E19-130
Drench Shower Vertical Supply
Table of Contents
Pre-Installation Information ............................................................ 2
Supplies Required:..........................................................................3
Assemble components....................................................................3
Connect water supply......................................................................3
Assembly of Components and Parts List........................................4

2
E19-130 Installation
7/18/2017 Bradley • 215-152E Rev. S; ECN 17-05-039
WARNING
Flush the water supply lines before beginning installation and after installation is complete. Test
the unit for leaks and adequate water flow. Main water supply to the eyewash should be “ON” at all
times. Provisions shall be made to prevent unauthorized shutoff.
CAUTION
Emergency equipment must be supplied with tepid water (60°F to 100°F/15.6°C to 37.8°C). Any
prolonged exposure to near freezing water affects the body's ability to maintain body temperature,
increasing the risk of hypothermia.
NOTICE
Before installing this product, ensure that there are adequate clearances around the product and
activation of the product does not interfere with other products or obstructions.
Avoid cleaners containing organic solvents, alcohols and hydrocarbons. Rinse with water after
cleaning.
IMPORTANT
The installation and location of all safety drench showers, eye and eye/face washes must comply
with the requirements of ANSI/ISEA Z358.1.
Read this installation manual completely to ensure proper installation, then file it with the owner or
maintenance department. Compliance and conformity to drain requirements and other local codes
and ordinances is the responsibility of the installer.
Separate parts from packaging and make sure all parts are accounted for before discarding any
packaging material. If any parts are missing, do not begin installation until you obtain the missing
parts.
The ANSI/ISEA Z358.1 standard requires an uninterrupted supply of flushing fluid. Bradley plumbed
emergency fixtures require a minimum of 30 PSI (0.21MPa) flowing pressure.
Self-closing spring-loaded valves are not UL classified to ANSI/ISEA Z358.1.
Weekly activation must be conducted on all plumbed emergency equipment to ensure a suitable
flushing fluid supply is present and any sediment build-up in the supply line is cleared. Emergency
equipment should be inspected monthly to address any maintenance issues ensuring the
equipment is in good operating condition and that there are no signs of wear.
Workers who may come in contact with potentially hazardous materials should be trained regarding
the placement and proper operation of emergency equipment per ANSI/ISEA Z358.1.
For questions regarding the operation or installation of this product, visit www.bradleycorp.com or
call 800-BRADLEY (272.3539).
Product warranties and parts information may also be found under ”Products” on our web site at
bradleycorp.com.

3
Installation E19-130
Bradley • 215-152E Rev. S; ECN 17-05-039 7/18/2017
Supplies Required:
• Teflon tape and pipe sealant
• Piping to 1" BSP water supply inlet
• Adequate supply pipe supports
• Minimum 4" (102 mm) drain to accommodate 30 gallons
(115 liters) per minute discharge for shower waste
• Sign-mounting hardware
Assemble components
1. Assemble the components as shown on page 4.
2. Apply pipe sealant to all male-threaded pipe joints.
3. Use a strap wrench around pipes when tightening to
prevent marring.
4. The bottom edge of the showerhead should be
2134mm (7'-0") from the floor.
Connect water supply
NOTICE! Do not rely on Bradley’s Drench Shower to support
supply piping.
1. Connect water supply piping to 1" BSP inlet on
unit (piping supplied by installer). Provide adequate
supports (supplied by installer) for supply pipe using
pipe hangers or other means.
2. Mount the safety sign to the wall using sign-mounting
hardware supplied by installer.
Ø 78.7mm
(3.1")
All dimensions assume standard thread engagement.
Variations in manufacturing allow for +/- 3mm (1/8")
per threaded joint. To find the tolerance of a dimension,
add the number of thread joints in between a
dimension and multiply it by 3mm (1/8").
610mm
(24")
229mm
(9")
2134mm
(7'-0")
to Floor
158mm
(6-1/4")
201mm
(8")

4
E19-130 Installation
7/18/2017 Bradley • 215-152E Rev. S; ECN 17-05-039
Assembly of Components and Parts List
P.O. Box 309, Menomonee Falls,WI 53051
R
TEST THIS UNIT EACH WEEK
Test-operate valve(s) each week and sign below.
Report any malfunctions immediately.
Ventil(e) wöchentlich im Testbetrieb prüfen, bestätigt
durch Unterschrift. Jegliche Störung sofort melden.
Date
Datum
Date
Signed
Unterschrift
Signe
Date
Date
Date Signed
Signed
Signed
DIESES GERÄT 1ST WÖCHENTLICH ZU PRÜFEN.
ESSAI HEBDOMADAIRE
Test le fonctionnement des valves chaque semaine et
signe en bas. S'il y à quelque chose qui ne va pas fait
un rapport immédiatement.
P.O. BOX 309, MENOMONEE FA LLS,WI 53052-0309 USA
TEL: 1-800-BRADLEY FAX: [phone])
http://www.bradleycorp.com
114-050
5
4
3.3
3.11
3.1
3
2
1
3.2
3.5
NOTE: Items 31.1–3.5 come preassembled as Item 3.
1" BSP
Supply Inlet NOTE: BSP threads are noted
with black line on threads.
NOTE: Use
teflon tape
only.
Item Part No. Qty. Description
1 S24-188 1 Plastic Showerhead Assembly
2 128-156A 1 Pull Rod - 24" Long
3 S30-060B 1 Stay-Open Ball Valve
Assembly 1" BSP
3.1 S27-278B 1 Ball Valve with Jam Nut
3.11 110-214 1 Jam Nut (only)
Item Part No. Qty. Description
3.2 153-489 1 Adapter
3.3 128-202 1 Handle
3.5 124-048 1 Washer
4 204-421 1 Emergency Tag
5 114-050E 1 Safety Sign
