BROSA Hans Console Table with Drawers User manual

ASSEMBLY GUIDE
Hans Console Table with Drawers
v1.0

Components
Upon unpacking your table from it’s delivery box, you should have the
separate pieces shown below. Follow the steps on the next pages to assemble
your new table.
A x 4
(Cross Dowel)
B x 4
(Threaded Bolt)
C x 4
(Washer)
D x 4
(Lock Washer)
E x 4
(Hex Nut)
F x 1
(Spanner)
Hardware
What you need
Leg x 4Table top x 1

Step 1 Insert the cross dowel (A) into the top hole of the leg
so that the side marker faces the bolt hole. Repeat
for all four legs.
Step 2 Screw the threaded bolt (B) into the corner hole.
Repeat for all four legs.
A x 4
B x 4
A
BB

Step 3 Place the table top on a at surface with underside
facing up. Insert a leg construction formed in previ-
ous steps into a corner opening. Fit a washer (C), a
lock washer (D) then a hex nut (E) to the threaded
bold and tighten with the spanner (F). Repeat for the
remaining legs.
Step 4 Gently ip the table and place on a level surface.
C x 4
D x 4
E x 4
F x 1
B
C
B
D
E
F

Step 5 Turn the twist inside of the drawer to adjust it’s ver-
tical position, so that there are exqual gaps above
and below the front wall.
+2.5
-2.5

UNLOCK
Step 6 To take the drawer out, open it, pull out the Lock
button inside of the drawer. Gently lift the front part
of of the drawer.

Step 7 To put the drawer back in, attach the connector in
the back of the drawer. Gently put down the front
part of of the drawer so that the front connectors
attach. Push back the Lock button inside of the
drawer.
LOCK

Step 8 Enjoy your new table!
