ASSEMBLY GUIDE
Field Triple Open Shelf
v1.0

Components
Before you get started, check you have all of the pieces below. If anything’s
missing, please visit
www.brosa.com.au/pages/product-return-and-parts-request and we’ll sort it
out right away.
Hardware
What you need
A x 9 B x 24 C x 1 aa x 2 bb x 1 cc x 2

Step 1 Align the short back connectors (3) with the side
frames (2) like below diagram. Make sure the bolt
holes overlap. Insert a short bolt (A) into the hole
and tighten it with the Allen key (C). Repeat this for
the remaining holes.
A x 4
C x 1

Step 2 Align the long back connectors (4) with the structure
formed in Step 1 like below diagram. Make sure the
bolt holes overlap. Insert a short bolt (A) into the
hole and tighten it with the Allen key (C). Repeat this
for the remaining holes.
A x 5
C x 1

Step 3 Align the shelves (1) with the structure formed in
Step 2. Make sure the bolt holes overlap. Fit a long
bolt (B) into the hole and tighten it with the Allen
key (C). Repeat this for the remaining holes to x the
shelves in place.
B x 24
C x 1

Step 4 Attaching the shelf to wall with anti-tip kits:
Attach the mounting bracket (aa) horizontally to the
shelf using the short screws (cc).
cc x 2
aa x 1
aa
cc

Step 5 Attaching the shelf to wall with anti-tip kits:
5.1 Determine where the piece is to be placed and
mark location on the wall for the mounting bracket
screw holes.
5.2 Drill the hole and use the appropriate wall plug
that is suitable for your wall composition.
5.3 Attach the mounting bracket (aa) horizontally to
the wall using appropriate fastener, through the
holes in the bracket and 2 wall plugs that are suit-
able to your wall and then tighten securely.
5.4 Lace the nylon strap (bb) down through the
brackets.
Slide the thin end of the strap through the receiving
end on the nylon strap. Pull to tighten the product
snug against wall.
aa x 1
bb x 1
WALL
