FabiaTech Low Power Series User manual

FabiaTech Corporation
IPC Solution
Website: http://www.fabiatech.com
Email: [e-mail]
Embedded CPU Board
Low Power Series
FB2653 User’ Manual
MAY 2006
Version: 1.0
Part Number: FB2653

ii
Copyright
©Copyright 2006FabIATech Corporation, The content of this publication may not
be reproduced in any part or as a whole, transcribed, stored in a retrieval system,
translated into any language, or transcribed in any form or by any means,
electronic, mechanical, and magnetic… or otherwise without the prior written
permission of FabiaTech Corporation.
Disclaimer
FabiaTech makes no representation of warranties with respect to the contents of
this publication. In an effort to continuously improve the product and add features,
FabiaTech reserves the right to revise the publication or change specifications
contained in it from time to time without prior notice of any kind from time to time.
FabiaTech shall not be reliable for technical or editorial errors or omissions, which
may occur in this document. FabiaTech shall not be reliable for any indirect,
special, incidental or consequential damages resulting from the furnishing,
performance, or use of this document.
Trademarks
Trademarks, brand names and products names mentioned in this publication are
used for identification purpose only and are the properties of their respective
owners.
Technical Support
If you have problems or difficulties in using the system or setting up the relevant
devices, and software that are not explained in this manual, please contact our
service engineer for service, or send email to suppo[email protected].
Returning Your Board For Service & Technical Support
If your board requires servicing, contact the dealer from whom you purchased the
product for service information. You can help assure efficient servicing of your
product by following these guidelines:
 A list of your name, address, telephone, facsimile number, or email address
where you may be reached during the day
 Description of you peripheral attachments
 Description of your software (operating system, version, application
software, etc.) and BIOS configuration
 Description of the symptoms (Extract wording any message)
For updated BIOS, drivers, manuals, or product information, please visit us at
www.fabiatech.com

iii
Table of Contents
FB2653 User’ Manual................................................................................................................i
Chapter 1 Introducing the FB2653 System ................................................................................. 1
Overview ....................................................................................................................................1
Series Comparison Table.........................................................................................................2
Layout .........................................................................................................................................3
Specifications ............................................................................................................................4
Packing List.................................................................................................................................5
Chapter 2 Hardware Installation .................................................................................................7
Before Installation .....................................................................................................................7
Hardware Features...................................................................................................................8
J3: Cooling Fan Connector ................................................................................9
J2: Mixed I/O and Indicator Header.................................................................9
CN11: Connecting the Keyboard and Mouse .............................................11
CN9, CN10 & J5, J8: Connecting the LAN ports and USB Ports.................11
DB1 & CN6, CN7: Connecting the COM ports .............................................12
CN12: Connecting the Audio Microphone In/ Speak Out.........................14
J4: TTL I/O Connector (5-pin 2.0mm JST)........................................................14
CN1: IDE hard Disk Connector.........................................................................15
CN2: Serial ATA hard Disk Connector.............................................................16
CN17 & JP9: Compact Flash Socket and Master/Slave Select.................17
BUS2: Mini-PCI Socket for WLAN Modules......................................................17
DIMM1: DIMM Socket for DDR Modules .........................................................18
BUS 1: PCI Slot ......................................................................................................18
CN5: ATX Power Connector .............................................................................19
SW1: User Defined Push Button Switch............................................................19
JP1: CMOS Clear Jumper..................................................................................20
BZ1 & J9: On-Board Buzzer & External Speaker Header..............................20
J12: Wake On LAN Jumper Header................................................................21
J11: AGP Power Option.....................................................................................21
LED1 & LED2:On-Board Power/HDD LED ........................................................22
J6: Temperature Sensor Header ......................................................................22

iv
Chapter 3 Installing CRT/LCD/Video......................................................................................... 23
LCD FLAT PANEL DISPLAY.......................................................................................................24
CRT & LCD DISPLAY ................................................................................................................25
DB1: DVI connector............................................................................................26
CN3 & CN4: LCD Connector and Power Connector..................................26
CRT & TV-Out DISPLAY............................................................................................................27
CN13: Connecting the S-Video Out ...............................................................27
Chapter 4 BIOS Setup.................................................................................................................. 29
Overview ..................................................................................................................................29
BIOS Functions.....................................................................................................30
Keyboard Convention.......................................................................................31
STANDARD CMOS Feature....................................................................................................32
Advanced BIOS Features......................................................................................................35
Hard Disk Boot Priority ........................................................................................35
Advanced Chipset Features................................................................................................38
DRAM Clock/Driver Control..............................................................................38
AGP & P2P Bridge Control ................................................................................39
CPU & PCI Bus Control.......................................................................................39
Integrated Peripherals...........................................................................................................41
VIA Onchip IDE Device......................................................................................41
VIA PCI Device....................................................................................................42
Super IO Device..................................................................................................43
Power Management Setup..................................................................................................44
IRQ/Event Activity Detect.................................................................................45
IRQs Activity Monitoring.....................................................................................45
PnP/PCI Configurations .........................................................................................................46
X IRQ/DMA Resources........................................................................................47
PC Health Status .....................................................................................................................48
Frequency/Voltage Control.................................................................................................49
Password Setup.......................................................................................................................50
Chapter 5 Software Installation.................................................................................................. 51
System Driver............................................................................................................................51
WIN 98/2000/XP Driver.................................................................................................51

v
VGA Driver for WIN98SE/ME/2000/XP..................................................................................52
Audio Drivers............................................................................................................................52
WIN 98/2000/XP Driver.................................................................................................52
USB 2.0 Driver ...........................................................................................................................53
WIN 9X/ME Driver..........................................................................................................53
LAN Utility & Driver...................................................................................................................53
BIOS Flash Utility.......................................................................................................................53
Watchdog Timer.....................................................................................................................54
Watchdog Timer Setting.............................................................................................55
Watchdog Timer Enabled..........................................................................................56
Watchdog Timer Trigger .............................................................................................57
Watchdog Timer Disabled .........................................................................................57
Programming RS-485..............................................................................................................58
Chapter 6 Technical Reference ................................................................................................ 63
Trouble Shooting for Post Beep and Error Messages........................................................63
Appendix...................................................................................................................................... 66
Dimension.................................................................................................................................66
Technical Reference..............................................................................................................67
Physical and Environmental.......................................................................................67
Serial Ports......................................................................................................................68

vi

FabiaTech Corporation
1
Chapter1IntroducingtheFB2653System
Overview
The FB2653 series is a Low power AMD NX and all in one CPU board. This user’s
manual provides information on the physical features, installation, and BIOS setup
of the FB2653.
Built to unleash the total potential of the AMD Geode™, support 1GHz CPU, this
board supports one IDE, one CF socket, one SATA interface, two 10/100/1000M
Base –TX LAN ports, DDR-RAM , mini PCI socket for wireless LAN, Four USB2.0 ports,
video out, audio and a VGA controller.
Each FB2653 has four ports for I/O communications. Three RS-232C ports and one
RS232/RS422/RS485 are available.
The FB2653 is perfect for ATM machines, KIOSK, point-of-sales/point-of-
information, gaming and infotainment, measurement technology, lotteries,
banking and Thin Client and small Embedded Control. The unit is only the unit is
only 146.0mm (D) X 203.0mm (W).

FabiaTech Corporation
2
SeriesComparisonTable
Model FB2653
Processor Supports AMD Geode™
NX-1500 and NX-1750 CPU’s
Chipset VIA KN400A+VT8237R Plus
1 184 Pin-DIMM (Max.) 1GB DDR333/266Mhz
CRT VGA Yes(DVI)
Watchdog Timer Yes
Multi I/O Four Serial ports
Enhanced IDE and CF One
SATA One
Video Out One
USB 2.0 Four
Audio Line -Out And Mic
RJ45 WAN port
(100/1000Mbps) Two
Mini-PCI Socket One
Dimensions (Unit: mm) 146.0mm(D) X 203.0mm(W)

FabiaTech Corporation
3
Layout
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1

FabiaTech Corporation
4
Specifications
 Supports AMD Geode™ NX1500 1GHz Low Power CPU and NX1750
1.4GHz CPU.
 5.25” (CDROM) size embedded board with PCI expansion bus.
 On board VGA (VIA KN400A) Supports DVI, LCD and Video out with
up to 64MB share memory.
 Provide one DIMM 184-pin Socket for up to 1GB DDR-333 maximum.
 One PCI IDE interface, one SATA interface and one Compact Flash
socket.
 Supports three RS-232 and one RS232/RS422/RS485 ports.
 Four USB 2.0 ports and four TTL IO Lines.
 Build-In AC97-codec, Support Mic-In, and Line-out.
 Build-In two Realtek RTL8110S 10/100/1000 base-TX with RJ45
connectors.
 Support one mini-PCI socket for WLAN applications
 On board Buzzer, LED indicator and PS/2 compatible keyboard and
mouse interface.
 Provides one CPU cooling fan connector and hardware monitoring
function.
 Power requires +5V/3.5A,3.3V/1.5A,5VSB/750mA maximum. (Base On
1.0GHz CPU)
 Dimensions 146.0mm(D) X 203.0mm(W)

FabiaTech Corporation
5
PackingList
Upon receiving the package, verify the following things. Should any of the
mentioned happens, contact us for immediate service.
• Unpack and inspect the FB2653 package for possible damage that may
occur during the delivery process.
• Verify the accessories in the package according to the packing list and see
if there is anything missing or incorrect package is included.
• If the cable(s) you use to install the FB2653 is not supplied from us, please
make sure the specification of the cable(s) is compatible with the FB2653
system.
Note: after you install the FB2653, it is recommended that you keep the diskette or
CD that contains drivers and document files, and keep the document
copies, or unused cables in the carton for future use.
The following lists the accessories that may be included in your FB2653 package.
Some accessories are optional items that are only shipped upon order.
• One FB2653 all-in-one CPU board.
• One Ultra DMA cable for IDE.
• One SATA signal cable and one power cable.
• Two RS232 Serial port adapter cable.
• One DVI to CRT adapter cable.
• One Y-type (3-terminal) PS/2 keyboard plus mouse port adapter cable.
• One compact disc includes software utility.

FabiaTech Corporation
6

FabiaTech Corporation
7
Chapter2HardwareInstallation
This chapter introduces the system connectors & jumper settings, and guides you to
apply them for field application.
BeforeInstallation
Before you install the system board, make sure you follow the following descriptions.
1. Before removing the board from its anti-static bag, wear an anti-static strap to
prevent the generation of Electricity Static Discharge (ESD). The ESD may be
created from human body that touches the board. It may do damage to the
board circuit.
2. Install or unplug any connector, module, or add-on card, be sure that the
power is disconnected from the system board. If not, this may damage the
system board components, module, or the add-on-card.
3. Installing a heat sink and cooling fan is necessary for heat dissipation from your
CPU. If heat sink or cooling fan is not mounted, this may cause the CPU fail due
to over-heating problem.
4. When you connect the connectors and memory modules, be careful with the
pin orientations.

FabiaTech Corporation
8
HardwareFeatures
The following lists the connectors and jumpers to install the FB2653.
Item Description
CN1 40-pin IDE Connector
CN2 7-pin SATA Connector
CN3 40-pin LCD Connector
CN4 5-pin Power Connector for LCD
CN5 20-pin ATX Power Connector
CN6,CN7 10-pin IDC Connector for COM3 and COM4
CN9,CN10 RJ45-LAN Connector & USB ports Connector
CN11 Keyboard and Mouse Connector
CN12 Audio Micro In/Speaker Out
CN13 RCA Jack (Video Out Connector)
CN14 DVI Connector
CN17 Compact Flash slot
J2 16-pin Mixed I/O and Indicator Header
J3 3-pin for Case/CPU Cooling Fan Connector
J4 5-pin for TTL I/O Connector
J5,J8 2-pin LAN1/LAN2 Indicator LED’s Header
J6 2-pin External Temp Sensor Header
J7 5-pin For IR Header
J10 3- pin for Touch Screen Header
J11 Select AGP 3.3V/1.5V Voltage
J12 2-pin Wake-On-LAN Select Jumper
JP1 3-pin Clear CMOS Jumper
JP2 3-pinSelect RS485 Terminal Resistor
JP3,JP4,JP5,JP8 2*3-pin Power Output Select for COM1~COM4
JP6 2*3-pin Audio Output Select
JP9 3-pin Master/Slave Select Compact Flash Device
LED1,LED2 Power and HDD LED’s Indicator
BUS1 PCI Connector
BUS2 Mini-PCI Socket
DIMM1 DDR DIMM Socket 184-pin
DB1 COM1/COM2, DB-SUB 9 Connector
Bz1,J9 On board Buzzer ,External Speaker Header
SW1 User Defined Button

FabiaTech Corporation
9
 J3: Cooling Fan Connector
J3 is a 3-pin Molex connector and which is reserved for driving CPU or case cooling
fan when non-low power CPU are used.
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
 J2: Mixed I/O and Indicator Header
The J2 (1, 2 pin and 3, 4 pin) are Power and HDD LED’s has two distinctive statues:
off for inactive operation and blinking light for activity. And the J2 (5, 6 pin
(LED1+/LED1-) and 7, 8 pin (LED2+/LED2-) for LAN ports. The LAN1 and LAN2 LED’s
indicate on-line/access status of LAN1 and LAN2 respectively.
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
J3 Description
1 Ground
2 +12V
3 Speed-In
J1 Signal J1 Signal
1 P/W LED+ 2 P/W LED -
3 HDD LED+ 4 HDD LED -
5 LAN1 LED+ 6 LAN1LED-
7 LAN2 LED+ 8 LAN2 LED-
9 NC 10 NC
11 Ext-Temp. 12 GNDA
13 Reset 14 GND
15 PWR-SW+ 16 PWR-SW-
1
3
J
3
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
J2

FabiaTech Corporation
10
1. The J2 pin 11, 12 is a 2-pin for connecting Resistive Temperature Sensor input
header and pin 13, 14 is a 2-pin for connecting to system reset button. It is
because hardware reset of FB2653 and restart system booting.
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
2. The J2 pin 15, 16 is a 2 pin connecting to PWE-SW; It’s Pushing the PWE-SW button
once will switch the FB2653 on and off. It’s depending on system BIOS (Power
Management Setup) or OS setting. Pushing the power button while in the on
mode for more than 4 seconds will turn the system off.
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
J1
1 3 5 7 9 11 13 15
2 4 6 8 10 12 14 16
J2

FabiaTech Corporation
11
 CN11: Connecting the Keyboard and Mouse
The CN11 uses the included adapter cable you can attach standard PS/2 type
keyboard and mouse. Standard PS/2 keyboard can be plugged into this
connector without any adapter cable. If PS/2 keyboard and mouse will be used
simultaneously, a Y-type (3-terminal) adapter cable is needed.
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
 CN9, CN10 & J5, J8: Connecting the LAN ports and USB Ports
The RJ45 connector with 2 LED’s for WAN/LAN. The left side LED (orange) indicates
data is being accessed and the right side LED (green) indicates on-line status. (On
indicates on-line and off indicates off-line) The following lists the pin assignment of
CN9, CN10 and J5, J8:
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
LAN1/LAN2 Signal LAN1/LAN2 Signal
1 TPTX+ 5 TPTX1-
2 TPTX - 6 TPRX -
3 TPRX+ 7 TPRX1+
4 TPTX1+ 8 TPRX1-
RJ45 connector
1
8
PIN2 LAN LED -
PIN1 LAN LED+
The following lists the pin assignment of RJ45.
LAN2-J5
1
2
LAN1-J8
1
2
Pin Description
1 Mouse Data
2 Keyboard Data
3 Ground
4 VCC
5 Mouse Clock
6 Keyboard Clock

FabiaTech Corporation
12
The FB2653 supports a four port USB connector. Any USB device can be attached to
USB ports with plug-and-play supported. The left side port is USB # 1/2 and the right side
port is USB # 3/4
 DB1 & CN6, CN7: Connecting the COM ports
The DB9 connector on bracket is 9-pin D-type male connector the serial port
COM3 and COM4 adapter cables are used to transfer 10-pin IDC connector into
standard DB9 connectors. The DB1 (COM1/2) is standard serial port connector.
The following tables show the signal connections of these connectors. Serial port 2
is designed for multiple proposes. Use BIOS setting select the RS-232, RS422 or RS-
485, and JP2 provides terminator select of RS-485 mode.
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
USB#1~4 Signal
Pin 1 USBV
Pin 2 USBD-
Pin 3 USBD+
Pin 4 USBG
DB-9 RS-232 RS-422 RS-485
1 -DCD
6 -DSR
2 RXD RX- 485-
7 -RTS TX-
3 -TXD RX+ 485+
8 -CTS TX+
4 -DTR
9 -RI
5 Ground
Metal Case Ground
4
1
USB connector
Factory Preset: RS232
*Note: Changing the setting in
BIOS setup program
32 1
3 2 1
Pin 1,2 Close:
Terminator
Enabled
JP2
Pin 2,3 Close:
Terminator
Disable
Default

FabiaTech Corporation
13
 JP3, JP4, JP5 & JP8: Select Power Source Jumper Select
All Serial ports provide power source will driver the “RI” signal pin if JP3, JP4 for
COM3, COM4 and JP5, JP8 for COM1, COM2 were located on the power output
position.
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
 J10: Touch Screen Header
J10 provide basic RS-232C signals of serial port 2 respectively. The basic RS-232C
signal is used to interface with touch screen controller internally.
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
3
1
J10
Pin 1: TXD
Pin 2: RXD
Pin 3: Ground
1
2
3
46
5
Factory Preset
+12V
JP3/JP4 JP3
/
JP4
RI3~RI4 +5V
JP3/JP4
65
4 3
1
2
Factory Preset
+12V
JP5/JP8 JP5
/
JP8
RI1/RI2 +5V
JP5/JP8
6 5
4 3
12
65
4 3
1
2
1
2
3
4 6
5 1
2
3
46
5

FabiaTech Corporation
14
 J7: 5-pin Infrared Header
The J7 provide infrared signal is used to interface with Infrared modules.
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
 CN12: Connecting the Audio Microphone In/ Speak Out
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
 J4: TTL I/O Connector (5-pin 2.0mm JST)
LED1
JP9
BUS1
BZ1
J9
J10 SW1 DB1 CN12 CN13 CN11CN14 CN10CN9
JP8
JP5
CN5
J11
CN6
CN7
JP3
JP4 J3
JP2
J7 J6
BT1
JP6
JP1
CN2
CN4
CN3
J5
J8
J4DIMM1 J2 J12
LED2
CN1
J4 TTL Lines Bit Location
1 Output Line 0 Bit 6 of 404eh
2 Output Line 1 Bit 7 of 404eh
3 Input Line 0 Bit 2 of 404bh
4 Input Line 1 Bit 3 of 404bh
5 Ground -
Line-Out
Mic-In
J
4
5
1
Pin 1: VCC
Pin 2: N.C.
Pin 3: IRRX
Pin 4: Ground
Pin 5: IRTX
5
1
J7
