fantastic furniture Java User manual

Version 1.0
Java
Dresser 6 Drawer
fantasticfurniture.com.au
Required
Two People

fantasticfurniture.com.au Page 2
Warning: Ensure the wall strap is attached
to avoid serious injury
To avoid any serious or fatal injury, a wall strap has been provided with
this product to prevent toppling. We strongly recommend that this
product is permanently fixed to the wall or other suitable surface. Fixing
of what fixing device to use.
Rattan
Rattan is a natural material that will respond to humidity in the
environment. Low humidity may cause the rattan to shrink.
High humidity may cause the rattan to absorb moisture and expand,
causing the weaving to look loose and wavy.
This is a natural phenomenon and not a defect.
Looks like you’ve found
your Fantastic!
Love it? Share it!
We’re thrilled you’ve chosen Fantastic Furniture
to help create a home you’ll love!
Fantastic buy! Share how it looks at home on Instagram
for your chance to win a $250 Fantastic Furniture Gift Card!
@fantasticfurniture

Read through the instructions carefully
before you begin.
Assembly Checklist
Identify and lay out all of the
components before you begin assembly.
Unless instructed, do not fully tighten
screws until the item is fully assembled.
!Never use power tools unless specifically instructed. They can damage your
components or hardware if used incorrectly.
!The most common mistakes made during assembly are using the wrong hardware or
getting components back to front.
!Always use a soft surface (such as carpet or cardboard) when assembling your
product to avoid scratching or damaging the surface of the product.
!Bulky items such as wardrobes and bunk beds should be assembled in the room they
will be used in as they may not fit through a door once assembled.
!Never use any glue until you are certain that the parts belong together.
!Periodically check and re-tighten all fasteners. Check the product care label or
website for product care instructions.
!If you are having any diculties assembling your product, missing any hardware or
components please visit our website Help Centre for further assistance.
!Please see page 2 for any safety requirements or weight restrictions.
Make sure you have all the required tools.
Never use power tools unless instructed.
Useful Information
fantasticfurniture.com.au Page 3

Parts list
Carton 1:
1 x Top Panel (P1)
1 x Left Side Panel (P2)
1 x Right Side Panel (P4)
1 x Bottom Panel (P5)
1 x Back Panel (P6)
4 x Legs (P7)
1 x Large Middle Leg (P8)
1 x Small Middle Leg (P9)
What you need
to assemble the product
Other tools you need
Flat Head Screwdriver;
Phillips Head Screwdriver;
Mallet
fantasticfurniture.com.au
Page 4
Carton 2:
1 x Divider Panel (P3)
6 x Drawer Left Sides (P10)
6 x Drawer Right Sides (P11)
6 x Drawer Backs (P12)
6 x Drawer Rails (P13)
6 x Drawer Bases (P14)
6 x Drawer Fronts (P15)
Top Panel (P1)
Left Side Panel
(P2)
Right Side Panel
(P4)
Divider Panel
(P3)
Bottom Panel (P5)
Back Panel (P6)
Large Middle
Leg (P8)
Samll Middle
Leg (P9)
Leg (P7)
Leg (P7) Leg (P7)
Leg (P7)
X6
Drawer Front (P15)
Drawer Rail (P13)
Drawer Base (P14)
Drawer Back (P12)
Drawer Left
Side (P10)
Drawer Right
Side (P11)

fantasticfurniture.com.au
Page 5
Hardware Pack
45 x Cam Bolts
(H1)
9 x Large Cam
Nuts (H2)
14 x Dowels ø8mm
(H3)
6 x Handles
(H4)
16 x Screws 16mm
(H6)
12 x Flat Washers
(H9)
8 x Spring
Washers (H10)
12 x Screws 28mm
(H11)
1 x Allen Key
(H12)
4 x Felt Pads
(H5)
8 x Bolts 55mm
(H8)
12 x Back Panel
Connectors (H7)
2 x Screws 25mm
(H14)
36 x Small Cam
Nuts (H15)
2 x Wall Straps
(H13)
12 x Dowels ø6mm
(H16)
43 x Screws 38mm
(H17)
12 x Slides
(H19)
72 x Screws 12mm
(H18)
1 x Adjustable
Foot (H20)

Page 6fantasticfurniture.com.au
H1
H5
H12
H8
H10
H9
(P7)
(P7) (P7)
(P7)
(P5)
(P5)
Attach 1 x felt (H5) onto each leg (P7) as shown.
Attach 1 x leg (P7) onto bottom panel (P5), using 2 x bolts (H8), 2 x spring washers (H10)
and 2 x flat washers (H9).
Tighten the bolts with allen key (H12).
Repeat this step for the other 3 x legs (P7).
Screw 3 x cam bolts (H1) into bottom panel (P5).
X4
Step 1
You will need
4 x Felt Pads
(H5)
Step 2
You will need
8 x Bolts
(H8)
8 x Flat
Washers (H9)
8 x Spring
Washers (H10)
1 x Allen Key
(H12)
3 x Cam Bolts
(H1)
H1
H1
(P7)
(P7)

Page 7
Insert 2 x dowels (H3) into large middle leg (P8) and small middle
leg (P9).If needed use a mallet to gently tap the dowels into place.
Screw 1 x adjustable foot (H20) into large middle (P8).
Attach small middle leg (P9) to large middle leg (P8) with 1 x screw (H17),
using a phillips head screwdriver.
(P5)
(P8)
(P9)
H2
H2
H2
Position the assembled middle legs (P8, P9)
onto the bottom panel as shown.
Insert 3 x large cam nuts (H2) into the assembled middle legs (P8, P9).
Rotate the cam nuts so the arrows point towards the incoming
cam bolts.
Using a flat head screwdriver turn clockwise to lock.
With assistance, turn the assembled frame over.
fantasticfurniture.com.au
H20
H3
H3
H17
(P8) (P8)
(P9) (P9)
This is how a cam nut works........
The head of the cam
bolt goes into the open
mouth of the cam nut.
You then turn the cam
nut so it tightens over
the bolt.
Required
Two People
Phillips Head
Screwdriver
2 x Dowels
ø8mm (H3)
1 x Adjustable
Foot (H20)
1 x crews
38mm (H17)
Mallet
3 x Large Cam
Nuts (H2)
Flat Head
Screwdriver
Step 3
You will need
Step 4
You will need

Step 5
Page 8fantasticfurniture.com.au
You will need
Phillips Head
Screwdriver
18 x Screws
12mm (H18)
6 x Slides
(H19)
Mallet
H19
Separate the 12 x slide runners (H19-2) and slide tracks (H19-1)
from the slides (H19) by following the steps below:
Extend the slide runner (H19-2) all the way out.
Press down the plastic release lever on the slide track (H19-1)
and pull out the slide runner (H19-2) completely.
H19
Slide runner H19-2 Slide track H19-1
H19-1
H19-1
Note the position of the rubber stopper
Attach 6 x separated slide tracks (H19-1)
onto left & right side panels (P2, P4)
with 18 x screws (H18), using a phillips head screwdriver as shown.
Ensure the slide tracks (H19-1) are attached so the rubber stopper is positioned
near the grooves on left & right side panels (P2, P4) as shown.
Insert 8 x dowels (H3) into left & right side panels (P2, P4) as shown.
If needed use a mallet to gently tap the dowels into place.
Adjust runner to access the screw holes.
H19-1
8 x Dowels
ø8mm (H3)
H3
H3
H3
H3
H18
H19-1
H19-1
H19-1
H19-1
Please fasten the screws through
these holes for this step.
H18
H18
H18
H18
H18
H3
H3
H18
H18
H18
H18
H19-1
H19-1
H19-1
H3
H3
H18
H18
(P2)
(P4)

Step 6
Page 9fantasticfurniture.com.au
You will need
Phillips Head
Screwdriver
18 x Screws
12mm (H18)
6 x Slide
Tracks (H19-1)
Mallet
H19-1
Attach 3 x separated slide tracks (H19-1)
onto divider panel (P3)
with 9 x screws (H18) as shown.
Turn divider panel (P4) over.
Attach 3 x separated slide tracks (H19-1) onto divider panel (P3) with 9 x screws (H18)
as shown,
using a phillips head screwdriver.
It is important to note that the screws on this side need to be fixed into dierent holes
compared to the slide track (H19-1) on the other side of the divider panel (P3).
Insert 4 x dowels (H3) into divider panel (P3) as shown.
If needed use a mallet to gently tap the dowels into place.
H19-1
4 x Dowels
ø8mm (H3)
H19-1
Please fasten the screws through
these holes for this step.
(P3)
(P3)
Raw
edge
H19-1
H19-1
H19-1
H19-1
H19-1
H19-1
H3
H3
H3
H3
H18
H18
H18
H18
H18
H18
H18
H18
H18
H18
H18
H18
H19-1
Please fasten the screws through
these holes for this step.
Note the position
of the rubber stopper
Important Note:
The screws need to be fixed
into dierent holes compared
to the other side.

Page 10fantasticfurniture.com.au
(P6)
Required
Two People
H17
H17
H17
H17
H17
H17
(P2)
(P3)
(P4)
(P5)
Required
Two People
With assistance, attach left & right side panels (P2, P4) and divider panel (P3)
to bottom panel (P5), ensuring the grooves on all panels (P2, P4, P5) align.
Screw 6 x screws (H17) into left & righ side panels (P2, P4) and divider panel (P3) as shwon,
using a phillips head screwdriver. With assistance, carefully turn the assembled frame over.
Unfold and slide back panel (P6)
into the grooves
on left & righ side panels (P2, P4) and bottom panel (P5).
(P2)
(P4)
(P3)
(P5)
Step 7
You will need
Phillips Head
Screwdriver
6 x Screws
38mm (H17)
Step 8
Laminated
edge

Page 11fantasticfurniture.com.au
Screw 6 x cam bolts (H1) into top panel (P1), using a phillips
head screwdriver.
H2
H2
(P1)
(P1)
H2
H2
H2
H2
H1
H1
H1
H1
H1
H1
Required
Two People
(P2)
(P4)
Step 9
You will need
Step 10
You will need
Flat Head
Screwdriver
6 x Large Cam
Nuts (H2)
6 x Cam Bolts
(H1)
Phillips Head
Screwdriver
With assistance, position top panel (P1) onto the assembled frame as shown.
Insert 6 x large cam nuts (H2) into left & right panels (P2, P4) and divider panel (P3).
Rotate the cam nuts so the arrows point towards the incoming cam bolts.
Using a flat head screwdriver turn clockwise to lock.
(P3)

Page 12fantasticfurniture.com.au
If necessary, gently adjust the top panel (P1) sideways in either direction
until XX and YY are equal.
Holding it in place, fix 12 x back panel connectors (H7) to assembled unit
with 12 x screws (H6) as shown, using a phillips head screwdriver.
Screw 4 x screws (H6) into back panel (P6) as shown, using a phillips head screwdriver.
Screw 36 x cam bolts (H1) into drawer fronts (P15x6), using a phillips head screwdriver.
X6
Step 11
You will need
Step 12
You will need
Phillips Head
Screwdriver
16 x Screws
16mm (H6)
12 x Back Panel
Connectors (H7)
36 x Cam
Bolts (H1)
Phillips Head
Screwdriver
H6
H6
H6
H6
Required
Two People
(P1)
XX
YY
XX
YY
XX=YY
H7
H6
(P1)
(P1)
H7
(P6)
(P6)
(P6)
H7 H7 H7 H7
H7
H7
H7
H7
H7
H7
(P15)
H1
H1
H1
H1
H1

Page 13fantasticfurniture.com.au
Insert 1 x dowel (H16) into each side panel (P10, P11) as shown.
If needed use a mallet to gently tap the dowels into place.
(P15)
(P10)
(P11)
(P13)
H15
H15
H15
H15
H15
Position 1 x drawer left side (P10),
1 x drawer right side (P11)
and 1 x drawer rail (P13) onto drawer front (P15).
Ensure the grooves on drawer left & right side (P10, P11) and drawer rail (P13) align.
Insert 6 x small cam nuts (H15) into drawer left & right sides (P10, P11) and drawer rails (P13).
Rotate the cam nuts so the arrows point towards the incoming cam bolts.
Using a flat head screwdriver turn clockwise to lock.
Repeat this step for the other 5 x drawer assembly.
X6
X6
H16
(P10)
H16
(P11)
Step 13
You will need
Step 14
You will need
Mallet
12 x Dowels
ø6mm (H16)
Flat Head
Screwdriver
36 x Small
Cam Nuts (H15)

Page 14fantasticfurniture.com.au
(P14)
(P10)
(P11) (P15)
Slide drawer base (P14)
into the grooves on drawer left & right sides (P10, P11) and drawer front (P15).
Repeat this step for the other 5 x drawer assembly.
H17
H17
H17
H17
H17
H17
(P11)
(P10)
(P13)
(P12)
Attach drawer back (P12) onto an assembled drawer with 6 x screws (H17),
using a phillips head screwdriver as shown.
Repeat this step for the other 5 x drawer assembly.
X6
X6
Step 15
Step 16
You will need
36 x Screws
38mm (H17)
Phillips Head
Screwdriver
Ensure the pre-drilled holes
on drawer left & right sides (P10, P11) align
with holes on back panel (P12),
and the holes on back panel (P12)
align with the holes on
drawer rail (P13).

Step 17
Page 15fantasticfurniture.com.au
H19-2
You will need
Phillips head
screwdriver
36x Screws
12mm (H18)
12 x Slides
Runners(19-2)
Please fasten the screws through
these holes for this step.
Attach 1 x slide runner (H19-2) to each drawer left side (P10) and drawer right side (P11)
with 3 x screws (H18), using a phillips head screwdriver as shown.
Repeat this step for the other 5 x drawer assembly
Step 18
Phillips head
screwdriver
6 x Handles
(H4)
12 x Screws
28mm (H11)
(P15)
(H4)
H11
Attach 1 x handles (H4) onto a drawer front (P15) with 2 x screws (H11),
using a phillips head screwdriver as shown.
Repeat this step for the other 5 x drawer assembly
X6
You will need
H19-2
H19-2
H19-2
H19-2
H18
(P11)
H18
H18
H18
H18
H18
H11
(P10)

Page 16fantasticfurniture.com.au
Step 19
H19-2
H19-1
Move inner ball bearing track
to front of slide track (H19-1).
Gently insert drawer slide runner (H19-2)
in between the ball bearing track.
Position drawer so that slide runners (H19-2) align with slide tracks (H19-1) as shown.
Gently push drawer into the closed position.

Page 17fantasticfurniture.com.au
Step 20
H14
H9
H13
H14
H9
H13
H13
H9 H14
Fix 2 x wall straps (H13) to
top panel (P1) with
2 xscrews (H14) and
2 x flat washers (H9)
as shown, using a phillips
head screwdriver.
Step 21
You will need
2 x Flat
Washer (H9)
Phillips Head
Screwdriver
H9
Wall
Screw
H13
Required
Two People
Seek advice from a qualified
trades person on how to
attach this wall strap to
your specific wall.
Screw and wall plug are not included.
Please use appropriate fixtures for your wall.
With assistance, move the dresser to its final position.
Attach the wall straps to the wall with
the appropriate fixtures using a phillips head screwdriver.
Make sure they are firmly attached and secure.
We strongly recommend
that this product is permanently
fixed to the wall
or other suitable surface.
You will need
2 x Flat
Washers (H9)
2 x Screws
25mm (H14)
2 x Wall Straps
(H13)
Phillips Head
Screwdriver

Step 22
Page 18fantasticfurniture.com.au
Job complete!
In the interest of our environment please dispose
of all packaging thoughtfully.
