LIMIT 5100 User manual

Coating Thickness Gauge 5100

Language Contents
Language page
English ....................................................................2-3
Svenska..................................................................4-5
Norsk....................................................................... -7
Dansk......................................................................8-9
Suomi......................................................................10-11
Deutsch...................................................................12-13
Nederlands.............................................................14-15
Français..................................................................16-17
Italiano.....................................................................18-19
Español...................................................................20-21
Português...............................................................22-23
Ελληvikά .................................................................24-25
Polski.......................................................................26-27
Eesti.........................................................................28-29
LietuviŠkai...............................................................30-31
Latviski....................................................................32-33
Pycckий ..................................................................34-35
6
1

2
Coating Thickness Gauge Limit 5100.
General information
Limit 5100 measure thickness of coating. E.g. paint,
plastic, porcelain enamel, copper, zinc, aluminium,
chrome galvanizing layer on magnetic and non-
magnetic materials.
Specification
Range 0 – 1000 μm
Reading 0-100 μm 0,1 μm
100-1000 μm 1 μm
Accuracy + 2,5 μm or 1-3 %.
Battery 4 st 1,5 V AAA
Automatic off After 2 minuts
Operation
1. On or manuell OFF. Push the Ө-button.
The instrument will be auto-calibrate so always keep the
probe away from any metal for 3 seconds after power on.
2. Select magnetic or non-magnetic material with N/NF
button. The display indicate Fe for magnetic material or
NFe for non-magnetic material.
3. Select μm for reading in 1/1000 mm.
4. Place the probe on an layer to be measured. Read
the coating thickness on the display.
5. For next measurement lift the probe more than 10
mm and repeat the measurement.
English

3
English
Calibration
1. Place the probe on an uncoated area.
2. Push the ZERO button.
3. Lift the probe.
4. Select a calibration foil according to your
measurement range. Measure the calibration foil on the
uncoated area.
5. Lift the probe and adjust with the ▲▼buttons the
value on the display to same value as foil.
6. Repeat the test measurement and adjust the value
until the result is correct.
It is recommended that calibration is made on same
material as to be measured.
Replace battery
When battery symbol shows on the display.
Remove the battery lid on backside and replace with 4
pcs 1,5 V batterys type AAA.
