Lamp FD35EV User manual

1
Door height Max.2400 mm
2401 -2700 mm
Door width Max.1200 mm
700 -1200 mm
Min. Door thickness
Min.22 mm
Max. Door weight 35 kg / door
Vertical adjustment
2 mm upward, 4 mm downward
ABOUT THE PRODUCT
SPECIFICATIONS
FOR YOUR SAFETY AND CORRECT INSTALLATION
FD35EV SLIDING DOOR SYSTEM Installation Manual
(For Mortised, Drop or False Ceiling, with Surface Mount Rollers
PartNo.FD35EVHMP
Thank you for using our product. Before installation, please read this manual thoroughly to ensure correct installation.
Please keep this manual at hand for future reference.
●
This is a parts set for a sliding door system for residential
& commercial use.
●
The door can be installed without the use of tools.
WARNING
If not followed, death or serious injury may result.

Caution
If not followed, injury or damage may result. 
This product should be installed by a qualified person in accordance with this manual. If it is not installed correctly, the door
may fall and cause injury.
Provide a frame that can withstand the weight and impact of opening and closing the door. Be sure to use the specified
screws and tighten them securely. If the mounting strength is insufficient, the door may fall and cause injury.
Do not use this product for any other purpose, or with doors that are outside the specifications of this manual.
Do not disassemble or modify any parts other than those described in this document.
Follow the specified dimensions, specifications, and alignment of the door and frame. Warping, tilting or twisting of the
frame or door may cause failure.
If cutting any parts, make sure to remove any burrs before installation. Also check the upper track for any left-over burrs or
scraps and remove these.
This product is a part for architectural fittings. After installation, please check the function and safety of the final product.
Please inform the end user how to use the product safely.
Make sure to check the screws for slack at regular intervals (one month from first usage, half a year, and then one time
every year is recommended).
Prohibited
Warning
Caution Required
Meaning of symbols

2
❶Plug in
❸Pull out
❹Align the door end
and the holder end
and fasten
❷Push up
Tapping screw4×40
(includedin②)
Align
holder
1Cutting and Providing Hole on Upper Track
2
Mounting Parts on Door
Cut end
I4.5 I7.8 CSK
(for track fixing)
30
Hole processingCutting
When cutting, reinforce the
track to prevent deformation
at the cut section.
CAUTION
COMPONENT PARTS
ASSEMBLY
№ ① ②③④
Name
Upper track for
(surface mount)
Upper track for
(recessed mount)
Upper roller End catch Floor guide S
Item No. FD35EV-TRM FD35EV-TRH FD35EV-WRM FD35EV-TRM-HTST FD50-BGR18
Item
2 pcs 2 pcs 1 pc
Hole pitch
：300 mm
Pitch end 
：30 mm
Accessories −
Countersunk head
tapping screw
4×40・・・3 pcs
−
Countersunk head
tapping screw
4×20……4 pc
Remarks Recommended screw:Countersunk
head tapping screw 3.5×25 −−−
OPTIONAL PART
№ ⑤⑥⑦
Name Door bottom
guide track
Spanner
wrench Track cleaner
Item No.
FD30-HRBT1500SIL FD35EV-WRM-SP8 FD30-TRC
Item
Hole pitch ：250 mm
Pitch end ：30 mm
Accessories −−−
Remarks
Recommended
screw:
Countersunk head
tapping screw 4×20
−−
(This describes installation of a single sliding door.）

3
④Floor guide
44
18
3RVLWLRQWKHÀRRUJXLGHEHORZWKHFHQWHURI
the upper track so that it is covered by the
door when it is opened and closed.
Temporarily fasten through
the slotted holes with the
provided screws.
4 × 20
(included in④)
Slotted hole
3Inserting Parts into Upper Track
Mounting of Floor Guide Temporarily
５
Be careful not to overtighten the screws and
screw heads protruding on upper track.
It may cause deformation of track.
Caution
looseinclined overtightened deeper groove
４Mounting of Upper Track（
Recommended screw: Countersunk head tapping screw 3.5×25）
Pay attention to the
direction of the rollers
Upper track
Remove any dirt or aluminum
chips from the track.
Fasten bumper blocks
temporarily to prevent the
inserted parts from falling.
Caution
End catch
End catch
Upper roller
Upper roller
1
2
3
4
Upper track
Cut end
14
Insert the parts in order from to with care of direction.

4
Support 10mm
To be removed
after hanging
protruding part
Floor guide
Roller
main body
CLICK
Roller
holder
❶Place a 10 mm support under the door.
❷While holding the door, place the groove under the door on the protruding part of the
ÀRRUJXLGH
Hanging Door
6
Adjusting, Fastening the Floor Guide
8
❶
❷
Verify that the main unit is not dislocated from
the casing, either of the door ends.
CAUTION
7Adjustment of Door Height
$GMXVWGRRUSDUDOOHOWRWKHXSSHUWUDFNZLWKPPFOHDUDQFHEHWZHHQWKHGRRUDQGÀRRU
Caution
Do not turn the adjustment screw beyond the
adjustment range. It may cause damage
Adjustment range ：6mm
Adjust by turning the hanger
bolt of the upper roller with
spanner wrench .
18
Hanging bolt root
4 mm
2mm
Up
Down
If the door movement is not smooth, remove the door,
WKHQDGMXVWWKHÀRRUJXLGHIRUZDUGVRUEDFNZDUGV
2 mm
Adjustment range 4mm
2 mm
4 × 20
(included in④)
Tighten all four screws
after the adjustment.
Lever is on
the bottom.
OK

5
9Fixing the End Catch Position
Fix the end catch 3 mm from the position where door stops.
Adjust the position of the end catch where it catches the hanger bolt
of the roller when the door is stopped by the frame or door stopper.
Do not overtighten the screw.
It may deform the part.
Appendix1How to remove door
Pay attention not to let the door fall.
CAUTION
Use a 10 mm support under the door.
❶Plug in
❸Pull out
❷Push up
,QVHUWWKHÀDWHQGRIWKHVSDQQHU
into the lever part of the upper
roller.(A flat-blade screwdriver
can be used as a substitute. )
CAUTION
TROUBLESHOOTING
5 mm of space
Trailing edge of stopped door
PERIODICAL INSPECTION
・Clean inside of track.
・Check upper and lower space of the door. If necessary, adjust the space.
Trouble Checkpoint Solution
Abnormal noise during
operation
&KHFNLIGRRUERWWRPFRQWDFWVWKHÀRRU 9HULI\WKDWWKHWUDFN¿[LQJVFUHZVDUHQRWORRVHQHG7KHQDGMXVWWKHGRRUKHLJKWVXFKWKDW
WKHFOHDUDQFHEHWZHHQWKHGRRUERWWRPDQGÀRRULV±PP
Check if door touches adjacent parts. $GMXVWWKHSRVLWLRQRIÀRRUJXLGHWRDYRLGFRQWDFWZLWKDGMDFHQWREMHFWV
Check track rollers for aluminum dust. Remove the track, then pull out and clean the roller.
Check for loose screws retaining the upper track. Retighten screws to free the roller.
Heavy door operation
&KHFNLIGRRUERWWRPFRQWDFWVWKHÀRRU 9HULI\WKDWWKHWUDFN¿[LQJVFUHZVDUHQRWORRVHQHG7KHQDGMXVWWKHGRRUKHLJKWVXFKWKDW
WKHFOHDUDQFHEHWZHHQWKHGRRUERWWRPDQGÀRRULV±PP
Check if door touches adjacent parts. $GMXVWWKHSRVLWLRQRIÀRRUJXLGHWRDYRLGFRQWDFWZLWKDGMDFHQWREMHFWV
Door does not move. Check the track retaining screws for looseness. Retighten screws to free the roller.
Door starts to move. Check the upper track if it is set horizontally. Using a level gauge, reset upper track horizontally.
End catch does not work
properly. Check if roller is installed correctly.
If a roller for the two-way soft closer (FD35EV-WRH) is installed by mistake, the jump
prevention nut on the roller will interfere with the end catch. Replace it with the correct
roller.

6
21
1
Upper frame
20 0
-0.5
20
18
20 1
Recommended screw: Countersunk head tapping screw3.5×25
10
5
16
28
12
15
10 18 22
22
Door height DH
30
44
18
4
Door width DW
68
33
3.5
2
33
21
I4.4I7.8 CSK
3.5
3
【Door process dimensions】
12
15
Door bottom guide track
⑤
17
15
When using door bottom guide track (Optional parts）
Upper track (recessed mounted)
Upper track (surface mounted)
Door thickness Dt
SUGATSUNE KOGYO CO.,LTD
Tokyo, JAPAN
Phone: [phone] E-mail:[email protected]
SUGATSUNE KOGYO (UK) LTD
Reading, UK
Phone: [phone] E-mail:[email protected]
SUGATSUNE EUROPE GmbH
Dusseldorf, GERMANY
Phone: [phone] E-mail:[email protected]
SUGATSUNE SHANGHAI Co., LTD
Shanghai, CHINA
Phone: [phone] E-mail:[email protected]
Guangzhou, CHINA
Phone: [phone] E-mail:[email protected]
SUGATSUNE KOGYO INDIA PRIVATE LIMITED
Mumbai, INDIA
Phone: [phone] E-mail:[email protected]
SUGATSUNE AMERICA, INC
California, USA
Phone: [phone] E-mail:[email protected]
Chicago, USA
Phone: [phone] E-mail:[email protected].
SUGATSUNE CANADA, INC.
Phone: [phone] E-mail:[email protected]
2021.08 1478-1
INSTALLATION DRAWING (EXAMPLE) （This describes installation of a single sliding door.）
