Bradley 400 Series User manual

P.O. Box 309, Menomonee Falls, WI USA 53052-0309
PHONE 800.BRADLEY (800.272.3539) FAX [phone]
bradleycorp.com
Installation
HDWL-INSTR-001 Rev. D; ECN 12-14-004J
© 2012 Bradley
Page 1 of 16 12/13/2012
Plastic Laminate Restroom Partitions
Floor-Mounted with Overhead Brace
Series 400
Table of Contents
Pre-Installation Information ....................2
Layout Dimensions for Brackets ................3
Mounting Brackets to Wall .....................4
Leveling Bolts to Pilaster ......................5
Mounting Brackets to Pilasters ...............5–6
Pilaster Shoes ..............................6
Panels and Pilasters .......................7–8
Headrail ...................................9
Hinges ................................10–12
Latch and Strike/Keeper ..................13–14
Urinal Screens ..........................15–16
IMPORTANT
Read this installation manual completely to ensure proper installation, then file it with the owner
or maintenance department. This installation manual provides instruction for the assembly of
normal partition configurations and standard components. Non-standard configurations or
components including but not limited to curved or angled walls, partial walls, oversized panels,
or modified hardware are not covered in this manual. Compliance and conformity to local codes
and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding
packaging material. If any parts are missing, do not begin installation until you obtain the missing
parts. To prevent warping, always lay the material flat. Do not lean the material against the wall or
stack unevenly.
Before beginning installation, make sure that the wall and floor backing are adequate to support
the secure mounting of the toilet compartment units.
To minimize break-out, always use a support block when drilling through plastic laminate material.
Use caution when drilling. Accuracy is important!
Product warranties and parts information may be found on Bradley's web site at bradleycorp.com.
Installation
THIS
SIDE
UP
Packing List
•
•
•
•
*HDWL-INSTR-001*
For Standard Height
Doors and Panels Only

2
Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400 Installation
12/13/2012 Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J
Supplies Required:
Hardware Provided
#14-16 Plastic
Anchor
FAST-T373
#14 x 2" Button-Head Sheet
Metal Screw Torx-T27 Drive
FAST-P002
(Stainless)
#10 x ⁵⁄₈"
Button-Head
Sheet Metal Screw
Torx-T27 Drive
FAST-Z0019
Example of Submittal Drawing
• Chalk line and pencil
• Tape measure and 4' level
• Jigsaw (or hacksaw) and circular saw
• Two spring clamps
• ¹⁄₈", ⁵⁄₃₂", ⁷⁄₃₂", ¼" and ²⁵⁄₆₄" drill bits
• Power drill or screw gun with drill bit extension
• ⁵⁄₁₆" ceramic tile and masonry drill bit
• Hammer drill
• Spacer, 12" (305mm) high and strong enough to
support weight of panel
#14 x ⁵⁄₈"
Button-Head
Sheet Metal Screw
Torx-T27 Drive
FAST-Z0016
#10 x 1"
Button-Head
Sheet Metal Screw
Torx-T27 Drive
FAST-Z0028
¼"- 14 x ⁵⁄₈"
Sheet Metal Screw
Torx-T27 Drive
FAST-S355A
#10 x ¾"
Flat-Head
Sheet Metal Screw
Torx-T25 Drive
FAST-Z0006
⁵⁄₁₆"- 18 x ³⁄₈"
Tee Nut
FAST-Z0037
#14 x 2" Button-Head Sheet
Metal Screw Torx-T27 Drive
FAST-Z002
(Chrome Plated)
#10-24 x ¾"
Button-Head
Barrel Nut
Torx-T27 Drive
FAST-Z003
(Chrome Plated)
#10-24 x ¾"
Button-Head
Barrel Nut
Torx-T27 Drive
FAST-P003
(Stainless)
#10-24 x ½"
Button-Head
Shoulder Screw
Torx-T27 Drive
FAST-S0018
#10-24 x ¾"
Button-Head
Shoulder Screw
Torx-T27 Drive
FAST-Z004
(Chrome Plated)
#10-24 x ¾"
Button-Head
Shoulder Screw
Torx-T27 Drive
FAST-P004
(Stainless)
#10-24 x 1"
Button-Head
Shoulder Screw
Torx-T27 Drive
FAST-Z004A
(Chrome Plated)
#10-24 x 1"
Button-Head
Shoulder Screw
Torx-T27 Drive
FAST-P004A
(Stainless)
#10-24 x 2"
Flat-Head
Machine Screw
Torx-T25 Drive
FAST-Z0027
⁵⁄₁₆"- 18 x 3"
Leveling Bolt
FAST-S0039
Washer Flat
⁹⁄₃₂" x ⁵⁄₈"
P10-449
#10-24 x ½"
Button-Head
Shoulder Screw
Torz-T27 Drive
FAST-Z0003
61¼"
(1556mm)
to face
60½"
(1537mm)
wall to
centerline
36"
(914mm)
center to
center
36"
(914mm)
24"
(610mm)
24"
(610mm)
10"
(254mm)
3" (76mm)
1" (25mm) gap
1"
(25mm)
gap
½"
(13mm)
gap
3"
3½"
1½"
20½"
8½"
58½"
(1486mm)
58½"
(1486mm)
HR062
HR120

3
Installation Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400
Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J 12/13/2012
*
*
*
*
*
*
C
L
C
L
C
L
C
L
C
L
C
L
Pilaster plumb line
When installing the partition components, consult
the applicable Mills Partition submittal drawing
for compartment layout dimensions.
1Layout Dimensions - Stirrup Brackets (Standard)
Pilaster centerline: Measure from
the back wall forward to the face of the
compartment, subtract ⁵⁄₈" (16mm) and mark
this location on the floor (“A”). Mark the
same measurement on the opposite end of
your layout (“A1”) and draw a straight line
connecting both marks.
FOR FREESTANDING (FS) PARTITIONS:
Refer to submittal drawings and determine
the approximate location of the outside
panels. Establish dimensions “A” and “A1”
as explained above.
A
Panel centerline: Measure the stall width across the
back wall and place a mark at the base of the rear wall
(“B”). Repeat this step for each panel, starting each
measurement from the last panel centerline (“B1”).
B
Stirrup brackets: Draw a plumb line on all walls
from each pilaster and panel centerline. From the
highest point in the room, measure 18" (457mm)
and 64" (1626mm) from the floor and place a
mark on the pilaster/panel plumb line. These
marks represent the hole center line of the stirrup
brackets. Use a level to transfer that mark to all
other plumb lines (“C”).
C
Panel
plumb line
C
L
C
L
C
L
C
L
*
*
*
Pilaster plumb line
When installing the partition components,
consult the applicable Mills Partition submittal
drawing for compartment layout dimensions.
1a Layout Dimensions - Continuous Brackets (Optional)
Pilaster centerline: Measure from
the back wall forward to the face of the
compartment, subtract ⁵⁄₈" (16mm) and
mark this location on the floor (“A”).
Mark the same measurement on the
opposite end of your layout (“A1”) and
draw a straight line connecting both
marks.
FOR FREESTANDING (FS)
PARTITIONS: Refer to submittal
drawings and determine the
approximate location of the outside
panels. Establish dimensions “A” and
“A1” as explained above.
A
Panel centerline: Measure the stall width across the
back wall and place a mark at the base of the rear wall
(“B”). Repeat this step for each panel, starting each
measurement from the last panel centerline (“B1”).
B
Continuous brackets:Draw a plumb line on all walls from each
pilaster and panel centerline. From the highest point in the room,
measure 12½" (318mm) (for stainless steel) or 12¼" (311mm)
(for aluminum) from the floor and place a mark on the pilaster/
panel plumb line. Use a level to transfer that mark to all other
plumb lines (“C”).
C
Panel
plumb line
64"
(1626mm)
18"
(457mm)
"C"
"C"
"C"
"C"
"C"
"C"
"C"
"C"
"B"
"B"
"B1"
"B1"
"A1"
"A1"
"A"
"A"
"C"

4
Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400 Installation
12/13/2012 Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J
2Stirrup Brackets to Wall (Standard)
established level line
pilaster/panel plumb line
floor
C
LPlace the center of each stirrup
bracket at the established level
line. Center the bracket opening
on the pilaster/panel plumb line.
A
Insert the plastic anchors
in all holes and secure the
brackets to the wall with the
#14 x 2" (chrome plated)
screws provided.
C
On end panel and pilaster applications, position the bracket
with the ear facing toward the inside of the stall.
Using the bracket as a
template, mark the hole
locations on the wall. Remove
the bracket and drill a Ø ⁵⁄₁₆"
hole (min. 2" [51mm] deep) at
each hole location.
B
One-Eared
Bracket
Two-Eared
Bracket
2a Continuous Brackets to Wall (Optional)
established level line
pilaster/panel
plumb line
floor
C
L
Place the bottom of each
continuous bracket at the
established level line. Center
the bracket opening on the
pilaster/panel plumb line.
A
Insert the plastic anchors
in all holes and secure the
brackets to the wall with
the #14 x 2" (stainless)
screws provided.
C
On end panel and pliaster applications, position the bracket
with the ear facing toward the inside of the stall.
Using the bracket as a
template, mark the hole
locations on the wall.
Remove the bracket
and drill a Ø ⁵⁄₁₆" hole
(min. 2" [51mm] deep)
at each hole location.
B
Pilaster bracket is shown here; 1¼" opening brackets are
for pilasters, and 1" opening brackets are for panels.
Brackets are used as templates but since the hole patterns
may be different, the brackets may not be interchanged.
Pilaster bracket is shown here; 1¼" opening brackets are for
pilasters, and 1" opening brackets are for panels.
One-Eared
Bracket
Two-Eared
Bracket

5
Installation Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400
Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J 12/13/2012
3Leveling bolts to Pilaster
Notch indicates bottom of pre-drilled
pilasters. Standard pilasters are
symmetric and do not have notch.
Notch indicates bottom of pre-drilled
pilasters. Standard pilasters are
symmetric and do not have notch.
Use leveling screw to adjust
height of pilaster
Use a hammer to pound
T-nut into hole. Use leveling screws to
adjust height of pilaster
Use a hammer to pound
t-nuts into holes.
Drill a Ø ²⁵⁄₆₄" hole, 3" (76mm)
deep. Hole should be approximately
centered for pilasters 3"–16"
(76mm–406mm) wide.
A
Drill a Ø ²⁵⁄₆₄" hole, 3" (76mm)
deep. Hole should be 2" (51mm)
off each end for the pilasters
18"–24"(457mm–610mm) wide.
A
C
L
C
L
4Stirrup Brackets to Pilaster (Standard)
Refer to the submittal drawing to locate the split
dimension and layout location of each marked pilaster.
If installing steel reinforced pilasters refer to label
on pilaster for attaching brackets.
Measure 17" (432mm) and 63" (1600mm) down from the top of
each pilaster and place a mark on the pilaster split centerline.
These marks represent the level line for the stirrup brackets.
Pilaster shown is for reference only. Actual pilaster varies
depending on application.
A
Secure the Brackets
C
Locate the Brackets
B
Split Split
17"
(432mm)
63"
(1600mm)
For Stirrup Bracket: Place brackets at each established level line. Center
the bracket opening on the pilaster split centerline. Using the bracket as a
template, mark the hole locations on the pilaster. Remove the bracket and
drill a Ø ⁵⁄₃₂" x ⁵⁄₈" (16mm) deep pilot hole at each location.
For Alcove Bracket: Place the center of each bracket at the established
level line. Using the bracket as a template, mark the hole locations on the
pilaster. Remove the bracket and drill Ø 1/4" holes through the pilaster at
each pilaster bracket hole.
For Alcove Brackets: Secure the brackets
to the pilasters using the #10-24 x 1" (chrome
plated) shoulder screws and #10-24 x ¾"
(chrome plated) barrel nuts and to the panels
with the #10-24 x ¾" (chrome plated) shoulder
screws and #10-24 x ¾" (chrome plated) barrel
nuts provided.
For Stirrup Brackets:
Secure the bracket to the
pilasters using the #14 x ⁵⁄₈"
screws provided.
Pre-Drilled Pilasters (Optional)

6
Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400 Installation
12/13/2012 Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J
C
L
4a Continuous Brackets to Pilaster (Optional)
Refer to the submittal drawing to locate the split
dimension and layout location of each marked pilaster.
If installing steel reinforced
pilasters refer to label on pilaster
for attaching brackets.
Measure down from the top of the pilaster and place a mark
on the pilaster split centerline at dimensions "A" & "B" for
the respective bracket (see table at left).
Pilaster shown is for reference only. Actual pilaster varies
depending on application.
A
Secure the bracket to the
pilasters using the #14 x ⁵⁄₈"
screws provided.
C
Split Split
"A"
"B"
Dim. "A" Dim. "B"
Aluminum
Bracket
11¼"
(286mm)
68¾"
(1746mm)
Stainless
Steel
Bracket
11½"
(292mm)
68½"
(1740mm)
Place the continuous bracket between each
established level line. Center the bracket
opening on the pilaster split centerline. Using
the bracket as a template, mark the hole
locations on the pilaster. Remove the bracket
and drill a Ø ⁵⁄₃₂" x ⁵⁄₈" (16mm) deep pilot hole
at each location.
B
5Pilaster Shoes
This view is an example only. Refer to your submittal drawing for actual sizes. Layout the pilaster and door widths on the
pilaster centerline leaving the appropriate gap between the wall and pilaster. Place the corresponding shoe on the pilaster
centerline, center the shoes between the pilaster marks. Using the shoes as a template mark the hole locations.
A
Insert plastic anchors
into the holes and fasten
the shoe to the anchors
using hardware provided.
C
Drill Ø ⁵⁄₁₆" holes (min 2"
[51mm] deep) in the floor
and make sure the holes
are free of dirt and debris.
B
Install the shoes starting with the one closest to the wall
36" (914mm)
Door Opening
Pilaster Centerline
24" (610mm)
3"
(76mm) 10"
(254mm)
1" (25mm) Gap
24" (610mm)
Door Opening
⁹⁄₃₂" x ⁵⁄₈" Flat Washer
#14 x 2" Screw
(stainless)
Stainless Steel Shoe
Plastic
Anchor
Brackets are used as templates but since the hole patterns
may be different, the brackets may not be interchanged.
Refer to step 4 for location and
attachment of alcove brackets

7
Installation Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400
Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J 12/13/2012
6Panels and Pilasters with Stirrup Brackets (Standard)
Pilasters located at walls should be mounted first. Start at one end and install a panel, then a pilaster. Continue alternating until
installation is complete. When installing in an alcove or in-corner alcove, use an alcove bracket to secure the pilaster to the panel.
Set the pilaster into the shoe while at the same
time placing into the wall bracket.
A
B
Using the brackets as templates, drill Ø ¼" holes
through the panel at each panel bracket hole. Secure
the panel to the brackets with the #10-24 x ¾" (chrome
plated) barrel nuts and #10-24 x ¾" (chrome plated)
shoulder screws provided.
A
Place a panel on the spacer and insert the panel into the
wall brackets.
Set the pilaster into the shoe while at the same time
placing the bracket around the panel.
Pilasters at Wall Pilasters with Panels
Check to make sure the pilasters are plumb and level to each other. The pilaster height can be adjusted with the leveling screw that
was placed at the bottom of the pilaster (see page 5 for attaching leveling bolt).
B
Using the brackets as templates, drill Ø ¼"
holes through the pilaster at each pilaster
bracket hole. Secure the pilaster to the brackets
with the #10-24 x ¾" (chrome plated) barrel
nuts and #10-24 x 1" (chrome plated) shoulder
screws provided.
When installing pilasters at walls, the gaps range
from ½" to 1¼" (13mm to 32mm). Refer to your
submittal drawing for your gap sizes.
Refer to your submittal drawing and leave the appropriate
gaps. Standard gap is 1" (25mm) between the panel and
wall and ½" (13mm) between the panel and pilaster.
Using the hole in the shoe as a template, drill a
Ø ⁵⁄₃₂" pilot hole all the way through the pilaster.
Secure the shoe to the pilaster with the ¼-14 x ⁵⁄₈"
fasteners provided.
CUsing the hole in the shoe as a template, drill a Ø ⁵⁄₃₂"
pilot hole all the way through the pilaster. Secure the shoe
to the pilaster with the ¼-14 x ⁵⁄₈" fasteners provided.
C
Spacer 12" (305mm)

8
Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400 Installation
12/13/2012 Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J
Set the pilaster into the shoe while at the same
time placing into the wall bracket.
A
Pilasters at Wall Pilasters with Panels
6a Panels and Pilasters with Continuous Brackets (Optional)
Pilasters located at walls should be mounted first. Start at one end and install a panel, then a pilaster. Continue alternating until
installation is complete. When installing in an alcove or in-corner alcove, use an alcove bracket to secure the pilaster to the panel.
B
Using the brackets as templates, drill Ø ¼" holes
through the panel at each panel bracket hole. Secure
the panel to the bracket with the #10-24 x ¾" (stainless)
barrel nuts and #10-24 x ¾" (stainless) shoulder screws
for aluminum or stainless steel brackets.
Check to make sure the pilasters are plumb and level to each other. The pilaster height can be adjusted with the
leveling screw that was placed at the bottom of the pilaster (see page 5 for attaching leveling bolt).
B
Using the bracket as a template, drill Ø ¼"
holes through the pilaster at each pilaster
bracket hole. Secure the pilaster to the bracket
with the #10-24 x ¾" (stainless) barrel nuts
and #10-24 x 1" (stainless) shoulder screws for
aluminum or stainless steel brackets.
APlace a panel on the spacer and insert the panel into
the wall bracket.
Set the pilaster into the shoe placing the bracket
around the panel.
Using the hole in the shoe as a template, drill a
Ø ⁵⁄₃₂" pilot hole all the way through the pilaster.
Secure the shoe to the pilaster with the ¼-14 x ⁵⁄₈"
fasteners provided.
CUsing the hole in the shoe as a template, drill a Ø ⁵⁄₃₂" pilot
hole all the way through the pilaster. Secure the shoe to
the pilaster with the ¼-14 x ⁵⁄₈" fasteners provided.
C
Spacer 12" (305mm)
When installing pilasters at walls, the gaps range
from ½" to 1¼" (13mm to 32mm). Refer to your
submittal drawing for your gap sizes.
Refer to your submittal drawing and leave the appropriate
gaps. Standard gap is 1" (25mm) between the panel and
wall and ½" (13mm) between the panel and pilaster.

9
Installation Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400
Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J 12/13/2012
For open end applications, cut the headrail to the appropriate length (if
required). Attach the bracket to the wall at the correct height (see step B).
Attach the internal bracket to a pilaster with #10 x ⁵⁄₈" screws at the correct
height (see view below). The headrail should be level with any adjacent
headrail and should be located directly over the panel. Position each
headrail onto the brackets and secure with required fasteners. Install the
headrail end cap.
E
7Headrail
Make sure the pilasters are plumb and that the pilaster has been secured to the shoe. Leave the appropriate door opening
between the pilasters as shown on your submittal drawing.
Place headrail over the top of the pilasters
and slide it tight into the mounting bracket.
Use the headrail bracket as a template
and drill a Ø ¼" hole through the headrail.
Secure the headrail to the headrail bracket
with the #10-24 x 1-³⁄₈" (chrome plated)
shoulder screw and #10-24 x ¾" (chrome
plated) barrel nut provided.
C
Make sure the pilaster is plumb and that the spacing between
the pilasters for the doors is the correct dimension. On the back
of each pilaster (starting with the first pilaster), drill a Ø ⁷⁄₃₂" hole
through one face of the headrail only.
Using this hole as a template, drill a Ø ¹⁄₈" pilot hole into the
pilaster, ⁵⁄₈" (16mm) deep. Secure the headrail to the back of each
pilaster with the #10 x ⁵⁄₈" screws provided.
D
Completed Headrail Assembly
The illustrations on this page show mounting hardware and fasteners for a generic application. Refer to your submittals
to determine your actual headrail configurations.
Some headrail sections may need to be cut to an appropriate size. Refer to your submittals for general headrail placement.
Place headrail over the top of each pilaster
located at the wall and slide it tight against
the side wall. Mark the outline of the headrail
on the wall and remove the headrail.
A
Wall
Place the headrail bracket on the outline marked on the wall.
Mark the bracket mounting holes on the wall and drill Ø ⁵⁄₁₆" (min.
2" [51mm] deep) holes at each location. Secure each bracket
to the wall with the #14 x 2" (chrome plated) screws and plastic
anchors provided.
B
Headrail configurations that come to an intersection should meet over pilaster (see completed headrail assembly view below).

10
Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400 Installation
12/13/2012 Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J
8Wraparound Gravity Hinges (Standard)
Before installing the hinges, make sure the door openings are the appropriate size, all pilasters are
plumb, secured to the shoe and that the headrail is installed. Determine the door swing by facing the
compartment from the outside. Refer to your submittal drawings to determine each specific door swing
for your application.
Right-hand
inswing
(RHI)
Left-hand
inswing
(LHI)
Right-hand
outswing
(RHO)
Left-hand
outswing
(LHO)
"A"
"B" "B"
"B"
"A" "A"
Dim. "A" Dim. "B"
Floor
Mounted
Overhead
Braced
13¼"
(337mm)
66⁵⁄₃₂"
(1680mm)
Wall Hung
69⁷⁄₃₂"
(1758mm)
13¼"
(337mm)
66⁵⁄₃₂"
(1680mm)
Wall Hung
58"
(1473mm)
1¾"
(34mm)
53²¹⁄₃₂
(1388mm)
Floor Mounted
Overhead Braced Wall Hung
69⁷⁄₃₂" (1758mm)
Wall Hung
58" (1473mm)
Measure down "A" and "B"
from the top of the pilaster
and mark a level line. This
line represents the upper hole
location of the top and bottom
hinge. Refer to chart below for
Dimensions "A" and "B".
A
Using the hinge as a
template, drill Ø ¼" holes
through the pilaster.
B

11
Installation Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400
Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J 12/13/2012
Insert top nylon cam into the upper
and lower door hinge closure
bracket so the cam base is flush
with the bracket surface.
A
Insert each door hinge closure bracket
(with top cam in place) into the upper
and lower openings in the door,
anchoring with a #10 x 1" screw.
B
Connect the pilaster portions of the hinge
to the door portions of the hinges by
inserting the hinge pin through the top
and bottom of the door until the pin is
flush with the top of the door.
D
With hinges assembled to the door, set
the door on the 12" spacer. Postion the
door so that the hinge bracket wraps
around the pilaster. Starting at the top
hinge bracket hole, secure door to
pilaster with #10-24 x ¾" (chrome plated)
barrel nut and #10-24 x 1" (chrome
plated) shoulder screw.
Finished View of Hinge
E
8Wraparound Gravity Hinges (Standard)
The door hinge assembly consists of separate door and pilaster hardware.
Identical assemblies are provided for the top and bottom hinge.
Insert bottom nylon cam into the pilaster portion
of the hinge bracket assembly. The cam should
be set to the same desired position on the upper
and lower hinge assemblies.
C
Botttom cam can be set in
different positions (-30°,
-15°, 0°, 15°, and 30°) by
sliding cam rib into the
different bracket grooves
Bottom
Cam
Bottom
Cam
Barrel
Nut
Pilaster
Hinge
Bracket
Shoulder
Screw
Screw
Closure
Bracket
Top
Cam
Hinge
Pin
Door
Pilaster portion of hinge

12
Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400 Installation
12/13/2012 Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J
8a Continuous Spring-Loaded Piano Hinge (Optional)
Spacer 12" (305mm)
above finished floor
Place a door on a spacer
and set the gap at the hinge
and latch side. Standard
gap is ⁹⁄₃₂" (7mm).
A
The hinge should be plumb and
centered in the ⁹⁄₃₂" (7mm) gap
opening and also top to bottom
(approximately ¼" (6mm)down
from the top of the door).
B
Before installing the hinges, make sure the door openings are the appropriate size, all pilasters are
plumb, secured to the shoe and that the headrail is installed. Determine the door swing by facing the
compartment from the outside. Refer to your submittal drawings to determine each specific door swing
for your application.
Right-hand
inswing
(RHI)
Left-hand
inswing
(LHI)
Right-hand
outswing
(RHO)
Left-hand
outswing
(LHO)
Closed Door View
Continuous Piano Hinge Part # Prefix HDWT-S0209 Part # Prefix HDWT-S0208
The part numbers listed are prefixes only and
are used to identify the appropriate door kit
based on your door swing as determined above.
Inswinging doors should have hinges mounted
on the inside of the stall while outswinging doors
should have hinges mounted on the outside of
the stall.
(left hand in, right hand out,
knuckles facing front)
(right hand in, left hand out,
knuckles facing front)
Door
side Pilaster
side
Door
side
Pilaster
side
Using the hinge as a template, drill Ø ¼"
holes through the door at the top and
bottom holes. Secure the hinge to the door
with the #10-24 x ½" shoulder screws and
#10-24 x ¾" (stainless) barrel nuts provided.
Check to make sure the gaps are still at
⁹⁄₃₂" (7mm). Using the hinge as a template
drill Ø ¼" holes through the pilaster at the
top and bottom holes. Secure the hinge
to the pilaster with #10-24 x ¾" (stainless)
shoulder screws and 10-24 x ¾" (stainless)
barrel nuts. Drill Ø ¼" holes through the
remaining hinge holes on the door and
pilaster. Secure with the fasteners provided.
C

13
Installation Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400
Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J 12/13/2012
C
L
L
C
C
L
C
L
L
C
C
L
9Latch and Strike/Keeper for Inswing Doors
Local codes vary from state to state. Check your local
codes before installing the coat hook and door pulls.
C
With the door in the closed position, place the
keeper on the pilaster and then align the latch
slide bar so that it fits within the top notch of
the keeper and operates freely. This will allow
the egress function to operate properly should
the latch malfunction.
D
Using the keeper as a template, mark the
hole locations on the pilaster and drill two
Ø ¼" holes through the pilaster. Secure the
strike/keeper to the pilaster with #10-24 x ¾"
(chrome plated) barrel nuts and #10-24 x 1"
(chrome plated) shoulder screws provided.
F
Install the coat hook on the
inside of the door on the
latch side at a location 3"
(76mm) down from the top
and 3" (76mm) in from the
side. Using the coat hook
as a template, drill two Ø ¹⁄₈"
pilot holes ⁵⁄₈" (16mm) deep.
Secure the coat hook with the
#10 x ⁵⁄₈" screws provided.
A
BUsing the latch as a template, mark the hole locations on the
door. Remove the latch and drill an Ø ¹⁄₈" x ⁵⁄₈" (16mm) deep
pilot hole at each location. Secure the latch to the door with
the #10 x ⁵⁄₈" screws provided.
Position the slide latch on the inside of the door,
centered top to bottom on the door. The leading edge of
the latch body should be ¹⁄₈" (3mm) from the door edge.
EFor 34"–36" doors, drill
two Ø ¼" holes (spaced
3½" [89 mm] apart)
through the door and
mount the door pulls
to the door as shown
with the #10-24 x 2" flat
machine screws provided.
3"
(76mm)
3"
(76mm)
C
L
L
C
C
L
Typical Inswing Flat Strike/Keeper
Using the flat strike/keeper as
a template drill two Ø ¹⁄₈" pilot
holes ¾" (19mm) deep. Secure
the inswing flat strike/keeper
with the #10 x ¾" screws
provided.
B
C
L
L
C
C
L
C
L
L
C
C
L
¹⁄₈"
(3mm)
C
L
L
C
C
L
C
L
L
C
C
L
3½"
(89mm)
Position the strike as shown
(door with slide latch should be
in the closed position and latch
should be able to engage the
slot in the flat strike).
A

14
Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400 Installation
12/13/2012 Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J
C
L
L
C
C
L
9a Latch and Strike/Keeper for Outswing Doors
Local codes vary from state to state. Check your local
codes before installing the coat hook and door pulls.
C
L
L
C
C
L
C
L
L
C
C
L
FInstall the wall bumper on the outside of the door
on the latch side at a location 3" (76mm) up from
the bottom and 3" (76mm) in from the side. Drill
two Ø ¹⁄₈" pilot holes ⁵⁄₈" (16mm) deep. Secure the
wall bumper with the #10 x ⁵⁄₈" screws provided.
3" (76mm)
A
B
Using the latch as a template, mark the hole locations on
the door. Remove the latch and drill an Ø ¹⁄₈" x ⁵⁄₈" (16mm)
deep pilot hole at each location. Secure the latch and
spacer to the door with the #10 x 1" screws provided.
Position the slide latch on the inside of the door, centered
top to bottom on the door. The leading edge of the latch
body should be ⁵⁄₈" (16mm) from the door edge. C
With the door in the closed position, place the keeper
on the pilaster and then align the latch slide bar so
that it fits within the top notch of the keeper and
operates freely.This will allow the egress function to
operate properly should the latch malfunction.
C
L
L
C
C
L
DUsing the keeper as a template, mark the hole
locations on the pilaster and drill two Ø ¹⁄₄" holes
through the pilaster. Secure the keeper to the
pilaster as shown with #10-24 x ¾" (chrome
plated) barrel nuts and #10-24 x 1" (chrome plated)
shoulder screws provided.
Place the strike on the pilaster below the keeper as
shown. Make the hole locations on the pilaster and
drill two Ø ¼" holes through the pilaster. Secure
the strike to the pilaster with #10-24 x ¾" (chrome
plated) barrel nuts and #10-24 x 1" (chrome plated)
shoulder screws provided.
C
L
L
C
C
L
⁵⁄₈"
(16mm)
3"
(76mm)
E
For outswing doors, drill two Ø ¼"
holes (spaced 3½" [89mm] apart)
through the door and mount the
door pulls to the door with the
#10-24 x 2" flat machine screws
provided (as shown).
3½"
(89mm)
C
L
L
C
C
L
Typical Outswing Flat Strike/Keeper
Position the strike as shown
(door with slide latch should be
in the closed position and latch
should slide over the top tab
portion of the flat strike).
A
Using the flat strike/keeper
as a template drill two Ø ¹⁄₈"
pilot holes ¾" (19mm) deep.
Secure the outswing flat
strike/keeper with the
#10 x ¾" screws provided.
B
36" (914mm)
Install the coat hook on the pilaster
36" (914mm) above finished floor as
shown. Drill two Ø ⁵⁄₃₂" pilot holes ⁵⁄₈"
(16mm) deep. Secure the coat hook
with the #14 x ⁵⁄₈" screws provided.
G

15
Installation Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400
Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J 12/13/2012
10 Urinal Screens with Stirrup Brackets (Standard)
Before installing the urinal screen components,
determine the correct location for your application.
Draw a plumb line on all walls
representing urinal screen
centers (see chart below for
measurements). These marks
represent hole centerlines for
the brackets. Use a level to
transfer that mark to all other
plumb lines.
A
Place the center of each stirrup bracket at each
established level line. Center the bracket opening
on the plumb line. Using the bracket as a template,
mark the hole locations on the wall. Remove the
bracket and drill a Ø ⁵⁄₁₆" x min. 2" (51mm) deep
hole at each hole location.
B
Place the bottom of each urinal screen 18" (457mm)
up from floor. Establish a 1" (25mm) gap between
the finished wall and urinal screen edge. A spacer
may help to support the weight of the screen and
establish the appropriate distances.
D
Insert the plastic anchors in all
holes and secure the brackets
with the #14 x 2" (chrome plated)
screws provided.
C
Drill Ø ¼" holes through the screen at each
bracket hole. Secure the screen to the
brackets with #10-24 x ¾" (chrome plated)
barrel nuts and #10-24 x ¾" (chrome plated)
shoulder screws provided.
E
Dim. "A"
Dim. "B"
Dim. "C"
established
level line
urinal
plumb line
floor
Dim. "A" Dim. "B" Dim. "C"
15" (381mm) for 42" (1067mm) screens or
18" (457mm) for 48" (1219mm) screens
15" (381mm) for 42" (1067mm) screens or
18" (457mm) for 48" (1219mm) screens
24" (610mm) for 42" (1067mm) screens or
24" (610mm) for 48" (1219mm) screens

16
Plastic Laminate Restroom Partitions, Floor-Mounted with Overhead Brace — Series 400 Installation
12/13/2012 Bradley • HDWL-INSTR-001 Rev. D; ECN 12-14-004J
Before installing the urinal screen components,
determine the correct location for your application.
Brackets are used as templates but since the
hole patterns may be different, the brackets may
not be interchanged.
Draw a plumb line on all walls
representing urinal screen centers.
Measure 18½" (470mm) up for
42" (1067mm) tall urinal screens
or 21½" (546mm) up for 48"
(1219mm) tall urinal screens from
the floor and place a mark on the
plumb line. Use a level to transfer
that mark to all other plumb lines.
A
Using the bracket as a template mark
the hole locations on the wall. Remove
the bracket and drill a Ø ⁵⁄₁₆" x min. 2"
(51mm) deep hole at each hole location.
C
Place the bottom of the
continuous bracket at
the established level line.
Center the bracket opening
on the plumb line.
B
Drill Ø ¼" holes through the screen at each
bracket hole. Secure the screen to the
bracket with #10-24 x ¾" (stainless) barrel
nuts and #10-24 x ¾" (stainless) shoulder
screws provided.
F
10a Urinal Screens with Continuous Brackets (Optional)
Place the bottom of each urinal screen
18" (457mm) up from floor. Establish a 1"
(25mm) gap between the finished wall and
urinal screen edge. A spacer may help
to support the weight of the screen and
establish the appropriate distances.
E
Insert the plastic anchors
in all holes and secure the
bracket with the #14 x 2"
(stainless) screws provided.
D
18½"(470mm) for
42"(1067mm) tall screens
or 21½" (546mm) for
48"(1219mm) tall screens
established
level line
urinal plumb line
floor
