CMC AZORP User manual

AZORP™
ISO 9001 Certied
© CMC Rescue, Inc. All rights reserved
CMC and are registered marks of CMC Rescue Inc.
CMC Control No.: 72740X-01IN01_Rev00
CMC Rescue, Inc.
6740 Cortona Drive
Goleta, CA 93117, USA
805-562-9120 / 800-235-5741
cmcpro.com
SAMPLE INSPECTION AND MAINTENANCE LOG
The following sample log provides an example of the records that can be maintained by the
purchaser or user.
EQUIPMENT INSPECTION AND MAINTENANCE LOG
Item______________#______ Date in Service________
Brand/Model_________________ Strength___________
Date How Used or Maintained Comments Name
Find the latest version of this manual at cmcpro.com.

Activities involving the use of this device are potentially dangerous. You are responsible for your
own actions and decisions. Before using this device, you must:
• Read and understand these user instructions, labels, and warnings.
• Familiarize yourself with its capabilities and limitations.
• Obtain specic training in its proper use.
• Understand and accept the risks involved.
FAILURE TO HEED ANY OF THESE WARNINGS MAY RESULT IN SEVERE INJURY OR DEATH.
WARNINGS
Before each use, the user should:
• Conrm the device is functioning properly.
• Verify the presence and legibility of the product markings.
• Verify there is no excessive wear or indications of damage such as deformation, corrosion,
sharp edges, cracks, or burrs. Minor nicks or sharp spots may be smoothed with emery cloth
or similar.
• Check for the presence of dirt or foreign objects that can affect or prevent normal operation
such as grit, sand, rocks, and debris.
During each use, the user should:
• Conrm all pieces of equipment are correctly positioned with respect to each other.
• Monitor the condition of the device and its connections to other equipment in the system.
• Do not allow anything to interfere with the operation of the device or its components.
• Keep foreign objects out of the device.
LIMITATIONS AND PROPER USE
The design of the AZORP is such that it provides a focal rigging point when used with the Arizona
Vortex multipod in various congurations. Certication of the AZORP applies to it’s structural integrity
as an anchor plate and not the overall stability of the system. Consult the Arizona Vortex manual for
additional information.
The AZORP is a special type of rigplate for advanced users only. You must understand the resulting
forces and be sure all equipment is compatible and carabiners, etc. are properly positioned. The
AZORP, carabiners and all other equipment must be free to align with the load. Techniques involving
the AZORP and Vortex require specialized training and advanced understanding of rigging physics.
The AZORP is tested and rated for a total maximum breaking strength. The AZORP is often rigged
with multiple holes being used. Verify that the total force on any single hole does not exceed what
you have determined to be a safe working load. The AZORP is very strong between any two holes,
but it is the strongest between holes that are directly opposite from each other. Avoid torsional loads
and diagonal forces on the AZORP.
Both the inner and Outer AZORP can be used together or separated. The blue “outer” AZORP can
be used with the outer leg of the Arizona Vortex and the orange “inner” can be used with the inner
leg of the Vortex. Equipment must be free to align with the load, any restraint is dangerous. Do not
allow any bending force on the AZORP or it may break or break the connectors.
CARRYING, MAINTENANCE & STORAGE
During all use, carrying, storage and transport keep the equipment away from acids, alkalis, rust and
strong chemicals. Do not expose the equipment to direct heat, ame or high temperatures.
Clean equipment using clean fresh water to remove any dust or debris. Do not use a pressure
washer for cleaning. If the equipment gets wet, remove excess moisture and allow to air dry at
temperatures between 10° C and 30° C. Lubricate moving parts as needed.
During storage and transport, protect the equipment from heat, direct sunlight, moisture, chemicals,
and external loads or impacts. Do not store where the equipment may be exposed to moist air,
particularly where dissimilar metals are stored together.
WARRANTY & REPAIRS
If your CMC product has a defect due to workmanship or materials, please contact CMC Customer
Support at [email protected] for warranty information and service.
CMC’s warranty does not cover damages caused by improper care, improper use, alterations and
modications, accidental damage or the natural breakdown of material over extended use and time.
The equipment should not be modied in any way or altered to allow attachment of additional parts
without the manufacturer’s written recommendation. If original components are modied or removed
from the product, its safety aspects may be restricted.
All repair work shall be performed by the manufacturer. All other work or modications void the
warranty and releases CMC from all liability and responsibility as the manufacturer.
USER INFORMATION
User Information shall be provided to the user of the product. NFPA Standard 1983, incorporated
into the 2022 edition of NFPA 2500 recommends separating the User Information from the equipment
and retaining the information in a permanent record. The standard also recommends making a copy
of the User Information to keep with the equipment and that the information should be referred to
before and after each use.
Additional information regarding life safety equipment can be found in NFPA 1500 and NFPA 1858
and NFPA 1983, incorporated in the 2022 edition of NFPA 2500.
LIFESPAN / INSPECTION / RETIREMENT
CMC does not specify an expiration date for hardware because the service life depends greatly on
how and where it is used. The type of use, intensity of use, and environment of use are all factors in
determining serviceability of the equipment. A single exceptional event can be cause for retirement
after only one use, such as exposure to sharp edges, extreme temperatures, chemicals, or harsh
environments.
A device must be retired when:
• It fails to pass inspection.
• It fails to function properly.
• It has illegible product markings.
• It shows signs of damage or excessive wear.
• It has been subjected to shock loads, falls, or abnormal use.
• It has been exposed to harsh chemical reagents.
• It has an unknown usage history.
• You have any doubt as to its condition or reliability.
• When it becomes obsolete due to changes in legislation, standards, technique or incompatibility
with other equipment.
Remove retired equipment from service and destroy it to prevent further use.
Inspect the equipment according to your department’s policy for inspecting life safety equipment.
CMC recommends a detailed inspection by a competent person at least once every 12 months
depending on current regulations and conditions of use. Record the date, inspector name, and
inspection results in the equipment log as well as any other relevant information to track the
usage history.
THIS ANCHOR PLATE MEETS THE AUXILIARY EQUIPMENT REQUIREMENTS OF
NFPA 1983, INCORPORATED IN THE 2022 EDITION OF NFPA 2500.
• 727401-01 AZORP, INNER ORG, ARIZONA VORTEX. GENERAL USE (G) MBS
60 kN (13,489 lb)
• 727402-01 AZORP, OUTER BLU, ARIZONA VORTEX, GENERAL USE (G) MBS
60 kN (13,489 lb)
