KUHN GMD16 User manual

Original instructions
KN225BGB_A
Read carefully before starting the machine
Operator's manual
Disc mower
---A1025-60B00001 > ---A1025-60B99999
GMD16-GMD20
KN225BGB_A - English - 06-2019
*KN225BGB_A*

1. - Dear Owner
GMD16-GMD20
3
KN225BGB_A
Disc mower
1. Dear Owner
In buying a Kuhn machine you have chosen wisely. Into it have gone years of thought, research and
improvement. You will find, as have thousands of owners all over the world, that you have the best that
engineering skill and actual field testing can produce. You have purchased a dependable machine, but only
through proper care and operation can you expect to receive the performance and long service built into it.
This manual contains all the necessary information for you to receive full efficiency from your machine. The
performance you get from this machine is largely dependent on how well you read and understand this
manual and apply this knowledge. Please DO NOT ASSUME YOU KNOW HOW TO OPERATE AND
MAINTAIN YOUR MACHINE before reading this manual carefully. KEEP THIS MANUAL AVAILABLE FOR
REFERENCE. Pass it on to the next owner if you re-sell the machine.
Your KUHN dealer can offer a complete line of genuine KUHN service parts. These parts are manufactured
and carefully inspected in the same factory that builds the machine to assure high quality and accurate
fitting of any necessary replacements.
About improvements
We are continually striving to improve our products. We therefore reserve the right to make improvements
or changes when it becomes practical to do so, without incurring any obligations to make changes or
additions to the equipment sold previously.
Wear parts
Wearing parts fitted on our machines have been tested in very different situations to optimize their service
life. Nevertheless, the service life depends highly on theconditions of use (products tohandle,soil,weather
conditions, etc...).
Document illustrations
The illustrations in this manual may be based on one type of machine only. However, all instructions apply
to all machines covered in this manual.
Copyright 2019 KUHN

GMD16-GMD20
42. - Contents
KN225BGB_A
Disc mower
2. Contents
1. Dear Owner .....................................................................................................................3
2. Contents..........................................................................................................................4
3. Identification of the machine.........................................................................................8
3.1 Front view ........................................................................................................................................ 8
3.2 Rear view.........................................................................................................................................8
3.3 Identification of the machine............................................................................................................9
3.3.1 Location of the plates .........................................................................................................9
3.3.2 Description..........................................................................................................................9
3.4 Optional equipment.........................................................................................................................11
4. Safety.............................................................................................................................12
4.1 Description of symbols used in this document............................................................................... 12
4.2 Safety instructions ......................................................................................................................... 13
4.2.1 Introduction....................................................................................................................... 13
4.2.2 Read and follow the safety instructions............................................................................ 14
4.2.3 Precautions to be taken before carrying out any operations on the machine................... 14
4.2.4 Precautions to take before using the machine ................................................................. 15
4.2.5 Precautions when driving ................................................................................................. 15
4.2.6 Precautions when driving on public roads........................................................................15
4.2.7 Maximum speed...............................................................................................................20
4.2.8 Precautions when coupling...............................................................................................21
4.2.9 Hydraulic circuit................................................................................................................21
4.2.10 PTO shaft.......................................................................................................................... 22
4.2.11 Waste disposal .................................................................................................................23
4.2.12 Remote controlled components........................................................................................ 24
4.2.13 Safety decals.................................................................................................................... 24
4.2.14 Precautions for maintenance and repair work.................................................................. 25
4.2.15 Projection of stones and foreign objects........................................................................... 26
4.2.16 Precautions during manoeuvres....................................................................................... 26
4.2.17 Precautions for machine use............................................................................................ 27
4.2.18 Precautions to take before using the parking stands........................................................ 27
4.3 Location and description of safety decals on the machine ............................................................ 28
4.3.1 Location of safety decals..................................................................................................28
4.3.2 Description of safety decals.............................................................................................. 29

2. - Contents
GMD16-GMD20
5
KN225BGB_A
Disc mower
4.4 Road safety equipment and recommendations............................................................................. 31
4.4.1 Instructions specific to France.......................................................................................... 32
4.4.2 Instructions specific to the USA........................................................................................ 32
4.5 Likely critical failures...................................................................................................................... 32
4.6 Incorrect use of the machine by the user ...................................................................................... 33
4.7 Limit state criteria........................................................................................................................... 33
5. Machine specifications................................................................................................ 34
5.1 Description and glossary ............................................................................................................... 34
5.1.1 Designated use of the machine........................................................................................ 35
5.2 Technical specifications................................................................................................................. 36
5.2.1 Designated parameters.................................................................................................... 36
5.3 Required equipment...................................................................................................................... 37
5.3.1 PTO shaft: ........................................................................................................................ 37
5.3.2 Put into the working or transport position......................................................................... 38
5.3.3 Cutter bar ......................................................................................................................... 38
5.4 Sound levels.................................................................................................................................. 39
6. Putting into service...................................................................................................... 40
6.1 Description of control elements ..................................................................................................... 40
6.2 Coupling and uncoupling............................................................................................................... 41
6.2.1 Description of coupling elements ..................................................................................... 41
6.2.2 Preparing the tractor......................................................................................................... 41
6.2.3 Preparing the machine..................................................................................................... 43
6.2.4 Coupling the machine.......................................................................................................45
6.2.5 Hydraulic connections......................................................................................................46
6.2.6 Electrical connection ........................................................................................................ 46
6.2.7 Fit check chain ................................................................................................................. 46
6.2.8 Primary PTO shaft............................................................................................................ 47
6.2.9 Adjusting the machine......................................................................................................48
6.2.10 Uncoupling the machine................................................................................................... 50
7. Instructions for transport............................................................................................ 51
7.1 Putting the machine into transport position ................................................................................... 51
7.2 Conformity with the road regulations............................................................................................. 52
8. Instructions for work................................................................................................... 53
8.1 Putting the machine into work position.......................................................................................... 53
8.2 Adjustments in working position .................................................................................................... 55
8.2.1 Cutting height................................................................................................................... 55
8.2.2 Swathing system.............................................................................................................. 56
8.2.3 Compensating spring tension........................................................................................... 56

GMD16-GMD20
62. - Contents
KN225BGB_A
Disc mower
8.3 Machine use .................................................................................................................................. 57
8.3.1 Drive speed ......................................................................................................................57
8.3.2 Headland turn maneuvers................................................................................................ 57
8.3.3 Machine safety .................................................................................................................58
9. Optional equipment......................................................................................................60
9.1 Raised skid shoes.......................................................................................................................... 60
9.2 High cone disc kit (GMD20)........................................................................................................... 60
9.3 Side deflector................................................................................................................................. 61
9.4 Side deflector with high cone disk .................................................................................................61
9.5 Toolbox .......................................................................................................................................... 61
9.6 Lighting and signalling ................................................................................................................... 62
9.6.1 Electrical connection.........................................................................................................62
9.7 Lateral signalling equipment.......................................................................................................... 62
9.8 Lighting and signalling (Only for USA)........................................................................................... 63
9.8.1 Electrical connection.........................................................................................................63
9.9 Manual hydraulic cutter bar lift pump............................................................................................. 63
9.9.1 Coupling and uncoupling.................................................................................................. 64
9.9.2 Putting the machine into transport position ...................................................................... 64
9.9.3 Putting the machine into work position............................................................................. 65
9.10 Device for mowing at an angle of - 40°.......................................................................................... 65
9.11 Wear plate...................................................................................................................................... 65
10. Maintenance and storage ............................................................................................66
10.1 Frequency chart.............................................................................................................................66
10.2 Lubrication .....................................................................................................................................67
10.2.1 PTO shafts........................................................................................................................67
10.2.2 Oil change ........................................................................................................................ 69
10.3 Maintenance .................................................................................................................................. 73
10.3.1 Belt tension.......................................................................................................................73
10.3.2 Breather plug checking and cleaning ............................................................................... 74
10.3.3 Checking cutterbar oil level ..............................................................................................75
10.3.4 Check angle gearbox oil level........................................................................................... 76
10.3.5 Inspection of knives and securing elements..................................................................... 77
10.3.6 Knife replacement.............................................................................................................79
10.3.7 Disc replacement..............................................................................................................81
10.3.8 Outer and inner cones......................................................................................................82

2. - Contents
GMD16-GMD20
7
KN225BGB_A
Disc mower
10.4 Storage .......................................................................................................................................... 83
10.4.1 At the end of each season................................................................................................ 83
10.4.2 At the start of each season...............................................................................................83
10.4.3 Storage............................................................................................................................. 84
10.5 Dismantling and scrapping of the machine....................................................................................84
11. Troubleshooting guide................................................................................................ 85
12. Appendix....................................................................................................................... 87
12.1 Calculating the load on an axle ..................................................................................................... 87
13. Limited Warranty.......................................................................................................... 94

GMD16-GMD20
83. - Identification of the machine
KN225BGB_A
Disc mower
3. Identification of the machine
3.1 Front view
3.2 Rear view

3. - Identification of the machine
GMD16-GMD20
9
KN225BGB_A
Disc mower
3.3 Identification of the machine
- Do not remove the manufacturer,
homologation and marking plates attached
to the machine.
3.3.1 Location of the plates
- Please write below the type and serial number of
the machine:
• Serial Number:
- This information is to be given to the Kuhn
authorized dealer for any spare parts order or
warranty claim.
3.3.2 Description
Model identification plate
1: Manufacturer name and address
3: Brand
4: KUHN logo
5: Description of the machine
7: Model
9a: Machine serial number
9b: Barcode (Machine serial number)
12: Weight empty (Minimum/Maximum)
18: Data matrix
19: Plate reference
27: Place of manufacture
28: Manufactured by... for...
34: Special operation
9: Serial Nr. 34: Ex
5: Machine
7: Model
09993000
3: Brand
kg
kg
12: Unladen Mass min/Max
3: 商 Brand
9: 机架号 Serial Nr. 34: Ex
5: 机器描述 Machine
7: 型号 Model
kg
12: 卸重量最小/最大Unladen Mass min/max kg
1
34
18
19
3
9a
5
7
12
28
27
9b
4

GMD16-GMD20
10 3. - Identification of the machine
KN225BGB_A
Disc mower
Certification plate (CE)
For machines aimed at countries which are
members of the European Union (EC marking).
4: KUHN logo
7: Model
9: Machine serial number
19: Plate reference
23: Logo CE
24: Manufacturing year
26: Model year
54: Data matrix
Certification plate (EAC)
For machines aimed at countries member of the
Eurasian customs union (EAC marking).
4: KUHN logo
7: Model
9: Machine serial number
19: Plate reference
23: Logo EAC
25: Manufacturing year
26: Model year
54: Data matrix
Importer plate (BRASIL)
For machines to be sent to Brazil.
1: Manufacturer name and address
4: KUHN logo
7: Model
9: Machine serial number
19: Plate reference
24: Manufacturing year
54: Data matrix
24: Year of Construction
26: Model Year
7: Model
9: Serial Nr.
23
54
4
19
7
9
24
26
25: Month-Year of Construction
26: Model Year
7: Model
9: Serial Nr.
23
54
4
26
25
7
9
19
24: Year of Construction
19
54 4
1
24
97

3. - Identification of the machine
GMD16-GMD20
11
KN225BGB_A
Disc mower
3.4 Optional equipment
- Tick box corresponding to the equipment fitted on
your machine:
Raised skid shoes.
High cone disc kit (GMD20).
Side deflector.
Side deflector with high cone disk.
Toolbox.
Lighting and signalling.
Lateral signalling equipment.
Lighting and signalling (Only for USA).
Manual hydraulic cutter bar lift pump.
Device for mowing at an angle of -40°.
Wear plate.

GMD16-GMD20
12 4. - Safety
KN225BGB_A
Disc mower
4. Safety
4.1 Description of symbols used in
this document
This symbol indicates a potentially hazardous
situation that if not avoided, could result in serious
bodily injury.
Thissymbolisused to identify special instructions or
procedures which, if not followed strictly, could
result in machinery damage.
This symbol is used to communicate technical
information of particular interest.

4. - Safety
GMD16-GMD20
13
KN225BGB_A
Disc mower
4.2 Safety instructions
4.2.1 Introduction
The machine must only be operated, maintained and repaired by competent persons who are familiar with
machines' specifications and operation and aware of safety regulations for preventing accidents.
The operator must imperatively respect safety instructions in this manual and in the warnings posted on the
machine. The operator is also obliged to respect current legislation concerning accident prevention, work
safety and public traffic circulation.
Designated use of the machine also means following operation, maintenance and repair recommendations
given by the manufacturer, and using only genuine spare parts, equipment and accessories, as
recommended by the manufacturer.
The manufacturer is not held liable for any damage resulting from machine applications other than those
specified by the manufacturer. Any use other than the designated operation is at the risk and responsibility
of the operator.
The manufacturer is not held liable for any damage or accident resulting from machine modifications carried
out by the operator himself or by a third party without previous written agreement from the manufacturer.

GMD16-GMD20
14 4. - Safety
KN225BGB_A
Disc mower
4.2.2 Read and follow the safety instructions
Before using the machine, carefully read all the
safety instructions in this manual and the warnings
placed on the machine.
Before starting work, the operator must be familiar
with all machine controls, handling devices and their
functions. It is too late to learn once work has been
started!
Never let anyone operate the machine who is not
trained to do so.
Should you have any difficulties in understanding
any parts of this manual, please contact your KUHN
dealer.
4.2.3 Precautions to be taken before carrying
out any operations on the machine
Before leaving the tractor or before adjusting,
maintaining or repairing the machine, disengage the
PTO drive, turn off the engine, remove ignition key
and wait until all moving parts have come to a
complete stop and apply park brake.

4. - Safety
GMD16-GMD20
15
KN225BGB_A
Disc mower
4.2.4 Precautions to take before using the
machine
Do not wear loose clothing which could become
caught up in moving parts.
Wear the appropriate protective clothing for the
work in hand (gloves, shoes, goggles, helmet, ear
defenders, etc.).
Ensure that all operating controls (ropes, cables,
rods, etc) are placed so as they cannot be operated
unintentionally and cause damage or injury.
Before operating the machine, check tightness of
nuts and bolts, particularly on fixing elements (tines,
forks, blades, knives, etc). Retighten if necessary.
Before operating the machine, ensure that all the
safety guards are firmly in place and in good
condition. Immediately replace any worn or
damaged guard.
4.2.5 Precautions when driving
Tractor handling, stability, performance and braking
efficiency are all affected by weight distribution,
trailed or mounted implements, additional ballast
and driving conditions. It is therefore of great
importance that the operator exercises caution in
every given situation.
Groundspeed must be adapted to ground conditions
as well as to roads and paths. Always avoid abrupt
changes of direction.
Be particularly cautious when turning corners,
paying attention to machine overhang, length,
height and weight.
Never use a narrow track tractor on very uneven or
steeply sloping ground.
Never leave the tractor seat while the machine is
operating.
Carrying people or animals on the machine when
working or in transport is strictly forbidden.
4.2.6 Precautions when driving on public
roads
Dimensions
Depending on the dimensions of the machine,
contact the relevant authorities to ensure that it can

GMD16-GMD20
16 4. - Safety
KN225BGB_A
Disc mower
be legally transported on public roads.
If the machine is over the maximum legal size,
follow the local regulations forspecial transportation
of oversize equipment.
Transport position
Before transporting the machine on public roads,
place the machine into its transport position,
according to the instructions in this manual.
Lights and indicators
Before transporting the machine on public roads,
ensure that all legally required lightings and
signallings are in place.
Ensure that lightings and signallings are clean and in
good working order. Replace any missing or broken
equipment.
Always obey current regulations for driving
on roads.

4. - Safety
GMD16-GMD20
17
KN225BGB_A
Disc mower
Gross weight and weight per axle
Description of symbols
The drawings are not legally binding, their only aim is to illustrate the method to use.
Prior to driving on public roads, check that all criteria are met to be in conformity with the
countrie's regulations:
- When coupling a tool to the front and/or rear 3-point lift linkage, the maximum authorized
payload must not be exceeded.
- When coupling tools to the frontand/or rear 3-point lift linkages, the maximum load on tractor's
tires must not be exceeded.
- The load on the tractor front axle must always represent 20 % of the tractor unladen weight.
For machines with hoppers or tanks:
- If the total unit weight exceeds the tractor Gross Combined Weight Rating in accordance with
the countrie's legislation, empty the hopper to travel on public roads.
- In any case, we recommend to travel on public roads with empty hoppers and tanks.
Description Units Description
T kg Tractor unladen weight
PTAC kg Gross Combined Weight Rating
T1 kg Unladen load on tractor front axle
T2 kg Empty load on tractor rear axle
t kg Axle loads (Tractor + machine)
t1 kg Load on front axle (Tractor + machine)
t2 kg Load on rear axle (Tractor + machine)
t1 max kg Maximum load authorized on the tractor front axle according to the tires
t2 max kg Maximum load authorized on the tractor rear axle according to the tires
M1 kg Total weight of front tool or front ballast

GMD16-GMD20
18 4. - Safety
KN225BGB_A
Disc mower
How to proceed:
Stage 1:
Stage 2:
To measure:
- Tractor tare (T).
T = _____kg
T = ________ kg
- Couple the machine to the tractor.
To measure:
- Load on front axle (t1):
• Tractor + machine (transport position).
To do:
- If the front axle load (t1) is below 20% of the tractor
tare (T), add ballast weights (M1) to exceed the
minimum load on the front axle.
Example:
• (T) = 7500 kg (16535 lb)
• 20% of T = 1500 kg (3300 lb)
• (t1) = 700 kg (1545 lb).
• 700 kg (1545 lb) < 1500 kg (3300 lb).
- Add ballast weights until the minimum front axle
load is exceeded.
- Repeat checking procedure.
t1 = _____kg
t1 = ________ kg
t1 < 20% Tt1 < 20% T
t1t1 ≥20% T20% T

4. - Safety
GMD16-GMD20
19
KN225BGB_A
Disc mower
Stage 3:
Stage 4:
To measure:
- Total weight (t):
• Tractor + machine (transport position).
• Ballast weights.
Checking:
- To go to the next stage:
• Check in the tractor's operator's manual that the
value measured is below the tractor's Gross
Combined Weight Rating.
To do:
- If t < PTAC go to the next stage.
- If the total unit weight exceeds the tractor Gross
Combined Weight Rating in accordance with the
countrie's legislation, empty the hopper to travel on
public roads.
- Repeat checking procedure.
Example:
• (t) = 10000 kg (22046 lb).
• PTAC = 13000 kg (28660 lb).
• t < PTAC: Go to the next stage.
kgkg
t = _____kg
To measure:
- Load on rear axle (t2):
• Tractor + machine (transport position).
• Ballast weights.
Checking:
- Check in the tractor's operator's manual that the
value measured is below the maximum allowed
tractor rear axle load.
- Check that tyre and rim specifiations are in
conformity with the requirements of the tractor
manufacturer.
Example:
• Load on rear axle (t2) = 8500 kg (18740 lb).
• Check in the tractor's operator's manual that the
value measured is below the maximum allowed
tractor rear axle load.
• Check that tyre and rim specifiations are in
conformity with the requirements of the tractor
manufacturer.
kgkg
t2 = _____kg
t2 = ________ kg
t2 > t2 maxt2 > t2 max
t2t2 ≤t2 maxt2 max

GMD16-GMD20
20 4. - Safety
KN225BGB_A
Disc mower
4.2.7 Maximum speed
- Always keep to the legal speed limit for driving a
tractor-machine assembly on public roads.
