone]
http://www.boschrexroth.de/
Dept. BRC/EP7 (CV/NH)
This document has been printed on chlorine-free bleached paper.
Title
Type of Documentation
Document Typecode
Internal File Reference
Purpose of Documentation
Record of Revisions
Copyright
Validity
Published by
Note

BTV30.2 Contents I
DOK-MTC200-BTV30.2****-PR02-EN-P
Contents
1 System Presentation 1-1
1.1 Brief Description............................................................................................................................. 1-1
1.2 Peculiarities.................................................................................................................................... 1-1
1.3 Standard Configuration .................................................................................................................. 1-2
1.4 Additional Modules......................................................................................................................... 1-2
1.5 Operating System .......................................................................................................................... 1-2
2 Important directions for use 2-1
2.1 Appropriate use.............................................................................................................................. 2-1
Introduction .............................................................................................................................. 2-1
Areas of use and application....................................................................................................2-2
2.2 Inappropriate use ........................................................................................................................... 2-2
3 Safety Instructions for Electric Drives and Controls 3-1
3.1 Introduction..................................................................................................................................... 3-1
3.2 Explanations................................................................................................................................... 3-1
3.3 Hazards by Improper Use .............................................................................................................. 3-2
3.4 General Information ....................................................................................................................... 3-3
3.5 Protection Against Contact with Electrical Parts............................................................................ 3-5
3.6 Protection Against Electric Shock by Protective Low Voltage (PELV)........................................... 3-6
3.7 Protection Against Dangerous Movements.................................................................................... 3-7
3.8 Protection Against Magnetic and Electromagnetic Fields During Operation and Mounting .......... 3-9
3.9 Protection Against Contact with Hot Parts ................................................................................... 3-10
3.10 Protection During Handling and Mounting ................................................................................... 3-10
3.11 Battery Safety............................................................................................................................... 3-11
3.12 Protection Against Pressurized Systems..................................................................................... 3-11
4 Technical Data 4-1
4.1 General Technical Data ................................................................................................................. 4-1
4.2 Specification of the Power Supply Unit.......................................................................................... 4-2
4.3 Ambient Conditions ........................................................................................................................ 4-2
4.4 Parts Subject to Wear .................................................................................................................... 4-3
5 Dimensions 5-1
5.1 Housing Dimensions ...................................................................................................................... 5-1
5.2 Mounting Dimensions..................................................................................................................... 5-3

II Contents BTV30.2
DOK-MTC200-BTV30.2****-PR02-EN-P
6 Front Panel, Keyboard 6-1
6.1 Floppy Disk Flap ............................................................................................................................ 6-1
6.2 Status Indicators ............................................................................................................................ 6-2
6.3 Keyboard........................................................................................................................................ 6-2
Explanation and Emulation of the Special Keys ...................................................................... 6-3
Keyboard Mouse...................................................................................................................... 6-4
6.4 Machine Function Keys.................................................................................................................. 6-5
Addressing ............................................................................................................................... 6-5
7 Connection Pin Assignment 7-1
7.1 General Connections ..................................................................................................................... 7-1
7.2 Interfaces of the BTV30.2 .............................................................................................................. 7-2
Interfaces of the Slot CPU ....................................................................................................... 7-2
LPT1-Printer Port and SIS .......................................................................................................7-4
7.3 Realisation of the BTV30 PC version............................................................................................. 7-5
Connector pin assignments ..................................................................................................... 7-5
8 Application Example 8-1
8.1 Networking Example for RS485 Communication........................................................................... 8-1
8.2 Application Example for INTERBUS Connection........................................................................... 8-2
8.3 Application Example for SERCOS Interface.................................................................................. 8-3
9 SLOT-CPU Card 9-1
9.1 Performance Characteristics.......................................................................................................... 9-1
9.2 Technical Data ............................................................................................................................... 9-2
Electrical Specification ............................................................................................................. 9-2
CPU and Memory Specification............................................................................................... 9-2
Onboard Video Controller ........................................................................................................9-2
General Specifications ............................................................................................................. 9-3
9.3 AMIBIOS Setup.............................................................................................................................. 9-4
AMIBIOS Setup Main Menu..................................................................................................... 9-5
Setup Types............................................................................................................................. 9-6
Security .................................................................................................................................. 9-11
Default.................................................................................................................................... 9-12
AMIBIOS Power-On Self Test ............................................................................................... 9-13
INSIDE Interrupts................................................................................................................... 9-13
9.4 Installation of the Memory Module ............................................................................................... 9-14
10 Ordering Information 10-1
10.1 Type Code.................................................................................................................................... 10-1
10.2 Configuration Type Codes ........................................................................................................... 10-2
BTV30.2C............................................................................................................................... 10-2
BTV30.2S............................................................................................................................... 10-3
BTV30.2E............................................................................................................................... 10-4
BTV30.2P............................................................................................................................... 10-5
BTV30.2T ............................................................................................................................... 10-5

BTV30.2 Contents III
DOK-MTC200-BTV30.2****-PR02-EN-P
11 Accessories 11-1
11.1 Connectors and Standard Cables................................................................................................ 11-1
Standard Interface Connectors.............................................................................................. 11-2
11.2 Ethernet Card PCM-E01.1 ........................................................................................................... 11-3
Technical Data ....................................................................................................................... 11-4
Elements on the Slot Sheet ...................................................................................................11-5
Installation.............................................................................................................................. 11-7
12 Included Equipment 12-1
13 List of Figures 13-1
14 Index 14-1
15 Service & Support 15-1
15.1 Helpdesk ...................................................................................................................................... 15-1
15.2 Service-Hotline............................................................................................................................. 15-1
15.3 Internet ......................................................................................................................................... 15-1
15.4 Vor der Kontaktaufnahme... - Before contacting us..................................................................... 15-1
15.5 Kundenbetreuungsstellen - Sales & Service Facilities ................................................................ 15-2

IV Contents BTV30.2
DOK-MTC200-BTV30.2****-PR02-EN-P

BTV30.2 System Presentation 1-1
DOK-MTC200-BTV30.2****-PR02-EN-P
1 System Presentation
1.1 Brief Description
The BTV30 unit is a PC-based machine control panel into which one or
more NC controllers with PLC or one or more stand-alone PLC can be
integrated. The number of modules that can be integrated depends on
their configuration. Currently, there are 9 slots available.
PWR HDD
SYSTEM200 BTV30
R1
R2
R3
R4
R5
R6
R7
R8
QWE R T Y U O P
ASDFGHJKL
ZXCVBN
\
CTRL ALT ALT CTRL
DEL
INSERT
END
HOME
I
F1 F2 F3 F4 F5 F6 F7 F8 F9 F10
PAGE
UP
'
"
,
<
M
;
:
TAB
`
~
1
!
2
@
3
#
4
$
5
%
6
^
7
&
8
*
9
(
0
)
=
+
-
_
[
{
]
}
.
>
/
?
PAGE
DOWN
ESC
P 0 … P n
|
U1 U2
U3 U4 U5
3.5" floppy disk drive
R1-R8 machine
function keys
ASCII keyboard
connector for
external keyboard
status indicator
Cursor block, keyboard mouse
special Windows keys
PC function keys
BTV30_2_Frontplatte.fh7
Fig. 1-1: BTV30.2 front panel
1.2 Peculiarities
The BTV30.2 unit possesses the functionality and the control elements of
a complete industry PC.
Besides the 10.4-in flat color display and a full ASCII keyboard (MFII
compatible) with cursor block, keyboard mouse, and special Windows
keys, there are a standard floppy disk drive and a connector for an
external keyboard behind a lockable flap.
In addition to the 10 PC function keys beneath the display, there are 8
machine function keys to the right of the display which are either
connected to an external female connector or - if there is an integrated
SPS module - directly to the SPS.
The sturdy front panel, which is made from PC/ABS, contains real key
elements that permit non-fatiguing work, even during extended
programming sessions.

1-2 System Presentation BTV30.2
DOK-MTC200-BTV30.2****-PR02-EN-P
The display is protected by a pane of glass that complies with the EMC
requirements.
The BTV30.2 unit is suitable for surface mounting and for base
installation. Together with the optically and dimensionally compatible
BTM15 and BTM16 machine control panels, you can set up a modern and
attractive control panel in a flat or raised form.
1.3 Standard Configuration
•SLOT-CPU min. 300 MHz with integrated graphic controller,
4 MB video memory
•64 or 128 MB work memory
•min. 3 GB hard disk
•3,5" disk drive
•10,4" TFT color display
•Power supply 115 - 230 VAC
•1x serial Interface RS232
•1x RS232, RS485, RS422 to Indramat standard (SIS)
•1x parallel interface (LPT1)
1.4 Additional Modules
The following additional modules are currently available:
•PLC module with BT-Bus
•CNC module with SERCOS fiber optics interface
•10 / 100 MBit Ethernet-Card PCM-E01.1
The configuration type code gives you all the currently available
configurations (see page 10-2).
1.5 Operating System
•For license reasons, the BTV30.2 unit is only delivered with an
installed operating system. As operating system WindowsNT 4.0 is
available
•In addition to the operating system, the user interface of an MTC200
CNC controller or an ISP200 PLC controller can also be pre-installed.

BTV30.2 Important directions for use 2-1
DOK-MTC200-BTV30.2****-PR02-EN-P
2 Important directions for use
2.1 Appropriate use
Introduction
Rexroth Indramat products represent state-of-the-art developments and
manufacturing. They are tested prior to delivery to ensure operating safety
and reliability.
The products may only be used in the manner that is defined as
appropriate. If they are used in an inappropriate manner, then situations
can develop that may lead to property damage or injury to personnel.
Note: Rexroth Indramat, as manufacturer, is not liable for any
damages resulting from inappropriate use. In such cases, the
guarantee and the right to payment of damages resulting from
inappropriate use are forfeited. The user alone carries all
responsibility of the risks.
Before using Rexroth Indramat products, make sure that all the pre-
requisites for appropriate use of the products are satisfied:
•Personnel that in any way, shape or form uses our products must first
read and understand the relevant safety instructions and be familiar
with appropriate use.
•If the product takes the form of hardware, then they must remain in
their original state, in other words, no structural changes are permitted.
It is not permitted to decompile software products or alter source
codes.
•Do not mount damaged or faulty products or use them in operation.
•Make sure that the products have been installed in the manner
described in the relevant documentation.

2-2 Important directions for use BTV30.2
DOK-MTC200-BTV30.2****-PR02-EN-P
Areas of use and application
The BTV30.2 is a PC-based user and visualization terminal into which
one or several NC controls with PLC or one or more stand-alone PLCs
can be mounted. The BTV30.2 terminal made by Rexroth Indramat is
designed for use in the following cases:
•as a user, visualization and programming terminal with integral control
hardware in a stand-alone machine,
•as a user, visualization and programming terminal for connected
RECO controls,
Note: The BTV30.2 may only be used with the accessories and parts
specified in this document. If a component has not been
specifically named, then it may not be either mounted or
connected. The same applies to cables and lines.
Operation is only permitted in the specified configurations and
combinations of components using the software and firmware
as specified in the relevant function descriptions.
The machine user and visualization terminal is designed for control tasks
in an installation with multiple axes.
Available for an application-specific use of the terminals are unit types
with differing drive power and different interfaces.
Typical areas of application of a BTV30.2 are:
•Lathes
•Milling machines
•Machining centers.
The BTV30.2 may only be operated under the assembly, installation and
ambient conditions as described here (temperature, system of protection,
humidity, EMC requirements, etc.) and in the position specified.
2.2 Inappropriate use
Using the BTV30 unit outside of the above-referenced areas of
application or under operating conditions other than described in the
document and the technical data specified is defined as “inappropriate
use".
The terminals may not be used if
•they are subject to operating conditions that do not meet the above
specified ambient conditions. This includes, for example, operation
under water, in the case of extreme temperature fluctuations or
extreme maximum temperatures or if
•Rexroth Indramat has not specifically released them for that intended
purpose. Please note the specifications outlined in the general Safety
Instructions!

BTV30.2 Safety Instructions for Electric Drives and Controls 3-1
DOK-MTC200-BTV30.2****-PR02-EN-P
3 Safety Instructions for Electric Drives and Controls
3.1 Introduction
Read these instructions before the initial startup of the equipment in order
to eliminate the risk of bodily harm or material damage. Follow these
safety instructions at all times.
Do not attempt to install or start up this equipment without first reading all
documentation provided with the product. Read and understand these
safety instructions and all user documentation of the equipment prior to
working with the equipment at any time. If you do not have the user
documentation for your equipment, contact your local Rexroth Indramat
representative to send this documentation immediately to the person or
persons responsible for the safe operation of this equipment.
If the equipment is resold, rented or transferred or passed on to others,
then these safety instructions must be delivered with the equipment.
WARNING
Improper use of this equipment, failure to follow
the safety instructions in this document or
tampering with the product, including disabling
of safety devices, may result in material
damage, bodily harm, electric shock or even
death!
3.2 Explanations
The safety instructions describe the following degrees of hazard
seriousness in compliance with ANSI Z535. The degree of hazard
seriousness informs about the consequences resulting from non-
compliance with the safety instructions.
Warning symbol with signal
word
Degree of hazard seriousness according
to ANSI
DANGER
Death or severe bodily harm will occur.
WARNING
Death or severe bodily harm may occur.
CAUTION
Bodily harm or material damage may occur.
Fig. 3-1: Hazard classification (according to ANSI Z535)

3-2 Safety Instructions for Electric Drives and Controls BTV30.2
DOK-MTC200-BTV30.2****-PR02-EN-P
3.3 Hazards by Improper Use
DANGER
High voltage and high discharge current!
Danger to life or severe bodily harm by electric
shock!
DANGER
Dangerous movements! Danger to life, severe
bodily harm or material damage by
unintentional motor movements!
WARNING
High electrical voltage due to wrong
connections! Danger to life or bodily harm by
electric shock!
WARNING
Health hazard for persons with heart
pacemakers, metal implants and hearing aids in
proximity to electrical equipment!
CAUTION
Surface of machine housing could be extremely
hot! Danger of injury! Danger of burns!
CAUTION
Risk of injury due to improper handling! Bodily
harm caused by crushing, shearing, cutting and
mechanical shock or incorrect handling of
pressurized systems!
CAUTION
Risk of injury due to incorrect handling of
batteries!

BTV30.2 Safety Instructions for Electric Drives and Controls 3-3
DOK-MTC200-BTV30.2****-PR02-EN-P
3.4 General Information
•Rexroth Indramat GmbH is not liable for damages resulting from
failure to observe the warnings provided in this documentation.
•Read the operating, maintenance and safety instructions in your
language before starting up the machine. If you find that you cannot
completely understand the documentation for your product, please ask
your supplier to clarify.
•Proper and correct transport, storage, assembly and installation as
well as care in operation and maintenance are prerequisites for
optimal and safe operation of this equipment.
•Only persons who are trained and qualified for the use and operation
of the equipment may work on this equipment or within its proximity.
•The persons are qualified if they have sufficient knowledge of the
assembly, installation and operation of the equipment as well as an
understanding of all warnings and precautionary measures noted in
these instructions.
•Furthermore, they must be trained, instructed and qualified to
switch electrical circuits and equipment on and off in accordance with
technical safety regulations, to ground them and to mark them
according to the requirements of safe work practices. They must have
adequate safety equipment and be trained in first aid.
•Only use spare parts and accessories approved by the manufacturer.
•Follow all safety regulations and requirements for the specific
application as practiced in the country of use.
•The equipment is designed for installation in industrial machinery.
•The ambient conditions given in the product documentation must be
observed.
•Use only safety features and applications that are clearly and explicitly
approved in the Project Planning Manual.
For example, the following areas of use are not permitted: construction
cranes, elevators used for people or freight, devices and vehicles to
transport people, medical applications, refinery plants, transport of
hazardous goods, nuclear applications, applications sensitive to high
frequency, mining, food processing, control of protection equipment
(also in a machine).
•The information given in the documentation of the product with regard
to the use of the delivered components contains only examples of
applications and suggestions.
The machine and installation manufacturer must
•make sure that the delivered components are suited for his
individual application and check the information given in this
documentation with regard to the use of the components,
•make sure that his application complies with the applicable safety
regulations and standards and carry out the required measures,
modifications and complements.
•Startup of the delivered components is only permitted once it is sure
that the machine or installation in which they are installed complies
with the national regulations, safety specifications and standards of the
application.

3-4 Safety Instructions for Electric Drives and Controls BTV30.2
DOK-MTC200-BTV30.2****-PR02-EN-P
•Operation is only permitted if the national EMC regulations for the
application are met.
The instructions for installation in accordance with EMC requirements
can be found in the documentation "EMC in Drive and Control
Systems".
The machine or installation manufacturer is responsible for
compliance with the limiting values as prescribed in the national
regulations.
•Technical data, connections and operational conditions are specified in
the product documentation and must be followed at all times.

BTV30.2 Safety Instructions for Electric Drives and Controls 3-5
DOK-MTC200-BTV30.2****-PR02-EN-P
3.5 Protection Against Contact with Electrical Parts
Note: This section refers to equipment and drive components with
voltages above 50 Volts.
Touching live parts with voltages of 50 Volts and more with bare hands or
conductive tools or touching ungrounded housings can be dangerous and
cause electric shock. In order to operate electrical equipment, certain
parts must unavoidably have dangerous voltages applied to them.
DANGER
High electrical voltage! Danger to life, severe
bodily harm by electric shock!
⇒Only those trained and qualified to work with or on
electrical equipment are permitted to operate, maintain
or repair this equipment.
⇒Follow general construction and safety regulations when
working on high voltage installations.
⇒Before switching on power the ground wire must be
permanently connected to all electrical units according
to the connection diagram.
⇒Do not operate electrical equipment at any time, even
for brief measurements or tests, if the ground wire is not
permanently connected to the points of the components
provided for this purpose.
⇒Before working with electrical parts with voltage higher
than 50 V, the equipment must be disconnected from
the mains voltage or power supply. Make sure the
equipment cannot be switched on again unintended.
⇒The following should be observed with electrical drive
and filter components:
⇒Wait five (5) minutes after switching off power to allow
capacitors to discharge before beginning to work.
Measure the voltage on the capacitors before beginning
to work to make sure that the equipment is safe to
touch.
⇒Never touch the electrical connection points of a
component while power is turned on.
⇒Install the covers and guards provided with the
equipment properly before switching the equipment on.
Prevent contact with live parts at any time.
⇒A residual-current-operated protective device (RCD)
must not be used on electric drives! Indirect contact
must be prevented by other means, for example, by an
overcurrent protective device.
⇒Electrical components with exposed live parts and
uncovered high voltage terminals must be installed in a
protective housing, for example, in a control cabinet.

3-6 Safety Instructions for Electric Drives and Controls BTV30.2
DOK-MTC200-BTV30.2****-PR02-EN-P
To be observed with electrical drive and filter components:
DANGER
High electrical voltage on the housing!
High leakage current! Danger to life, danger of
injury by electric shock!
⇒Connect the electrical equipment, the housings of all
electrical units and motors permanently with the safety
conductor at the ground points before power is
switched on. Look at the connection diagram. This is
even necessary for brief tests.
⇒Connect the safety conductor of the electrical
equipment always permanently and firmly to the
supply mains. Leakage current exceeds 3.5 mA in
normal operation.
⇒Use a copper conductor with at least 10 mm²cross
section over its entire course for this safety conductor
connection!
⇒Prior to startups, even for brief tests, always connect
the protective conductor or connect with ground wire.
Otherwise, high voltages can occur on the housing
that lead to electric shock.
3.6 Protection Against Electric Shock by Protective Low
Voltage (PELV)
All connections and terminals with voltages between 0 and 50 Volts on
Rexroth Indramat products are protective low voltages designed in
accordance with international standards on electrical safety.
WARNING
High electrical voltage due to wrong
connections! Danger to life, bodily harm by
electric shock!
⇒Only connect equipment, electrical components and
cables of the protective low voltage type (PELV =
Protective Extra Low Voltage) to all terminals and
clamps with voltages of 0 to 50 Volts.
⇒Only electrical circuits may be connected which are
safely isolated against high voltage circuits. Safe
isolation is achieved, for example, with an isolating
transformer, an opto-electronic coupler or when
battery-operated.

BTV30.2 Safety Instructions for Electric Drives and Controls 3-7
DOK-MTC200-BTV30.2****-PR02-EN-P
3.7 Protection Against Dangerous Movements
Dangerous movements can be caused by faulty control of the connected
motors. Some common examples are:
•improper or wrong wiring of cable connections
•incorrect operation of the equipment components
•wrong input of parameters before operation
•malfunction of sensors, encoders and monitoring devices
•defective components
•software or firmware errors
Dangerous movements can occur immediately after equipment is
switched on or even after an unspecified time of trouble-free operation.
The monitoring in the drive components will normally be sufficient to avoid
faulty operation in the connected drives. Regarding personal safety,
especially the danger of bodily injury and material damage, this alone
cannot be relied upon to ensure complete safety. Until the integrated
monitoring functions become effective, it must be assumed in any case
that faulty drive movements will occur. The extent of faulty drive
movements depends upon the type of control and the state of operation.

3-8 Safety Instructions for Electric Drives and Controls BTV30.2
DOK-MTC200-BTV30.2****-PR02-EN-P
DANGER
Dangerous movements! Danger to life, risk of
injury, severe bodily harm or material damage!
⇒Ensure personal safety by means of qualified and
tested higher-level monitoring devices or measures
integrated in the installation. Unintended machine
motion is possible if monitoring devices are disabled,
bypassed or not activated.
⇒Pay attention to unintended machine motion or other
malfunction in any mode of operation.
⇒Keep free and clear of the machine’s range of motion
and moving parts. Possible measures to prevent
people from accidentally entering the machine’s range
of motion:
- use safety fences
- use safety guards
- use protective coverings
- install light curtains or light barriers
⇒Fences and coverings must be strong enough to
resist maximum possible momentum, especially if
there is a possibility of loose parts flying off.
⇒Mount the emergency stop switch in the immediate
reach of the operator. Verify that the emergency stop
works before startup. Don’t operate the machine if the
emergency stop is not working.
⇒Isolate the drive power connection by means of an
emergency stop circuit or use a starting lockout to
prevent unintentional start.
⇒Make sure that the drives are brought to a safe
standstill before accessing or entering the danger
zone. Safe standstill can be achieved by switching off
the power supply contactor or by safe mechanical
locking of moving parts.
⇒Secure vertical axes against falling or dropping after
switching off the motor power by, for example:
- mechanically securing the vertical axes
- adding an external braking/ arrester/ clamping
mechanism
- ensuring sufficient equilibration of the vertical axes
The standard equipment motor brake or an external
brake controlled directly by the drive controller are
not sufficient to guarantee personal safety!

BTV30.2 Safety Instructions for Electric Drives and Controls 3-9
DOK-MTC200-BTV30.2****-PR02-EN-P
⇒Disconnect electrical power to the equipment using a
master switch and secure the switch against
reconnection for:
- maintenance and repair work
- cleaning of equipment
- long periods of discontinued equipment use
⇒Prevent the operation of high-frequency, remote
control and radio equipment near electronics circuits
and supply leads. If the use of such equipment cannot
be avoided, verify the system and the installation for
possible malfunctions in all possible positions of
normal use before initial startup. If necessary, perform
a special electromagnetic compatibility (EMC) test on
the installation.
3.8 Protection Against Magnetic and Electromagnetic Fields
During Operation and Mounting
Magnetic and electromagnetic fields generated near current-carrying
conductors and permanent magnets in motors represent a serious health
hazard to persons with heart pacemakers, metal implants and hearing
aids.
WARNING
Health hazard for persons with heart
pacemakers, metal implants and hearing aids in
proximity to electrical equipment!
⇒Persons with heart pacemakers, hearing aids and
metal implants are not permitted to enter the following
areas:
- Areas in which electrical equipment and parts are
mounted, being operated or started up.
- Areas in which parts of motors with permanent
magnets are being stored, operated, repaired or
mounted.
⇒If it is necessary for a person with a heart pacemaker
to enter such an area, then a doctor must be
consulted prior to doing so. Heart pacemakers that
are already implanted or will be implanted in the
future, have a considerable variation in their electrical
noise immunity. Therefore there are no rules with
general validity.
⇒Persons with hearing aids, metal implants or metal
pieces must consult a doctor before they enter the
areas described above. Otherwise, health hazards will
occur.

3-10 Safety Instructions for Electric Drives and Controls BTV30.2
DOK-MTC200-BTV30.2****-PR02-EN-P
3.9 Protection Against Contact with Hot Parts
CAUTION
Housing surfaces could be extremely hot!
Danger of injury! Danger of burns!
⇒Do not touch housing surfaces near sources of heat!
Danger of burns!
⇒After switching the equipment off, wait at least ten (10)
minutes to allow it to cool down before touching it.
⇒Do not touch hot parts of the equipment, such as
housings with integrated heat sinks and resistors.
Danger of burns!
3.10 Protection During Handling and Mounting
Under certain conditions, incorrect handling and mounting of parts and
components may cause injuries.
CAUTION
Risk of injury by incorrect handling! Bodily
harm caused by crushing, shearing, cutting and
mechanical shock!
⇒Observe general installation and safety instructions
with regard to handling and mounting.
⇒Use appropriate mounting and transport equipment.
⇒Take precautions to avoid pinching and crushing.
⇒Use only appropriate tools. If specified by the product
documentation, special tools must be used.
⇒Use lifting devices and tools correctly and safely.
⇒For safe protection wear appropriate protective
clothing, e.g. safety glasses, safety shoes and safety
gloves.
⇒Never stand under suspended loads.
⇒Clean up liquids from the floor immediately to prevent
slipping.
