Dometic SKYSCREEN POWERED Series User manual

WINDOWS, DOORS & LIGHTS
SKYSCREEN
SKYSCREEN POWERED
Roofblind
Installation and Operating Manual . . . . .12
Dachrollo
Montage- und Bedienungsanleitung . . 22
Store de toit
Instructions de montage
et de service . . . . . . . . . . . . . . . . . . . . . . 33
Estor de techo
Instrucciones de montaje y de uso . . . . 43
Persiana de teto
Instruções de montagem e manual de
instruções . . . . . . . . . . . . . . . . . . . . . . . . 53
Tenda da tetto
Istruzioni di montaggio e d’uso . . . . . . . 63
Dakgordijn
Montagehandleiding en
gebruiksaanwijzing. . . . . . . . . . . . . . . . . 73
Tagrullegardin
Monterings- og betjeningsvejledning. . 83
Takmonterad rullgardin
Monterings- och bruksanvisning . . . . . . 93
Rullegardin for tak
Monterings- og bruksanvisning . . . . . . 103
Kattokaihdin
Asennus- ja käyttöohje. . . . . . . . . . . . . . 113
Ролета для люков
Инструкция по монтажу
и эксплуатации. . . . . . . . . . . . . . . . . . . . 123
Roleta dachowa
Instrukcja montażu i obsługi . . . . . . . . . 134
Strešná roleta
Návod na montáž a uvedenie
do prevádzky . . . . . . . . . . . . . . . . . . . . .145
Stropní roleta
Návod k montáži a obsluze . . . . . . . . . . 155
Tet őa bl akroló
Szerelési és használati útmutató . . . . . . 165
EN
DE
FR
ES
PT
IT
NL
DA
SV
NO
FI
RU
PL
SK
CS
HU
Skyscreen_IOM_EMEA16.book Seite 1 Donnerstag, 19. Dezember 2019 2:04 14

Skyscreen_IOM_EMEA16.book Seite 2 Donnerstag, 19. Dezember 2019 2:04 14

3
Skyscreen Powered
1
2
3
1
24 V
12 V
2x
2
Skyscreen_IOM_EMEA16.book Seite 3 Donnerstag, 19. Dezember 2019 2:04 14

Skyscreen Powered
4
≤3 mm ≤3 mm
3
4x
1.
1.
1.
1.
2.
4
Skyscreen_IOM_EMEA16.book Seite 4 Donnerstag, 19. Dezember 2019 2:04 14

5
Skyscreen Powered
4x
5
L1
L2
2
4
1
3
L1
L2
2
4
1
3
bk
bk
bk
bk
rd
rd
rd
rd
wh
gy
gy
wh
12 V/24 V
12 V/24 V
2
1
4
3
6
Skyscreen_IOM_EMEA16.book Seite 5 Donnerstag, 19. Dezember 2019 2:04 14

Skyscreen Powered
6
wh/gy
gy
gy
wh/gy
bk
bk
rd
rd
MOTORMOTOR
12 V/24 V
12 V/24 V
1
5
2
3
7
gy
gy
ye
wh/gy
To Motor(s)
24 V DC Supply
UP Master
DOWN Master
COMMON
UP Individual
DOWN Individual
bk
bk
bk
rd
rd
UP COMM
COMM
NO
NC
NO
NC
DOWN
gy
gy
ye
wh/gy
To Motor(s)
24 V DC Supply
UP Master
DOWN Master
COMMON
UP Individual
DOWN Individual
bk
UP COMM
COMM
NO
NC
NO
NC
DOWN
12 V/24 V
12 V/24 V
7
7
16
6
2
3
8
Skyscreen_IOM_EMEA16.book Seite 6 Donnerstag, 19. Dezember 2019 2:04 14

7
Skyscreen Powered
2.
3.
1.
9
1. 3.
5.
2. 4.
0
Skyscreen_IOM_EMEA16.book Seite 7 Donnerstag, 19. Dezember 2019 2:04 14

Skyscreen Powered
8
2.
1.
a
4.
3.
1.
2.
7.
6.
5.
==
b
Skyscreen_IOM_EMEA16.book Seite 8 Donnerstag, 19. Dezember 2019 2:04 14

9
Skyscreen Powered
Ø 5
≤800
69≤800
≥284
B
B
AA
27,3
9,5
36,3
58
≤800
69≤800
≥284
B
A − A
C − C
CC
37
69
60
36,3
40
c
Skyscreen_IOM_EMEA16.book Seite 9 Donnerstag, 19. Dezember 2019 2:04 14

Skyscreen Powered
10
EN DE FR ES PT IT NL DA SV NO FI RU PL SK CS HU
-W White Weiß Blanc Blanco Branco Bianco Wit Hvid Vit Hvit Valkoinen Белый Biały Biela Bílá Fehér
-BL Black Schwarz Noir Negro Preto Nero Zwart Sort Svart Svart Musta Черный Czarny Čierna Černá Fekete
2x
2x
10x
10x
2x
4x
4x
2x
CS-SPR-CORNER COVER-KIT-W
CS-SPR-CORNER COVER-KIT-BL
CS-SPR-SPARES KIT
CS-SPR-PANEL TOOL
d
Skyscreen_IOM_EMEA16.book Seite 10 Donnerstag, 19. Dezember 2019 2:04 14

11
Skyscreen Powered
SSP...PASSY
SSP...PASSY
SSP...PASSY
e
Skyscreen_IOM_EMEA16.book Seite 11 Donnerstag, 19. Dezember 2019 2:04 14

EN
Explanation of symbols Skyscreen Powered
12
Please read this instruction manual carefully before installation and
first use, and store it in a safe place. If you pass on the product to
another person, hand over this instruction manual along with it.
Content
1 Explanation of symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
2 Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
3 Scope of delivery. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
4 Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
5 Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
6 Technical description . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
7 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
8 Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
9 Cleaning and maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
10 Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
11 Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
12 Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
13 Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
1 Explanation of symbols
!
!
A
I
WARNING!
Safety instruction: Indicates a hazardous situation that, if not avoided, could
result in death or serious injury.
CAUTION!
Safety instruction: Indicates a hazardous situation that, if not avoided, could
result in minor or moderate injury.
NOTICE!
Indicates a situation that, if not avoided, can result in property damage.
NOTE
Supplementary information for operating the product.
Skyscreen_IOM_EMEA16.book Seite 12 Donnerstag, 19. Dezember 2019 2:04 14

13
EN
Skyscreen Powered Safety instructions
2 Safety instructions
The manufacturer accepts no liability for damage in the following cases:
• Faulty assembly or connection
• Damage to the product resulting from mechanical influences and incorrect
connection voltage
• Alterations to the product without express permission from the manufacturer
• Use for purposes other than those described in the operating manual
2.1 General safety
!WARNING! Failure to obey these warnings could result in death or
serious injury.
Health hazard
• This device can be used by children aged from 8 years and above and per-
sons with reduced physical, sensory or mental capabilities or lack of experi-
ence and knowledge if they have been given supervision or instruction
concerning use of the device in a safe way and understand the hazards
involved.
• Children shall not play with the device.
• Cleaning and user maintenance shall not be made by children without super-
vision.
• Blinds should be stowed before maneuvering to ensure no restriction of the
driver vision.
Suffocation hazard
• This product contains small parts. Keep it away from children.
• The packaging includes plastic bags. Keep them away from children.
!CAUTION! Failure to obey these cautions could result in minor or
moderate injury.
Risk of injury
• The product must be installed by a technician or a competent person using
suitable fastening material (for example, screws, wall plugs). This makes it
possible to avoid injury due to improper installation.
• Do not fit powered blinds under escape hatches.
• Take reasonable precaution when installing the blind and wear appropriate
personal protective equipment.
•Only for boats and yachts: If the blind is fitted beneath an open sunroof,
then the blind should be stowed when driving at more than 10 knots or with
a sea state of more than moderate, because this can damage the blind. Parts
that come loose may injure people in the vicinity.
Skyscreen_IOM_EMEA16.book Seite 13 Donnerstag, 19. Dezember 2019 2:04 14

EN
Scope of delivery Skyscreen Powered
14
ANOTICE!
Damage hazard
• Check that the voltage specification on the cable label is the same as that of
the power supply.
• Use screws and plugs suitable for the wall construction to fix the blind.
• Ensure not to drill through the wall.
• Ensure that your hands are clean or wear suitable gloves to avoid marking the
fabric.
3 Scope of delivery
4 Accessories
Available as accessories (not included in the scope of delivery):
You can find your authorised customer service centre at dometic.com.
5 Intended use
The Skyscreen Powered roofblind is suitable for installation in yachts, boats,
motor homes, caravans or homes. The design and size of the frame are custom-
made. The fabric of the blinds is cut to the customer‘s specifications.
The blinds are designed for interior use only and should not be installed in bath-
rooms, wet rooms or other location with a high level of humidity.
I
Item in
fig. 1, page 3 Quantity Description
1 1 Blind unit
2 4 Corner covers (optional)
34Sidecover(optional)
Description Ref. no.
AP Remote control 9110004562
IRS-300 9110004557
NOTE
The motors have a built-in, self resetting thermal cut-out for safety reasons.
Prolonged use or over loading the blind could trigger the cut-out. If this
happens allow the motor to cool for a few minutes.
Skyscreen_IOM_EMEA16.book Seite 14 Donnerstag, 19. Dezember 2019 2:04 14

15
EN
Skyscreen Powered Technical description
6 Technical description
The blinds are available for a connection to 12 Vgor 24 Vg.
The motor can be controlled using:
• Switches
• AP Remote control
• Central control systems
The number on the product label in the head rail indicates the blind type.
The dimension drawings show the required measurements for fixing with surface
covers or concealed with the boat headlining (fig. c, page 9).
7 Installation
!
7.1 Electrical installation
A
Proceed as follows:
➤Decide on the routing of the motor wire (fig. 2, page 3).
➤Check the voltage of the blind (see cable label).
➤Choose a location for the control device (such as switch or remote control)
which must be installed in a visible location.
➤Connect the blind according to the circuit diagram:
– Manually switched blinds (fig. 6, page 5)
– Remotely controlled blinds (fig. 7, page 6)
– Other control system (fig. 8, page 6)
WARNING! Risk of injury
Disconnect the power supply before you begin and ensure that it can not be
reconnected until installation has been completed.
NOTICE! Risk of damage
• Ensure cables are not damaged during installation.
• Ensure that a 12 V or 24 V power supply line is available for the drive (rated
power 13.2 W) at the point of installation.
• Ensure that the power supply line is suitably arranged and protected.
• Ensure that routings of cables through walls or bulkheads are protected
and insulated by appropriate bushing, grommets or cable conduits.
• Secure all cables to prevent any contact with moving parts.
Skyscreen_IOM_EMEA16.book Seite 15 Donnerstag, 19. Dezember 2019 2:04 14

EN
Installation Skyscreen Powered
16
Key to circuit diagrams:
7.2 Frame fitting
A
Proceed as shown (fig. 4, page 4):
➤Align the blind with the window cut-out and mark where the holes are to be
drilled for the frame.
➤Fix the frame with the screws to the ceiling.
I
➤If necessary, you can remove a panel as shown (fig. 9, page 7 and fig. 0,
page 7 for installations without headlining or fig. a, page 8 for installations
with headlining).
Item Description
1Fused12Vgor 24 Vgsupply
(fuse rating: 2 A for 12 Vg, 1 A for 24 Vg)
2Headrailmotor1
3Headrailmotor2
4 Customer supplied switch (DPDT (double pole, double throw),
latching or momentary, 12/24 Vg, 3 A)
5APReceiver
6 Automation system dry contact component
7IRS-300
bk black
rd red
wh white
gy gray
ye yellow
NOTICE! Risk of damage
• Use packing material where required (fig. 3, page 4). The side tracks must
be perpendicular to the head rail.
• Use screws and plugs suitable for the wall construction to fix the frame to
the recess. Pre-drill at the marked points.
• Ensure not to drill through the wall.
NOTE
Check whether the moving rail is square and moves freely. If the moving rail is
not square it can be adjusted as shown (fig. 9, page 7 to fig. b, page 8).
Skyscreen_IOM_EMEA16.book Seite 16 Donnerstag, 19. Dezember 2019 2:04 14

17
EN
Skyscreen Powered Operation
7.3 Cover fitting (optional)
➤Proceed as shown (fig. 5, page 5).
8Operation
A
I
•Only if operated by switches: When operating the blind with switches
each switch operates each blind independently.
•Only if operated with the AP Remote control: When operating the blind
with the AP Remote control each blind is independently operated via sepa-
rate channels on the remote control.
• Each blind can be stopped in any position.
• When operating the blind with an automation system, the operation is
dependent on the programming of the control interface.
• The blind automatically stops
– when the blind is fully deployed,
– when the blind is fully stowed
– if the blind hits an obstruction (including the other moving rail)
NOTICE! Risk of damage while driving
Only for boats and yachts: If the blind is fitted beneath an open sunroof,
then the blind should be stowed when driving at more than 10 knots or with a
sea state of more than moderate, because this can damage the blind. Parts that
come loose may injure people in the vicinity.
NOTE
•When operating the blind using switches or an automation
system: If the movement direction is reversed too quickly, the motor might
not detect the polarity change and will just stop. To prevent this, the power
must be off for at least 0.5 seconds before the movement direction is
reversed.
• When the motor is stopped the power consumption falls to 8.5 mA. After
approximately 4 minutes the motor automatically switches off.
Skyscreen_IOM_EMEA16.book Seite 17 Donnerstag, 19. Dezember 2019 2:04 14

EN
Cleaning and maintenance Skyscreen Powered
18
9 Cleaning and maintenance
A
I
Removing dust
➤Dust the blind regularly with a dust rag, dust glove or a vacuum cleaner with
a brush attachment. Blow excess dust off of your fabric using a can of com-
pressed air or a hair dryer on a cool setting.
➤Fully deploy the blind to clean the fabric.
➤Fully stow the blind to clean around the frame.
Spot cleaning
➤Spot-clean with a soft white cloth, moistened with warm water. Add a mild
detergent if needed (non-abrasive and with no additives).
➤Blot gently to avoid creasing or damaging the fabric. Always leave the blind
deployed to dry thoroughly.
Removing bugs
➤To prevent damage to delicate fabrics, do not use any type of stick, wand or
handle to push out anything caught in your blinds. We recommend gently
blowing out using either a can of compressed air or a hair dryer on a cool
setting.
➤The blind panels can be removed for cleaning.
Cleaning windows
➤Alwaysensure your blinds arefullystowedbefore cleaning windows. Thiswill
prevent spoiling the blind fabric by splatter or sprays of water or detergent.
Panels can be unclipped and removed for window cleaning (fig. 9, page 7
and fig. 0, page 7 for installations without headlining or fig. a, page 8 for
installations with headlining).
NOTICE! Risk of damage
• Do not grease, oil or lubricate the blind. Lubricants will damage the fabric.
• Be careful not to crease the fabric when using the brush attachment of a
vacuum cleaner.
• Rubbing can damage fabrics. Do not scrub.
• Spot-cleaning may result in cleaner areas than the surrounding.
• Do not soak the blinds.
• The manufacturer recommends testing any cleaning agents on a hidden
area of the blind first.
NOTE Cleaning by professional cleaning personnel
The manufacturer cannot be held liable for improper cleaning methods or
agents used by professional cleaning personnel. In this case the responsibility
lies with the cleaning company.
Skyscreen_IOM_EMEA16.book Seite 18 Donnerstag, 19. Dezember 2019 2:04 14

19
EN
Skyscreen Powered Troubleshooting
Replacing the fabric panel
➤Fabrics can be removed for cleaning or replacement (fig. 9, page 7 and
fig. 0, page 7 for installations without headlining or fig. a, page 8 for
installations with headlining).
Due to batch variation, replacement fabric colours may vary slightly in shade.
10 Troubleshooting
Fault Solution
Moving rail not straight ➤Disconnect the first fabric panel at the
opposite end to the crooked moving
rail(fig. 9, page 7andfig. 0,page 7
for installations without headlining or
fig. a, page 8 for installations with
headlining).
➤Adjust the coupling (fig. b, page 8).
Moving rail jams. ➤Check the side tracks for debris or
obstructions.
Motor not working ➤Check if wiring for voltage to the motor
is correct.
➤If power supply is checked and the
motor is still faulty contact your
distributor.
➤If using the AP Remote control refer to
the AP Remote control manual.
Motor running slow or fast ➤Check for correct supply voltage.
AP Remote control (optional) not operat-
ing
➤Refer to the AP Remote control
manual.
Motor runs but blind does not move ➤Check inside the side tracks for
obstructions.
➤Check that the side tracks have been
installed properly and have not been
twisted or distorted too far in or out.
Skyscreen_IOM_EMEA16.book Seite 19 Donnerstag, 19. Dezember 2019 2:04 14

EN
Warranty Skyscreen Powered
20
11 Warranty
The statutory warranty period applies. If the product is defective, please contact
the manufacturer's branch in your country or your retailer. You can find your
authorised customer service centre at dometic.com.
For repair and warranty processing, please include the following information
when you return the product:
• The number on the product label in the head rail.
• A reason for the claim or description of the fault.
If it is not possible to return the product, please provide photographs or video
identifying the defect.
12 Disposal
➤If possible, dispose of the packaging material in the appropriate recycling
container.
➤If you wish to finally dispose of the product, ask your local recycling centre or
specialist dealer for details about how to do this in accordance with the appli-
cable disposal regulations.
Skyscreen_IOM_EMEA16.book Seite 20 Donnerstag, 19. Dezember 2019 2:04 14
