Dometic Oceanair SKYSCREEN User manual

WINDOWS, DOORS &
LIGHTS
SKYSCREEN
Dometic Oceanair Skyscreen Powered
Roofblind
Installation and Operating Manual . . . . . 9
Dachrollo
Montage- und Bedienungsanleitung . . .18
Store de toit
Instructions de montage
et de service . . . . . . . . . . . . . . . . . . . . . . 28
Estor de techo
Instrucciones de montaje y de uso . . . . 38
Persiana de teto
Instruções de montagem e manual de
instruções . . . . . . . . . . . . . . . . . . . . . . . . 48
Oscurante
Istruzioni di montaggio e d’uso . . . . . . . 58
Dakgordijn
Montagehandleiding en
gebruiksaanwijzing. . . . . . . . . . . . . . . . . 67
Tagrullegardin
Monterings- og betjeningsvejledning. . 77
Takmonterad rullgardin
Monterings- och bruksanvisning . . . . . . 86
Rullegardin for tak
Monterings- og bruksanvisning . . . . . . .95
Kattokaihdin
Asennus- ja käyttöohje. . . . . . . . . . . . . . 104
Ролета для люков
Инструкция по монтажу
и эксплуатации. . . . . . . . . . . . . . . . . . . . 113
Roleta dachowa
Instrukcja montażu i obsługi . . . . . . . . . 123
Strešná roleta
Návod na montáž a uvedenie
do prevádzky . . . . . . . . . . . . . . . . . . . . .133
Stropní roleta
Návod k montáži a obsluze . . . . . . . . . . 142
Tetőab la kroló
Szerelési és használati útmutató . . . . . . 151
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU

© 2022 Dometic Group. The visual appearance of the contents of this manual is protected by
copyright and design law. The underlying technical design and the products contained herein may
be protected by design, patent or be patent pending. The trademarks mentioned in this manual
belong to Dometic Sweden AB. All rights are reserved.

3
Skyscreen Powered
1
2
3
1
24 V
12 V
2x
2

Skyscreen Powered
4
3 mm 3 mm
90°
90°
3
4x
1.
1.
1.
1.
2.
4

5
Skyscreen Powered
4x
5
bk
rd
MOTOR
Dometic Radio Receiver
Dometic 9 Chn, 433 MHz Transmitter
HEADRAIL
1
4
2
wh
bk/wh
12 V/24 V DC
12 V/24 V DC
Atlantic 12S - Double End 12 V DC
HD TM24 24 V DC
Atlantic 24S - Double End 24 V DC
3
6

Skyscreen Powered
6
Atlantic 12S - Double End 12 V DC
HD TM24 24 V DC
Atlantic 24S - Double End 24 V DC
bk/wh
wh
HEADRAIL
1
2
12V/24V DC
3
Dometic 9 Chn, 433 MHz Transmitter
7
Atlantic 12S - Double End 12 V DC
HD TM24 24 V DC
24 V DC
Atlantic 24S - Double End 24 V DC
bk
rd
HEADRAIL
1
2
wh/gy
gy
5
12 V/24 V DC
Somfy LV25 - B64
24 V DC
Somfy LW25 - B83
3
8
bk
rd
MOTOR
Somfy DC RTS
Somfy Remote Control
HEADRAIL
1
4
2
wh
bk/wh
24 V DC Somfy LW25-B83
HD TM24
24 VDC
Somfy LV25-B64 24 V DC
24 V DC
3
9

7
Skyscreen Powered
bk/wh
wh
HEADRAIL
1
2
24 V DC Somfy LW25-B83
HD TM24
24 V DC
Somfy LV25-B64 24 V DC
24 V DC
3
Somfy Remote Control
0

Skyscreen Powered
8
Ø 5
≤800
69≤800
≥284
B
B
AA
27,3
9,5
36,3
58
≤800
69≤800
≥284
B
A − A
C − C
CC
37
69
60
36,3
40
a

9
EN
Skyscreen Powered Explanation of symbols
Please read these instructions carefully and follow all instructions, guidelines, and warnings included in this product manual in order to ensure that you install, use,
and maintain the product properly at all times. These instructions MUST stay with this product.
By using the product, you hereby confirm that you have read all instructions, guidelines, and warnings carefully and that you understand and agree to abide by
the terms and conditions as set forth herein. You agree to usethis product only for the intended purpose and application and in accordance with the instructions,
guidelines, and warnings as set forth in this product manual as well as in accordance with all applicable laws and regulations. A failure to read and follow the
instructions and warnings set forth herein may result in an injury to yourself and others, damage to your product or damage to other property in the vicinity. This
product manual, including the instructions, guidelines, and warnings, and related documentation, may be subject to changes and updates. For up-to-date prod-
uct information, please visit documents.dometic.com.
Contents
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
3 Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
7 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
8 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
9 Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
11 Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
12 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
1 Explanation of symbols
!
!
A
I
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided, could
result in minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.

EN
Safety instructions Skyscreen Powered
10
2 Safety instructions
!WARNING! Failure to obey these warnings could result in death or seri-
ous injury.
Electrocution hazard (only for powered blinds)
• Do not operate the device if it is visibly damaged.
• If the power cable for this device is damaged, it must be replaced by the
manufacturer, customer service or a similarly qualified or competent person
in order to prevent safety hazards.
• Inadequate repairs may cause serious hazards.
• Disconnect the blind from the power supply before carrying out any mainte-
nance.
Health hazard
• This device can be used by children aged from 8 years and above and per-
sons with reduced physical, sensory or mental capabilities or lack of experi-
ence and knowledge if they have been given supervision or instruction
concerning use of the device in a safe way and understand the hazards
involved.
• Children shall not play with the device.
• Cleaning and user maintenance shall not be made by children without super-
vision.
• Blinds should be stowed before maneuvering to ensure no restriction of the
driver vision.
•Only for powered blinds: Do not fit powered blinds to escape hatches.
Suffocation hazard
• This device contains small parts. Keep it away from children under 3 years.
• The packaging includes plastic bags. Keep them away from children under
3 years.
!CAUTION! Failure to obey these cautions could result in minor or mod-
erate injury.
Risk of injury
• The device must only be installed, removed or repaired by qualified or com-
petent person using suitable fastening material.
• Take reasonable precaution when installing the blind and wear appropriate
personal protective equipment.
•Only for boats and yachts: If the blind is in front of an open window, then
the blind should be stowed when driving at more than 10 knots or in a sea
state of more than moderate, as this can cause damage to the blind. Parts that
come loose may injure persons in the vicinity.

11
EN
Skyscreen Powered Scope of delivery
ANOTICE!
Damage hazard
• Blinds should be stowed completely when boat or vehicle is under way.
• Use screws and plugs suitable for the wall construction to fix the blind.
• Ensure that you do not drill through the wall.
• Ensure that your hands are clean or wear suitable gloves to avoid marking the
fabric.
•Only for powered blinds:
– Check that the voltage specification on the cable label is the same as that
of the power supply.
– Only use cables with a suitable cross-section.
3 Scope of delivery
4 Accessories
Accessories are available using the separate order form. You can find your autho-
rized customer service center at dometic.com.
5 Intended use
The blind is suitable for:
• Installation in yachts and boats
• Installation in caravans and motor homes
• Installation in homes
The design and size of the blinds are custom-made. The fabric of the blinds is cut
to fit the customer‘s specifications.
The blinds are designed for interior use only and should not be installed in bath-
rooms, wet rooms or other locations with a high level of humidity.
This product is only suitable for the intended purpose and application in accor-
dance with these instructions.
Item in
fig. 1, page 3 Quantity Description
1 1 Blind unit
2 4 Corner cover (optional)
3 4 Side cover (optional)

EN
Technical description Skyscreen Powered
12
This manual provides information that is necessary for proper installation and/or
operation of the product. Poor installation and/or improper operating or main-
tenance will result in unsatisfactory performance and a possible failure.
The manufacturer accepts no liability for any injury or damage to the product
resulting from:
• Incorrect assembly or connection, including excess voltage
• Incorrect maintenance or use of spare parts other than original spare parts
provided by the manufacturer
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in this manual
Dometic reserves the right to change product appearance and product
specifications.
6 Technical description
The blinds are available for a connection to 12 Vgor 24 Vg.
The motor can be controlled using:
• Switches
• AP Remote control
• Central control systems
The number on the product label in the head rail indicates the blind type.
The dimension drawings show the required measurements for fixing with surface
covers or concealed with the boat headlining (fig. a, page 8).
INOTE
The motors have a built-in, self resetting thermal cut-out for safety reasons.
Prolonged use or over loading the blind could trigger the cut-out. If this
happens allow the motor to cool for up to half an hour.

13
EN
Skyscreen Powered Installation
7 Installation
!
7.1 Electrical installation
The powered blinds are available for a connection to a 12/24 Vg power supply.
The data plate on the head rail provides important information on the specifica-
tions of the motor.
The following notes must be observed when connecting the blinds:
• Ensure cables are not damaged during installation. Routings of cables
through walls or bulkheads must be protected and insulated by appropriate
bushing, grommets or cable conduits.
• Ensure that a 12 V or 24 V stabilized power supply line is available for the
drive at the point of installation. The power supply line is suitably arranged
and protected.
• Secure all cables to prevent any contact with moving parts.
• Only use power supply units and control elements recommended by the
manufacturer to prevent damage or faults during operation caused by incom-
patible electrical components.
• Control devices (e.g. switches) must be installed in visible locations.
➤Connect the motor as shown in the wiring diagrams:
– Dometic radio controlled blind internal receiver (fig. 6, page 5)
– Dometic radio controlled blind external receiver (fig. 7, page 6)
– Manually switched blind (fig. 8, page 6)
– Somfy radio controlled blind external receiver (fig. 9, page 6)
– Somfy radio controlled blind internal receiver (fig. 0, page 7)
WARNING! Risk of injury
Disconnect the power supply before you begin and ensure that it can not be
reconnected until installation has been completed.
The electrical power supply must be connected by a qualified electrician who
has demonstrated skill and knowledge related to the construction and opera-
tion of electrical equipment and installations and has received safety training to
identify and avoid the hazards involved.

EN
Installation Skyscreen Powered
14
Key to wiring diagrams
I
7.2 Frame fitting
A
Proceed as shown (fig. 4, page 4):
1. Align the blind with the window cut-out and mark where the holes are to be
drilled for the frame.
2. Fix the frame with the screws to the ceiling.
3. Check whether the moving rail is square and moves freely.
7.3 Cover fitting (optional)
➤Proceed as shown (fig. 5, page 5).
Pos. Description
1Fused12Vg/24 Vgpower supply (fuse rating 2 A for 24 Vg, 1 A for
12 Vg)
2Headrail
3 Head rail motor options
4 External receiver
5 Customer supplied DPDTswitch (double pole, double throw), center off,
latching or momentary, 12 Vg/24 Vg, 3 A)
bk Black
rd Red
gy Gray
wh White
NOTE
Observe the applicable documents for the controls and the operating ele-
ments.
NOTICE! Damage hazard
• Use packing material where required (fig. 3, page 4). The side tracks must
be perpendicular to the head rail.
• Use screws and plugs suitable for the wall construction to fix the frame to
the recess. Pre-drill at the marked points.
• Ensure not to drill through the wall.

15
EN
Skyscreen Powered Operation
8Operation
A
I
•Only if operated by switches: When operating the blind with switches
each switch operates each blind independently.
•Only if operated with the AP Remote control: When operating the blind
with the AP Remote control each blind is independently operated via sepa-
rate channels on the remote control.
• Each blind can be stopped in any position.
• When operating the blind with an automation system, the operation is
dependent on the programming of the control interface.
• The blind automatically stops
– When the blind is fully deployed
– When the blind is fully stowed
– If the blind hits an obstruction (including the other moving rail)
9 Cleaning and maintenance
A
NOTICE! Damage hazard while driving
Only for boats and yachts: If the blind is fitted beneath an open sunroof,
then the blind should be stowed when driving at more than 10 knots or with a
sea state of more than moderate, because this can damage the blind. Parts that
come loose may injure people in the vicinity.
NOTE
•When operating the blind using switches or an automation
system: If the movement direction is reversed too quickly, the motor might
not detect the polarity change and will just stop. To prevent this, the power
must be off for at least 0.5 seconds before the movement direction is
reversed.
• When the motor is stopped the power consumption falls to 8.5 mA. After
approximately 4 minutes the motor automatically switches off.
NOTICE! Damage hazard
• Do not grease, oil or lubricate the blind. Lubricants will damage the fabric.
• Be careful not to crease the fabric when using the brush attachment of a
vacuum cleaner.
• Rubbing can damage fabrics. Do not scrub.
• Spot-cleaning may result in cleaner areas than the surrounding.
• Do not soak the blinds.
• The manufacturer recommends testing any cleaning agents on a hidden
area of the blind first.

EN
Troubleshooting Skyscreen Powered
16
I
Removing dust
➤Dust the blind regularly with a dust rag, dust glove or a vacuum cleaner with
a brush attachment. Blow excess dust off of your fabric using a can of com-
pressed air or a hair dryer on a cool setting.
➤Fully deploy the blind to clean the fabric.
➤Fully stow the blind to clean around the frame.
Spot cleaning
➤Spot-clean with a soft white cloth, moistened with warm water. Add a mild
detergent if needed (non-abrasive and with no additives).
➤Blot gently to avoid creasing or damaging the fabric. Always leave the blind
deployed to dry thoroughly.
Cleaning windows
➤Alwaysensureyourblindsare fullystowed before cleaning windows. This will
prevent spoiling the blind fabric by splatter or sprays of water or detergent.
10 Troubleshooting
NOTE Cleaning by professional cleaning personnel
The manufacturer cannot be held liable for improper cleaning methods or
agents used by professional cleaning personnel. In this case the responsibility
lies with the cleaning company.
Fault Solution
Moving rail jams ➤Check the side tracks for debris or obstructions.
Motor not working ➤Check if wiring for voltage to the motor is correct.
➤If power supply is checked and the motor is still
faulty contact your distributor.
➤If using the AP Remote control refer to the AP
Remote control manual.
Motor running slow or fast ➤Check for correct supply voltage.
AP Remote control (optional)
not operating
➤Refer to the AP Remote control manual.
Motor runs but blind does
not move
➤Check inside the side tracks for obstructions.
➤Check that the side tracks have been installed pro-
perly and have not been twisted or distorted too far
in or out.

17
EN
Skyscreen Powered Warranty
11 Warranty
The statutory warranty period applies. If the product is defective, please contact
your retailer or the manufacturer's branch in your country (see dometic.com/
dealer).
For repair and warranty processing, please include the following documents
when you send in the product:
• A copy of the receipt with purchasing date
• A reason for the claim or description of the fault
• The number on the product label with details on the dimensions and material
specifications
Note that self-repair or nonprofessional repair can have safety consequences
and might void the warranty.
12 Disposal
➤Place the packaging material in the appropriate recycling waste bins wherever pos-
sible.
➤Consult a local recycling center or specialist dealer for details about how to dispose
of the product in accordance with the applicable disposal regulations.
➤The product can be disposed free of charge.

DE
Erläuterung der Symbole Skyscreen Powered
18
Lesen und befolgen Sie bitte alle Anweisungen, Richtlinien und Warnhinweise in diesem Produkthandbuch sorgfältig, um sicherzustellen, dass Sie das Produkt
ordnungsgemäß installieren und stets ordnungsgemäß betreiben und warten. Diese Anleitung MUSS bei dem Produkt verbleiben.
Durch die Verwendung des Produktes bestätigen Sie hiermit, dass Sie alle Anweisungen, Richtlinien und Warnhinweise sorgfältig gelesen haben und dass Sie
die hierin dargelegten Bestimmungen verstanden haben und ihnen zustimmen. Sie erklären sich damit einverstanden, dieses Produkt nur für den angegebenen
Verwendungszweck und gemäß den Anweisungen, Richtlinien und Warnhinweisen dieses Produkthandbuchs sowie gemäß allen geltenden Gesetzen und Vor-
schriften zu verwenden. Eine Nichtbeachtung der hierin enthaltenen Anweisungen und Warnhinweise kann zu einer Verletzung Ihrer selbst und anderer Perso-
nen, zu Schäden an Ihrem Produkt oder zu Schäden an anderem Eigentum in der Umgebung führen. Dieses Produkthandbuch, einschließlich derAnweisungen,
Richtlinien und Warnhinweise, sowie die zugehörige Dokumentation können Änderungen und Aktualisierungen unterliegen. Aktuelle Produktinformationen fin-
den Sie unter documents.dometic.com.
Inhalt
1 Erläuterung der Symbole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
2 Sicherheitshinweise . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
3 Lieferumfang . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4 Zubehör . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
5 Bestimmungsgemäßer Gebrauch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
6 Technische Beschreibung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .21
7 Montage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
8 Bedienung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
9 Reinigung und Pflege . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
10 Fehlersuche und Fehlerbehebung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
11 Garantie. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
12 Entsorgung . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
1 Erläuterung der Symbole
!
!
A
WARNUNG!
Sicherheitshinweis: Kennzeichnet eine Gefahrensituation, die zum Tod
oder schwerer Verletzung führen könnte, wenn die jeweiligen Anweisungen
nicht befolgt werden.
VORSICHT!
Sicherheitshinweis: Kennzeichnet eine Gefahrensituation, die zu geringer
oder mittelschwerer Verletzung führen könnte, wenn die jeweiligen Anweisun-
gen nicht befolgt werden.
ACHTUNG!
Kennzeichnet eine Situation, die zu Sachschäden führen kann, wenn die jewei-
ligen Anweisungen nicht befolgt werden.

19
DE
Skyscreen Powered Sicherheitshinweise
I
2 Sicherheitshinweise
!WARNUNG! Nichtbeachtung dieser Warnungen kann zum Tod oder
schwerer Verletzung führen.
Stromschlaggefahr (nur bei elektrischen Rollos)
• Wenn das Gerät sichtbare Beschädigungen aufweist, dürfen Sie es nicht in
Betrieb nehmen.
• Wenn das Anschlusskabel dieses Geräts beschädigt ist, muss es durch den
Hersteller, seinen Kundendienst oder ähnlich qualifiziertes Fachpersonal
ersetzt werden, um Gefährdungen zu vermeiden.
• Durch unsachgemäße Reparaturen können erhebliche Gefahren entstehen.
• Trennen Sie das Rollo von der Stromversorgung, bevor Sie mit der Durchfüh-
rung von Wartungsarbeiten beginnen.
Gesundheitsgefahr
• Dieses Gerät kann von Kindern ab 8 Jahren und von Personen mit verringer-
ten physischen, sensorischen oder mentalen Fähigkeiten oder Mangel an
Erfahrung und/oder Wissen verwendet werden, wenn diese Personen
beaufsichtigt werden oder im sicheren Gebrauch des Geräts unterwiesen
wurden und die daraus resultierenden Gefahren verstanden haben.
• Kinder dürfen nicht mit dem Gerät spielen.
• Reinigung und Benutzerwartung dürfen nicht durch unbeaufsichtigte Kinder
durchgeführt werden.
• Fahren Sie das Rollo vor der Fahrt ein, um sicherzustellen, dass die Sicht des
Fahrers nicht beeinträchtigt ist.
•Nur bei elektrischen Rollos: Elektrische Rollos dürfen nicht an Notluken
angebracht werden.
Erstickungsgefahr
• Das Gerät enthält Kleinteile. Von Kindern unter 3 Jahren fernhalten.
• Die Verpackung enthält Kunststofftüten. Von Kindern unter 3 Jahren fernhal-
ten.
!VORSICHT! Nichtbeachtung dieser Hinweise kann zu leichten bis mit-
telschweren Verletzungen führen.
Verletzungsgefahr
• Der Ein- und Ausbau oder eine Reparatur darf nur durch eine qualifizierte Per-
son bzw. Fachpersonal mit geeignetem Befestigungsmaterial vorgenom-
men werden.
• Die Montage des Rollos ist mit gebührender Sorgfalt und mit geeigneter
Schutzausrüstung durchzuführen.
HINWEIS
Ergänzende Informationen zur Bedienung des Produktes.

DE
Lieferumfang Skyscreen Powered
20
•Nur bei Booten und Yachten: Wenn sich das Rollo vor einem geöffneten
Fenster befindet, sollte es bei Fahrgeschwindigkeiten von über 10 Knoten
oder bei mehr als moderatem Seegang eingezogen werden, da das Rollo
ansonsten Schaden nehmen kann. Sich lösende Teile können Personen in
der Umgebung verletzen.
AACHTUNG!
Beschädigungsgefahr
• Bei fahrenden Booten und Fahrzeugen sollten Rollos stets vollständig einge-
zogen sein.
• Verwenden Sie zur Befestigung des Rollos ausschließlich Schrauben und
Dübel, die für die Wandkonstruktion geeignet sind.
• Achten Sie darauf, nicht die Wand zu durchbohren.
• Reinigen Sie vor den Arbeiten die Hände oder tragen Sie geeignete Hand-
schuhe, um Flecken auf dem Tuch zu vermeiden.
•Nur bei elektrischen Rollos:
– Prüfen Sie, ob die Spannungsangabe auf dem Typenschild mit der vor-
handenen Energieversorgung übereinstimmt.
– Verwenden Sie nur Kabel mit passendem Leitungsquerschnitt.
3 Lieferumfang
4 Zubehör
Zubehör ist über das separate Bestellformular erhältlich. Ein autorisiertes Kun-
dendienstzentrum finden Sie unter dometic.com.
5 Bestimmungsgemäßer Gebrauch
Das Rollo ist geeignet für:
• Einbau in Yachten und Boote
• Einbau in Wohnwagen und Wohnmobile
• Einbau in Häuser und Wohnungen
Pos. in
Abb. 1,
Seite 3
Anzahl Beschreibung
1 1 Rolloeinheit
2 4 Eckenabdeckung (optional)
3 4 Seitenabdeckung (optional)
