LVLD1
Verge®Lavatory System – LVLD-Series
with Evero®Natural Quartz Material
WARNING
Turn OFF electrical power to the electrical outlets, then unplug all electrical units prior to installation.
Electrical power MUST remain off until installation is complete.
Installer’s hardware must be appropriate for wall construction. Wall anchors must have a minimum pull-out
rating of 1,000 lbs. NOTICE
Make sure that all water supply lines have been flushed and then completely turned off before beginning
installation. Debris in supply lines can cause valves to malfunction.
IMPORTANT
Read this entire installation manual to ensure proper installation. When finished with the installation, file
this manual with the owner or maintenance department. Compliance and conformity to local codes and
ordinances is the responsibility of the installer. Product warranties may be found under “Products” on our
Web site at bradleycorp.com.
Separate parts from packaging and make sure all parts are accounted for before discarding any packaging
material. If any parts are missing, do not begin installation until you obtain the missing parts.
For standard height mounting, do not exceed the recommended 34" distance from the top of the lav deck
to the finished floor. To meet ADA requirements, the lav deck cannot exceed the 34" maximum height
dimension.
Patent Pending
Système lave-mains Verge®– Série LVLD
avec matériau au quartz naturel Evero®
Brevet en instance
Sistema de lavabo Verge®– Serie LVLD
con material de cuarzo natural Evero®
Patente pendiente

LVLD1 Installation
26/2/2016 Bradley • 215-1777 Rev. F; ECN 16-08-008
Table of Contents
Components ................................................................................................................................................................................. 3–4
Supplies Required ............................................................................................................................................................................ 5
Dimensions................................................................................................................................................................................... 5–6
Rough-Ins ......................................................................................................................................................................................... 7
Frame Mounting................................................................................................................................................................................ 8
Faucet Box and Valve Mounting ....................................................................................................................................................... 9
Overflow Plug Assembly................................................................................................................................................................... 9
Drain Assembly .............................................................................................................................................................................. 10
Faucets and Optional Soap Valve .................................................................................................................................................. 10
Bowl Mounting................................................................................................................................................................................ 11
Strainer and P-trap ......................................................................................................................................................................... 11
Adjust Temperature......................................................................................................................................................................... 12
Trap Cover ...................................................................................................................................................................................... 12
Cleaning and Maintenance............................................................................................................................................................. 13
Table des matières
Composants .............................................................................................................................................................................. 15-16
Fournitures requises....................................................................................................................................................................... 17
Dimensions................................................................................................................................................................................ 17-18
Raccordements .............................................................................................................................................................................. 19
Montage du bâti.............................................................................................................................................................................. 20
Fixation du boîtier de batterie et de la vanne................................................................................................................................. 21
Assemblage du bouchon de trop-plein........................................................................................................................................... 21
Assemblage de l’écoulement.......................................................................................................................................................... 22
Robinets et vanne à savon en option............................................................................................................................................. 22
Fixation de la vasque ..................................................................................................................................................................... 23
Tamis et siphon en P...................................................................................................................................................................... 23
Fair couler l'eau pour régler la température ................................................................................................................................... 24
Couvre-siphon ................................................................................................................................................................................ 24
Nettoyage et entretien .................................................................................................................................................................... 25
Contenido
Componentes ............................................................................................................................................................................ 27-28
Materiales necesarios .................................................................................................................................................................... 29
Dimensiones............................................................................................................................................................................. 29–30
Colocación de las tuberías empotradas......................................................................................................................................... 31
Montaje de la estructura................................................................................................................................................................. 32
Montaje de la caja de la llave y de la válvula................................................................................................................................. 33
Conjunto de tapón contra desbordes ............................................................................................................................................. 33
Conjunto de desagüe ..................................................................................................................................................................... 34
Llaves y válvula de jabón opcional................................................................................................................................................. 34
Montaje de la palangana................................................................................................................................................................ 35
Filtro y sifón en P ........................................................................................................................................................................... 35
Adjuste la temperatura ................................................................................................................................................................... 36
Cubierta del sifón ........................................................................................................................................................................... 36
Limpieza y mantenimiento.............................................................................................................................................................. 37

Installation LVLD1
Bradley • 215-1777 Rev. F; ECN 16-08-008 6/2/2016 3
Components
Frame
(S17-375)
Access Panel
(186-1878)
Complete Hardware Prepack (S45-2473)
Frame Mounting Qty.
Washer, Square 9 (4 extra)
Washer, Flat 1" O.D. 2
Bowl-To-Frame (S45-2481) Qty.
Screw, ¼-20 x ½" 3 (1 extra)
Washer, Flat ⁵⁄₈" O.D. 3 (1 extra)
Trap Cover (S45-2482) Qty.
Screw, 10-24 x ½" 6 (2 extra)
#10 Finishing Washer 6 (2 extra)
Trap Hook Bracket 1
Screw, 10-24 x 3⁄8" 1
Washer, Flat 35⁄64" O.D. 1
Bowl
Contact your Bradley Representative for color options
Complete Drain Prepack
(S45-2811)
O-Ring
(125-111)
Drain
Adapter
Packing
Washer
#10-24
Screw
Drain
Adapter
Prepack
(S45-2480)
Chrome P-trap (S29-094)
Plastic P-trap (269-1697)
Prepack
(S45-2810) *Screw
Strainer
*Standoff, Hex,
SS #6-32 x 1"
*Screw #6-32
x 1-1/4" Pan
*Included in
Prepack S45-2778
TMV Valve
(½" NPTM
Outlet)
(S45-2701)
Hose Prepack
(S45-2730)
Supply
Fittings
(S45-2712)
Hose Prepack
(S45-2702)
TMV Supply
Connections
Tempered Supply
Connections
Plastic Hose
Plastic
Hose

LVLD1 Installation
46/2/2016 Bradley • 215-1777 Rev. F; ECN 16-08-008
Components
IR-DCD Faucet*
(S53-336)
CAP-DCA Faucet**
(S53-334)
Battery Box Prepack
(S45-2508)
(includes bracket and
mounting hardware)
Battery Box for
CAP-DCA Faucets
6315-KT0000 Soap Dispenser 6324-68 Soap Dispenser 6334 Soap Dispenser
Optional
Transformer
Plug-In Transformer
Option (PT) for
IR-DCD Faucet
(S53-337)
Plug-in transformer option (PT)
includes Transformer (S53-338),
Adapter (S53-339), and Grounding
Kit (S53-349) for CAP-DCA Faucets
0.35 GPM aerator
(S05-209)
(required/included with IR-DCD
and CAP-DCA Faucets)
IR-DCG Faucet*
(S53-350)
0.35 GPM aerator
(S05-213)
(required/included
with IR-DCG faucet)
Plug-In Transformer
Option (PT) for
IR-DCG Faucet
(153-486)
*Adapter included with faucet (TMV: S45-2872, TL: S45-2871) *Adapter included with faucet (TMV: S45-2872, TL: S45-2871)
**Adapter S45-2873 included with faucet

Installation LVLD1
Bradley • 215-1777 Rev. F; ECN 16-08-008 6/2/2016 5
20-3/4"
(527mm)
Dimensions
Top View
Front View
Supplies Required
• (7) 3⁄8" fasteners and wall anchors (minimum pull-out rating of 1,000 lbs.)
• 1/2" hot/cold or tempered supply piping
• 1-1/2" NPT drain piping
• OPTIONAL: 110 volt GFCI protected electrical outlet for 100–120 VAC plug-in transformer (for Bradley Faucets)
• Screen filter(s) as needed, if not included with faucet(s)
15"
(381mm)
5-1/2"
(140mm)
19-1/2"
(495mm)
6-1/2"
(165mm)
6-1/4"
(159mm)
10-3/4"
(273mm)
30"
(762mm)
29-1/2"
(749mm)

LVLD1 Installation
66/2/2016 Bradley • 215-1777 Rev. F; ECN 16-08-008
Dimensions – Side View
33-3/4"
(857mm)
27"
(686mm)
10-5/16"
(262mm)
12-13/16"
(325mm)
ADA Standard
and TAS Height
Juvenile and TAS,
Grades 6 thru 12
20-1/8"
(511mm)
34-1/2"
(876mm)
8-5/16"
(211mm)
8" (203mm)
30-3/4"
(781mm)
24"
(610mm)
8" (203mm)
17-1/8"
(435mm)
12-13/16"
(325mm)
10-5/16"
(262mm)
8-5/16"
(211mm)
31-1/2"
(800mm)
14-3/4"
(375mm)
14-3/4"
(375mm)

Installation LVLD1
Bradley • 215-1777 Rev. F; ECN 16-08-008 6/2/2016 7
C
34-1/4"
(876mm)
Ref.
B
A
D
E
26-3/4"
(679mm)
H
32-1/2"
(826mm)
21-1/4"
(540mm)
A
B
B
B
Finished Floor
B
Standard rough-in shown.
RIM HEIGHT VERTICAL HEIGHT ADJUSTMENTS
FOR CODES A–E and H FIXTURE STYLE
33-3/4" None Standard Height, ADA and TAS
30-3/4" Subtract 3" ADA Juvenile and TAS, Grades 6 thru 12
CODE DESCRIPTION QTY.
A 3⁄8" Bowl Anchors with a Minimum Pull-Out Force of 1,000 lbs. (reinforce walls at anchor points) 2
B 3⁄8" Frame Anchors with a Minimum Pull-Out Force of 1,000 lbs. (reinforce walls at anchor points) 5
H, C 1/2" Hot/Cold Supplies, Stub-Out 2" From Wall 1
D 110v GFI Protected Electrical Outlet (AC version only) 1
E 1-1/2" NPT Drain, Stub-Out 2" from Wall 1
F #10 Anchors for Valve Bracket Installation 2
17-1/2"
(445mm)
1-3/4"
(44mm)
2-1/8"
(54mm)
4"
(102mm)
3"
(76mm)
32-1/8"
(816mm)
23-9/16"
(587mm)
8-3/4"
(222mm)
6-3/16"
(181mm)
Rough-Ins
26"
(660mm)
13"
(330mm)
Areas marked with a crosshatch
require sufficient backing compliant
with local building codes.
C
L
FF

LVLD1 Installation
86/2/2016 Bradley • 215-1777 Rev. F; ECN 16-08-008
Frame Mounting
16"
(406mm)
centers
13"
(330mm)
A
Finished Floor
Drywall
Support Backing Mounting
Height "A" Dimension
Standard Height, ADA and TAS 20" (508mm)
ADA, Juvenile and TAS, Grades
6 thru 12 17" (432mm)
19-1/2"
(279mm)
Typical installation is shown. It may be necessary to repair the wall
after mounting. The fixture may not cover all of the wall modifications.
1
The frame and the bowl
must be adequately
supported.
A
Drain, supplies and electrical box are
shown in their approximate locations.
Cut clearance holes in the backing as
required.
NOTE: Backing should equal the
thickness of the drywall (½" minimum).
B
If needed, shim the
frame at anchor points to
ensure the offset bracket
is straight. Leave the
top screw loose for bowl
installation.
C
Use 3/8" fasteners and square washers
provided to secure the frame to the backing
(5) places. Shim frame as necessary.
D
Fasteners (supplied by installer)
to secure backing to studs

Installation LVLD1
Bradley • 215-1777 Rev. F; ECN 16-08-008 6/2/2016 9
Mount the faucet box onto
the bracket with valve
positioned toward the wall
(if applicable).
A
NONE Option
Plastic
Hose
WARNING! Water supply to Battery Box
Solenoid MUST be supplied
using a plastic hose (provided
by Bradley).
Mounting Faucet Box and Valve to Frame
2
Overflow Plug Assembly
3
Hang the faucet box bracket onto the
frame in the orientation shown. Piping
connection of box should point toward
the back of the unit (see faucet
installation instructions for assembly)
B
Assemble overflow drain
cap to basin as shown.
A
Secure the TMA valve to the wall
at the location shown using (2) #10
fasteners. See rough-in section for
valve rough-in location.
C
Outlet to battery box.
Use 1/2" plastic supply
hose.
Assemble the shutoff valves to
the hot and cold supplies. Attach
stainless steel 1/2" supply hoses
from the hot and cold shutoff valves
to the TMA valve.
D
O-Ring (125-111)
Overflow plug
Packing Washer
Overflow Plug Prepack
(S45-2812)
#10-24 Screw

LVLD1 Installation
10 6/2/2016 Bradley • 215-1777 Rev. F; ECN 16-08-008
O-Ring
Drain
Adapter
Packing
Washer
#10-24
Screw
For ease of drain installation, lay the bowl on its back.
For ease of installation, leave
the bowl laying on its back.
4Drain Assembly
5Faucets and Optional Soap Valve
Remove and discard
existing 0.5 GPM aerator
and replace with .35
GPM 1.3L/min aerator
(included).
A
Install the faucets and optional
soap valves according to
manufacturer's instructions.
B
Bradley Model 6315 Soap
Dispenser is shown
#6-32 x 1-1/4"
Screw
Standoff, Hex
SS #6-32 x 1"
Thread screw into drain
adapter until it becomes
fully engaged.
A
Thread the standoff onto
the now fully engaged
screw.
B

Installation LVLD1
Bradley • 215-1777 Rev. F; ECN 16-08-008 6/2/2016 11
Washer
1/4"-20
Screw
Secure the bowl to the
wall using the 1" O.D.
flat washers (supplied by
Bradley), 3/8" fasteners
and 3/8" anchors
(supplied by installer).
B
Bowl Mounting (to Frame and Wall)
6
Press firmly on the back of
the bowl to seat the bowl
into the frame.
Tighten the top screw on
the frame.
A
Strainer and P-Trap
7
Attach the strainer screw
to the strainer. Do not
overtighten.
A
Strainer
Thread the strainer screw
through the boss on the
drain adapter and secure
the strainer to the bowl.
B
Check to be sure the
basin is level.
C

LVLD1 Installation
12 6/2/2016 Bradley • 215-1777 Rev. F; ECN 16-08-008
Adjust Temperature with Water Running
H
C
ALoosen Cap Screw about 1/4" (4-6
turns) and lift up cover (do not
remove).
BUsing cover, turn cartridge gently until
desired water temperature is reached.
Do not turn past stops as this may
damage unit. Push cover down and
tighten screw.
This valve is NOT factory preset.
Upon installation, the temperature
of this valve must be checked and
adjusted to ensure delivery of a
safe water temperature. Water
in excess of 110°F (43°C) may
cause scalding.
8
Hook
#10-24
Screw
Washer
#10-24
Flat Head
Screw
Finishing
Washer
Make all connections before installing trap cover.
Trap Cover
9
Hang the trap cover onto
the hook, then secure the
trap cover with the screws
provided, starting with the
side screws.
A

Installation LVLD1
Bradley • 215-1777 Rev. F; ECN 16-08-008 6/2/2016 13
Cleaning and Maintenance for Evero
Material Description: Evero Natural Quartz Material is made from a blend of acrylic modified bio-based polyester resin, natural
quartz and other materials and is resistant to chemicals, stains, burns and impact. Surface damage can be easily repaired with
everyday cleansers or fine grit abrasives.
Routine Cleaning: For regular cleaning, use standard commercial or household products such as Simple Green®, Creamy
Cleanser brand, Formula 409®or Windex®.
Stubborn Stains: Remove tough stains, with non abrasive cleaners and pads such as a white Scotch Brite®pad and Lysol®.
Special Situations for Evero Material
Hard Water Deposits: Remove hard water deposits with a mild solution of vinegar and water. Always rinse the unit thoroughly
after cleaning.
Restoring the surface: Refresh and restore the rich surface with one of the following:
Geo Series: Color enhancer such as Tenax®Ager
Pearl Series: Impregnating sealer such as DryTreat Stain - Proof Original™ or Miracle Sealants 511 Impregnator
NOTICE! Do not use strong acid or alkaline chemicals and cleansers to clean Evero. If these chemicals
come in contact with the surface, wipe them off immediately and rinse with soapy water. Avoid
contact with harsh chemicals such as paint remover, bleach, acetone, etc. Avoid contact with hot
pans and objects.
Repair Kits: Evero repair kits are available. Contact your Bradley representative or distributor for part numbers and pricing.
Repair kits are made to order and have a shelf life of 30 days.
Cleaning and maintenance instructions for stainless steel
Material Description: Stainless steel is extremely durable, and maintenance is simple and inexpensive. Proper care, particularly
under corrosive conditions, is essential. Always start with the simplest solution and work your way toward the more complicated.
Routine cleaning: Daily or as often as needed use a solution of warm water and soap, detergent, or ammonia. Apply the cleaning
solution per the manufacturer’s instructions and always use a soft cloth or sponge to avoid damaging the finish.
Stubborn Stains: To remove stains from stainless steel use a stainless steel cleaner and polish such as Ball®stainless steel
cleaner or a soft abrasive. Always follow the manufacturer’s instructions and apply in the same direction as the polish lines.
NOTICE! Never use ordinary steel wool or steel brushes on stainless steel. Always use stainless steel wool
or stainless steel brushes.
Special Situations for Material
Fingerprints and Smears: To remove fingerprints or smears use a high quality stainless steel cleaner and polish in accordance
with the manufacturer’s instructions. Many of these products leave a protective coating that helps prevent future smears and
fingerprints.
Grease and Oil : To remove grease and oil use a quality commercial detergent or caustic cleaner. Apply in accordance to the
manufacturer’s instructions and in the direction of the polish lines.
Precautions: Avoid prolonged contact with chlorides (bleaches, salts), bromides (sanitizing agents), thiocyanates (pesticides,
photography chemicals, and some foods), and iodides on stainless steel equipment, especially if acid conditions exist.
NOTICE! Do not permit salty solutions to evaporate and dry on stainless steel.
The appearance of rust streaks on stainless steel leads to the belief that the stainless steel is rusting. Look for the actual source
of the rust in some iron or steel particles which may be touching, but not actually a part of the stainless steel structure.
NOTICE! Strongly acidic or caustic cleaners may attack the steel, causing a reddish film to appear. The use
of these cleaners should be avoided.
Brand Names: Use of brand names is intended only to indicate a type of cleaner. This does not constitute an endorsement, nor
does the omission of any brand name cleaner imply its inadequacy. Many products named are regional in distribution, and can be
found in local supermarkets, department and hardware stores, or through your cleaning service. It is emphasized that all products
should be used in strict accordance with package instructions.
Evero is a unique cast material. Aggregate flow and distribution as well as shades of color can vary from
product to product creating natural characteristics.

LVLD1 Installation
14 6/2/2016 Bradley • 215-1777 Rev. F; ECN 16-08-008
AVERTISSEMENT
Couper l’alimentation électrique des prises de courant, puis débrancher tous les appareils électriques avant
de procéder à l’installation. L’alimentation électrique doit IMPÉRATIVEMENT être coupée jusqu’à la fin de
l’installation.
La visserie de l’installateur doit être adaptée à la nature du mur. Les ancrages muraux doivent avoir une
résistance nominale à l’arrachement d’au moins 1 000 lb (4,45 kN).
AVIS
S’assurer que toutes les conduites d’arrivée d’eau ont été purgées puis correctement fermées avant de
commencer l’installation. La présence de débris dans les conduites peut causer un mauvais fonctionnement
des vannes. IMPORTANT
Veiller à lire ce manuel en entier pour assurer une installation correcte. Lorsque l’installation est terminée,
remettre ce manuel au propriétaire ou au service d’entretien. La mise en conformité et le respect de la
réglementation en vigueur relèvent de la responsabilité des installateurs. Les garanties de produit peuvent
être trouvées sous « Products » sur notre site Web à www.bradleycorp.com
Déballer les pièces et s’assurer qu’elles sont toutes présentes avant de jeter les emballages. Le cas échéant,
ne pas commencer l’installation avant d’avoir obtenu toutes les pièces manquantes.
Pour les poses de hauteur standard, ne pas dépasser la distance conseillée de 34" (864mm) entre le dessus
du rebord de lavabo et le sol fini. Pour être conforme aux exigences ADA, le rebord de lavabo ne devra pas
dépasser la hauteur maximale de 34" (864mm).

Installation LVLD1
Bradley • 215-1777 Rev. F; ECN 16-08-008 6/2/2016 15
Composants
Bâti (S17-
375)
Panneau d’accès
(186-1878)
Trousse de quincaillerie complète (S45-2473)
Montage du bâti Qté
Rondelle carrée 9 (4 en plus)
Rondelle plate 1" dia. ext. 2
Vasque-bâti (S45-2481) Qté
Vis 1/4-20 x 1/2" 3 (1 en plus)
Rondelle plate" 5/8 dia. ext. 3 (1 en plus)
Couvre-siphon (S45-2482) Qté
Vis 10-24 x 1/2" 6 (2 en plus)
Rondelle de finition n° 10 6 (2 en plus)
Crochet support de siphon 1
Vis 10-24 x 3⁄8" 1
Rondelle plate 35⁄64" dia. ext. 1
Vasque
Se renseigner sur le choix de couleurs auprès
du représentant Bradley.
Trousse d’écoulement
complète (S45-2811)
Joint torique
(125-111)
Adaptateur
d’écoulement
Bague
d’étanchéité
Vis n°
10-24
Trousse
adaptateur
d’écoulement
(S45-2480)
Siphon en P chromé (S29-094)
Siphon en P en plastique (269-1697)
Vanne TMV
(Sortie ½" NPTM)
(S45-2701)
Trousse tuyaux
(S45-2730)
Raccords
d’alimentation
(S45-2712)
Trousse tuyaux
(S45-2702)
Raccordements
d’alimentation
TMV
Raccordements
d’alimentation tempérée
Tuyau en
plastique
Tuyau en
plastique
Trousse
(S45-2810) * Vis
Tamis
* Entretoise hexa,
inox #6-32 x 1"
* Vis cylindrique
bombée n°6-32 x
1-1/4"
* Inclus dans la
trousse S45-2778

LVLD1 Installation
16 6/2/2016 Bradley • 215-1777 Rev. F; ECN 16-08-008
Composants
Robinet IR-
DCD (S53-336)
Robinet CAP-DCA
(S53-334)
Trousse boîtier de
batterie
(S45-2508)
(comprend le support et
la visserie de fixation)
Boîtier de batterie pour
robinets CAP-DCA
Distributeur de savon
6315-KT0000 Distributeur de savon
6324-68
Distributeur de savon
6334
Transformateur
en option
L’option à
transformateur à fiche
(PT) pour robinet
IR-DCD
(S53-337)
L’option à transformateur à fiche (PT)
comprend le transformateur (S53-338),
l’adaptateur (S53-339) et le nécessaire
de mise à la terre (S53-349) pour les
robinets CAP-DCA
Aérateur 0,35 GPM
(S05-209)
(requis/fourni avec les robinets
IR-DCD et CAP-DCA)
Robinet IR-DCG
(S53-350)
Aérateur 0,35 GPM
(S05-213)
(requis/fourni avec les
robinets IR-DCG)
L’option à
transformateur à fiche
(PT) pour robinet
IR-DCG
(153-486)
*l’adaptateur fourni avec le robinet (TMV: S45-2872, TL: S45-2871) *l’adaptateur fourni avec le robinet (TMV: S45-2872, TL: S45-2871)
**l’adaptateur (S45-2873) fourni avec le robinet
l’adaptateur fourni avec le robinet

Installation LVLD1
Bradley • 215-1777 Rev. F; ECN 16-08-008 6/2/2016 17
Dimensions
Vue de dessus
Vue de face
Fournitures requises
• Sept (7) chevilles d’ancrage et vis de 3⁄8" (résistance nominale à l’arrachement d’au moins 1000 lb)
• Tuyauterie d’alimentation d’eau chaude/froide ou tempérée ½"
• Tuyauterie d’écoulement 1½" NPT
• EN OPTION : Prise électrique 110 V à disjoncteur à protection DDFT (GFCI) pour transformateur à fiche 100–120
VCA (pour robinets Bradley)
• Filtre(s) à tamis selon les besoins, si non fourni(s) avec le(s) robinet(s)
20-3/4"
(527mm)
15"
(381mm)
5-1/2"
(140mm)
19-1/2"
(495mm)
6-1/2"
(165mm)
6-1/4"
(159mm)
10-3/4"
(273mm)
30"
(762mm)
29-1/2"
(749mm)

LVLD1 Installation
18 6/2/2016 Bradley • 215-1777 Rev. F; ECN 16-08-008
Dimensions — Vue de côté
33¾"
(857mm)
27"
(686mm)
10⁵⁄₁₆"
(262mm)
12¹³⁄₁₆"
(325mm)
Hauteur ADA
standard et TAS
Enfant et TAS, 6e
à 12e années
20¹⁄₈"
(511mm)
34½"
(876mm)
8⁵⁄₁₆"
(211mm)
8" (203mm)
30¾"
(781mm)
24"
(610mm)
8" (203mm)
17¹⁄₈"
(435mm)
12¹³⁄₁₆"
(325mm)
10⁵⁄₁₆"
(262mm)
8⁵⁄₁₆"
(211mm)
31½"
(800mm)
14¾"
(375mm)
14¾"
(375mm)

Installation LVLD1
Bradley • 215-1777 Rev. F; ECN 16-08-008 6/2/2016 19
C
34½"
(876mm)
Réf.
B
A
D
E
26¾"
(679mm)
H
32½"
(826mm)
21¼"
(540mm)
A
B
B
B
Plancher fini
B
Raccordements standard représentés.
HAUTEUR
DU REBORD AJUSTEMENTS DE LA HAUTEUR POUR LES CODES A–E et H TYPE D’APPAREIL
33¾" (857mm) Aucun Hauteur standard, ADA et TAS
30¾" (781mm) Retrancher 3" (76mm) ADA, enfant et TAS, 6e à 12e années
CODE DESCRIPTION QTÉ
AChevilles d’ancrage de vasque de 3/8" d’une résistance minimale à l’arrachement de 1 000 lb
(renforcer les murs aux points d’ancrage) 2
BChevilles d’ancrage de bâti de 3/8" d’une résistance minimale à l’arrachement de 1 000 lb
(renforcer les murs aux points d’ancrage) 5
H, C Arrivées d’eau chaude/froide de 1/2", tubulure à 2" (51mm) du mur 1
D Prise électrique 110 V à disjoncteur à protection DDFT (GFI) (version courant secteur seulement) 1
E Écoulement 1-1/2" NPT, tubulure à 2" (51mm) du mur 1
F Chevilles d’ancrage n° 10 pour l’installation du support de vanne 2
17½"
(445mm)
1¾"
(44mm)
2¹⁄₈"
(54mm)
4"
(102mm)
3"
(76mm)
32¹⁄₈"
(816mm)
23⁹⁄₁₆"
(587mm)
8¾"
(222mm)
6³⁄₁₆"
(181mm)
Raccordements
26"
(660mm)
13"
(330mm)
Les surfaces hachurées nécessitent
un renfort suffisant conforme au
code du bâtiment en vigueur.
FF
C
L

LVLD1 Installation
20 6/2/2016 Bradley • 215-1777 Rev. F; ECN 16-08-008
Montage du bâti
16"
(406mm)
entre
centres
13"
(330mm)
A
Plancher fini
Cloison sèche
Hauteur de pose des renforts Dimension « A »
Hauteur standard, ADA et TAS 20" (508mm)
ADA, enfant et TAS,
6e à 12e années 17" (432mm)
19.5"
(279mm)
Installation typique représentée. Il peut être nécessaire de réparer le mur après la pose.
Il est possible que l’appareil ne masque pas toutes les modifications apportées au mur.
1
Le bâti et la vasque doivent
avoir un support suffisant.
A
L’écoulement, les arrivées et le boîtier électrique
sont représentés à leurs emplacements
approximatifs. Découper des trous de
dégagement dans le renfort comme il se doit.
REMARQUE : Le renfort doit être de même
épaisseur que la cloison sèche (½" minimum).
B
Le cas échéant, placer
des cales sous le bâti
aux points d’ancrage
pour s’assurer que la
console de support est
droite. Laisser la vis
supérieure desserrée pour
l’installation de la vasque.
C
Utiliser des vis de ³⁄₈" et des rondelles
carrées pour attacher le bâti au renfort à
cinq (5) emplacements. Placer des cales
sous le bâti comme il se doit.
D
Visserie (fournie par
l’installateur) pour attacher le
renfort aux montants
