LVAD2 Installation
24/17/2017 Bradley • 215-1850 Rev. A; ECN 17-08-002
WARNING
Make sure that all water supply lines have been flushed and then completely turned off before beginning
installation. Debris in supply lines can cause valves to malfunction.
Turn OFF electrical power to the electrical outlets, then unplug all electrical units prior to installation. Electrical
power MUST remain off until installation is complete.
Installer's hardware must be appropriate for wall construction. Wall anchors must have a minimum pull-out
rating of 1,000 pounds.
IMPORTANT
Read this entire installation manual to ensure proper installation. When finished with the installation, file this
manual with the owner or maintenance department. Compliance and conformity to local codes and ordinances
is the responsibility of the installer. Product warranties may be found under “Products” on our Web site at
www.bradleycorp.com.
Separate parts from packaging and make sure all parts are accounted for before discarding any packaging
material. If any parts are missing, do not begin installation until you obtain the missing parts.
For standard height mounting, do not exceed the recommended 33.5" distance from the fixture rim to the
finished floor.

Installation LVAD2
Bradley • 215-1850 Rev. A; ECN 17-08-002 4/17/2017 3
Components
LVAD2BO
Contact your Bradley
Representative for color options
Individual Rough-In Option
Chrome P-trap (S29-094)
Plastic P-trap (269-1697)
O-Ring
(125-111)
Drain
Adapter
Packing
Washer
#10-24
Screw
Drain
Adapter
Prepack
(S45-2480)
Access Panel
(186-1912)
Wall Bracket
(140-1128)
Drain Cap
(111-140)
Drain Cap Spacer
(269-2540)
Trough Strainer
(173-039)
Trough Strainer Screw
(160-353)
Access Panel Bracket
(140-1172)
#10 Access Panel
Thumb Screw
(160-536)
Access Panel Security
Screw Option
(S45-2880)
TMV Valve
(1/2" NPTM
Outlet)
(S45-2701)
Hose Prepack
(S45-2730)
Supply
Fittings
(S45-2510)
TMV Supply
Connections
Plastic Hose
Supply Fittings
(S45-2511)
Hose Prepack
(S45-2731)
Tempered Supply
Connections
Plastic
Hose
Plastic Hose
Stainless
Steel
Hose

LVAD2 Installation
44/17/2017 Bradley • 215-1850 Rev. A; ECN 17-08-002
Components
IR-DCD Faucet
(S53-336)
CAP-DCA Faucet
(S53-334)
Battery Box for
CAP-DCA Faucets
6315-KT0000 Soap Dispenser 6324-68 Soap Dispenser 6334 Soap Dispenser
Optional
Transformer
Plug-In Transformer
Option (PT) for
IR-DCD Faucet
(S53-337)
Plug-in transformer option (PT)
includes Transformer (S53-338),
Adapter (S53-339), and Grounding
Kit (S53-349) for CAP-DCA Faucets
IR-DCG Faucet
(S53-350)
Plug-In Transformer
Option (PT) for
IR-DCG Faucet
(153-486)
*Adapter included with faucet (TMV: S45-2872, TL: S45-2871) *Adapter included with faucet (TMV: S45-2872, TL: S45-2871)
**Adapter S45-2873 included with faucet

Installation LVAD2
Bradley • 215-1850 Rev. A; ECN 17-08-002 4/17/2017 5
Dimensions
Top View (shown with CAP-DCA faucet and 6315 soap)
Front View
Supplies Required
• (6) ³⁄₈" fasteners and wall anchors for bowl and wall bracket (minimum pull-out rating of 1,000 lbs.)
• (4) ¼" fasteners and wall anchors for access panel brackets (minimum pull-out rating of 100 lbs.)
• ½" hot/cold or tempered stub-out
• 1½" NPT drain stub-out(s)
• OPTIONAL: (2) 110 volt GFCI protected electrical outlets for 100–120 VAC plug-in transformers only
• Screen filter(s) as needed, if not included with faucet(s)
• Drill
• Crescent wrench
• Tape Measure
14-3/8"
(366mm)
21"
(533mm)
5"
(127mm) 6"
(152mm)
1-5/8"
(40mm)
2-1/2"
(64mm)
50"
(1270mm)
59-3/4"
(1518mm)
20"
(509mm)
3-3/4"
(95mm)
56-7/8"
(1444mm)
60"
(1524mm)
• Phillips screw driver
• Flat head screw driver
• Level
6"
(152mm)
15"
(381mm)
15"
(381mm)

LVAD2 Installation
64/17/2017 Bradley • 215-1850 Rev. A; ECN 17-08-002
Dimensions – Side View
A
B
14"
(357mm)
3-3/4"
(95mm)
C
20"
(508mm)
21"
(534mm)
20°
7-1/2"
(190mm)
7-1/2"
(191mm)
2"
(50mm)
ADA/TAS Standard Height
ADA/TAS Juvenile Height
(Children 6-12 years) CSA Standard Height
Dim A 33-1/2" (851mm) 30-1/2" (775mm) 33-1/2" (851mm)
Dim B 27" (686mm) 24" (610mm) 29-29/32" (760mm)
Dim C 13-1/2" (343mm) 10-1/2" (267mm) 13-1/2" (536mm)

Installation LVAD2
Bradley • 215-1850 Rev. A; ECN 17-08-002 4/17/2017 7
Mounting for Standard, ADA and TAS height shown.
Structural Rough-Ins
Points A, B and C require sufficient backing
compliant with local building codes.
WARNING Ensure bowl is completely seated in
the wall bracket and securely fastened
to the wall at point A.
(mm)
A
A
B
B
C
L
CODE DESCRIPTION QTY.
A Install (1) 3/8" wall anchor with a minimum pull-out force of 1,000 lbs. per local codes at locations shown 2
B
Provide structural backing compliant with local building codes. 2
C Install wall anchor with a minimum pull-out force of 100 lbs. per local codes at locations shown 4
Wall Bracket
RIM HEIGHT VERTICAL HEIGHT ADJUSTMENTS FIXTURE STYLE
33½" No Adjustment Standard Height, ADA, TAS and CSA
30½" Subtract 3" Juvenile, ADA and TAS
C
C
28-1/8"
(723)
Bottom
of
Bracket
33-1/2"
(851)
24-1/8"
(612)
13-1/8"
(333)
27-5/8"
(701)
27-5/8"
(701)
24-1/8"
(612)
3/4"
(19)
36-1/2" (927)
25" (635) 25" (635)
25-1/4"
(640)
Secure bracket to wall using min. (2)
3/8" anchor bolts to the left of C/L and
min. (2) 3/8" anchor bolts to the right
of C/L. The (2) anchor bolts to the right
of C/L must be min. 16" apart from the
anchor bolts to the left of C/L. When
mounting is complete, check to ensure
the bracket is level. See Step 1: Bracket
Mounting for more information.
31-1/2"
(800)

LVAD2 Installation
84/17/2017 Bradley • 215-1850 Rev. A; ECN 17-08-002
Plumbing and Electrical Rough-Ins
Mounting for Standard, ADA and TAS height shown.
(mm)
33-1/2"
(851)
24-1/8"
(613)
17-1/2"
(444)
Min
AE
H C
C
L
2-1/4"
(57)
1"
(25)
Finished Floor
25" (635)
4-1/2"
(114)
E
CODE DESCRIPTION QTY.
A 1½" NPT Drain, Stub-out 2" from wall 1
H,C ½" Nominal (⁵⁄₈" O.D. Comp.) Hot/Cold supplies, Stub-out 2" from wall 1
E 110V GFI protected electrical outlet 2

Installation LVAD2
Bradley • 215-1850 Rev. A; ECN 17-08-002 4/17/2017 9
Bracket Mounting
Typical installation is shown. It may be necessary to repair the wall
after mounting. The fixture may not cover all of the wall modifications.
1
Mounting height per structural rough-in dimensions.
For ease of drain installation, lay the bowl on its back.
2Drain Assembly
Install wall bracket to wall
per structural rough-in
dimensions. Check to
ensure the bracket is
level. Example anchor
locations shown.
A
C
L
16"
(406mm)
min.
O-Ring
Drain
Adapter
Packing
Washer
#10-24
Screw
Assemble the remaining components as
shown and thread the four screws through
the drain adapter and into the basin inserts.
Ensure the screws compress the drain
adapter evenly onto the basin.
A

LVAD2 Installation
10 4/17/2017 Bradley • 215-1850 Rev. A; ECN 17-08-002
Bowl Mounting (to Bracket and Wall)
4
Faucet Installation
3
For ease of drain installation,
lay the bowl on its back.
Install the faucets and optional
soap valves according to the
manufacturer's instructions.
A
Position bowl above wall bracket.
Press firmly on the back of the bowl
to seat the bowl flange into the wall
bracket lip. Ensure bowl is level.
ASecure the bowl to the wall anchors
using fasteners per the structural
rough-in requirement (supplied by
installer).
B
WARNING Ensure bowl is completely seated in
the wall bracket and securely fastened
to the wall at point A.
CAUTION Bracket is not
intended to support
the weight of bowl
for an extended
period of time. Be
sure to secure the
bowl to the wall
using appropriate
fasteners.
Other basin models may be shown
for faucet mounting visual.
CAUTION Positioning bowl
onto bracket may
require two people.
