Heatscope Spot User manual

ORIGINAL INSTALLATION
AND INSTRUCTION MANUAL
Electric ambient carbon radiant heater
for indoor and outdoor areas
Made in Germany
US
Art.-Nr.: 19-010-S
EMC
WEEE-Reg.-Nr.
DE45650441
IP44
VISION
IP24
SPOT

GreenChance Inc. · 8417 Washington Blvd. · Roseville USA CA95678
US
SAFETY INFORMATION
HEATSCOPE® infrared heaters must be installed and executed only by an
authorized expert / trained professional electrician in accordance with
the applicable standards and regulaons for electrical wiring in electrical
trade in the respecve country / region of installaon.
Have a qualied electrician install a properly grounded receptacle outlet,
acceptable for outdoor use and protected from snow and rain, immedi-
ately adjacent to the locaon where the heater will be used. Route the
supply cord and locate the heater so as to be protected from damage by
live stock. Do not use extension cords. Inspect cord before using. Unplug
heater at receptacle outlet when not in use or before removing, and
store heater indoors aer winter season.
All relevant local building and re safety regulaons must be observed at
any me and under any circumstances.
WARNING: This unit is not equipped with an applicaon to regulate the
room temperature. The heater must not be used in small rooms inha-
bited by people who cannot leave the room unaided, unless constant
supervision is ensured.
Be careful when operang the unit. Children younger than 3 years must
be kept away, unless they are overseen all the me. Children older than
3 years and younger than 8 years are allowed to switch on and o the
unit, if they are overseen, or if they were instructed how to use the unit
safely and have received instrucons how to operate/use the unit, assu-
med the unit is installed properly. CAUTION: Some parts of the unit get
very hot and may cause burns! High cauousness is imperave, if child-
ren or persons with reduced physical, sensory or mental abilies or lack
of experience and/or knowledge. are present in the room.
Children older than 3 years and younger than 8 years are not allowed to
connect the plug, to control the unit, to clean the unit and/or to main-
tain the unit.
Children older than 8 years and persons with reduced physical, sensory
or mental abilies or lack of experience and/or knowledge can use this
MUNICH HOME SYSTEMS

Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net US
unit, if they are overseen, or if they were instructed how to use the unit
safely and have received instrucons how to operate/use the unit and
which en dangerments may result during the use of the unit. Children
must not be playing with the unit. Cleaning and maintenance must not
be done by children, unless they are supervised by a person responsible
for their safety.
The unit must never be used unaended. Children must be supervised
at all mes to ensure that they do not play with the unit, switch it on
unintenonally or adjust it.
CAUTION! The device is not intended for use by persons (including child-
ren) with reduced physical, sensory or mental capacity – it has to be kept
out of reach from these persons especially from children.
It is NOT ALLOWED to use the heater in hazardous locaons listed below;
installaon in non-hazardous locaons only:
· Class I, Division 1 classied locaons (areas where ignitable concentra-
ons of ammable gases, vapors or liquids can exist all of the me or
some of the me under normal operang condions);
· Zone 0 classied locaons (areas where ignitable concentraons of
ammable gases, vapors or liquids are present connuously or for long
periods of me under normal operang condions);
· Zone 1 classied locaon (areas where ignitable concentraons of am-
mable gases, vapors or liquids are likely to exist under normal operang
condions);
· Class I, Division 2 or Zone 2 classied locaons (areas where ignitable
concentraons of ammable gases, vapors or liquids are not likely to
exist under normal operang condions);
· Class II, Division 1 classied locaons (areas where ignitable concentra-
ons of combusble dust can exist all of the me or some of the me
under normal operang condions);
· Class II, Division 2 classied locaons (areas where ignitable concentra-
ons of combusble dust are not likely to exist under normal operang
AMBIENT HEATING SOLUTIONS

GreenChance Inc. · 8417 Washington Blvd. · Roseville USA CA95678
US
MUNICH HOME SYSTEMS
condions);
· Class III, Division 1 classied locaons (areas where easily ignitable
bers or materials producing combusble yings are handled, manufac-
tured or used.
· Class III, Division 2 classied locaons (areas where easily ignitable
bers are stored or handled);
· Zone 20 classied locaons (areas where ignitable concentraons of
combusble dust or ignitable bers/yings are present connuously or
for long periods of me under normal operang condions);
· Zone 21 classied locaon (area where ignitable concentraons of com-
busble dust or ignitable bers/yings are likely to exist under normal
operang condions);
· Zone 22 classied locaons (areas where ignitable concentraons of
combusble dust or ignitable bers/yings are not likely to exist under
normal operang condions).
1. Please check that your HEATSCOPE® radiant heater and accessories are
complete and not damaged. In special take care of the glass holders of
the model range VISION, which hold and surround the glass ceramic front
screen. Press the holders carefully back in posion, unll they click into
place again.
If the housing or reector is deformed/damaged or the heang element is
broken, do not use the HEATSCOPE® unit. Please contact the vendor or the
manufacturer.
The cable must not be crushed, squeezed or damaged.
If the unit or accessories show signs of defects, cracking, breakage or
other damage or if the industrial glass ceramics screen is damaged, discon-
nue use and have them repaired. In this case, disconnect the unit from
the power supply, return it to the manufacturer or dispose of it. The unit
should be labelled accordingly to prevent it being reconnected.
2. For installaon use only the supplied accessories or original accessories

Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net US
AMBIENT HEATING SOLUTIONS
approved by the manufacturer. The power cable or other components of
the HEATSCOPE® radiant heater may only be replaced by a professional
servicing company enlisted by the manufacturer. Before starng the
installaon, you must ensure that the operang voltage corresponds to
that stated on the nameplate of the HEATSCOPE® or accessories. Note that
depending on the currently available supply voltage the actual power of
the device may change as well as the emied power as a result of environ-
mental inuences.
The supply cable must be connected generally in a commercially available
wet room distribuon box with IP65 protecon class acc. to IEC or UL /
CSA (not within the scope of supply).
3. HEATSCOPE® heaters together with all available accessories feature IP
protecon class IP44 (model VISION) resp. IP24 (model SPOT). Neverthel-
ess, it is mandatory to install the unit on a surface where it is well pro-
tected from any weather inuences like rain and dust from above; so the
HEATSCOPE® has to be installed under a roof, an overhang or in combio-
naon with the oponal available weather shield. Never install the HEAT-
SCOPE® heater on combusble material like wood, wooden surfaces etc.
4. CAUTION! To provide connued protecon against risk of electric shock,
connect to properly grounded outlets only. As soon as the unit is con-
nected to a power source and switched on using an „ON/OFF“ switch or
other operang component, it takes a maximum of 15-30 seconds unl it
reaches its operang temperature.
Important! Before rst use, please clean the heater surface with an alco-
hol-free customary glass cleaner. Fingerprints can cause discolour at the
surface.
5. CAUTION! Hot surface! Avoid contact! Risk of burns! – The front screen
(approx. 572 °F) and protecve n front (approx. 572 °F) gets very hot
while the unit is operang.
Do not cover either part of the front or the enre front of the radiant hea-
ter. Do not touch any part of the HEATSCOPE® during operaon and up to
30 minutes aer switching it o.

GreenChance Inc. · 8417 Washington Blvd. · Roseville USA CA95678
US
MUNICH HOME SYSTEMS
6. For your own safety, never dry texles or other materials using the
HEATSCOPE®. Covering the radiant heater may result in a re! Always
maintain a distance from the heang surface of the HEATSCOPE® of at
least 59.06 inch from texles, cloth and other easy inammable so mate-
rials.
7. Ensure that cables, furniture, ammable materials or other objects do
not come into contact with the surface of the radiant heater and never
cover the unit. Under no circumstances should the unit be covered or en-
closed with insulang or similar materials. Adequate venlaon surroun-
ding the heater must be ensured at any me. Ledgers, beams and raers
must not be cut into or grooved to install the infrared heater.
When installing the HEATSCOPE® radiant heater, ensure that the lower
edge of the unit is at least 70.87 inch from the ground and the safety
clearances from the wall and ceiling set out in this manual are maintained.
Always maintain a distance from the heang surface of the HEATSCOPE®
of at least 59.06 inch from texles, cloth and other easy inammable so
materials.
8. Disconnect the radiant heater from the power supply before cleaning
it, adjusng the angle or removing it from the wall/ceiling. Wait unl the
heang elements are not glowing any more and the housing is nocably
cooled down. If buried cables are used, switch o the power using an
omnipolar switch.
9. The HEATSCOPE® features an omnipolar „ON/OFF“ switch. The unit can
be controlled manually either using an IR remote control (supplied, de-
pending on the model) or a selector switch on the unit itself (depending
on the model as well). The unit must be connected to a residual current
circuit breaker and a fuse on the installaon side – a ground fault circuit
interrupter (GFCI) must be installed.
10. The unit must only be used with an approved isolang system, which
must be built in the exisng electrical installaon acc. to the facility regula-
ons. The heater comes as standard with a separate open-ended cable for
connecon purposes.

Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net US
AMBIENT HEATING SOLUTIONS
11. The power cable or buried cable with omnipolar switch may only be
replaced by a professional specialist electrical company enlisted or appro-
ved by the manufacturer. Heang elements, other components or parts of
the housing may only be replaced by a service organisaon enlisted by the
manufacturer.
If you yourself or someone enlisted by you carries out repairs, they will not
be covered by the guarantee. Improper repairs and incorrect installaon
or operaon shall invalidate the guarantee immediately.
12. If the heater was installed inappropriately or was connected unhomo-
geneously with the local electrical supply cable, high transfer resistances
may occur, which lead to overheang of the device. For the heang system
and many custom applicaons the heaters were equipped with a NTC
tempe rature control and an addional latching temperature limiter.
Ordinarily possible overhaeng due to inappropriate installaon is protec-
ted by the NTC temperature control and the latching temperature limiter.
If overheang of a carbon heang element occur due to interlinkage of
mounng and installaon mistakes, the carbon laments inside of the
quarz tubes will fuse and safely disconnect the current ow. Even aer a
mechanical break of the quarz tubes, the carbon heang spirals will not
work any longer. Besides the n front screen of the SPOT heaters and the
glass ceramic, high temperature resistant front screen of the VISION hea-
ters provide best pro tecon of the installed carbon heang elements.
Funconal descripon of the NTC temperature control: If the system
temperature of the electronical control exceeds 217.4 °F, the upper hea-
ng element will shut o temporary by default to avoid overhaeng of
the electronical parts. Aer a short me the heang element will switch
on automacally again. The self-controlled shut o of the heater will take
place only, if the heat dissipaon inside the device is inappropriate, if
the heat radiaon is interfered or if the ambience temperetaure is way
too high. Apart from that the NTC temperature control supports energy
sangs, if the ambient tempe ratures are too high and the highest heang
level of the heang unit is not necessary.
Funconal descripon of the latching temperature limiter: If the NTC

GreenChance Inc. · 8417 Washington Blvd. · Roseville USA CA95678
US
temperature control is not working against expectaons, the latching tem-
perature limiter will shut down the lower heang element permanently,
unl the heater is shut o totally by hand. Aer cooling down (warm to
the touch) and xing the inappropriate heat dissipaon inside the device
and/or the interferred heat radiaon the heater can be switched on again.
If the lower heang element shuts down once more, a system malfuncon
or a heat dissipaon inside the device or an interference of the heat radia-
on or an error in the electrical installaon may be the reason. If a system
malfuncon inside the device causes the shut down, the heater must be
repaired by a professional technician; please contact your dealer imme-
diately. If a wrong cable connecon causes the shut down, this has to be
checked and xed through a professional electrician on the spot.
Installaon and connecng regulaons with tested and approved luster
terminals are part of the delivered equipment.
13. The radiant heater must not be installed directly below a power sour-
ce/socket. The sides of the unit must be at least 7.87 inch from the nea-
rest power source. Sockets/power sources must be freely accessible at all
mes and comply with the following specicaons: 220–240 V AC ~, 50/60
Hz, 16 A with 16 A fuse. No other loads may be connected to this power
source.
14. The radiant heater must must not be installed in rooms where there
is high humidity (bathroom, spa, pool etc.) in close vicinity to bathtubes,
showers or pools. The distance to the bathtub or shower must be at least
39.37 inch and the distance to the pool at least 78.74 inch. A person
standing in the bathtube, shower or pool should never reach the switch or
controller of the heater. If the HEATSCOPE® is installed in such an envi-
ronment with high humidity, the switches or other operang components
must be posioned in such a way that they cannot be touched by per-
sons who are in direct contact with water. Bathroom heaters must not be
operated with a separate automac thermostat or mer. When a radiant
heater is installed in a bathroom, the CE standard requires that at least
one heang element visibly „glows“ as soon as the unit is switched on.
15. CAUTION! To provide connued protecon against the risk of electric
MUNICH HOME SYSTEMS

Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net US
shock, disconnect the supply cord before cleaning., adjusng the angle
or removing it from the wall/ceiling. Wait unl the heang elements are
not glowing any more and the housing is nocably cooled down. If buried
cables are used, switch o the power using an omnipolar switch. Wait at
least 30 minutes aer the last use before you start cleaning it. All surfaces
should be cleaned using a damp cloth only. Never use cleaning products
containing alkaline substances such as sodium hydroxide or soap, surfac-
tants or solvents such as alcohol. Use only a very so cloth or a brush for
the reector and the heang elements.
16. Make absolutely sure to always switch o the device aer use.
AMBIENT HEATING SOLUTIONS

GreenChance Inc. · 8417 Washington Blvd. · Roseville USA CA95678
US
Ceiling Installaon
2 x2 x 2 x 4 x
1 x
1. 2.
3.
2 x
2 x 4 x2 x
A (inch) B (inch)
MHS-SP1600 ≤ 9.45 ≥ 5.32
MHS-SP2200 ≤ 11.81 ≥ 6.89
MHS-SP2800 ≤ 14.57 ≥ 6.89
≤ A
≥ B ≥ B
MUNICH HOME SYSTEMS
A (inch) B (inch)
MHS-VE1600/MHS-VT1600 ≤ 11.81 ≥ 6.89
MHS-VE2200/MHS-VT2200 ≤ 25.59 ≥ 6.89
MHS-VE2800/MHS-VT2800 ≤ 45.28 ≥ 6.89

Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net US
Wall mounng
1. 2.
3.
2 x
1 x
2 x 2 x 4 x2 x 2 x 4 x 4 x2 x
≤ A
≥ B ≥ B
≤ A
≥ B ≥ B
≤ A
≥ B ≥ B
AMBIENT HEATING SOLUTIONS

GreenChance Inc. · 8417 Washington Blvd. · Roseville USA CA95678
US
O
I
III
Manual control
MHS-VE1600BK.200, MHS-VE2200BK.200, MHS-VE3200BK.200,
MHS-VE1600WT.200, MHS-VE2200WT.200, MHS-VE3200WT.200
O
I
III
O
I
IIIIII
100 %
50 %
0 %
O
I
III
0 %
LED:
MUNICH HOME SYSTEMS
O
I

Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net US
IR remote control
MHS-SP1600BK.250, MHS-SP2200BK.200, MHS-SP2800BK.200,
MHS-SP1600WT.250, MHS-SP2200WT.200, MHS-SP2800WT.200
MHS-VT1600BK.200, MHS-VT2200BK.200, MHS-VT3200BK.200,
MHS-VT1600WT.200, MHS-VT2200WT.200, MHS-VT3200WT.200
AMBIENT HEATING SOLUTIONS
O
I
ON
/ OFF
+ 1
– 1




AMBIENT HEATING
MIN.
/ MAX. ·
···
O
I
O
I
0 %
0 %
100 %


O
I


50 %


100 %
O
I
O
I


0 %
0 %
LED:

GreenChance Inc. · 8417 Washington Blvd. · Roseville USA CA95678
US
Electrical connecon 110–120 V AC~
G
L2
L1
O
I
HEATSCOPE® SP
MHS-SP1600BK.250
MHS-SP1600WT.250
MUNICH HOME SYSTEMS
110-120 V AC~
50/60 Hz
G L2 L1
Circuit breaker / fuse switch
on the installaon side
The supply cable must be connected
generally in a commercially available wet
room distribuon box with IP65 protecon
class acc. to IEC or UL / CSA (not within the
scope of supply).
INPUT

Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net US
MHS-SP1600BK.250
MHS-SP1600WT.250
AMBIENT HEATING SOLUTIONS

GreenChance Inc. · 8417 Washington Blvd. · Roseville USA CA95678
US
Electrical connecon 220–240 V AC~
G
L2
L1
O
I
HEATSCOPE® SP // HEATSCOPE® VT
MHS-SP2200BK.200, MHS-SP2800BK.200,
MHS-SP2200WT.200, MHS-SP2800WT.200
MHS-VT1600BK.200, MHS-VT2200BK.200, MHS-VT3200BK.200,
MHS-VT1600WT.200, MHS-VT2200WT.200, MHS-VT3200WT.200
MUNICH HOME SYSTEMS
220-240 V AC~
50/60 Hz
G L2 L1
Circuit breaker / fuse switch
on the installaon side
The supply cable must be connected
generally in a commercially available wet
room distribuon box with IP65 protecon
class acc. to IEC or UL / CSA (not within the
scope of supply).
INPUT

Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net US
L1 L1
G
L2
L1
acc. VDE 0293
MHS-VE1600BK.200, MHS-VE2200BK.200, MHS-VE3200BK.200,
MHS-VE1600WT.200, MHS-VE2200WT.200, MHS-VE3200WT.200
O
I
III
HEATSCOPE® VE
220-240 V AC~
50/60 Hz
AMBIENT HEATING SOLUTIONS
G L2
A: 50% B: 50%
Circuit breaker / fuse switch
on the installaon side
The supply cable must be connected
generally in a commercially available wet
room distribuon box with IP65 protecon
class acc. to IEC or UL / CSA (not within the
scope of supply).
INPUT

GreenChance Inc. · 8417 Washington Blvd. · Roseville USA CA95678
US
Minimum distances wall mounng
The following installaon regulaons ensure that the HEATSCOPE® ambient heater is working eecvely.
All minimum clearances that must be met regardless of the installaon environment are listed.
MUNICH HOME SYSTEMS



> 70.78 inch
> 5.91 inch
< 15.75 inch
> 70.78 inch
> 70.78 inch
> 5.91 inch
> 59.06 inch
> 15.75 inch
> 59.06 inch

Phone: [phone]-1001 · Fax: [phone] · E-Mail: inf[email protected] · www.greenchance.net US
X X
X
AMBIENT HEATING SOLUTIONS
The clearances given are minimum values and may dier from the local building and re regula-
ons.The laer must be observed and complied with in any case.

GreenChance Inc. · 8417 Washington Blvd. · Roseville USA CA95678
US
MUNICH HOME SYSTEMS
Minimum distances ceiling mounng
The following installaon conguraon ensures that the HEATSCOPE™ radiant heater is working eecvely.
All the minimum clearances that must be met regardless of the installaon environment are listed.



> 78.74 inch
> 6.69 inch
> 15.75 inch
> 78.74 inch
> 78.74 inch
> 5.91 inch
> 59.06 inch
> 6.69 inch
> 3.94 inch
> 15.75 inch
