BROSA Hans Sideboard User manual

ASSEMBLY GUIDE
Hans Sideboard
v1.0

Components
Upon unpacking your storage from it’s delivery box, you should have the
separate pieces shown below. Follow the steps on the next pages to assemble
your new storage.
A x 4
(Cross Dowel)
B x 4
(Threaded Bolt)
C x 4
(Washer)
D x 4
(Lock Washer)
E x 4
(Hex Nut)
G x 4
(Shelf Support)
aa x 2
(Mounting Plate)
bb x 1
(Nylon Strap)
cc x 2
(Screw)
F x 1
(Spanner)
Hardware
What you need
Leg x 4
Central
Leg x 1
Shelf x 3
Body x 1
12
3
4

Step 1 Insert the cross dowel (A) into the top hole of the leg
(2) so that the side marker faces the bolt hole.
Repeat for all four legs.
Step 2 Screw the threaded bolt (B) into the corner hole.
Repeat for all four legs.
A x 4
B x 4
A
2
2
B
B

Step 3 Place the storage body (1) on on it’s back. Insert a
leg construction formed in previous steps (2) into a
corner opening. Fit a washer (C), a lock washer (D)
then a hex nut (E) to the threaded bold and tighten
with the spanner (F). Repeat for the remaining legs.
Screw central leg (4) onto the metal plate. Continue
to tighten until it’s securely fastened.
With help of the assistant, carefully stand the unit
uptight.
C x 4
D x 4
E x 4
F x 1
4
2
2
4
2
2
1
B
D
F
E
C

Step 4
J x 8
Insert a pair of shelf supports (J) into the holes on
the one side of the storage compartment. Make sure
that both supports are on the same level. Tilt the
shelf so it ts into the opening. Insert the shelf and
rest on the supports.
While holding the other side higher, insert the
second pair of supports (J) into the facing holes.
Make sure they are on the same height level. Lower
the shelf until it rests securely on all four supports.
Repeat for the other shelfs.
G
3
3
3
G
G

Step 5 hinges if needed.
5.1 Vertical adjustment via slots on mounting plate
by slackening and retightening the screws on the
mounting plate.
5.2 Lateral adjustment by screw adjustent.
5.3 Front-to-Back adjustment by slackening and
retightening the hinge-arm mounting screw.
Step 5.1 Step 5.2
Step 5.3

Step 6 Turn the twist inside of the drawer to adjust it’s ver-
tical position, so that there are exqual gaps above
and below the front wall.
+2.5
-2.5

UNLOCK
Step 7 To take the drawer out, open it, pull out the Lock
button inside of the drawer. Gently lift the front part
of of the drawer.

Step 8 To put the drawer back in, attach the connector in
the back of the drawer. Gently put down the front
part of of the drawer so that the front connectors
attach. Push back the Lock button inside of the
drawer.
LOCK

Step 9 Fix a mounting plate (aa) to the back of the storage
using at head screws (cc).
By using appropriate fastener based upon wall com-
position, x another mounting plate (aa) to the wall.
Connect two plates with the nylon srap (bb).
Tighten the strap so that the table is xed in the
place.
aa x 2
cc x 2
bb x 1
cc
cc
aa
WALL
aa bb
aa

Step 10 Enjoy your new storage!
