Ecom ecom-DP User manual

Operating Instructions

Page 2 ecom-DP
Index Page
1. Design ecom-DP 3
2. Initialisation
2.1. Power supply 4
2.2. Accumulator charging 4
2.3. Clock set 4
3. Numerical indication
3.1. Zeroing pressure sensors 6
3.2. Freezing measurement values 6
3.3. Min. / Max. measurement values 7
3.4. Printout measurement values 7
3.5. Contrast and display backlit 7
4. Check programs
4.1. Setup 8
4.2. Pressure check 9
4.3. Preliminary check 10
4.4. Main check 11
4.5. Usability check 12
5. Set clock 15
6. Internal instrument settings
6.1. Switch on/off key beep 15
6.2. Pressure Auto -> 0 by start 16
6.3. Choose printer (ecom-P) 16
6.4. Battery loading 16
6.5. Display damping 16
6.6. Pressure unit 17
7. Sensor setup 18
8. View service info 18
9. Data logger program „ecom-DP Logger“ 19
10. Technical data ecom-DP 20
11. Maintenance tip 21

ecom-DP Page 3
1. Design ecom-DP
Connections
Pmax = 1500 hPa
Connections (Option)
Pmax = 1500 hPa
oder Pmax = 70 hPa
IR interface
(for IR printer)
Function keys
(current function is
shown on display)
Connection
loading unit
Graphic display
Cursor keys
OK-key
ON/OFF key

Page 4 ecom-DP
2. Initialisation
2.1. Power supply
The ecom-DP is powered by 3 batteries or 3 accumula-
tors. The following types can be used to operate the
instrument:
- Battery 1,5 V AA (Mignon)
- Accumulator 1,2 V AA NiCd (nickel cadmium)
- Accumulator 1,2 V AA NiMh (metal hydride)
If you are using a loading unit, please adjust the func-
tion „Bat. Loading“ (see chapter 6.4.)
Open the battery compartment and insert the batteries.
Be careful to ensure proper polarity. If using the re-
chargeable battery type, it will be necessary to fully
charge the batteries prior to initial use (approx. 4 hours).
The voltage of the batteries is monitored by the DP and
will indicate a low battery condition by approx. 3.3 V by
beeping and flashing a signal on the LCD display. If the
voltage sinks (approx. 3 V) so the ecom-DP will auto-
matically switch off.
2.2. Accumulator charging
The accumulator charging procedure is monitored by
the ecom-DP. Once connected to AC power, the in-
strument switches on. During the charging procedure, a
BATTERY indicator will be shown on the LCD display.
Once the battery is fully charged, the BATTERY indica-
tor on the display will blink. It is possible to operate the
ecom-DP on AC power during the charging procedure
by pressing the <ON> button.
2.3. Setting clock
The internal clock and the internal RAM memory of the
ecom-DP are buffered via a capacitor. If the instrument
is without current supply during more than approx. 10
minutes, the recorded information gets lost. Before us-
ing the ecom-DP for the first time, adjust the internal
clock and delete the internal RAM memory.
Battery warning

ecom-DP Page 5
Press <ON> to switch on the ecom-DP.
The instrument displays the following:
Clock set
Delete RAM
Press OK to continue!
- Press twice the <OK> key and the measurement value
menu will be displayed.
- Press <F2> (wrench symbol) to call up the menu „In-
strument settings“.
- With the cursor keys <UP/DOWN> scroll until the
menu point “Set clock”.
- Press <OK> to activate.
Date and time can be set as follows:
1. Select with the cursor keys <RIGHT/LEFT> the posi-
tion to be changed (corresponding field blinks).
2. Adjust the correct numbers with the cursor keys
<UP/DOWN>.
3. Press <OK> to confirm correct date and time set-
tings.

Page 6 ecom-DP
3. Numerical indication
After switch-on, the specifications of the pressure sen-
sor will be displayed: denomination, measurement
range and connection seizure (+/-). Press <OK> to
access to the measurement value menu.
3.1. Zeroing the internal pressure sensor
As the difference pressure sensor can drift because of
its sensitivity in the zero point (also by attaching to met-
al surfaces by magnetic holder), it is possible to reset
the zero point.
- Press <F2> (DP->0) to activate the function for zero
point correction of the pressure sensors.
- Press <F3> (DP1) to zero the value of the pressure
sensor 1.
- Press <F4> (DP2) to zero the value of the pressure
sensor 2.
- Press <F2> (ESC) to quit the menu.
Different functions can be called up with the function
key <F1>. The current seizure of the other function keys
(<F2> - <F4>) is shown on the display. Press one time
<F1> to display the functions „Hold“, „Min/Max“ and
„Print“.
3.2. Freezing of measurement value
- Press <F2> (Hold) to „freeze“ that measurement value
displayed at the time the key is pressed (active function
= Hold indication blinks).
- Press again <F2> (Hold) to quit the „freezing“ and the
current value will be displayed.
1. Before making measurements, the instrument must have
adapted the ambient temperature!
2. Make sure, that the ambient temperature remains constant
during measurement!
If „Pressure Auto -> O by start“ is set on
„YES“ (Chapter 6.2), so the internal pres-
sure sensors should be flown with pres-
sure first after the switch-on of the in-
strument, as they are zeroed during
said switch-on procedure.

ecom-DP Page 7
3.3. Minimal / Maximal measurement values
With <F3> (Min/Max) the determined minimal and max-
imal values since unit switch-on (or deleting via „CLR“)
can be called up.
- Press one time <F3> (Min/Max) to view the lowest
determined values (Min/Max blinks).
- Press <F2> (CLR) to delete the minimal values (new
scanning begins).
- Press again <F3> (Min) to view the highest values
(Min/Max blinks).
- Press <F2> (CLR) to delete the highest values (new
scanning begins).
- Press one more time <F3> (Max) to quit the menu.
3.4. Measurement values printout
Press <F4> (Print) to transmit the current measurement
values via the infrared interface to the IR printer (op-
tion).
Condition hereto is a trouble free connection (direct
sight) between the sending diode at the front of the in-
strument and the receiving diode of the printer. The
distance between both instruments should not exceed
40 cm (1.3 foot), otherwise a trouble free transmission is
not warranted at any time.
3.5. Contrast adjustment and lighting
Basing on the previous function seizure, the functions
„LUMI“ and „Light“ are displayed after pressing <F1>.
The graphic display of the ecom-DP can be adjusted to
different visual conditions. The contrast can be adjusted
in 5 steps (each key pressing = one step) while pressing
<F3> (LUMI). Additionally the backlighting of the display
can be activated while pressing <F4> (Light).
-----------------------------------
ecom-DP
-----------------------------------
Date Time
05.10.01 12:12:50
-----------------------------------
P1 0.0 (hPa)
P2 0.0 (hPa)
-----------------------------------
min max
P1 -0.1 0.1 (hPa)
P2 -0.1 0.1 (hPa)
-----------------------------------
ecom GmbH
Am Grossen Teich 2
58640 Iserlohn
Tel. [phone]
