BROSA Edward Bed Frame Base User manual

ASSEMBLY GUIDE
Edward Bed Frame Base
v1.0

5
Components
Upon unpacking your bed from it’s delivery box, you should have the separate
pieces shown below. Follow the steps on the next pages to assemble your new
bed.
Headboard x 1
Slat set x 1
Sideboard x 1
Sideboard x 1
Footboard x 1
Wooden leg x 4 Middle leg x 1 Corner leg x 4
Hardware
What you need
A x 2 B x 2 C x 2 D x 2 E x 1 F x 1 G x 1
1
2
34
5
6 7 8

Step 1 Screw a wooden leg (6) into the hole on the bottom
of the sideboard (2), making sure the plastic washer
is attached to the leg. Repeat for the other sideboard
(3) and footboard (4).
Step 2 Loosen the screws on the sideboards (2) (3) and
footboard (4) using the allen key (E).
2
3
2
3
6
6
E x 1 E
4
4

Step 3 Step 3.1 Hook the headboard (1) to the front end of
both sideboards (2) (3).
Step 3.2 Hook the back end of both sideboards (2) (3)
to the footboard (4).
Step 3.3 Tighten the bolts using the allen key (E).
E x 1
E
Step 3.1
Step 3.2
Step 3.3
Step 3.2
Step 3.3
2
2
3
3
1
1
4
4
E

Step 4 Step 4.1 Unfold the slat set (5) to make a full size slat
set.
Step 4.2 Fit a spring washer (C) to the bolt (A)
(B). Insert the bolt into the
hole on the side face of the middle metal bar, making
sure it protrudes from the other metal bar.
Step 4.3 Fit a nut (D) to the bolt protruding from the
other side and tighten with the allen key (E) and the
spanner (F).
Repeat for the other hole on the middle metal bar.
A x 2
B x 2
C x 2
Step 4.1
Step 4.2 Step 4.3
D x 2
E x 1
F x 1
A
B
E
F
C
D
5

Step 5 Middle leg is not necessary. If sleeping with 2 people
or for additional weight support, we recommend
installing middle leg into corresponding place.
Step 5.1 Unscrew bolts and nuts from the middle leg
(7).
Step 5.2 Align the middle leg with the holes on the
middle bars of the slat set.
Step 5.3 Insert the bolts from the other side.
Step 5.4 Attach the nuts to the bolts and tighten with
the screw driver (G) and spanner (F).
F x 1
G x 1
7
Step 5.1
Step 5.2 Step 5.3 Step 5.4
G
F
7 7

Step 6 Corner legs are not necessary. If sleeping with 2
people or for additional weight support, we recom-
mend installing corner legs into corresponding
places.
Step 6.1 Rest the metal frame on the structure
formed in Step 3.
Step 6.2 Unscrew bolts and nuts from the corner legs
(8) using the screw driver.
Step 6.3 Insert the bolts from the top and tighten
with a screw driver.
G x 1
Step 6.1 Step 6.2
Step 6.3
8
G
G

Step 7 Enjoy your new bed!
