Bradley Express MG Series User manual

215-1480 Rev. G; ECN 13-08-025
© 2014 Bradley
Page 1 of 20 4/9/2014
Installation
P.O. Box 309, Menomonee Falls, WI 53052-0309
Phone: 800.BRADLEY (800.272.3539) Fax: [phone]
bradleycorp.com
MG-2/TT
Express®Lavatory
System - MG-Series
with TouchTime®Control
Table of Contents
Pre-Installation Information ..............2
Dimensions..........................3-4
Installation Instructions............... 5-13
Cleaning and Maintenance .............14
Assembly of Components ............15-17
Solenoid Valve Troubleshooting .......18-19
Navigator®Valve Maintenance...........20
IMPORTANT
Read this entire installation manual to ensure proper
installation.
Flush all the water supply lines before making connections.
Wall anchors used must have a minimum pull-out rating of
1,000 lbs.
File these instructions with the owner or maintenance
department.
Product warranties may be found under “Product
Information” on our web site at www.bradleycorp.com.

Express®Lavatory System - MG-Series with TouchTime®Control
MG-2/TT Installation
24/9/2014 Bradley • 215-1480 Rev. G; ECN 13-08-025
Pre-Installation Information
Barrier-free and ADA compliant - standard height mounting
The MG-2/TT Express®Lavatory System must have a rim height no higher than 34" above finished floor to be
compliant with Americans with Disabilities Act (ADA). When mounted at 34" rim height, the MG-2/TT Express®
Lavatory System meets ADA, ANSI and UFAS requirements for barrier-free clearances, reaches and controls.
Always check local codes and ordinances for compliance.
Barrier-free and ADA compliant - juvenile height mounting
The MG-2/TT Express®Lavatory System must have a rim height no higher than 30" above finished floor to
be compliant with Americans with Disabilities Act (ADA) Accessibility Guidelines for Buildings and Facilities:
Building Elements Designed for Children’s Use; Final Rule.
Texas Accessibility Standards compliant:
The MG-2/TT Express®Lavatory System meets Texas Accessibility standards (TAS) for barrier-free
clearances, reaches and controls. Always check local codes and ordinances for compliance.
TouchTime®switch and solenoid
Each sprayhead is controlled by a TouchTime®switch, enabling each user to activate a single flow of water.
Each valve uses less than half the maximum of hot water allowed by the ANSI/ASHRAE/IESNA 90.1-1989
Standard.
Supplies required for installation:
• (8)³⁄₈" wall anchors, bolts and washers to mount frame and bowl to wall
(minimum pull-out rating of 1,000 lbs.)
• ½"Nominalcoppertubingforhotandcoldsuppliesand1½"NPTdrainpiping
• 110voltelectricaloutletfor110/24VACplug-intransformer(supplied)
• 240/208-voltor277-voltelectricaloutletforoptionalelectrictanklesswaterheater

Express®Lavatory System - MG-Series with TouchTime®Control
Installation MG-2/TT
Bradley • 215-1480 Rev. G; ECN 13-08-025 4/9/2014 3
MG-2/TT Express®Lavatory System Dimensions
54"
(1372)
42"
(1067)
15"
(381)
27"
(686)
47"
(1194)
(mm)
(mm)
*Subtract 4" from vertical dimensions for compliance with ADA guidelines for children’s use.
22"
(559)
*39"
(991)
*33½"
(851)
*29½"
(749)
*17½"
(445)
21½"
(546)
9½"
(241)
(mm)
15"
(381)

Express®Lavatory System - MG-Series with TouchTime®Control
MG-2/TT Installation
44/9/2014 Bradley • 215-1480 Rev. G; ECN 13-08-025
Dimensions continued . . .
TAS Juvenile Height
Grades 6 thru 8 or 9
TAS Juvenile Height
Grades Pre-K thru 5 or 6
37½"
(952)
32"
(813)
28"
(711)
16"
(406)
FLOOR
35½"
(902)
30"
(762)
26"
(660)
14"
(356)
FLOOR
(mm)
(mm)

Express®Lavatory System - MG-Series with TouchTime®Control
Installation MG-2/TT
Bradley • 215-1480 Rev. G; ECN 13-08-025 4/9/2014 5
Installation Instructions
Step 1: Rough in supplies and optional hot water heater
NOTE: See Figure 1 (below), 1a, 1b (for TAS on page 6) and Figure 2 (on page 7) when roughing
in the MG-2/TT Express®.
IMPORTANT: Flush the supply lines before making connections. Debris in supply lines will cause
the valves to malfunction.
IMPORTANT: Dimensions shown in Figure 1 are for Standard Height Mounted
MG-2/TT Express®.
1. Rough in ½" nominal copper tubing for hot and cold supply lines through wall at dimensions shown.
2. Rough in 1½" NPT drain waste connection through wall at dimensions shown.
3. OPTIONAL HOT WATER HEATER: Rough in appropriate electrical supply per local code (recommended
240/208-volt or 277-volt electrical box location shown below).
4"
(102)
5"
(127)
FLOOR
14"
(356)
14"
(356)
*22³⁄₈"
(568)
*28¼"
(718)
*25¾"
(654)
½" NOMINAL COPPER TUBING
FOR HOT AND COLD SUPPLIES OR
TEMPERED SUPPLY – STUB OUT 2"
³⁄₈" WALL ANCHORS (8) PLACES MIN. PULL-OUT
STRENGTH 1000 LBS. PER ANCHOR
110V GFI
PROTECTED
ELECTRICAL
OUTLET
*Juvenile Height Mounting:
Subtract 4" from vertical dimensions for compliance with ADA guidelines for children’s use.
Figure 1
Standard Height Mounting CENTERLINE
OF FIXTURE
1½" NPT DRAIN
STUB OUT 2"
*24½"
(654)
*26"
(660)
*31½"
(800)
3¾" (95)
*19½"
(495)
4"
(102)
4" (102)RECOMMENDED 240V/208V
OR 277V FOR OPTIONAL
ELECTRICAL BOX
LOCATION
(2½" l x 3" w x 4" h)
RECOMMENDED
240V/208V OR 277V
FOR OPTIONAL
ELECTRICAL BOX
LOCATION
(4" l x 3" w x 4" h)
*23"
(584)
HC
16½"
(419)
APPROX. DIMENSION
25½" (648)
APPROX. DIMENSION
25½" (648)
AA
B
BBB
B
B

Express®Lavatory System - MG-Series with TouchTime®Control
MG-2/TT Installation
64/9/2014 Bradley • 215-1480 Rev. G; ECN 13-08-025
Figure 1a
TAS - Texas Accessibility
Standards:
Juvenile Height (grades
Pre-K thru 5 or 6)
4"
(102)
5"
(127)
FLOOR
14"
(356)
14"
(356)
18⁷⁄₈"
(479)
24¾"
(629)
22¼"
(565)
½" NOMINAL COPPER TUBING FOR HOT AND COLD SUPPLIES OR
TEMPERED SUPPLY – STUB OUT 2"
³⁄₈" WALL ANCHORS (8) PLACES MIN. PULL-OUT STRENGTH 1000 LBS. PER ANCHOR
CENTERLINE OF FIXTURE
1½" NPT DRAIN
STUB OUT 2"
21"
(533)
22½"
(572)
28"
(711)
3¾" (95)
16"
(406)
4"
(102)
4" (102)RECOMMENDED 240V/208V
OR 277V FOR OPTIONAL
ELECTRICAL BOX
LOCATION
(2½" l x 3" w x 4" h)
RECOMMENDED
240V/208V OR 277V
FOR OPTIONAL
ELECTRICAL BOX
LOCATION
(4" l x 3" w x 4" h)
19½"
(495)
HC
16½"
(419)
APPROX. DIMENSION
25½" (648)
APPROX. DIMENSION
25½" (648)
AA
B
BB B
B
B
Figure 1b
TAS - Texas Accessibility
Standards:
Juvenile Height (grades 6
thru 8 or 9)
4"
(102)
5"
(127)
FLOOR
14"
(356)
14"
(356)
26-3/4"
(679)
24-1/4"
(616)
½" NOMINAL COPPER TUBING FOR HOT AND COLD SUPPLIES OR TEMPERED
SUPPLY – STUB OUT 2"
³⁄₈" WALL ANCHORS (8) PLACES MIN. PULL-OUT STRENGTH 1000 LBS. PER ANCHOR
CENTERLINE OF FIXTURE
1½" NPT DRAIN
STUB OUT 2"
23"
(584)
3¾" (95)
18"
(457)
4"
(102)
4" (102)RECOMMENDED 240V/208V
OR 277V FOR OPTIONAL
ELECTRICAL BOX
LOCATION
(2½" l x 3" w x 4" h)
RECOMMENDED
240V/208V OR 277V
FOR OPTIONAL
ELECTRICAL BOX
LOCATION
(4" l x 3" w x 4" h)
21½"
(546)
HC
16-1/2"
(419)
APPROX. DIMENSION
25½" (648)
APPROX. DIMENSION
25½" (648)
AA
B
BB B
B
B
30"
(762)
20⁷⁄₈"
(530)
24½"
(622)
110V GFI
PROTECTED
ELECTRICAL
OUTLET
110V GFI
PROTECTED
ELECTRICAL
OUTLET

Express®Lavatory System - MG-Series with TouchTime®Control
Installation MG-2/TT
Bradley • 215-1480 Rev. G; ECN 13-08-025 4/9/2014 7
Installation Instructions continued . . .
Step 2: Rough in wall anchors and electrical outlet
IMPORTANT: Turn OFF electrical power to the outlet when installing the Express®Lavatory
System.
1. Install a 110 volt GFI protected electrical outlet per local code at the location shown in Figure 2.
2. Install six ³⁄₈" wall anchors with a minimum pull-out rating of 1,000 lbs. (supplied by installer) at the
locations marked (ref. location “B” shown in Figure 1, 1a or 1b on pages 5-6).
NOTE: The dimensions for the wall anchors at location "A" are for reference only.
3. On the back of the bowl, measure the distance between the ¾" bowl mounting holes. Divide this
measurement in half. Measure and mark this dimension on the wall to the left of the centerline and to the
right of the centerline. Install two ³⁄₈" wall anchors with a minimum pull-out rating of 1,000 lbs. (supplied by
installer) at the locations marked (ref. location "A" shown in Figure 1, 1a or 1b on pages 5-6).
NOTE: The anchors will be used to mount the Express®MG-2/IR bowl and frame to the wall.
Figure 2
110 VOLT GFCI
ELECTRICAL OUTLET
TRANSFORMER
LOCATION
½" NOMINAL
COPPER TUBING
FOR HOT AND
COLD SUPPLIES OR
TEMPERED SUPPLY.
STUB OUT 2”
1½" NPT DRAIN
STUB OUT 2”

Express®Lavatory System - MG-Series with TouchTime®Control
MG-2/TT Installation
84/9/2014 Bradley • 215-1480 Rev. G; ECN 13-08-025
Installation Instructions continued . . .
Step 3: Mount frame to wall
1. Loosen, but do not remove the three bottom access panel screws.
2. Remove the two top access panel screws and washers securing the access panel to the frame and
remove the access panel (see Figure 3).
3. Position the frame with Terreon®End Caps attached, against the wall, ensuring that it is level.
IMPORTANT: Anchoring the frame to a wall that is not flat may cause the frame to bend. If
necessary, install shims to compensate for wall distortion.
4. Ensure that the back of the frame is flat against the wall. If wall is not flat, insert shims behind the frame
to ensure that it will not bend when anchored.
5. Once you have positioned the frame such that it is level and flat against the wall or shimmed, use the ³⁄₈"
bolts and washers to mount the frame to the wall.
Figure 3
³⁄₈" BOLTS AND WASHERS
(6) PLACES
TERREON®
END CAP
LEFT
STAINLESS STEEL
ACCESS PANEL
TERREON®
END CAP
RIGHT
FRAME
¼" - 20 SCREWS
AND FINISHING
WASHERS
(5) PLACES
FRONT VIEW

Express®Lavatory System - MG-Series with TouchTime®Control
Installation MG-2/TT
Bradley • 215-1480 Rev. G; ECN 13-08-025 4/9/2014 9
Installation Instructions continued . . .
Step 4: Install bowl assembly
IMPORTANT: See Figure 4 below when installing the bowl assembly. If the fixture has soap option,
refer to the soap installation manual 215-1585 before installing the bowl assembly.
1. With someone to assist you, place the bowl assembly squarely onto the frame being careful not to pinch
tubing between bowl and frame.
2. Attachthefrontofthebowlassemblytotheframeusingthetwo¼-20x½"pan-head
screws and washers provided. Do not tighten screws at this time.
IMPORTANT: When bolting the bowl assembly to the wall, do not overtighten the bolts.
Overtightening bolts can damage the Terreon®material.
3. After the bowl assembly is attached to the frame, install the two ³⁄₈" bolts and washers
(supplied by the installer) to bolt the bowl to the wall anchors. Do not overtighten bolts.
4. Tighten the screws installed in procedure #2 above to secure the bowl assembly to the frame.
Do not overtighten.
5. If necessary, adjust sprayhead body to fit closely to wall by adjusting sprayhead mounting bolts. See
Figure 8 on page 14 for sprayhead mounting bolt locations.
Figure 4
³⁄₈" BOLT
AND WASHER
TERREON®
END CAP (R) TERREON®
END CAP (L)
FRAME SPRAYHEAD
³⁄₈" BOLT
AND WASHER
BOWL
¼"-20 x ½"
PAN HEAD
SCREWS AND
WASHERS
(2) PLACES
BACK VIEW

Express®Lavatory System - MG-Series with TouchTime®Control
MG-2/TT Installation
10 4/9/2014 Bradley • 215-1480 Rev. G; ECN 13-08-025
Installation Instructions continued . . .
Step 5: Connecting supply
1. Loosen but do not remove the two mounting screws holding the valve bracket to the frame. Slide the
valve bracket up until the larger cutout in the frame’s slot aligns with the screw head (see Figure 5b).
Then lift up to remove the valve bracket from the frame.
2 FOR HOT AND COLD SUPPLY: Attach the stops to the hot and cold water supply piping from the wall.
Connect the flexible hoses to the Navigator Mixing Valve and to the stops (see Figure 5a).
NOTE: The “H” on Navigator Mixing Valve indicates hot water supply inlet.
 FORSINGLETEMPEREDSUPPLY:Attachthestoptothe½"temperedsupplyline.Connectthestopto
the tempered line adapter with the flexible supply hose (Figure 5c).
3. AssembletheP-trapbyconnectingthe1½"tubularpipetothetailpieceandtothe1½"drainpipestubbed
out of the wall.
4. Install the strainer on the drain plug opening inside the bowl, and push the strainer firmly into place.
Secure the stainer with the screw provided.
Figure 5a FLEXIBLE SUPPLY
HOSE
NAVIGATOR
THERMOSTATIC
MIXING VALVE
FLEXIBLE
SUPPLY
HOSE
CONNECT TO
HOT WATER
SUPPLY
CONNECT TO
COLD WATER
SUPPLY
Figure 5c
FLEXIBLE
SUPPLY HOSE
(TO SOLENOID
BRACKET)
TO SUPPLY LINE
TEMPERED
LINE ADAPTER
(S39-804)
Hot and
Cold
Supplies
Single
Tempered
Supply
Figure 5b
SLOT IN
FRAME
VALVE BRACKET
MOUNTING SCREW

Express®Lavatory System - MG-Series with TouchTime®Control
Installation MG-2/TT
Bradley • 215-1480 Rev. G; ECN 13-08-025 4/9/2014 11
Installation Instructions continued . . .
Step 6: Connecting optional hot water heater
NOTE: 240/208 or 277 voltage is required for hot water heater.
Refer to the installation manual provided with the hot water heater
for further installation information.
1. Remove the two screws from the back of the water heater.
Attach the bracket with the screws as shown in Figure 6a.
2. Hang the water heater on the rear frame member to the right
of the vertical frame member (see Figure 6b).
3. Connectthe½"flexiblehosefromthecoldwatersupply
stub-out to the hot water heater inlet.
4. Connectthe½"flexiblehosefromthehotwaterheateroutlet
to the supply inlet on the solenoid valve assembly.
RECOMMENDED 240V/208V
ELECTICAL BOX LOCATION, 4" x 4"
OPTIONAL 240V/208V ELECTICAL
BOX LOCATION, 2-1/2" x 4"
COLD WATER
SUPPLY
2" (51mm)
REF. ONLY
WATER HEATER EX95TMLB
MOUNTING CLIP
INLET
OUTLET
VERTICAL FRAME
MEMBER
COLD WATER
SUPPLY
HANG WATER HEATER
ON REAR FRAME MEMBER
TO THE RIGHT OF THE
VERTICAL FRAME MEMBER
REFERENCE WATER HEATER
INSTRUCTIONS FOR REQUIRED
ELECTRICAL CONNECTIONS.
FOR CLARITY,
BOWL NOT SHOWN.
WATER HEATER EX95TMLB
(269-1767), 240V/208V
5-1/4" x 9-3/4" x 2-1/16"
WATER
HEATER
BRACKET
(140-945)
SCREWS
REMOVE (2) SCREWS FROM
BACK OF WATER HEATER.
ATTACH BRACKET WITH
SCREWS AS SHOWN.
Figure 6c
Figure 6b
Figure 6a

Express®Lavatory System - MG-Series with TouchTime®Control
MG-2/TT Installation
12 4/9/2014 Bradley • 215-1480 Rev. G; ECN 13-08-025
Figure 7
Installation Instructions continued . . .
Step 7: Connecting electrical and supply tubing
WARNING: MG-2/TT must be connected to 24 VAC Class II plug-in transformer provided.
Connection to 110 VAC may cause personal injury and/or damage to electronics.
Connection of leads other than shown may cause permanent damage to the switch.
1. Insert the two sprayhead supply tubes into the two solenoid tube connectors by loosening the
compression nut and firmly pushing the tubing into the connector until the tubes are fully seated, then
re-tighten the compression nut (hand-tight plus two full turns with a wrench) (see Figure 7).
2. Connect the wires per the wiring diagram shown below.
3. Align the mounting screws with slots on the frame. Valve bracket slides down to lock into place.
4. Turn on the water supply to the MG-2/TT Express®and check for leaks.
5. Turn on the electrical power, trigger the TouchTime®push buttons and check for proper function (the
timing is electronically controlled and set at 15 seconds).
B Black G Brown
F BrownA Black
Left Button
Left
Gray
Right
Green
Right
Gray
Right Button
Left
Green
A Black
C Black
D Black
E Brown
F Brown
G Brown
H Brown
Right Gray
Right Green
Left Green
B Black
Left Gray
Transformer
S83-134
Green Supply
Tube
Red Supply
Tube

Express®Lavatory System - MG-Series with TouchTime®Control
Installation MG-2/TT
Bradley • 215-1480 Rev. G; ECN 13-08-025 4/9/2014 13
Installation Instructions continued . . .
Step 8: Adjust the temperature
1. Check the temperature when approximately 1.0 GPM water flow is reached and adjust if necessary (the
range of the valve is 95°F–125°F (35°C–52°C).
2. Loosen Cap Screw about ¼" (4-6 turns) and lift up cover (do not remove).
3. Using cover, turn cartridge gently until desired water temperature is reached. Do not turn past stops as
this may damage unit. Push cover down and tighten screw.
4. Reinstall panel to frame with the five Torx-head screws provided (see Figure 3 on page 8).
NOTE: Push button activation takes place only when released, (prevents “hold open” activation).
This valve is NOT factory preset. Upon installation, the temperature of this valve must be checked and adjusted
to ensure delivery of a safe water temperature. Water in excess of 110°F (43°C) may cause scalding.
H
C
Figure 8

Express®Lavatory System - MG-Series with TouchTime®Control
MG-2/TT Installation
14 4/9/2014 Bradley • 215-1480 Rev. G; ECN 13-08-025
Cleaning and Maintenance Instructions
IMPORTANT: Strong alkaline or acid-based chemicals and cleansers should not be used to clean
the MG-2/TT Express®. If these chemicals come in contact with the Terreon®surface,
wipe off the surface immediately and flush with soapy water. Avoid unnecessary or
prolonged contact with hot pans and objects.
Terreon®and panel maintenance
The bowl, sprayhead and pedestal end caps are made of Terreon®, a solid cast polyester resin
material. Terreon®resists chemicals, stains, burns and impact, and is repairable with everyday cleaners or
fine-grit abrasives. The panel is made of stainless steel. With regular cleaning, your MG-2/TT Express®will
provide years of dependable service.
Stainless Steel Access Panel cleaning
Stainless steel is extremely durable, and maintenance is simple and inexpensive. Proper care, particularly
under corrosive conditions, is essential. Ordinary deposits of dirt and grease are quickly removed with soap
and water. Whenever possible, the metal should be thoroughly rinsed and dried after washing. To remove
tightly adhering deposits, use stainless steel polishing powder. In all cases, rub in the direction of the stainless
steel grain.
IMPORTANT: Never use ordinary steel wool or steel brushes on stainless steel. Always use
stainless steel wool or stainless steel brushes.
Avoid prolonged contact with chlorides, bromides, thiocyanates, and iodides on stainless steel equipment,
especially if acid conditions exist. Do not permit salty solutions to evaporate and dry on stainless steel. The
appearance of rust streaks on stainless steel leads to the belief that the stainless steel is rusting. Look for the
source of the rust in some iron or steel particles which may be touching, but not actually a part of the stainless
steel structure. NOTE: Strongly acidic or caustic cleaners may attack the steel causing a reddish film to
appear. The use of these cleaners should be avoided.
Terreon®Bowl, Sprayhead and Pedestal End Cap cleaning
IMPORTANT: To sustain original finish, additional care is recommended for dark colored solid
surfaces to maintain highest quality color. The original luster can be maintained by
periodically applying furniture polish, mineral oil or a solid surface cleaner or polish.
For more information on restoring dark colors, see Bradley document #1505. Length
of time between applications varies with usage.
• Forregularcleaning,usestandardcommercialorhouseholdproductssuchasFormula409®or Windex®.
• RemovetoughstainswithAjax®, Comet®or Soft-Scrub®and a green Scotch-Brite®pad or lightly sand in a
circular motion with 240 grit wet/dry sandpaper. The finish can be renewed with a maroon Scotch-Brite®pad.
• RemovescratcheswithagreenScotch-Brite®pad. The finish can be renewed with a maroon Scotch-
Brite®pad. Remove hard water build-up with a mild solution of vinegar and water.
* Use of brand names is intended to indicate a type of cleaner and does not constitute an endorsement.
** It is emphasized that all products should be used in strict accordance with package instructions.
• Repair kit: A repair kit is available from Bradley to repair/patch the Terreon®bowl and shelf. Contact your
Bradley representative to order a repair kit and be sure to specify color.

Express®Lavatory System - MG-Series with TouchTime®Control
Installation MG-2/TT
Bradley • 215-1480 Rev. G; ECN 13-08-025 4/9/2014 15
Assembly of Components
SPRAYHEAD BODY
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
BOWL
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
END CAP (RIGHT)
(PART NUMBER VARIES WITH
COLOR OF UNIT. CONTACT
YOUR LOCAL BRADLEY REP.
FOR ASSISTANCE).
END CAP (LEFT)
(PART NUMBER VARIES
WITH COLOR OF UNIT.
CONTACT YOUR LOCAL
BRADLEY REP. FOR
ASSISTANCE).
SPRAYHEAD
MOUNTING BOLTS (3)
STAINLESS STEEL
ACCESS PANEL
186-1263
Figure 9

Express®Lavatory System - MG-Series with TouchTime®Control
MG-2/TT Installation
16 4/9/2014 Bradley • 215-1480 Rev. G; ECN 13-08-025
Assembly of Components continued . . .
Sensor assembly and solenoid valve access
• Toaccesssolenoids:
Using a ⁵⁄₃₂" Allen socket wrench, loosen, but do not remove the three bottom access panel screws. Remove
the two top access panel screws and washers securing the panel to the frame and remove the access panel
(see Figure 3 on page 8). Solenoids are located on left side of frame (see Figure 10).
•To remove sprayhead:
Remove (3) bolts located underside of bowl neck (see Figures 9 and 11). Carefully remove sprayhead from
bowl.
•To access sprayhead/aerator/lens and sensor assembly:
Remove (2) screws and washers from the access plate assembly using a ¹⁄₈" Allen socket wrench. The access
plate assembly is located underneath the sprayhead (2) places (see Figure 12 on page 17), the assembly will
drop down to access the lens, sensor, and sensor eyes, housing flow control and tube connector.
Figure 10
Figure 11
SPRAYHEAD BODY
MOUNTING LOCATION
TO BOWL (3) PLACES
SPRAYHEAD AERATOR
ASSEMBLY S05-166
NAVIGATOR
MIXING VALVE
FRAME
SOLENOIDS
⁵⁄₁₆" I.D. BRAIDED
HOSE 269-1365

Express®Lavatory System - MG-Series with TouchTime®Control
Installation MG-2/TT
Bradley • 215-1480 Rev. G; ECN 13-08-025 4/9/2014 17
Assembly of Components continued . . .
SPACER
182-115
¼" CONNECTOR
145-089
SCREW-ALLEN SOCKET #10-24
160-138
AERATOR/HOUSING-FLOW
CONTROL
S05-142A
Figure 12
TOUCHTIME®SWITCH
(15-SECOND)
S83-139B
ACCESS PLATE/AERATOR
ASSEMBLY
S05-166
ACCESS PLATE
150-201
NUT
110-115
TouchTime®and Aerator/Access Plate Assemblies
Other replacement parts
110-24 VAC CLASS II
PLUG-IN TRANSFORMER
S83-134

Express®Lavatory System - MG-Series with TouchTime®Control
MG-2/TT Installation
18 4/9/2014 Bradley • 215-1480 Rev. G; ECN 13-08-025
Troubleshooting Solenoid Valve (VAC)
CAUTION: Turn off electrical and water supplies to unit before troubleshooting.
Problem: An individual operating station fails to shut off and drips.
Cause: There is debris trapped between the diaphragm and the valve seat.
Solution: Remove debris between diaphragm and the valve seat.
1. Remove the three #8 Phillips-head screws that hold the solenoid valve assembly together. Be careful not
to lose the armature or spring (see Figure 13 on page 19).
2. Remove the diaphragm. Remove any particles that have been trapped between the diaphragm and the
valve seat. Rinse off the diaphragm and inspect for damage. Make sure the center orifice and both small
side orifices are open.
3. Reassemble in reverse order, being careful not to overtighten the Phillips-head screws or you may crack
the plastic valve body. Tighten until the armature plate makes contact with the plastic body.
4. Reconnect the wiring per diagram on page 12.
Problem: An individual operating station fails to turn on.
Cause: A failed coil for the valve or loose electrical connection to the terminal.
Solution: Test the station to determine cause.
1. Disconnect the wires from the coil of an adjacent valve. Disconnect the wires from the problem valve and
reconnect to the adjacent valve.
2. Turn on electrical and water supplies to the unit. Pass your hand in front of the sensor of the problem
station, and the adjacent station should turn on.
If the adjacent station turns on and cycles normally, replace the coil on the problem valve.
If the adjacent valve fails to turn on, inspect the wires from the sensor cable and do the following:
• makesuretherearenobreaksandthatthefullyinsulateddisconnectterminalsarefirmlycrimpedin
place;
• turnofftheelectricalandwatersupplies;
• reconnecttotheadjacentvalveandturnontheelectricalandwatersuppliestotheunit;
• passyourhandinfrontofthesensor.Ifthestationstillfailstoturnon,replacethesensor
(see page 19).
Troubleshooting – Stop Valve
Problem Cause Solution
Water just
dribbles or does
not flow from
sprayhead
Water supply malfunctioning 1. Close the stops and check the valves that supply water to
the lavatory system.
2. Inspect the stop valves for proper installation.
Water sprayhead
delivers all hot or
cold water
Water supply or mixing valve
malfunctioning
1. Close the stops and check the valves that supply water to
the lavatory system.
2. Inspect the stop valves for proper installation.
3. Inspect mixing valve for proper hot and cold installation. A
red marking indicates the hot inlet.

Express®Lavatory System - MG-Series with TouchTime®Control
Installation MG-2/TT
Bradley • 215-1480 Rev. G; ECN 13-08-025 4/9/2014 19
1
2
3
4
5
6
7
8
9
8DESCRIPTIONQTY.PART NO.REF.
1 1 118-307 VALVE BODY, 1/4" CLOSED
2 1 269-983 DIAPHRAGM
3 1 269-577 ARMATURE
4 1 269-578 SPRING
5 1 269-1729 ARMATURE HOUSING
6 1 269-1730 CLAMP, ARMATURE HOUSING
7 1 269-579 COIL, SOLENOID VALVE
8 3 160-447 SCREW, #8 X 5/8
9 1 125-165 O-RING, #2-013
1 118-307A VALVE BODY, 1/4" THRU
1
Figure 13
Solenoid Valve S07-067 (closed body) and S07-067A (thru body)

Express®Lavatory System - MG-Series with TouchTime®Control
MG-2/TT Installation
20 4/9/2014 Bradley • 215-1480 Rev. G; ECN 13-08-025
Problem Cause Solution
External leaks. Damaged cartridge or O-rings. Replace cartridge with part number 269-1927
Improper water
temperature or
temperature
fluctuation.
Hot water supply is not 10° above desired set point. Increase hot water supply temperature
Valve temperature is not properly set. Adjust the temperature as shown on page 13, step 8.
Limited water
flow.
Dirt and debris have built up in the valve or strainer. 1. Check to make sure both hot and cold supplies are
connected to the Navigator mixing valve and that they
have water flow.
2. Remove cover and U-clip. Remove the cartridge and
clean the strainer. It is not required to grease cartridge,
however if desired, use silicone grease only. Do not use
grease on check valves.
Thermostatic Mixing Valve Troubleshooting
Before attempting to troubleshoot the valve or disassemble the components, check for the following conditions:
• Ifstopvalvesareused,makesurethattheyarefullyopen.
• Makesurethatthehotandcoldinletpipesareconnectedproperly,andthattherearenocross-connectionsor
leaking stop valves.
• Checkthehotwaterheateroutputtomakesurethatitisatleast10°Fabovethesettemperature.
Be sure to close the appropriate shut-off valves prior to disassembly of the valve and reopen the valves after inspection and
repair is complete.
Tempered Line Adapter Option
Part no. S39-804
(replaces S59-4000 if tempered line
is used)
Strainer
(173-028)
Parts List
Item Part No. Description Quantity
S59-4000 S59-4000A S59-4000BY
1 160-463 Cap Screw 1 1 1
2 107-582 Cover 1 1 1
3 269-1927 Thermostatic Cartridge 1 1 1
4 198-014 Check Valve* 2 2 2
5 132-051 Retaining Ring* 2 2 2
6 118-319 Valve Body 1 1 1
7 146-079 U-Clip 1 1 1
* Included with Prepack S65-326
1
2
3
4
5
4
5
7
6
