BROSA Parc Sideboard User manual

ASSEMBLY GUIDE
Parc Sideboard
v1.0

Components
Upon unpacking your sideboard from it’s delivery box, you should have the
separate pieces shown below. Follow the steps on the next pages to assemble
your new sideboard.
1
2
Sideboard x 1
Leg x 4
A x 8
Spec: 5/16 x 60mm
B x 8
Spec: Ø8 x Ø14mm
D x 8
Spec: Ø3.5 x 11mm
G x 2
Spec: Ø7 x 26mm
H x 2
Spec: 192 x 26mm
E x 2
Spec: Ø3.8 x 32mm
F x 2
Spec: Ø3.8 x 16mm
I x 1
Spec: M5
C x 4
Spec:
Hardware What you need

Step 1
B x 8
I x 1
A x 8
Align a leg (2) to the underside of the sideboard (1) so
that the screw holes are overlapping. Fit a washer (B)
to a bolt (A) and screw into a hole and repeat for the
other bolt to secure the leg in place. Repeat process
for the remaining legs (2) and use the allen key (I) to
tighten all of the bolts (A).
Step 2 Lift the sideboard and turn it upright placing it rmly
down on a level surface. Align a handle (C) to its
corresponding place and secure it with two screws (D).
Repeat for the remaining handles (C).
D x 8
C x 4
1
2
A
I
B
C
D

Step 3 Align a strap (H) to the back of the sideboard and secure
in place with a screw (F). Repeat for the other strap (H).
Step 4 4.1 At the location where the sideboard will be placed,
mark out two holes along the wall where you’ll secure
the straps. With a 7mm drill bit, drill the two holes.
Warning: check the wall for hidden pipes and cables
before drilling holes.
4.2 Insert the expansion bolts (G) into the wall by
hammering it gently into place followed by the screws
(E) to secure the straps to the wall.
H x 2
F x 2
G x 2
E x 2
Step 4.1
Step 4.2
H
F
Ø7
E
G

Step 5 e sideboard is 120cm wide by 82cm high and 47cm
deep and can take up to 60kg maximum weight on top
and 5kg inside each draw. Enjoy your new sideboard!
82.0cm
120.0cm
47.0cm
60KG
MAX
5KG
MAX
