BROSA Baker Lamp Table User manual

ASSEMBLY GUIDE
Baker Lamp Table
v1.0

Components
E x 4
(Dowel)
(Ø8 x 30)
B x 8
(M6 Short Bolt)
(M6 x 35)
C x 1
(Allen Key)
(M4 x 30 x 107)
A x 2
(Long Bolt)
(M8 x 80)
Hardware
What you need
Leg x 1
Leg Base
Upper Part x 1
Leg Base
Lower Part x 1
Mounting
Plate x 1
Table Top x 1
Before you get started, check you have all of the pieces below. If anything’s
missing, please visit www.brosa.com.au/pages/product-return-and-parts-request
and we’ll sort it out right away.
1
2
3
4
5
D x 2
(M8 Short Bolt)
(M8 x 35)

Step 1 1.1 Insert two dowels (E) into the diagonal holes of
the mounting plate (2).
1.2 Insert two dowels (E) into the diagonal holes at
the top of the leg base upper part (4).
1.3 Align the leg (3) with the mounting plate (2) and
attach the parts together. Secure them with M8
short bolts (D) using the Allen key (C).
1.4 Align the leg (3) with the leg base upper part (4)
and attach the parts together.
E x 4
C x 1
D x 2
4
E
2 E
C
D
D
2
3
4
Step 1.1
Step 1.2
Step 1.3
Step 1.4

Step 2 Align the leg base lower part (5) with the upper part
(4) and attach the parts together. Secure them with
long bolts (A) using the Allen key (C).
A x 2
2
3
4
5
A
C
C x 1

Step 3 Align the formed leg structure with the underside of
the table top (1) so that the holes overlap. Secure
them with M6 short bolts (B) using the Allen key (C).
C x 1
B x 8
1
B
C
5
4
3
2

Step 4 Place the table upright on a level surface.
Enjoy your new lamp table!
