Festo MPA-F Series Operating and installation instructions

Description
Pneumatic MPAF
Valve terminal with
MPA−F pneumatics
Types:
MPAF−MPM−... and
MPAF−FB−...
Description
547 526
en 0804NH
[703 999]
MPA−F valve terminal

Contentsand general safety instructions
I
Festo P.BE−MPAF−EN en 0804NH
Original de. ......................................
Edition en 0804NH. ................................
Designation P.BE−MPAF−EN..........................
Orderno.547526. ................................
E(Festo AG&Co.KG, D73726 Esslingen, Germany, 2008)
Internet: http://www.festo.com
E−mail:[e-mail]
The reproduction, distribution and utilisation of this docu
ment as well as the communication of itscontentsto others
without express authorisation is prohibited.Offenderswill
beheld liable for compensation of damages. All rightsare
reserved, in particular the right to carry out patent, utility
model or ornamental design registration.

Contentsand general safety instructions
II Festo P.BE−MPAF−EN en 0804NH

Contentsand general safety instructions
III
Festo P.BE−MPAF−EN en 0804NH
Contents
Intended use VII..........................................................
Rangeof application and certificationsVII.....................................
Target group VIII..........................................................
Service VIII...............................................................
Notes on the use of this manual IX...........................................
Important user instructionsXI..............................................
1. Overview of components 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1The MPA−F valveterminal 1−4.........................................
1.1.1Overview of variants1−5.....................................
1.1.2 Description of components1−7................................
1.1.3 Connection and display components1−27........................
2. Assembly 2−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2.1General instructionson mounting and dismounting 2−4...................
2.2 Mounting variants2−5..............................................
2.2.1 Mounting / dismounting on an H−rail 2−6........................
2.2.2 Mounting / dismounting fromawall 2−10........................
2.3 Mounting/Dismounting the labelling system 2−13.........................
2.4 Mounting/dismounting the manual overridecap2−18.....................
3. Installation 3−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
3.1Compressed air preparation 3−4......................................
3.1.1Operation withnon−lubricated compressed air3−4................
3.1.2 Operation withlubricated compressed air3−4....................
3.2 General notes on connecting the tubing 3−7.............................
3.2.1Laying the tubing 3−8........................................

Contentsand general safety instructions
IVFesto P.BE−MPAF−EN en 0804NH
3.3 Connecting the MPA−F valveterminal 3−10...............................
3.3.1Pilot controlof the solenoid coils (pilot air supply) 3−11.............
3.3.2 MPA−F valveterminal withpressurezoneseparation 3−13...........
3.3.3 Operating the MPA−F valveterminal withreversible pressure
regulating valves 3−15........................................
3.3.4Setting the pressureregulating valve3−15.......................
3.3.5 Vacuum/ lowpressureoperation 3−18..........................
3.3.6 Connecting the pneumatic tubing 3−21..........................
3.3.7 Connecting the electric cables 3−24.............................
3.4Address assignment of the valves 3−29..................................
3.4.1MPA−F valveterminal withCPX terminal 3−29......................
3.4.2 MPA−F valveterminal withmulti−pin plug connection 3−31...........
4. Commissioning 4−1
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
4.1General information 4−4.............................................
4.1.1Beforecommissioning 4−4....................................
4.1.2 Pressureincrease in the completesupply 4−4....................
4.2 Manual override4−6................................................
4.3 Checking the valves and the valve−actuator combination 4−8...............
4.4LEDdisplay of the valves 4−13.........................................
4.5 Troubleshooting 4−16................................................
4.5.1Impairment of function 4−16...................................
4.5.2 Operating states of the pneumatic system 4−17...................

Contentsand general safety instructions
V
Festo P.BE−MPAF−EN en 0804NH
5. Conversion and maintenance 5−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
5.1General precautionary measures 5−4
..................................
5.2 Dismounting the MPA−F valveterminal 5−5..............................
5.3 Maintaining the MPA−F valveterminal 5−6...............................
5.3.1Cleaning the flat platesilencer5−6.............................
5.3.2 Swap the flat platesilencer or the exhaust plate5−7..............
5.3.3 Replacing valves or cover plates 5−7...........................
5.3.4Replacing electronics modules 5−10.............................
5.3.5 Replacing the manifold block, supply plateor MPA−F end plate5−17
..
5.3.6 Replacing interlinking boards5−21..............................
5.4 Converting the MPA−F valveterminal 5−25...............................
5.4.1 Conversion to different pressurezones 5−25......................
5.4.2 Adding valvepositions5−29...................................
5.4.3 Adding an electric supply plate(only for MPA−F valveterminal withCPX ter
minal)5−33.................................................
5.4.4Adding apressures sensor plate5−34...........................
A. Technical appendix A−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
A.1Technical dataA−3..................................................
A.2 Festo accessories A−16...............................................
B. Supplementary overview of components B−1. . . . . . . . . . . . . . . . . . . . . . . . . . .
B.1Overview of valveposition componentsB−3.............................
B.2 Isolating the MPA−F valveterminal fromthe CPX terminal B−12...............
C. Index C−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Contentsand general safety instructions
VIFesto P.BE−MPAF−EN en 0804NH

Contentsand general safety instructions
VII
Festo P.BE−MPAF−EN en 0804NH
Intended use
The MPA−F valveterminals described in this manual arein
tended for fitting into amachineor automated system. The
user must at all times observethe safety regulationsspeci
fied in this manual as well as the instructionsconcerning the
designated use of the relevant MPA−F valveterminal. The
MPA−F valveterminals may only beused as follows:
as designated in industrial applications
in original statuswithout unauthorised alterations.
Only the conversionsor modificationsdescribed in the
documentation accompanying the product arepermitted.
in technically perfect condition.
When used together withcommercially available compo
nents, such as actuators, the specified limitsfor pressures,
temperatures, electrical data, torques etc. must beobserved.
National and local safety regulationsmust also beobserved.
Range of application and certifications
The product fulfils the requirementsof the EU directives and
is marked withthe CE marking symbol.
Standardsand test values, which the product must comply
withand fulfil, can befound in the section Technical data".
The product−relevant EU directivecan befound in the declar
ation of conformance.

Contentsand general safety instructions
VIII Festo P.BE−MPAF−EN en 0804NH
Target group
This manual is directed exclusively at technicianstrained in
controland automation technology.
Service
Please consult your local Festo repair service if you haveany
technical problems.

Contentsand general safety instructions
IX
Festo P.BE−MPAF−EN en 0804NH
Notes on the use of this manual
This manual containsspecific information on mounting, in
stalling, commissioning, servicing and converting the MPA−F
valveterminal. It describes only the pneumatic components
and refersto the valveterminal connection variantslisted in
the table below.
Connection variants of the valve terminal type MPAF−..−VI
WithCPX terminal
Information on CPX modules can be
found in the manual for the relevant
module. An overview is provided in the
system description of your CPX ter
minal, table Descriptionsof the CPX
terminal".
WithMP connection
Information on the electric/electronic
components:
see leaflet withproduct
Tab.0/1: Connection variantsof the MPA−F valveterminal

Contentsand general safety instructions
XFesto P.BE−MPAF−EN en 0804NH
An overview of all user documentation for the CPX terminal is
provided in the corresponding system description.
The MPA−F valveterminal consistsof pneumatic and electric
components. The most important componentsareshown in
the following Fig.
12345 6
7
8
1
aJ
9
3
9
1Flat platesilencer or exhaust plate
2Pressuresensor plate
3Valves
4Cover plate
5Electrical supply plate
6End plate
7Pneumatic air supply plate
8Pressureregulator plate
9Manifold blocks
aJ Pneumatic part of the multiple
connector plateor the pneumatic
interface
Fig.0/1: Main componentsof the MPA−F valveterminal

Contentsand general safety instructions
XI
Festo P.BE−MPAF−EN en 0804NH
Important user instructions
Danger categories
This manual containsinstructionson the possible dangers
which can occur if the product is not used correctly.These
instructionsaremarked (Warning, Caution, etc), printed on
ashaded background and marked additionally withapicto
gram. Adistinction is madebetween the following danger
warnings:
Warning
... meansthat failureto observethis instruction may result
in seriouspersonal injury or damageto property.
Caution
... meansthat failureto observethis instruction may result
in personal injury or damageto property.
Note
... meansthat failureto observethis instruction may result
in damageto property.
The following pictogram markspassages in the text which
describeactivities withelectrostatically sensitivecompo
nents:
Electrostatic sensitivedevices: inappropriatehandling can
result in damageto components.

Contentsand general safety instructions
XII Festo P.BE−MPAF−EN en 0804NH
Identification of specific information
The following pictograms mark passages in the text which
contain special information.
Pictograms
Information:
Recommendations, tipsand references to other sources of
information.
Accessories:
Information on necessary or usefulaccessories for the Festo
product.
Environment:
Information on environment−friendly use of Festo products.
Text notations
·The bullet indicates activities which may becarried out in
any order.
1.Numerals denoteactivities which must becarried out in
the numerical order specified.
Arrowheadsindicategeneral lists.

Contentsand general safety instructions
XIII
Festo P.BE−MPAF−EN en 0804NH
The following product−specific terms and abbreviationsare
used in this manual:
Term/abbreviation Meaning
Basic componentsComponent (pneumatic interface, multiple connector plate, pneumatic
manifold block or pneumatic air supply plate) on which further com
ponents(exhaust plates, flat platesilencers, pressureregulator plate,
valves or cover plates) aremounted.
Blanking platePlatewithout valvefunction for sealing unused valvepositionson
manifold blocks.
ComponentsCommon termfor pneumatic interface, multiple connector plate, ex
haust plate, flat platesilencer, pneumatic manifold block or pneu
matic air supply plate, electrical supply plate, end plate, pressure
regulator plate, valveand cover plate
Connecting the tubing Connecting the supply lines (tubing) to the MPA−F valveterminal
CPX modules Common termfor the variousmodules which can beincorporated in a
CPX terminal
CPX terminal Modular, electric terminals of type50 and type53
Electrical interface Common termfor pneumatic interface or multiple connector plate.
Electrical supply platePlatefor additional load supply to the valves
Electronics module Module in the manifold block withan LED and solenoid coil manage
ment
End plateExtreme right−hand plateof the MPA−F valveterminal and extreme
left−hand plateof the CPX terminal withholes for fitting onto awall.
Exhaust platePlatefor ducted exhaust air withacommon exhaust port (3/5) or separ
ateexhaust ports(3) and (5).
I/O Input/output modules
Manifold block Platefor mounting monostable, bistable or mid−position valves, with
working lines (2) and (4).
SizeMPA1 with4 valvepositions
SizeMPA2 with2valvepositions
MO Manual overrideactuator
MPA1 or MPA23 Sizedesignation of the MPA−F valveterminal with10mm (MPA1) or
(MPA2) 20 mm widevalves

Contentsand general safety instructions
XIVFesto P.BE−MPAF−EN en 0804NH
Term/abbreviation Meaning
MPA−F valveterminal with
multi−pin plug connection
TypeMPAF...−MPM−...:
Variant of the MPA−F valveterminal withasub−D plug used to centrally
connect all valvesolenoid coils. The electrical interlinking is modular,
i.e. every manifold block has itsown circuit board.
Multi−pin plug connection Connection withmodular electrical interlinking typeMPAF...−MPM−..
Pneumatic air supply platePlatefor additional supply of compressed air to the valves, e.g.for
several pressurezones.
Pneumatic interface The pneumatic interface is the interface between the modular electri
cal peripherals of the CPX terminal and the MPA−F pneumatics.
Pneumatic module Module consisting of pneumatic manifold block, electronics module,
valves or cover plates and possibly withvertical stacking
Selector end plateRight−hand end plateof the MPA−F valveterminal withpilot air connec
tions(12/14) and (82/84).The selector end platehas acoding cap.
The setting of the coding cap defined whether the valveterminal is
operated using an internal or external pilot air supply.
Separating seal Special seal for creating pressurezones.
ValveMonostable, bistable and mid−position valves
Valveterminal MPA−F (Type33) valveterminal withmultiple connector or CPX ter
minal
Tab.0/2: Product−specific terms and abbreviations

Overview of components
1−1Festo P.BE−MPAF−EN en 0804NH
Chapter 1

1.Overview of components
1−2Festo P.BE−MPAF−EN en 0804NH
Contents
1. Overview of components 1−1. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
1.1The MPA−F valveterminal 1−4.........................................
1.1.1Overview of variants1−5.....................................
1.1.2 Description of components1−7................................
1.1.3 Connection and display components1−27........................

1.Overview of components
1−3
Festo P.BE−MPAF−EN en 0804NH
Contentsof this chapterThis chapter provides an overview of the following aspectsof
the MPA−F valveterminal:
the connection variantsand componentsof the valve
terminal
the maximumnumber of valvepositions
the identification codes of the pneumatic components
 Connection, display and operating elements
Further information Instructionson connecting the electric multi−pin plug can be
found in the accompanying leaflet.
Information on the modules of the CPX terminal can befound
in the CPX System Manual.
Information on the electronics modules of the MPA−F valve
terminal is provided in the accompanying leaflet and the
corresponding electronics description (see the system de
scription for your CPX terminal, table Descriptionsof the
CPX terminal").

1.Overview of components
1−4 Festo P.BE−MPAF−EN en 0804NH
1.1 The MPA−F valve terminal
Festo supportsyour machinetable automation taskswiththe
MPA−F valveterminal. The modular design of this valveter
minal allows you to optimally customizethe valveterminal to
suit your machineor plant.
The pneumatic valveterminal provides the following connec
tions:
Common channels for supply and exhaust air
Electric signals for all solenoid coils
Working lines (2) and (4) areprovided for each valveposition
on the individual pneumatic modules. The valves aresupplied
withcompressed air (operating pressureand pilot pressure)
via the common channels and connectionsin the basic com
ponents. The exhaust air (fromthe valves and the pilot ex
haust air) is also exhausted via these common channels.
Further modules for pressuresupply arealso available, e.g.
in order to supply pressurezones.
The valveterminal is fitted withcurrent reduction.The rated
current of the solenoid coils is reduced after the high−current
phase (switching operation).The current reduction offersthe
following advantages:
The valveterminal has alower energy consumption
The power supply unit for the voltagesupply to the valve
terminal can bedesigned moreeconomically depending
on the individual case
The solenoid coils haveless leakagepower and produce
less wasteheat
