Koden CVS-FX2 User manual

CVS-FX2/FX2BB Document revision history
0093102004-03 i
CVS-FX2/FX2BB Full Menu Reference
Doc No. 0093102004
Document Revision History
No. Doc. No-Rev. No. Date revised
(Y/M/D) Revised content
0 0093102004-00 2012/02/20 First edition
1 0093102004-01 2012/10/10 Menu List, Chapter 2, Chapter 5
2 0093102004-02 2014/03/10 Revision:
(From software KM-F15 Ver. 1.01 34 to Ver. 1.** **)
3 0093102004-03 2014/04/15 Revision:
(From software KM-F15 Ver. 1.01 35 to Ver. 1.** **)
4
5
6
7
8
9
10
Document No. Revised Version Norm
When part of the document needs to be revised, the document has advanced revision number. The
document No. is indicated at the lower right side on the cover and at the left or right side of the footer
region of each page.
© 2012-2014 Koden Electronics Co., Ltd. All rights reserved.
No part of this publication may be reproduced, transmitted, translated in any form by any means without
the written permission of Koden Electronics Co., Ltd. The technical descriptions contained in this
publication are subject to change without notice. Koden assumes no responsibility for any errors,
incidentals or consequential damages caused by misinterpretation of the descriptions contained in this
publication.

Important notice CVS-FX2/FX2BB
ii 0093102004-03
Important Notice
For copy and transcription of this Operation Manual (hereinafter referred to as this
manual), permission from Koden is needed. Koden prohibits the un-authorized copy and
transcription of this manual.
If this manual is lost or damaged, consult a dealer of Koden or Koden.
The specification of the products and the contents in this manual are subject to change
without notice.
The contents displayed on the menu of product may be different from the expression of
this manual. The fonts and shapes of the keys and menus in the illustration may differ
from the actual ones, and some parts may be omitted.
Koden is not liable for damages and troubles arisen from misunderstanding of the
contents in this manual.
Koden is not liable for any damages caused by earthquake, lightning, wind and flood
damage and fire for which Koden is not responsible, and actions by third parties, other
accidents, customer’s unintended error/abuse and the use under other abnormal
conditions.
Koden is not liable for damages of accompaniment (change/loss of memorized content,
loss of business profit, stop of business) arisen from use or failure of our products.
If the stored data are changed or lost, irrespective of causes of troubles and damages,
Koden is not liable for them.
Koden is not liable for any damages arisen from malfunction caused by combination of
software and connected equipment in which Koden is not engaged.

CVS-FX2/FX2BB For Your Safe Operation
0093102004-03 iii
For Your Safe Operation
Symbol used in this Operation Manual
The following graphical symbols are used in this manual. The meaning of each symbols shall
be well understood and apply at maintenance and inspection works.
Symbol Meaning
Mark for warning
This symbol denotes that there is a risk of death or serious injury when
not dealing with it correctly.
Mark for danger high voltage
This symbol denotes that there is a risk of death or serious injury caused
by electric shock when not dealing with it correctly.
Mark for caution
This symbol denotes that there is a risk of slight injury or damage of
device when not dealing with it correctly.
Mark for prohibition
This symbol denotes prohibition of the specified conduct. Description of
the prohibition is displayed near the mark.
Caution items on equipment
Be careful of a high voltage inside.
A high voltage, which may risk your life, is used. This high voltage
remains in the circuit after you have powered off switch. To prevent
touching the high voltage circuit inadvertently, the hard cover is provided
to the high voltage circuit and the high voltage caution label is affixed.
Ensure to power off switch for your safety and discharge the electricity
remaining in the capacity before starting to check. An engineer
authorized by our company should inspect and maintain
Be sure to power off in the boat.
If the power switch is inadvertently powered on during work, you will be
electrified. To prevent such accident from occurring, ensure to power off
in the boat and the power of equipment. Furthermore, it is safer to hang
the caution tag described as [Under Work] near the power switch of
equipment.
Be careful of dust
Inhaling dust may cause A respiratory disease. When cleaning the
inside of equipment, be careful not to inhale dust. Wearing a safety
mask is recommended.
Warning
Caution
Warnin
g
Warning

For Your Safe Operation CVS-FX2/FX2BB
iv 0093102004-03
Caution on location of equipment
Do not install the equipment where it is excessively damp and suffers
from excessive water drops.
Measures against static electricity
The static electricity may be generated from the carpet on the floor in
the cabin or clothes made of synthetic fiber. The static electricity may
destroy the electronic parts on the circuit board. Handle the circuit
board, taking the measure of static electricity free.
Caution at installation of a transducers
Install the transducer at the location where it is not affected by bubble
and noise The bubble and noise seriously degrade the performance of
this unit.
Cautions on handling
Do not disassemble or modify. It may leads to trouble, fire, smoking or
electric shock. In case of trouble, contact our dealer or our company.
In case of smoke or fire, boat power off and the power of this unit. It may
cause fire, electric shock or damage.
Be cautious of remaining high voltage.
A high voltage may remain in the capacitor for several minutes after you
have powered off. Before inspecting inside, wait at least 5 minutes after
powering off or discharge the remaining electricity in an appropriate
manner. Then, start the work.
The information displayed in this unit is not provided directly for your
navigation. For your navigation, be sure to see the specified material.
Use the specified fuse. If un-specified fuse is used, it may cause a fire,
smoke or damage.
Whenever transmitting, be sure to submerge the transducer in water
first. If transmitted without submerging the transducer, it may be
damaged.
Caution
Caution
Caution
Warning
Warning
Caution
Caution
Caution

CVS-FX2/FX2BB Contents
0093102004-03 v
Contents
Document Revision History .......................................................................................................................i
Important Notice ....................................................................................................................................... ii
For Your Safe Operation.......................................................................................................................... iii
Contents ..................................................................................................................................................v
Introduction.............................................................................................................................................. ix
Menu List..................................................................................................................................................x
Chapter 1 Echo Adjust/ Display Setup .................................................................1-1
1.1 Change of TX Power ...................................................................................................................... 1-1
1.1.1 TX Power (HF) ....................................................................................................................... 1-1
1.1.2 TX Power (LF) ........................................................................................................................ 1-1
1.2 Change of dynamic range of Echo................................................................................................. 1-2
1.3 Making of reflection strength at shallow and deep depth equal..................................................... 1-2
1.3.1 Changing of TVG Type........................................................................................................... 1-2
1.3.2 Changing of TVG Strength ..................................................................................................... 1-3
1.3.3 Changing of TVG Depth......................................................................................................... 1-3
1.3.4 Changing of TVG Adjust......................................................................................................... 1-3
1.4 Displaying of A Scope..................................................................................................................... 1-4
1.5 Display in of white line.................................................................................................................... 1-4
1.6 Changing of screen ........................................................................................................................ 1-5
1.6.1 Changing of Background Color of images of echo sounders ................................................ 1-5
1.6.2 Changing of display color of echo sounder images ............................................................... 1-5
1.6.3 To display of Scale/Not to display .......................................................................................... 1-6
1.6.4 Changing of Scale Position .................................................................................................... 1-6
1.6.5 Changing of Scale Value........................................................................................................ 1-6
1.6.6 Displaying of Color Bar Scale ................................................................................................ 1-6
1.6.7 Set the Image Title as frequency/ HFX LFX........................................................................... 1-7
1.6.8 Changing of Image Direction.................................................................................................. 1-7
1.6.9 Changing of display alignment of images .............................................................................. 1-7
1.6.10 Detailed display of image resolution and lapse time............................................................ 1-8
1.6.11 Changing of Width of Zoom Image....................................................................................... 1-8
1.6.12 Zoom Image Split ................................................................................................................. 1-9
1.7 Displaying of Water Temp Window................................................................................................. 1-9
1.7.1 Display of Water Temp Window/Not to display .................................................................... 1-10
1.7.2 Changing of W. Temp. Graph Range ................................................................................... 1-10
1.8 Changing of Depth Font Size and Depth Position/Display of Sub Depth Value .......................... 1-10
1.8.1 Changing of Depth Font Size............................................................................................... 1-10
1.8.2 Changing of display position of depth ...................................................................................1-11
1.8.3 Display of Sub Depth Value ..................................................................................................1-11
1.9 Changing of W. Temp. Font size ...................................................................................................1-11
1.10 Displaying of Speed Value/Not to display................................................................................... 1-12
1.11 Display of Detection Area/Not to display .................................................................................... 1-12
1.12 Widening of Bottom Search Range............................................................................................ 1-13
1.13 Selection of a Sounding Source (frequency).............................................................................. 1-13
1.14 Setting depth to perform Bottom Limit searching at Auto-Range / Auto-Shift ............................ 1-14

Contents CVS-FX2/FX2BB
vi 0093102004-03
1.15 Selecting method for Shift Operation (per each image/for whole screen at the same time)
............................................................................................................................................. 1-14
1.16 Selecting Range Operation (per image/Whole screen at same time)........................................ 1-15
Chapter 2 Alarm ..................................................................................................... 2-1
2.1 Use of Bottom Alarm....................................................................................................................... 2-1
2.1.1 Start/Stop of Bottom Alarm ..................................................................................................... 2-1
2.1.2 Setup of Upper Depth.............................................................................................................2-1
2.1.3 Setup of Lower Depth.............................................................................................................2-2
2.2 Use of Fish Alarm ........................................................................................................................... 2-2
2.2.1 Start/Stop Fish Alarm.............................................................................................................. 2-2
2.2.2 Setup of Fish From.................................................................................................................2-3
2.2.3 Setup of Fish Span .................................................................................................................2-3
2.2.4 Setup of Upper Level..............................................................................................................2-3
2.2.5 Setup of Lower Level.............................................................................................................. 2-4
2.2.6 Setup of Alarm Signal Length.................................................................................................2-4
2.2.7 Setup of Fish Image ...............................................................................................................2-4
2.3 Use Water Temp Alarm................................................................................................................... 2-5
2.3.1 Start/Stop Water Temp Alarm .................................................................................................2-5
2.3.2 Setup of Upper Temp Alarm ................................................................................................... 2-5
2.3.3 Setup of Lower Temp Alarm ...................................................................................................2-6
2.4 Use Speed Alarm............................................................................................................................ 2-6
2.4.1 Start/Stop Speed Alarm ..........................................................................................................2-6
2.4.2 Setup of Speed Limit ..............................................................................................................2-7
2.5 Use the alarm at waypoint navigation............................................................................................. 2-7
2.5.1 Sound alarm at arrival at waypoints ....................................................................................... 2-7
2.5.2 Sound alarm when XTE to waypoint has been found ............................................................ 2-8
2.5.3 Setup of NAV Alarm Range ....................................................................................................2-8
2.6 Voltage Alarm.................................................................................................................................. 2-9
2.7 Confirmation of alarm conditions .................................................................................................... 2-9
Chapter 3 NAV Operation ...................................................................................... 3-1
3.1 Starting waypoint NAV .................................................................................................................... 3-1
3.2 Cancellation of waypoint NAV ........................................................................................................ 3-1
3.3 Editing of Waypoint......................................................................................................................... 3-2
3.4 Deletion of waypoints...................................................................................................................... 3-2
3.5 Deletion of all waypoints in the waypoints list................................................................................. 3-3
3.6 Displaying of NAV Display .............................................................................................................. 3-3
3.6.1 Selection of NAV Display........................................................................................................ 3-4
3.6.2 Selection of types of NAV Display .......................................................................................... 3-4
3.7 Storage of waypoint data ................................................................................................................ 3-6
3.8 Recall of waypoint data................................................................................................................... 3-7
Chapter 4 Image List.............................................................................................. 4-1
4.1 Recall of Image............................................................................................................................... 4-1
4.2 Editing of Image Comment ............................................................................................................. 4-2
4.3 Deleting of Image............................................................................................................................ 4-4

CVS-FX2/FX2BB Contents
0093102004-03 vii
4.4 Deletion of all the images in the Image List ................................................................................... 4-5
4.5 Storage of image files..................................................................................................................... 4-5
4.6 Recall of image files....................................................................................................................... 4-5
Chapter 5 System Setting......................................................................................5-1
5.1 Allocation of function keys (F1/F2) to aimed operation.................................................................. 5-1
5.1.1 Setup of [F1] key....................................................................................................................5-1
5.1.2 Setup of [F2] key....................................................................................................................5-2
5.2 Display/No display of Guide........................................................................................................... 5-2
5.2.1 Display/No display of Guide Window.....................................................................................5-2
5.2.2 Display/No display of Func. Guide Window...........................................................................5-2
5.3 Display/No display of Header......................................................................................................... 5-2
5.4 Limitation of Menu to be changed.................................................................................................. 5-3
5.5 Use of Sona-tone™........................................................................................................................ 5-3
5.6 To reduce frequency of Bubble....................................................................................................... 5-3
5.7 Display/No display of Clock............................................................................................................ 5-3
5.8 Changing of buzzer volume of operation ....................................................................................... 5-3
5.9 Changing of Water Temp Source ................................................................................................... 5-4
5.10 Changing of Speed Source .......................................................................................................... 5-4
5.11 Use of EXT Trigger Type .............................................................................................................. 5-4
5.12 Correction..................................................................................................................................... 5-5
5.12.1 Setting of draft......................................................................................................................5-5
5.12.2 Correction of Sonic Speed ................................................................................................... 5-5
5.12.3 Correction of Water Temperature.........................................................................................5-5
5.12.4 Correction of Boat Speed.....................................................................................................5-6
5.12.5 Adjustment of transducer’s gain...........................................................................................5-6
5.12.6 Adjustment of Power Supply Frequency..............................................................................5-7
5.13 Use of Heaving............................................................................................................................. 5-7
5.13.1 ON/OFF of Heaving .............................................................................................................5-7
5.13.2 Setup of sensor's positions for Heaving...............................................................................5-8
5.14 Setup of transducer...................................................................................................................... 5-8
5.14.1 Setup of type of high frequency transducer.........................................................................5-8
5.14.2 Setup of type of low frequency transducer...........................................................................5-9
5.14.3 Setup of frequency and beam angle for HF 1 transducer....................................................5-9
5.14.4 Setup of frequency and beam angle for HF 2 transducer..................................................5-10
5.14.5 Setup of frequency and beam angle for LF 1 transducer ..................................................5-10
5.14.6 Setup of frequency and beam angle for LF 2 transducer ..................................................5-10
5.14.7 Setup of Bottom Limit HF....................................................................................................5-11
5.14.8 Setup of Bottom Limit LF.....................................................................................................5-11
5.15 Setup of Basics ...........................................................................................................................5-11
5.15.1 Selection of Language ........................................................................................................5-11
5.15.2 Changing of Range & Speed Unit.......................................................................................5-11
5.15.3 Changing of Depth Unit...................................................................................................... 5-12
5.15.4 Changing of Temperature Unit...........................................................................................5-12
5.15.5 Setup of Local time Offset.................................................................................................. 5-12
5.15.6 Selection of GPS................................................................................................................5-13
5.15.7 Initialization of GPS............................................................................................................5-13

Contents CVS-FX2/FX2BB
viii 0093102004-03
5.16 Setup of NMEA........................................................................................................................... 5-13
5.16.1 Setup of baud rate of NMEA1 (J8) .....................................................................................5-13
5.16.2 Setup of baud rate of NMEA2 (J3) .....................................................................................5-14
5.16.3 Selection of NMEA Output.................................................................................................. 5-14
5.16.4 Display of input sentence on NMEA Monitor...................................................................... 5-14
5.17 Customization ............................................................................................................................. 5-15
5.17.1 Changing of color of displayed items .................................................................................5-15
5.17.2 Changing of coloration of image of Color Bar Scale ..........................................................5-16
5.17.3 Changing of red coloration of image of fish display ...........................................................5-16
5.17.4 Distinction of the sea bottom ..............................................................................................5-17
5.18 Displaying of Simulation ............................................................................................................. 5-17
5.18.1 Displaying of prepared Simulation...................................................................................... 5-17
5.18.2 Selection of simulation .......................................................................................................5-17
5.19 To lock the keys not to be operated............................................................................................ 5-18
5.20 Returning to the Initialize ............................................................................................................ 5-18
5.21 Confirming of system conditions................................................................................................. 5-19
5.22 Updating of Program .................................................................................................................. 5-20
5.23 Storage of settings in Flash memory device............................................................................... 5-21
5.24 Recall settings by Flash memory device .................................................................................... 5-21
5.25 Setup of Network ........................................................................................................................ 5-22
5.25.1 Changing of IP Address......................................................................................................5-22
5.25.2 Acquisition of an IP Address from DHCP server ................................................................ 5-23
5.25.3 Changing of Subnet Mask ..................................................................................................5-23
5.25.4 Output Data Method/Not output .........................................................................................5-23
5.25.5 Input Data Method /Not input .............................................................................................5-23
5.25.6 Acquisition of images from Image List by PC.....................................................................5-24
Chapter 6 CCD Camera ......................................................................................... 6-1
6.1 Display of CCD camera images ..................................................................................................... 6-1
6.1.1 Scrolling of CCD camera images ........................................................................................... 6-1
6.1.2 Return the images of CCD camera to the center ................................................................... 6-1
6.1.3 Zoom/Reduce of CCD camera images .................................................................................. 6-2
Chapter 7 Data of SD Card and USB Memory...................................................... 7-1
7.1 Storage ........................................................................................................................................... 7-1
7.2 Recall.............................................................................................................................................. 7-1
7.3 SD Card recommendation .............................................................................................................. 7-1
7.4 USB Memory recommendation ...................................................................................................... 7-1
Chapter 8 INDEX .................................................................................................... 8-1

CVS-FX2/FX2BB Introduction
0093102004-03 ix
Introduction
CVS-FX2 is the 15inch LCD color echo sounder that can display images in 4 optional
frequencies.
CVS-FX2BB is the Black Box type without the display unit of CVS-FX2, for which customer
can select the display monitor of preference. The external monitor and connecting cable are
user supply.
This unit equipped with the latest digital process can accurately display circumstances in the
water under all conditions.
The main features of this unit are as follows:
This unit is a multi-frequency echo sounder with broadband transducers.
With a simple operation on a menu, frequencies up to 4 can be optionally set within a wide
range.
With digital reception processing, the high resolution in shallow depth and the noise
reduction capability in deep depth are both attainable. In addition, optimum images can be
displayed by the auto mode function.
The high-performance LCD maintains high visibility under any conditions. (Only CVS-FX2 )
With adoption of a special filter (AR coated), images can be seen clearly even under the
direct sunlight. Well protected against reflection on the LCD screen and dew condensation.
(Only CVS-FX2 )
This unit has high waterproof level and can be installed in an open bridge. (Only
CVS-FX2 )
Sona-ToneTM (Sonar sound) function provides fish school status by sound..
Up to 500 graphic images can be stored. Homing function is available by pushing event
key while recalling the stored images, to provide navigation guidance to the designated
position (optional GPS is required).
Various alarm functions are available (Bottom, school of fish, water temperature*, vessel
speed*, arrival*, XTE*, power source).
(Note: The mark * denotes that the connection of optional sensors is required)
The display and the operation units can be easility installed from the front side by flush
mounting. (Flush mounting of monitor is only for CVS-FX2).
RGB analog output to an external monitor is provided as standard. The use of external
monitor enables to observe the echo sounder images from the place distant from the main
unit (External monitor is owner supply).
The data for image, waypoint, and setting can be backed up in the USB memory and the
SD card, to be recalled later.
As the operation unit is separated, operation away from the processor and the display units
is possible.
.

Menu list CVS-FX2/FX2BB
x 0093102004-03
Menu List
The factory deafult setting is shown in bold and underlined.
1. [SHIFT/ M OFF] key
Shift OFF (OFF, ON)
Range Mode (Auto range, Manual, Auto shift)
2. [NORMAL/ZOOM] key
Normal/Zoom (Normal range operation, Zoom range operation)
3. [GAIN-R/SEL], [GAIN-L/SEL]
Individual gain (0.0 ~ 10.0: TVG type Optimized 6.0, TVG type Manual 3.0)
Interlocking gain (0.0 ~ 10.0: 0.0)
4. [RANGE] key
Interlocking range (5.0, 10.0, 20.0, 50.0, 100, 150, 300, 500 m: 50.0 m)
Individual range (5.0, 10.0, 20.0, 50.0, 100, 150, 300, 500 m: 50.0 m)
Zoom range (1, 2.5, 5, 7.5, 10, 15, 20, 25, 30, 40, 50, 60, 70, 80, 90, 100, 120 ,
140, 160, 180, 200, 220, 240, 260 m: 10m)
5. [SHIFT] key
Interlocking shift (0 ~ 3000 m: 0 m)
Individual shift (0 ~ 3000 m: 0 m)
6. [BRILL ] key
Screen brilliance (1 ~ 10: 10)
Panel brightness (1 ~ 10: 10)
7. [EVENT] key
(Store Position, Store image, Homing)
8. [F1] key
(Shift Digit Input, IR, Color Erase, Noise Reduction, Background
Color, TVG Adjust, White Line, A Scope, Image Swap, Image
Title, VRM Interval, NAV Start, Image Recall, Frequency, Event
Key Usage, Key Lock, Depth Unit, Color Tone, B.D. Mode)
9. [F2] key
(Shift Digit Input, IR, Color Erase, Noise Reduction, Background
Color, TVG Adjust, White Line, A Scope, Image Swap, Image
Title, VRM Interval, NAV Start, Image Recall, Frequency, Event
Key Usage, Key Lock, Depth Unit, Color Tone, B.D. Mode)
10. [Image speed/NAV] key
Image speed (Speed -2, Speed -1, Speed 0, Speed 1, Stop, Speed 2 (1/1),
Speed 3, Speed 4, Speed 5, Speed 6, Speed 7, Speed 8,
Speed 9)
NAV screen display (OFF, NAV 1 screen, NAV 2 screen)

CVS-FX2/FX2BB Menu List
0093102004-03 xi
11. [MENU] key
Echo Adjust IR (OFF, Low, High)
Color Erase (0 ~ 50 %, 0 %)
Noise Reduction (0~10: 0)
TX Power (HF) (20, 30, 40, 50, 60, 70, 80, 90, 100, Auto)
TX Power (LF) (20, 30, 40, 50, 60, 70, 80, 90, 100, Auto)
Dynamic Range HF1 (12 ~ 30 dB: 24 dB)
Dynamic Range HF2 (12 ~ 30 dB: 24 dB)
Dynamic Range LF1 (12 ~ 30 dB: 24 dB)
Dynamic Range LF2 (12 ~ 30 dB: 24 dB)
Background Color (Pale Blue, Marine Blue, Blue, Dark Blue, Black,
Pale Green Blue, Green Blue, Dark Green Blue, White,
Night Mode)
Color Tone (Monochrome, 8 color, 16 color, 64 color)
TVG TVG Type (Manual, Optimized)
TVG Strength HF1 (1 ~ 50: 25)
TVG Depth HF1 (2 ~ 1000 m: 50 m, 6 ~ 3300 ft, 1 ~ 550 fm, 1 ~ 610 I.fm,
1 ~ 660 J.fm)
TVG Adjust HF1 (2 ~ 30m: 2 m, 6 ~ 100 ft, 1 ~ 16 fm, 1 ~ 18 l.fm,
1 ~ 20 J.fm)
TVG Strength HF2 (1 ~ 50: 25)
TVG Depth HF2 (2 ~ 1000m: 50 m, 6 ~ 3300 ft, 1 ~ 550 fm, 1 ~ 610 l.fm,
1 ~ 660 J.fm)
TVG Adjust HF2 (2 ~ 30 m: 2 m, 6 ~ 100 ft, 1 ~ 16 fm, 1 ~ 18 l.fm,
1 ~ 20 J.fm)
TVG Strength LF1 (1 ~ 50: 25）
TVG Depth LF1 (2 ~ 1000 m: 50 m, 6 ~ 3300 ft, 1 ~ 550 fm, 1 ~ 610 l.fm,
1 ~ 660 J.fm)
TVG Adjust LF1 (2 ~ 30 m: 2 m, 6 ~ 100 ft, 1 ~ 16 fm, 1 ~ 18 l.fm,
1 ~ 20 J.fm)
TVG Strength LF2 (1 ~ 50: 25)
TVG Depth LF2 (2 ~ 1000 m,: 50 m, 6 ~ 3300 ft, 1 ~ 550 fm, 1 ~ 610 l.fm,
1 ~ 660 J.fm)
TVG Adjust LF2 (2 ~ 30 m,: 2 m, 6 ~ 100 ft, 1 ~ 16 fm, 1 ~ 18 l.fm,
1 ~ 20 J.fm)
Disp. Setup1 A Scope (OFF, ON)
White Line (OFF, 1, 2, 3, 4, 5, Auto)
Mix (A, B, C, D, Fish School Size)
Image Direction (←|←、→|→、←|→)
Image Swap (A|B, B|A)
Image Split (Vertical, Horizontal)
Width of Zoom Image (Wide, Medium, Narrow)
Zoom Image Split (Standard, Vertical)
Sub depth Value (OFF, m, fm, I.fm, ft, J.fm)
A

Menu list CVS-FX2/FX2BB
xii 0093102004-03
Disp. Setup2 Scale (OFF, ON)
Scale Position (Side, Center)
Scale Value (Small, Medium, Large)
Color Bar Scale (OFF, ON)
Image Title (Frequency, HF1 LF1)
Water Temp Window (OFF, 5 minutes, 10 minutes, 15 minutes, 30
minutes, 60 minutes)
W. Temp. Graph Range (2 ˚C, 5 ˚C, 10 ˚C)
Depth Font Size (OFF, Small, Medium, Large)
Depth Position (Bottom, Top)
W. Temp. Font Size (OFF, Small, Medium, Large)
Speed Value (OFF, ON)
Detection Area (OFF, ON)
VRM Interval (0.0 ~ 100.0 m: 0.0 m, 0.0 ~ 330.0 ft: 0.0 ft)
VRM Image (Active Screen, All screens)
Range Setup Range Operation (All screens same, Scr. Individual)
Range 1 (1.0 ~ 3000 m 85 steps: 5 m)
Range 2 (1.0 ~ 3000 m 85 steps: 10 m)
Range 3 (1.0 ~ 3000 m 85 steps: 20 m)
Range 4 (1.0 ~ 3000 m 85 steps: 50 m)
Range 5 (1.0 ~ 3000 m 85 steps: 100 m)
Range 6 (1.0 ~ 3000 m 85 steps: 150 m)
Range 7 (1.0 ~ 3000 m 85 steps: 300 m)
Range 8 (1.0 ~ 3000 m 85 steps: 500 m)
Shift Setup Shift Operation (All screens same, Scr. Individual)
Shift Type (Numerical Value, Range Dependant, Preset Value,
Range Ratio)
Shift Preset 1 (0 ~ 1000 m: 10 m, 0 ~ 3300 ft)
Shift Preset 2 (0 ~ 1000 m: 20 m, 0 ~ 3300 ft)
Shift Preset 3 (0 ~ 1000 m: 30 m, 0 ~ 3300 ft)
Shift Preset 4 (0 ~ 1000 m: 40 m, 0 ~ 3300 ft)
Shift Preset 5 (0 ~ 1000 m: 50 m, 0 ~ 3300 ft)
Shift Preset 6 (0 ~ 1000 m: 60 m, 0 ~ 3300 ft)
Shift Preset 7 (0 ~ 1000 m: 70 m, 0 ~ 3300 ft)
Shift Preset 8 (0 ~ 1000 m: 80 m, 0 ~ 3300 ft)
Zoom Shift Position (0 ~ 3000 m: 0 m, 0 ~ 8000 ft)
BTM Search Bottom Search Range (Inside Range, Outside Range)
Sounding Source (Auto Select, High1, High2, Low1, Low2)
Sounding Limit (100~ 4000 m,: 4000 m, 330 ~ 13000 ft: 12000 ft)
A
B

CVS-FX2/FX2BB Menu List
0093102004-03 xiii
Alarm1 Bottom Alarm (OFF, ON)
Upper depth (0 ~ Lower depth -1 m: 5 m)
Lower depth (Upper depth ~ 3000 m: 50 m)
Fish Alarm (OFF, ON)
Fish From (0.0 ~ 3000 m: 5 m)
Fish Span (1.0 ~ 3000 m: 50 m)
Upper Level (0 ~ 63 : 63)
Lower Level (0 ~ 63 : 0)
Alarm Signal Length (Short, Medium, Long)
Fish Image (High1, High2, Low1, Low2)
Alarm2 Water Temp Alarm (OFF, ON-Inside Range, ON-Out of range)
Upper Temp Alarm (Lower Temp Alarm ~ 45.0 ˚C: 20 ˚C)
Lower Temp Alarm (- 5 ˚C ~ Upper Temp Alarm: 15 ˚C)
Speed Alarm (OFF, ON-Faster, ON-Slower)
Speed Limit (0 ~ 80 kn: 0 kn)
Arrival Alarm (OFF, ON)
XTE Alarm (OFF, ON)
NAV Alarm Range (5 ~ 999 m: 10 m)
NAV NAV Start (Waypoint: No.1 ~ No. 10)
NAV Cancel (No, Yes)
WPT Edit (Waypoint: No.1 ~ No. 10)
WPT Delete (Waypoint: No.1 ~ No. 10)
Data Writing (SD Card, USB Memory)
Data Reading (SD Card, USB Memory)
Image Image Recall (Image: No.1 ~ No. 500)
Image Comment (Image: No.1 ~ No. 500)
Image Delete (Image: No.1 ~ No. 500)
Data Writing (SD Card, USB Memory)
Data Reading (SD Card, USB Memory)
Manual Set
Pulse Length HF1 (Short, Medium, Long)
Bandwidth HF1 (Narrow, 1, 2, 3, 4, Wide)
Pulse Length HF2 (Short, Medium, Long)
Bandwidth HF2 (Narrow, 1, 2, 3, 4, Wide)
Pulse Length LF1 (Short, Medium, Long)
Bandwidth LF1 (Narrow, 1, 2, 3, 4, Wide)
Pulse Length LF2 (Short, Medium, Long)
Bandwidth LF2 (Narrow, 1, 2, 3, 4, Wide)
B

Menu list CVS-FX2/FX2BB
xiv 0093102004-03
12. [SUB MENU] key
System Event Key Usage (Store Position, Store Image, Homing)
FUNC1.Key Setting
FUNC2.Key Setting
Guide Window (OFF, ON)
Func. Guide Window (OFF, ON)
Header Display (OFF, ON)
Simple Menu (OFF, ON)
CM Key Usage (CM, Screen Mode)
Gain type (Retractive Gain, Current Image)
Bubble (OFF, Low, High)
Clock Display (OFF, ON)
Source Inter. Buzzer Volume (OFF, Small, Medium, Large)
Water Temp Source (Internal Sensor, NMEA)
Speed Source (Internal Sensor, NMEA)
Ext Trigger Type (OFF, _↑¯, ¯↓_)
NMEA Monitor (NMEA1, NMEA2)
NMEA1 Baud Rate (4800bps, 9600bps, 19200bps, 38400bps)
（NMEA2） DBT Output (OFF, ON)
DPT Output (OFF, ON)
GGA Output (OFF, ON)
MTW Output (OFF, ON)
TLL Output (OFF, ON)
VHW Output (OFF, ON)
VTG Output (OF OFF, ON)
ZDA Output (OFF, ON)
GLL Output (OFF, ON)
HDT Output (OFF, ON)
MWV Output (OFF, ON)
RMC Output (OFF, ON)
Correct Draft Set (- 10.0 ~ 10.0: 0.0)
Sonic Speed (- 7 ~ 2 %: 0 %)
Water Temp (- 10.0 ~ 10.0: 0.0)
Boat Speed (Sensor: - 50 % ~ 50 %: 0 %, NMEA: - 10.0 ~ 10.0: 0.0)
Gain (TD) (- 50 ~ 50, HF1: 0, HF2: 0, LF1: 0, LF2: 0)
Power Supply Freq (100.0 ~ 130.0: 107.0)
C
(Shift Digit Input, IR (F2), Color Erase, Noise
Reduction, Background Color, TVG Adjust, White
Line, A Scope, Image Swap, Image Title (F1),
VRM Interval, NAV Start, Image Recall,
Frequency, Event Key Usage, Key Lock, Depth
Unit, Color Tone, B.D. Mode)

CVS-FX2/FX2BB Menu List
0093102004-03 xv
Heaving Heaving (OFF, ON)
HF TD Back and Forth (- 100.0 ~ 100.0: 0.0)
HF TD Right and Left (- 100.0 ~ 100.0: 0.0)
HF TD Height (- 100.0 ~ 100.0: 0.0)
LF TD Back and Forth (- 100.0 ~ 100.0: 0.0)
LF TD Right and Left (- 100.0 ~ 100.0: 0.0)
LF TD Height (- 100.0 ~ 100.0: 0.0)
TD Setting HF TD Type (OFF,
Broadband type: TDM-052, TDM-062, TDM-083,
Others: TDM-041, Others, TDM-041D, Others1)
LF TD Type (same as above)
HF TD1 Setting (Frequency: 24.0 ~ 240.0 kHz: 200 kHz,
Beam Angle: 1 ~ 120 ˚:7˚)
HF TD2 Setting (Frequency: 24.0 ~ 240.0 kHz: 130 kHz,
Beam Angle: 1 ~ 120 ˚:11˚)
LF TD1 Setting (Frequency: 24.0 ~ 240.0 kHz: 75 kHz,
Beam Angle: 1 ~ 120 ˚:10˚)
LF TD2 Setting (Frequency: 24.0 ~ 240.0 kHz: 38 kHz,
Beam Angle: 1 ~ 120 ˚:20˚)
Bottom Limit HF (1.0 ~ 3.0 m: 1.0 m)
Bottom Limit LF (1.0 ~ 3.0 m: 1.0 m)
Basics Language (English, Japanese, Greek, Spanish, Italian, French, Korean,
Thai, Chinese1, Chinese2)
Range&Speed Unit (NM,kn, km,km/h, sm,mph)
Depth Unit (m, fm, l.fm, ft, J.fm)
Temperature Unit ( ˚C, ˚F)
Localtime Offset (- 12.0 ~ 14.0: 0.0)
(Note:Default value is 9.0, when Japanese language is selected
upon initial startup.)
GPS Select (Others, Koden GPS, V102, VectorG1)
GPS Initialize (NO, yes)
Customize Color Customize (Depth Value Font, Depth Value Edge, Fish Alarm bar,
Bottom Alarm Bar, Zoom Range Bar, Scale Inside, Scale
Edge, Scale Val Inside, Scale Value Edge, Graph Line,
VRM Line, VRM Value Font, VRM Value Edge, VRM Inter.
Line, VRM Int Val Font, VRM Int Val Edge, W.temp Val
Font, W.Temp Val Edge, Speed Value Font, Speed Value
Edge, Header Display)
Color Divide (0 ~ 99, Red: 90, Orange: 78, Yellow: 66, Green: 53, Blue
Green: 39, Light Blue: 25, Blue: 12)
FishDispCol.Adj.(0~30:0)
B. D. Mode (OFF, 1, 2, 3)
D
CC

Menu list CVS-FX2/FX2BB
xvi 0093102004-03
Maintain Simulation (OFF, ON)
SimulationSelect(Shallow Depth, Intermediate*, Deep Depth*)
(*It is necessary to store the simulation data in the internal memory.)
KeyLock(OFF, ON)
Initialize (CM1, CM2, CM3, CM4, CM5, CM6, System All)
System Check (Panel Test, LCD Test)
All WPTs:DLT (No, Yes)
All IMG DT:DLT (No, Yes)
Image Output (OFF, ON)
System Program Load (PC Connection, SD Card, USB Memory)
Save Setting Value (SD Card, USB Memory)
Apply Setting Value (SD Card, USB Memory)‘
Network IP Address (000.000.000.000. ~ 255.255.255.255: 192.018.001.001)
DHCP Setting (OFF, ON)
Subnet Mask (000.000.000.000. ~ 255.255.255.255: 255.255.255.000)
Output Data Method (Color Level, OFF, AD Level)
Input Data Method (Color Level, OFF, AD Level)
D

CVS-FX2/FX2BB Chapter 1 Echo Adjust/Display Setup
0093102004-03 1-1
Chapter 1 Echo Adjust/
Display Setup
1.1 Change of TX Power
The strength of TX Power (transmission
output) can be changed.
When water depth is 50 m or less, the gain
of images are sometimes too high. In such
cases, the gain can be set appropriately by
reducing the [TX Power]. When own
equipment is affecting the echo sounders of
other boats, the interference noise to the
other boats can be reduced by weakening
the TX Power.
1.1.1 TX Power (HF)
Echo Adjust - TX Power (HF)
When TX Power (HF) has been changed,
the TX Power of the transducer connected to
the HF (high frequency) side can be
adjusted.
1. Press .
2. Select [Echo Adjust] - [TX Power (HF)].
3. Press [ ]of .
The setup box of [TX Power (HF)] will be
displayed.
4. Press [▲] and [▼] and select TX Power.
The smaller the value is, the weaker the
TX Power becomes.
5. Press to close the menu.
1.1.2 TX Power (LF)
Echo Adjust - TX Power (LF)
When TX Power (LF) is changed, the TX
Power of transducer connected to the LF
(low frequency) side can be adjusted.
1.Press .
2. Select [Echo Adjust] - [TX Power (LF)].
3. Press [ ]of .
The setup box of [TX Power (LF)] will be
displayed.
4. Press [▲] and [▼], and select TX Power.
The smaller the value is, the weaker the
TX Power becomes.
5. Press to close the menu.
Caution: At [Auto], transmission
output will be adjusted
depending of depth range. The
output is reduced for shallow
water, and is increased for
deep water.
Caution: At [Auto], transmission
output will be adjusted
depending of depth range. The
output is reduced for shallow
water, and is increased for deep
water.
Caution: Never activate transmission while transducer is out of water.

Chapter 1 Echo Adjust/Display Setup CVS-FX2/FX2BB
1-2 0093102004-03
How to adjust TVG:
Setup a gradient of gain variation at
[TVG Strength].
Setup a reference depth for
correction at [TVG Depth].
Setup a start depth for correction at
[TVG Adjust].
1.2 Change of dynamic range of Echo
Echo Adjust - Dynamic Range*1HF1, HF2,
LF1, LF2
The dynamic range of reflected signal (color
gradation) can be adjusted.
1.Press .
2. Select [Echo Adjust] - [Dynamic Range
XXX].
3. Press [ ]of .
The setup box of [Dynamic Range] will be
displayed.
4. Press [▲] and [▼] and select a value.
When the value is small, the expression
range of strong and weak signal change
is narrow, weaker signal will become
undistinguished. When the value is larger,
the expression range is wider and the
weaker signals become distinct.
5. Press to close the menu.
1.3 Making of reflection strength at
shallow and deep depth equal
At [Optimized] of TVG Type, it is set as the
bottom signal can be seen at a constant
level. At [Manual], the reflection strength of
fish depending on the depth can be set to be
seen uniformly.
1.3.1 Changing of TVG Type
TVG*2- TVG Type
TVG is a function to display images, by
correcting the attenuation of ultrasonic
sound through propagation in water and by
making reflection strength from deeper and
shallower depth equal,
1.Press .
2. Select [TVG] - [TVG Type]
3. Press [ ]of .
The setup box of [TVG Type] will be
displayed.
4. Press [▲] and [▼] to select a type.
At [Optimized], bottom signal will be
corrected to be a constant level at all
ranges. At the [TVG Adjust], it is possible
to change the effect of correction on
signal shallower than the start point.
At [Manual], user is to set [TVG Strength],
[TVG Depth] and [TVG Adjust] to produce
desired performance. (See the Basic
Operation Manual, “2.2.6 Adjustment of
TVG”).
5. Press to close the menu.
Main changing items here are as
follows:
To change TVG Type
To change TVG Strength
To change TVG Depth
*1 Dynamic Range: This is the function to expand and narrow down the signal range from blue to red in
images.
*2 TVG (Time variable gain): The signal strength is different between deep and shallow water and this is the
function to correct this.

CVS-FX2/FX2BB Chapter 1 Echo Adjust/Display Setup
0093102004-03 1-3
1.3.2 Changing of TVG Strength
TVG - TVG Strength HF1, HF2, LF1, LF2
The gradient of gain variation is adjusted to
reduce gain for shallower depth.
1.Press .
2. Select [TVG] - [TVG Strength XX].
3. Press [ ]of .
The setup box of [TVG Strength XX] will
be displayed.
4. Press [▲] and [▼] and set a value.
When the value is larger, the gradient will
be steeper (gain variation amount is large)
and when the value is smaller, the
gradient will be gentler (gain variation
amount is small).
5. Press to close the menu.
1.3.3 Changing of TVG Depth
TVG - TVG Depth HF1, HF2, LF1, LF2
The reference depth for correction will be
adjusted.
The reflected signal from depth shallower
this reference depth will be corrected to be
the same gain of the reference depth.
1.Press .
2. Select [TVG] - [TVG Depth XX].
3. Press [ ]of .
The setup box of [TVG Depth XX] will be
displayed.
4. Press [▲] and [▼] to set a value for
depth.
When the value is larger, the correction
reference depth becomes deeper and the
gain at shallower depth will be reduced
when smaller.
5. Press to close the menu.
1.3.4 Changing of TVG Adjust
TVG - TVG Adjust HF1, HF2, LF1, LF2
When correction is too much effective at
shallower depth, the correction start depth
will be adjusted. The correction amount at
depth shallower than the start depth will be
the same as that of the start depth.
1.Press .
2. Select [TVG] - [TVG Adjust XX[.
3. Press [ ]of .
The setup box of [TVG Adjust XX] will be
displayed.
4. Press [▲] and [▼] to set a value for
depth.
When the value is larger, the correction
start depth will become deeper and the
gain at shallower depth will increase.
Caution: When [Manual] is selected
for [TVG Type], setup shall be
done to every frequency.
Caution: When [Manual] is selected
for [TVG Type], setup shall be
done at every frequency.
