Hyosung NH2700
Manual
StockCheck.com

NH 2100T
Table of Contents
1. Introduction
1.1 About NH 2100T ·········································································· 1-2
1.2 Features ························································································ 1-2
1.3 What is in this Manual ·································································· 1-3
1.4 Terminologies ··············································································· 1-4
2. Safety Precautions
2.1 Overview ······················································································· 2-2
2.2 Description of Precaution Symbols ············································ 2-3
3. Hardware Specifications
3.1 Dimensions ····················································································· 3-2
3.2 Component Name and Locations ··············································· 3-3
3.3 LCD & Customer Keypad ····························································· 3-5
3.4 CDU (Cash Dispensing Unit) ························································· 3-6
3.5 SPR (Slip Printer/Receipt Printer) ··············································· 3-7
3.6 MCU (Magnetic Card Unit) ····························································· 3-8
3.7 Main Control Board ········································································ 3-9
3.8 Operating Environment ····························································· 3-10
4. Operating Instructions
4.1 Opening and Closing the Doors ·················································· 4-2
4.2 Replenishing the Cash Cassette ·················································4-4
4.3 Emptying the Reject Box ···························································· 4-6
4.4 Removing Bills ····································································· 4-7
4.5 Loading the Receipt Paper ······················································ 4-9
4.6 Receipt(Slip) Paper Jam Removal················································ 4-11
StockCheck.com

NH 2100T
5. Operator Functions
5.1 Basic System Operation ································································ 5-2
5.2 Settlement ··················································································· 5-5
5.3 Journal ················································································· 5-11
5.4 Report ·········································································· 5-19
5.5 Diagnostics ·········································································· 5-27
5.6 Customer Setup ·········································································· 5-39
5.7 System Setup ·········································································· 5-50
5.8 Host Setup ·········································································· 5-70
5.9 Transaction Setup ········································································ 5-94
6. Appendix
A. Summary of Specification ···························································· 6-2
B. Bill Conditions ················································································ 6-3
C. Receipt Paper Specifications ························································ 6-8
D. Magnetic Card Specifications ························································· 6-9
E. Error Codes Table ··································································· 6-10
StockCheck.com

NH 2100T 1. Introduction
1
1-
Chapter 1. Introduction
StockCheck.com

NH 2100T 1. Introduction
2
1-
1. Introduction
1.1 About the NH 2100T
The NH 2100T (Through-The-Wall Type) is designed to meet the higher transaction
volumes and the low maintenance components. Whether installed as a walk-up or drive-
through, NH 2100T offers solid, weatherized construction while its compact architecture
allows flexibility in mounting. The NH 2100T is easy to use, easy to service and is able
to support customer’s needs.
1.2 Features
H/W Features
zUL 291 Business Hours Vault
zElectronic combination lock
z5.7” mono trans-flective LCD (sun-viewable)
z16-key alphanumeric keypad (Encrypting PIN Pad)
z2,000 notes capacity Cash Dispenser(CDU)
zDip type magnetic card reader
zSemi-automated receipt paper loading and cutting
z56K modem for dial-up
zVoice guidance system
zModular design for easy maintenance
Functional Features
zElectronic journal
zQuick setup feature
StockCheck.com

NH 2100T 1. Introduction
3
1-
1.3 What is in this manual
This NH 2100T Manual contains all information needed for normal operational use.
This manual contains Unit Specifications, Opening & Closing Procedures, Operator
Functions(Supervisor Screen), Error Recovery, etc.
Some of the information in this manual may be subsequently updated based on the
customer’s needs or the improvement by Nautilus Hyosung.
StockCheck.com

NH 2100T 1. Introduction
4
1-
1.4 Terminologies
CE : Control Electronics◈
Earphone Jack : Voice Converter for Visually Disabled Persons (ADA)
◈
◈CDU : Cash Dispensing Unit
EPP : Encrypted PIN Pad
◈
ISO: International Standard Organization
◈
ISO 1: IATA(International Air Transaction Association)
◈
◈ISO 2: ABA (American Banks Association)
ISO 3: MINTS
◈(Mutual Institutions National Transfer Systems)
MCU : Magnetic Card Unit
◈
OPL : Operator
◈Panel (LCD Screen)
P/S : Power Supply
◈
SPR : Slip Printer (Receipt Printer)
◈
T
◈-SPL : Supervisor Panel (LCD Screen)
StockCheck.com

NH 2100T 2. Safety Precautions
1
2-
Chapter 2. Safety Precautions
StockCheck.com

NH 2100T 2. Safety Precautions
2
2-
2. Safety Precautions
2.1 Overview
Common Safety Precaution
Please read the following instructions before operating equipment.
zOperate equipment in the order outlined in this manual.
zFollow safety precautions indicated in this manual, as well as the equipment itself.
Failure to properly address these precautions may lead to injury or damage to
the product.
zAvoid operations not addressed in this manual.
zIf you cannot remedy system problems using the methods outlined in this manual,
please refer to contact information listed in the manual.
Safety Precautions outlined this manual provide
information on safe and proper handling of the
product. Non-compliance of the safety precautions
may result in injury or damage to the product.
This precaution symbol with sample term tells you
safety warnings during equipment handlings.
StockCheck.com

NH 2100T 2. Safety Precautions
3
2-
2.2 Description of Precaution Symbols
Symbol Description
Electrical Shock Warning
• Do not remove cover. Only a maintenance engineer in allowed to
open the cover.
• Do not touch. You may receive electric shock.
• Make sure to turn off the power when servicing the equipment.
High Temperature Warning
• Do not touch the equipment when it is running.
• The equipment can get extremely hot and may cause a burn.
• Make sure to close the cover before running the equipment.
Use Precaution when Moving
• The equipment is heavy. Make sure at least 2 people lift or move the
equipment.
• Do not attempt to move the equipment alone. You may be injured
from dropping the heavy equipment.
Fire Hazard
• Place the equipment in an area away from any combustible materials.
• The equipment may catch on fire from overheating or short circuit of
the power supply unit.
Disassembly Warnings
• Do not disassemble or modify the equipment unless you are a
certified engineer.
• Contact the service center for maintenance, adjustments and repairs.
• Improper disassembly may cause fire or electrical shock.
Collapse Precautions
• Do not place the equipment where the floor cannot sustain the weight
of the equipment, or on slanted or unstable surface.
• Equipment may fall and cause injury or damage.
StockCheck.com

NH 2100T 2. Safety Precautions
4
2-
Symbol Description
Unplug the Equipment
• Stop using the equipment immediately if it smokes, emits an unusual
smell, makes abnormal sounds, or if liquids or other foreign materials
enter the equipment.
• If the above-mentioned abnormalities occur, immediately turn off the
power, unplug the equipment and contact the service center.
• If you ignore these symptoms, the equipment may catch on fire or
cause electric shock.
StockCheck.com

NH 2100T 3. Hardware Specifications
3-1
Chapter 3. Hardware Specifications
StockCheck.com

NH 2100T 3. Hardware Specifications
3-2
3. Hardware Specifications
3.1 Dimensions
Fig. 3.1 Dimensions
StockCheck.com

NH 2100T 3. Hardware Specifications
3-3
3.2 Component Name and Locations
Component Location (Front)
Fig. 3.2 Component Location (Front)
1. Lighted Top Panel 5. Flicker
2. LCD & Customer Keypad 6. Card Reader Slot
3. Cash Tray 7. Earphone Jack
4. Slip Printer Slot 8. Encrypted PIN Pad
①
②
③
④⑤
⑥
⑦
⑧
StockCheck.com

NH 2100T 3. Hardware Specifications
3-4
Component Location (Back)
Fig. 3.3 Component Location (Back)
1. Slip Printer(SPR) 4. Supervisor Panel(T-SPL)
2. Cash Dispenser Unit(CDU) 5. System Door
3. Vault Door
①
②
③
④
⑤
StockCheck.com

NH 2100T 3. Hardware Specifications
3-5
3.3 LCD & Customer Keypad
Fig. 3.4 LCD & Customer Keypad
zScreen Size : 5.7″Mono LCD
zResolution : 320 ×240
zDisplay Characters : 40 ×15 (Standard Character)
Keypad
z10 Alphanumeric ,3,4, CANCEL, CLEAR, ENTER, BLANK Keypads
z8 Function Keys
ADA Port
zVoice assisted operation available through the headphone jack on the front bezel
StockCheck.com

NH 2100T 3. Hardware Specifications
3-6
3.4 CDU (Cash Dispensing Unit)
Fig. 3.5 CDU
Cash Dispenser Unit
zFriction feed cash dispensing unit
zDispensing speed : 7 notes/second
zCapacity of 2,000 new notes
zReject bin with capacity of 200 notes
zCash tray sensors
zSlides out for easy service
zDouble detection/Skewed note sensors
StockCheck.com

NH 2100T 3. Hardware Specifications
3-7
3.5 SPR (Slip Printer/Receipt Printer)
Fig. 3.6 SPR
Receipt Printer
z3 1/8" thermal printer
z100 mm/sec print speed
zAutomatic paper loading and cutting
zPaper out sensor
zAccommodates a 7" roll & slides out for easy service
zSee Appendix C : RECEIPT PAPER SEPECIFICATIONS
StockCheck.com

NH 2100T 3. Hardware Specifications
3-8
3.6 MCU (Magnetic Card Unit)
Fig. 3.7 MCU
Magnetic Card Unit
zDip type Card Reader (ISO Track 1 & 2)
zCard read timing : Ejection
zReadable ejection speed : 6 inches ~ 39.3 inches/second
zMTBF : 1 million passes
zSee Appendix D : MAGNETIC CARD SPECIFICATIONS
☞MTBF : Mean Time Between Failures
StockCheck.com

NH 2100T 3. Hardware Specifications
3-9
3.7 Main Control Board
Fig. 3.8 Main Control Board
zModem : 56kbps dial-up modem (standard)
zElectronic Journal : Max 2,000 transactions
zBattery back-up for set-up parameters
zReal Time Clock
