HYOSUNG MONiSAFE500S User manual

Installation Manual
MONiSAFE500S System
V01.00.00 (2019.06.21)
© Hyosung TNS Inc. All Rights Reserved.

© Hyosung TNS Inc. All Rights Reserved. I
Revision History
Installation Manual –MONiSAFE500S (MS500S) System
No.
Version
Date
Description of Change
Chapter
1
V01.00.00
2019/06/21
New Publication
All
© Hyosung TNS All Rights Reserved.
The content of this specification is protected by copyright laws.
2019. 06. 21. 1st Release

II © Hyosung TNS Inc. All Rights Reserved.
Contents
Chapter1. Preface...........................................................................................................................1-1
Purpose.........................................................................................................................................................1-1
Audience.......................................................................................................................................................1-1
Support Information ......................................................................................................................................1-1
What is in This Manual..................................................................................................................................1-1
Terminologies................................................................................................................................................1-2
Abbreviations of ATM....................................................................................................................................1-2
Safety Precautions........................................................................................................................................1-4
Précautions pour la sécurité (French)...........................................................................................................1-6
Related Document ........................................................................................................................................1-9
Chapter2. Introduction...................................................................................................................2-1
About the MS500S........................................................................................................................................2-1
System Identification Label...........................................................................................................................2-2
Chapter3. Installation Information ................................................................................................3-1
Installation Condition and Space ..................................................................................................................3-1
Exterior..........................................................................................................................................................3-2
Service Area..................................................................................................................................................3-6
Chapter4. System Installation .......................................................................................................4-1
Unpacking the ATM.......................................................................................................................................4-1
Installation Frame..........................................................................................................................................4-2
Power Requirements ....................................................................................................................................4-5
Notes.......................................................................................................................................Notes-1

Installation Manual Chapter1.Preface
© Hyosung TNS Inc. All Rights Reserved. 1-1
Chapter1. Preface
Purpose
▶This manual is produced to provide the guidelines for installers to comply with while installing it.
▶This manual describes how to prepare for and to proceed the installation of MS500S in advance.
Audience
▶This manual is for persons related to installing ATM in branches of banks, such as designers and
construction workers of the branches and ATM installers, to work efficiently and conveniently.
Support Information
▶If any question or installation error occurs while preparing for and installing ATM in compliance
with this manual, please contact maintenance staffs of Hyosung TNS. For the contact of
maintenance staffs of Hyosung TNS, see the E-mail addresses and telephone numbers provided
separately.
What is in This Manual
▶MONiSAFE referred to as “MS”
▶This manual is designed to provide the installation guide for the ATM and the detailed description
of the following:
▪Important Warnings
▪Information for installation
▶All information described in this manual is a licensed product of Hyosung TNS.
Some of the information in this manual may differ according to the network processor to be
connected and may be subsequently updated by the bank’s needs or the improvement by
Hyosung TNS.
It Is the policy of Hyosung TNS to improve products as new technology, components, software,
and firmware become available. Therefore Hyosung TNS reserves the right to change
specifications without notice.

Chapter1.Preface Installation Manual
1-2 © Hyosung TNS Inc. All Rights Reserved.
Terminologies
▶In this document the terminology listed below is used as follows:
▪Customer and consumer refer to any person who transacts business through the ATM.
▪Device and unit refer to the standard and optional ATM equipment, such as monitor, card reader,
printer and dispenser.
▪Fascia refers to the entire front portion of the unit, including the portion where the customer
transacts business.
▪Module refers to a plug-in device that can be serviced or replaced.
▪Note(s) and bill(s) refer to the individual documents loaded into and dispensed from the dispenser.
▪Servicing and maintenance refer to the supervisor, operator and technician’s tasks performed to
keep the ATM operational.
▪Screen refers to the text appearing on the customer display.
Abbreviations of ATM
▶In this document the abbreviations listed below is used as follows:
#
Abbreviations
Description
1
AD board
Analog Digital Board
2
ADA
The American Disabilities Act
3
AP
Application Program
4
Assy
Assembly
5
BRM
Bill Recycle Module
5-1
BC
Bill Checker Unit
5-2
BM
Body Module
5-3
BMD
Bill Recycling Machine Lower
5-4
BMU
Bill Recycling Machine Upper
5-5
CSM
Customer Service Module
5-6
CST
Transit Cassette
5-7
C Tr
Center Transport
5-8
F Tr
Front Transport
5-9
M Tr
Middle Transport
5-10
O Tr.
Option Transport
5-11
RC
Recycling Cassette
5-12
RJC
Reject Cassette
5-13
R Tr.
Rear Transport
6
BATT S/W
Battery Switch

Installation Manual Chapter1.Preface
© Hyosung TNS Inc. All Rights Reserved. 1-3
7
CAM
Camera Unit
8
CE
Control Electronics
9
EP
Elementary Program
10
H/W
Hardware
11
I/F
Interface
12
LCD
Liquid Crystal Display
13
OPL
Operation Panel for Customers to Operate
14
OSD board
On Screen Display Board
15
P/S
Power Supply
16
PNC
Panel Control Board
17
S/W
Switch
18
SIU
Sensor and Indications Unit
19
SP
Service Provider
20
TTU
Text Terminal Unit (OPL or SPL)

Chapter1.Preface Installation Manual
1-4 © Hyosung TNS Inc. All Rights Reserved.
Safety Precautions
▶Common Safety Precaution
Safety Precautions in outlined this manual provide information on safe and
proper handling of the product. Non-compliance of the safety precautions
may result in injury or damage to the product.
This precaution symbol with sample term tells you safety warnings during
equipment handlings.
▶Please read the following instructions before operating equipment.
▪Operate equipment in the order outlined in this manual.
▪Follow precautions indicated in this manual, as well as the equipment itself.
Failure to properly address these precautions may lead to injury or damage to the product.
▪Avoid operations not addressed in this manual.
▪If you cannot remedy system problems using the methods outlined in this manual, please refer to
contact information listed in the manual.
▪Any change or modifications in construction of this device which are not expressly approved by
the party responsible for compliance could void the user’s authority to operate the equipment.
<Note!>
This equipment has been tested and found to comply with the limits for a Class A digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference in which
case the user will be required to correct the interference at his own expense.
▶CAUTION
1. To reduce the risk of fire, use only No. 26 AWG OR LARGER Telecommunication cord
2. Risk of explosion if battery is replaced by an incorrect type.
Dispose used batteries according to the instructions.
3. For pluggable equipment, the socket-outlet shall be installed near the equipment and shall be
easily accessible.
4. The equipment is to be secured to the building structure before operation
5. A security container shall be permitted to optionally be provided with a secondary lock, but
improper use of the secondary lock feature will reduce the security level of the ATM.

Installation Manual Chapter1.Preface
© Hyosung TNS Inc. All Rights Reserved. 1-5
▶Description of Precaution Symbols
Symbol
Description
Electrical Shock Warning
▪Do not remove cover. Only a maintenance engineer is allowed to open
the cover.
▪Do not touch. You may receive electric shock.
▪Make sure to turn off the power when servicing the equipment.
High Temperature Warning
▪Do not touch the equipment when it is running.
▪The equipment can get extremely hot and may cause a burn.
▪Make sure to close the cover before running the equipment.
Use Precaution when Moving
▪The equipment is heavy. Make sure at least 2 people lift or move the
equipment.
▪Do not attempt to move the equipment alone. You may be injured from
dropping the heavy equipment.
Fire Hazard
▪Place the equipment in an area away from any combustible materials.
▪The equipment may catch on fire from overheating or short circuit of
the power supply unit.
Disassembly Warnings
▪Do not disassemble or modify the equipment unless you are a certified
engineer.
▪Contact the service center for maintenance, adjustments and repairs.
▪Improper disassembly may cause fire or electrical shock.
Collapse Precautions
▪Do not place the equipment where the floor cannot sustain the weight
of the equipment, or on slanted or unstable surface.
▪Equipment may fall and cause injury or damage.
Unplug the Equipment
▪Stop using the equipment immediately if it smokes, emits an unusual
smell, makes abnormal sounds, or if liquids or other foreign materials
enter the equipment.
▪If the above-mentioned abnormalities occur, immediately turn off the
power, unplug the equipment and contact the service center.
▪If you ignore these symptoms, the equipment may catch on fire or
cause electric shock.

Chapter1.Preface Installation Manual
1-6 © Hyosung TNS Inc. All Rights Reserved.
Précautions pour la sécurité (French)
►Précaution générale pour la sécurité
Précautions décrits de ce manuel fournissent des informations
sur une manipulation sûre et appropriée du produit. Le non-
respect des précautions peut causer des blessures ou
endommager le produit.
Ce symbole de précaution avec le terme d’example vous
indique des consignes de sécurité lors de la manipulation de
l'équipement.
►Veuillez lire des instructions suivantes avant d'utiliser l'équipement
▪Fonctionner l'équipement dans l'ordre indiqué dans ce manuel.
▪Suivre les précautions indiquées dans ce manuel, ainsi que l'équipement lui-même.
Le défaut de traiter correctement de ces précautions peut entraîner des blessures ou
endommager le produit.
▪Évitez des opérations non traitées dans ce manuel.
▪Si vous ne pouvez pas résoudre des problèmes du système en utilisant des méthodes
décrites dans ce manuel, veuillez se référer aux informations de contact figurant dans
le manuel, s’il vous plaît.
▪Certain changement ou des modifications dans la construction de ce dispositif qui ne
sont pas expressément approuvés par la partie responsable de la conformité
pourraient annuler l'autorité de l'utilisateur de faire fonctionner l'équipement.
<REMAQUE!>
Cet équipement a été testé et fondé pour se conformer aux limites pour un équipement
numérique de classe A, conformément à la partie 15 des règles FCC. Ces limites sont
conçues pour fournir une protection raisonnable contre des interférences nuisibles
lorsque l'équipement est utilisé dans un environnement commercial. Cet équipement
génère, utilise et peut émettre des fréquences radios et, s'il n'est pas installé et utilisé
conformément aux instructions de ce manuel, peut causer des interférences nuisibles
aux communications radios.
Le fonctionnement de cet équipement dans une zone résidentielle est susceptible de
provoquer des interférences nuisibles dans le cas, l'utilisateur devra corriger ces
interférences à ses propres frais.
►Description des symboles de précaution
Symbole
Description
Choc électrique
• Ne pas retirer le couvercle. Seul le technicien d'entretien est
autorisé à ouvrirle couvercle.
• Ne pas toucher. Vous pouvez avoir un choc électrique.
• Assurez-vous d'éteindre l'appareil lors de l'entretien de
l'équipement.

Installation Manual Chapter1.Preface
© Hyosung TNS Inc. All Rights Reserved. 1-7
Symbole
Description
Àhaute temperature
• Ne pas toucher l’équipement quand il est en marche.
• L’équipement peut devenir extrêmement chaud et peut
provoquer une brûlure.
• Assurez-vous de fermer le couvercle avant de lancer
l'équipement.
Soyez prudent lors du déplacement
• L'équipement est lourd. Assurez-vous d'au moins 2 personnes
pour soulever ou déplacer l'équipement
• N'essayez pas de déplacer l’équipement seul. Vous pouvez
être blessés par la chute de l'équipement lourd.
Risque d'incendie
• Placer l’équipement dans une zone éloignée de tous les
matériaux combustibles.
• L'équipement peut s'enflammer de surchauffe ou de court-
circuit de l'unité d'alimentation.
Démontage
• Ne pas démonter ou de modifier l'équipement, sauf si vous
êtes ingénieur certifié.
• Contacter le centre de service pour l'entretien, le réglage et
la réparation.
• Le mauvais démontage peut provoquer un incendie ou un
choc électrique.
Tomber
• Ne pas placer l'équipement dont le sol ne peut pas supporter
le poids de l'équipement, ou sur une surface inclinée ou
instable.
• L'équipement peut tomber et provoquer des blessures ou
des dommages.
Débrancher l'équipement
• Cessez d'utiliser l’équipement immédiatement si il fume, émet
une odeur inhabituelle, fait des bruits anormaux ou si des
liquides ou d'autres matériaux étrangers dans l'équipement.
• Si les anomalies mentionnées ci-dessus se produisent,
éteignez immédiatement la puissance, débranchez l'appareil
et contactez le centre de service.
• Si vous ignorez ces symptômes, l’équipement peut prendre
feu ou provoquer un choc électrique.
AVERTISSEMENT :
1. POUR RÉDUIRE LES RISQUES D'INCENDIE, UTILISEZ UNIQUEMENT AWG n °
26 OU LA LIGNES DE TELECOMMUNICATION PLUS GROSSE
2. RISQUE D'EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UN TYPE
INCORRECT. DISPOSER POUR UTILISATION DES BATTRIES SELON LES
INSTRUCTIONS

Chapter1.Preface Installation Manual
1-8 © Hyosung TNS Inc. All Rights Reserved.
3. POUR LES APPAREILS RACCORDES, LA PRISE DOIT ETRE INSTALLEE PRES
D’EQUIPEMENT POUR ÊTRE FACILEMENT ACCESSIBLE
4. L’EQUIPEMENT DOIT ETRE SECURISE A LA STRUCTURE DU BATIMENT AVANT
D'UTILISER

Installation Manual Chapter1.Preface
© Hyosung TNS Inc. All Rights Reserved. 1-9
Related Document
▶The related documents are listed as follows. If needed, please contact staffs of our technical
support team and maintenance team.
▪Operator Manual
▪Service Manual
For the contact of maintenance staffs of Hyosung TNS, see the E-mail addresses and telephone
numbers provided separately.

Installation Manual Chapter2.Introduction
© Hyosung TNS Inc. All Rights Reserved. 2-1
Chapter2. Introduction
About the MS500S
►The MS500S is a versatile, easily maintained delivery system that can be modified to keep pace
with the bank's changing needs.
►The benefits that the new concept MS500S provides are as follows.
Removes inconvenience which occurs when bank clerks directly handle cash with customers and
relieves workload upon tellers by processing deposit/ withdrawal of cash automatically.
Relieves risks and burden of directly handling cash by directly keeping cash deposited in a safe.
Allows tellers to calculate and close amount on hand faster than the existing manual calculation.
Abank customer and a teller can easily interact on a touch screen, just like talking, through
Hyosung TNS’s intuitive and easy UI.
Allows easy and quick installation and maintenance.

Chapter2.Introduction Installation Manual
2-2 © Hyosung TNS Inc. All Rights Reserved.
System Identification Label
►The System Label below shows the layout of the product identification label which is fixed inside the
ATM.

Installation Manual Chapter3.Installation Information
© Hyosung TNS Inc. All Rights Reserved. 3-1
Chapter3. Installation Information
Installation Condition and Space
►When you determine the location of your ATM, ensure that the physical environment including the
temperature and humidity, meets the requirements. Following conditions should be met before
installing equipment.
1. Avoid locations where intense direct sunlight is reflected off the LCD screen.
2. Avoid locations where strong static electricity can occur.
3. The ATM should be mounted on concrete or other nonflammable surface only.
4. The floor must allow easy wheelchair access from the front or the side.
5. Space required for servicing the machine should be considered before installation.

Chapter3.Installation Information Installation Manual
3-2 © Hyosung TNS Inc. All Rights Reserved.
Exterior
►Front Elevation

Installation Manual Chapter3.Installation Information
© Hyosung TNS Inc. All Rights Reserved. 3-3
►Side Elevation

Chapter3.Installation Information Installation Manual
3-4 © Hyosung TNS Inc. All Rights Reserved.
►Plan View

Installation Manual Chapter3.Installation Information
© Hyosung TNS Inc. All Rights Reserved. 3-5
►ISO View

Chapter3.Installation Information Installation Manual
3-6 © Hyosung TNS Inc. All Rights Reserved.
Service Area
►Minimum Installation
