FD35EV SLIDING DOOR SYSTEM Installation Manual
2XWVHW7\SHZLWK7ZRZD\VRIWFORVH
PartNo.：FD35EVDHCP-AK
●
This product is a parts set for an overlay indoor sliding door
system.
●
The door closes in a 2 soft motion steps; first slow, then
fast, and opens with a 1 step soft motion.
●
Easy door installation and adjustment.
Thank you for selecting our product. Before starting installation, please read this manual thoroughly to ensure correct installation.
Please keep this manual at hand for future reference.
Max. Door height
2400mm
Max. Door width
590 − 1200mm
0LQ'RRUWKLFNQHVV
30 − 36mm
Max. Door weight 35kg※1
9HUWLFDODGMXVWPHQW
3mmupward,4mmdownward
)URQWUHDUDGMXVWPHQW
± 2mm
ABOUT THE PRODUCT
SPECIFICATIONS
FOR YOUR SAFE WORK AND CORRECT INSTALLATION
・
The closing speed of the soft closing type door may change due to
ambient temperature, operating method or installation quality.
・
Recommended ambient temperature range is 5 to 40°C.
※1
If a light weight door is applied, you may feel the resistance
of the soft closer when opening the door.

2
⑫Door guide track
（Option）
15
17
⑪cover cap
(Option)
51
2
1
2
15 48
16
49
№① ② ③ ④ ⑤ ⑥ ⑦ ⑧ ⑨
Name Upper track Trigger Side cover Stopper plate
Screw for stopper
plate
Soft Closer Upper roller Bumper block Floor guide
Item No. )'(975$
)'(975$75* )'+$6& )'(9:5+'6& )'(9:5+1 )'(975$673 )'%*5
Item
2120/ 2420 / 2720mm
Hole pitch: PP
Pitch end: 10mm
1 pc
2sets
L/R1 ea 2pcs 4pcs
1 pc 1 pc
2pcs 1 pc
Accessory
Countersunk head
tapping screw 4×40
Countersunkφ6head
screw4×10････4pcs
NutM44pcs
Pan headtapping screw
î･･･････SFV
Pan headtapping screw
î･･･････SFV
Panheadtappingscrew4×252pcs
panheadscrewM4×162pcs
NutM4 2pcs
Countersunk head tapping
screw4×20･･･････4 pcs
――――
Countersunk head screw
î'
――――
№⑩
Name Door stopper
ÀRRU
Item No.
)'(9)673
Item
2pcs
Accessory
Pan head tapping
screw
î･････････SFV
―
OPTIONAL PARTS
№⑪ ⑫
Name Cover cap Door guide
track
Item No.
)':5+&3 )'+%576,/
Item
t=2
Hole pitch: 250 mm
Pitch end: PP
Nut
50
10
10
10
10
36
44
2
18
32
12 40 30 12
40
50
30
30
8
6
10
9
1
78
4
10
4
15
15
12
36
28
2
10
16
6
15
28
48
28
20
62.5
35.5
3.6
61.6
46.5
7.5
34.6
9
(7)
(10.5)
DH+13
When using
HH-P135
recessed pull
1.8
13.5
Door height DH
Door close
position
3
Track length
Track length /2
187.5[189.5]※2
2I5.6I9 CSK
Hole pitch 300
Door width DW
Door open
position
Process I5.6I9 CSK
fortrigger
DW 361 [DW 363] ※2
2
3
Door open
position
16.5
Trailing edge Leading edge
8
COMPONENT PARTS
When FRYHUFDS⑪(2SWLRQ
is used

:KHQXVLQJGRRUJXLGHWUDFN⑫
(Option）
'RRUSURFHVVGLPHQVLRQV
,167$//$7,21'5$:,1*(;$03/(
ACCESSORY：Spanner)')63
※ ²[ ]:KHQCover cap ⑪(Option) is used
Trigger JigTrigger
Countersunk head tapping
VFUHZVî'SFV
×7KHSDUWVEHORZZKLFKDUHSDFNHGZLWK
VRIWFORVHU①are not needed for this
DSSOLFDWLRQ
Screws for stopper plate are attached to ③above.
(2 pcs/set)

3
Correct set position
Incorrect set position
Trigger catcher
（Red colored part）
Correct set position
OK
I6
Trigger catcher
（Red colored part）
❶
❷
Main unit
Pull out casing
Pull up lever
Casing
Trigger、Bumper block
Track length
Track length/2
I5.6I9 CSK
I5.6I9 CSK 10
10
Cut end
2×
I4.5
2×
I4.5
2×
I4.5
50
※
3
30
172.5
40
12
※
3
※3 Door close position
2× I4.5
30 DW−376 50
※
3
40 12※
3
※3 Door open
position
Leading edge
Trailing
edge
ASSEMBLY
1&XWWLQJDQG3URYLGLQJ+ROHRQ8SSHU7UDFN
)DVWHQWKHFDVLQJ¿UPO\ZLWKWKHSURYLGHGVFUHZVUpper roller: Separate main unit from casing.
Preparation of mounting parts
2Installing Casing 3
9HUL¿FDWLRQ%HIRUH,QVWDOOLQJ6RIW&ORVHU
4
:LWKRXWYHUL¿FDWLRQWKHVHOIFORVLQJIHDWXUHPD\IDLO
If the position is wrong, pull back the trigger catcher to
WKHFRUUHFWSRVLWLRQXVLQJDPPGLDPHWHUURXQGEDU
+ROHSURFHVVLQJ
Cutting 3URFHVVLQJKROHVIRUWULJJHU
Take care of the direction
of upper track (leading
edge, trailing edge).

※3These dimensions vary according to the door open
or close position.


①Upper track
⑧Bumper block
⑥Soft Closer
⑦Upper roller
⑧Bumper block
❶
❷
❸❹
Countersunk tapping screw
4x40 (provided)
② Trigger
⑧Bumper block
Pan head screw
4×16
Nut
M4 （accessory）
Nut
M4 （accessory）
Countersunk head
screw 4×10 (D6)
5,QVHUWLQJ3DUWVLQWR8SSHU7UDFN
)L[LQJ8SSHU7UDFN
6
Installing Trigger
7
Verify that the upper track is set horizontally before
fastening.
Remove any dirt or aluminum chips from the track.
Insert the parts in order from ❶to ❹with care of direction.
Fasten triggers to the hole made during procedure 1
with the provided nuts.
1
Fasten bumper blocks temporarily to prevent the
inserted parts from falling.
Remove any dirt or aluminum chips from the track.
Leading edge
Trailing edge

5
4
30
16
4
上
下上 下
Mark
Lever
Mark
Lever
Long hole
Long hole
Support
Floor guide Lever
Casing
Roller
(main body)
CLICK
Fully closed
Fully opened
Leading edge Trailing edge
OK
⑨Floor guide
③Side cover
⑤Provided screw
④Stopper plate
8
9
Assembling Side Cover
Fixing Floor Guide Temporarily
Hanging Door
10
Position floor guide just below the
center of upper track.
3RVLWLRQWKHÀRRUJXLGHVRWKDWLWVUROOHUSDUWVWD\V
under the door when it is opened or closed.
Fasten the two elongated
holes with provided screws.
Put a 10 mm support under the door.
:KLOHKROGLQJWKHGRRULQVHUWWKH ÀRRU
guide into the groove under the door.
Insert the recessed roller into the casing until a
“click” sound is heard.
Verify that the roller is not dislocated from
the casing, for both door sides.

6
右
上
下
左
2 mm 2 mm
Front-rear adjustment
screw
Trigger
右
上
下
左
Clockwise: raise
Counterclockwise: lower
3 mm
4 mm
6‑13 9
Floor guide
Vertical adjustment
screw
$GMXVWLQJ'RRU3RVLWLRQ
12
9HUL¿FDWLRQRI6RIW&ORVHU2SHUDWLRQ
11
Remove the 10 mm support from under the door.
7KHVRIWFORVHULVHQJDJHGDSSUR[LPDWHO\PPDW
the leading edge (or 50 mm at the trailing edge) before
WKHGRRUUHDFKHVLWV¿QDOSRVLWLRQ
Please refer to the “Troubleshooting” section. when the
soft closer does not work correctly.
'RQRWFORVHWKHGRRUZLWKH[FHVVLYHIRUFH,W PD\
cause damage to the soft close mechanism.
Vertical adjustment range: 7 mm )URQWUHDU
adjustment range：4 mm
$GMXVWWKHGRRUSDUDOOHOWRWKHXSSHUWUDFNZLWKPPRIFOHDUDQFHEHWZHHQWKHGRRUDQGÀRRU
Do not turn adjustment screw
beyond adjustment range.
Do not use electric screwdriver.The adjustment of the door should
be done with the jump prevention nut
loosened.

7
Tighten
Pan head screw 4×30
Door stopper
(floor) unit
⑩Door stopper
(floor)
Door close
position
⑩Door stopper
(floor)
⑩Door stopper
(floor)
Door open
position
Jump prevention nut
$GMXVWLQJWKHÀRRUJXLGHDGMXVWPHQWUDQJHLVPP
13
Fastening the Jump Prevention Nut
14
,QVWDOOLQJGRRUVWRSSHUÀRRU
15
The jump prevention nut is on the hanger bolt of the recessed roller.
Tighten the nut with the provided spanner until it contacts the soft closer.
Fasten door stoppers at the positions where the door stops.
Be sure to tighten the nut
to prevent damaging parts.
adjustment range：4 mm
If the door movement is not smooth, remove the door,
WKHQDGMXVWWKHÀRRUJXLGHIRUZDUGVRUEDFNZDUGV
Tighten all four screws after the adjustment.

8
Spanner
Lever
How to remove door
PERIODICAL
INSPECTION
・Clean inside of track.
・Check upper and lower gaps between the door and frame. If necessary, adjust the gaps.
)LQDOYHUL¿FDWLRQ Verify that all screws are securely tightened, and verify that all screws have been used.
Supplement
Pay attention not to let the door fall.
Use a 10mm support under the door.
Then pull out the upper roller main unit from the door while raising
the lever.
It will be easier if you slide the hanger bolt with a spanner.
Trouble Checkpoint Solution
Door stops during soft
closing.
&KHFNLIGRRUERWWRPFRQWDFWVWKHÀRRU
9HULI\WKDWWKHWUDFN¿[LQJVFUHZVDUHQRWORRVHQHG
Then, adjust the door height such that the clearance between the door bottom
DQGÀRRULVPP
Check if upper track is set horizontally. Using a level gauge, reset upper track horizontally.
Check if mohair seal is installed. Reduce the friction between mohair and door.
No soft closing Check if trigger is installed. Install trigger to correct position.
&KHFNLIGRRULVFORVHGE\H[FHVVLYHIRUFH 'RQRWFORVHGRRUE\H[FHVVLYHIRUFHDVLWPD\GDPDJHVRIWFORVHU
The position of the trigger catcher may become
dislocated (See section .)
Slowly move the door toward the leading edge, then push the door firmly.
Repeat this action on the opposite side as well.
If it is still not improved, check the status of the trigger catcher in section .
Abnormal noise during
operation &KHFNLIGRRUERWWRPFRQWDFWVWKHÀRRU
9HULI\WKDWWKHWUDFN¿[LQJVFUHZVDUHQRWORRVHQHG
Then, adjust the door height such that the clearance between the door bottom
DQGÀRRULVPP
Check if door touches adjacent parts. Provide necessary space between door and adjacent objects.
Check track rollers for aluminum dust. Remove the track and pull out the roller. Then, clean the roller.
Check for loose screws retaining the upper track. Tighten the screw.
Heavy door operation Check if door touches adjacent parts. Correct door position to avoid contact with other objects.
$GMXVWSRVLWLRQRIÀRRUJXLGHRUVWRSSHU
&KHFNLIGRRUERWWRPFRQWDFWVWKHÀRRU
9HULI\WKDWWKHWUDFN¿[LQJVFUHZVDUHQRWORRVHQHG
Then, adjust the door height such that the clearance between the door bottom
DQGÀRRULVPP
Door starts to move. Check if the upper track is set horizontally. Using a level gauge, reset upper track horizontally.
■TROUBLESHOOTING
SUGATSUNE KOGYO CO.,LTD
Tokyo, JAPAN
Phone: [phone] E-mail:[email protected]
SUGATSUNE KOGYO (UK) LTD
Reading, UK
Phone: [phone] E-mail:[email protected]
SUGATSUNE EUROPE GmbH
Dusseldorf, GERMANY
Phone: [phone] E-mail:[email protected]
SUGATSUNE SHANGHAI Co., LTD
Shanghai, CHINA
Phone: [phone] E-mail:[email protected]
Guangzhou, CHINA
Phone: [phone] E-mail:[email protected]
SUGATSUNE KOGYO INDIA PRIVATE LIMITED
Mumbai, INDIA
Phone: [phone] E-mail:[email protected]
SUGATSUNE AMERICA, INC
California, USA
Phone: [phone] E-mail:[email protected]
Chicago, USA
Phone: [phone] E-mail:[email protected].
SUGATSUNE CANADA, INC.
Phone: [phone] E-mail:[email protected]
2019.02 1289-1
