BROSA Haruki Console Table User manual

ASSEMBLY GUIDE
Haruki Extendable Table
v1.0

Components
Upon unpacking your table from it’s delivery box, you should have the
separate pieces shown below. Follow the steps on the next pages to assemble
your new table.
Hardware
What you need
A x 16
Spec:
B x 16
Spec:
C x 3
Spec: Ø4 x 38mm
D x 1
Spec: Spec: Ø10 x 40mm
E x 2
Table top x 1
Corovin storage bag x 1
Leaf x 1
Leg
Type - 1 x 1
Leg
Type - 4 x 1 End apron x 1 End apron x 1
Leg
Type - 2 x 1
Leg
Type - 3 x 1

Step 1 1.1 Insert a steel dowel (A) into each of the holes along
the top of each leg (4, 5, 6 & 7) and secure into place by
screwing the ttings. Make sure that the direction of
the holes on the ttings are facing the correct way as
shown in the diagram.
1.2 Insert a dowel (E) in the middle hole on either side
of end apron (8).
Step 1.1
Step 1.2
A x 16
E x 2

Step 2
B x 4
D x 1
2.1 Align the end apron (9) to legs (6 & 7) so that the
steel dowels (A) t inside the holes of the end apron (9)
and rmly press together.
2.2 Insert a grub screw (B) in each of the four holes on
the end apron (9) and use the allen key (D) to tighten.
Step 3
B x 4
D x 1
3.1 Align the end apron (8) to legs (4 & 5) so that the
steel dowels (A) t inside the holes of the end apron (8)
and rmly press together.
3.2 Insert a grub screw (B) in each of the four holes on
the end apron (8) and use the allen key (D) to tighten.
Step 2.1
Step 2.2
Step 3.1
Step 3.2

B x 4
D x 1
Step 4.1
Step 4.2
Step 4.2
Step 4.3
Step 4 4.1 Align the structure assembled in Step 2 to the
underside of the table top (1) as shown so that the steel
dowels (A) t inside the corresponding holes.
4.2 Insert a grub screw (B) into the two holes on each
side of the structure and use the allen key (D) to tighten.
4.3 Lock the slides.

B x 4
C x 3
D x 1 Step 5.1
Step 5.2
Step 5.3
Step 5.3
Step 5 5.1 Secure end apron (9) to the table top (1) using the
round head screws (C) as shown in the diagram. You will
need a phillips head screw driver to x them into place.
5.2 Align the structure assembled in Step 3 to the
underside of the table top (1) as shown so that the steel
dowels (A) t inside the corresponding holes.
5.3 Insert a grub screw (B) into the two holes on each
side of the structure and use the allen key (D) to tighten.

Step 6 Ensure that you have already locked the slides in Step 4
before righting the table. Please note that when moving
the table you must remove the leaf, close the table top
and lock the slides before shifting. Enjoy your new table!
Step 7 e following steps are instrustions on how to extend
your table. Place the leaf onto a at, stable, clean and
soft surface before unfolding open the two leaf aprons
as shown.

Step 8 Unlock the slides that were locked in Step 4. Extend
the table by lifting the end apron, positioned behind
the front rail, then slide the structure all the way out
as shown.
Step 9 Align the leaf (3) over the side aprons so that the metal
pins on the leaf (3) are facing toward the front rail and
carefully slide it to connect with the front rail.

Step 10 To close the table lift the end apron, positioned behind
the front rail, then slide the structure all the way in,
making sure that the holes on the leaf (3) are aligned
and to the pins on the table top.
Step 11 Enusre that you have locked the slides after closing the
table as shown. When moving the table, remove the leaf,
close the table and lock the slides before shifting.

Step 12 To remove the leaf (3) unlock the slides that were locked
in Step 11 and extend the table by lifting the end apron,
positioned behind the front rail, then slide the structure
all the way out. Gently remove the leaf (3).
Step 13 Fold both leaf aprons at and then place the leaf (3) into
the corovin storage bag (2).

Step 14 14.1 Carefully place the leaf (3) onto the wood support
storage under the table top as shown.
14.2 Close the table by lifting the end apron, positioned
behind the front rail, then slide the structure all the way
in as shown, making sure the holes on the front rail are
aligned to the pins on the table top.
14.3 Lock the sides after closing the table.
Step 14.1
Step 14.2
Step 14.3
