Lockly SECURE PRO User manual

DEADBOLT EDITION
INSTALLATION
GUIDE
SECURE PRO

Reference installation parts overview foldout on back page
Welcome!
This guide will walk you through step-by-step how to
install and get your Lockly Secure Pro up and running.
Installation generally takes less than 30 minutes. If you
have any questions please reference our online support
at: Lockly.com/support or call [phone] for help.

Go to Lockly.com/installation to watch a video
version of this installation guide.
Download the BILT app in the Apple or Google Play
store for step-by-step interactive 3-D walk-through
installation instructions.
OR

Prepare door: remove existing deadbolt or use provided template to bore new holes.
Phillips Screwdriver
To complete the installation you will need:
Flathead Screwdriver Tape measure or ruler
1-⅜" (35mm)
to 2" (50mm)
1" (25mm)
2-⅜" (60mm)
or
2-¾" (70mm)
Cross-bore
2-⅛" (54mm)
Preparation
3

4
Deadbolt slot must align to the center of the door hole. Adjust as shown if needed.
The deadbolt comes set to 2-3/4" (70mm). Adjust length to 2-3/8” (60mm) if necessary.
(wear gloves to protect from possible pinching).
Hold the metal plate and
twist the deadbolt body
clockwise till it snaps to 2-3/8"
Deadbolt comes set at 2-3/4"
(70mm). To return to default,
while deadbolt is extended,
hold the metal plate and
twist the deadbolt body
counterclockwise till it snaps
to 2-3/4"
Push the crank to
extend the deadbolt
ADJUST DEADBOLT AND INSTALL
Step 1
B
B
B
B
A
CC
C
D
D
D
D
A
2-3/4" (70mm)
or 2-3/8” (60mm)

5
Extend the deadbolt by inserting a flat-head
screwdriver into the slot and turning clock-
wise.
Insert the deadbolt into door edge hole.
make sure that the right side is up and the
slot is in the vertical position. Secure with 2
screws.
(2X)
K
K
ADJUST DEADBOLT AND INSTALL
Step 1 continued
1
2

M
B
Adhesive tape
INSTALLING EXTERIOR ASSEMBLY (B)
6
Check the exterior assembly (B) alignment
to door hole and deadbolt before peeling
off film on adhesive strips.
Peel film from adhesive strips and make sure torque blade is in the vertical position with
the deadbolt extended. Place assembly and torque blade through the deadbolt slot
and guide connection cables through the cross-bore hole under the deadbolt as shown.
Complete mounting by aligning and securing until flush to exterior door surface.
Step 2
Vertical
Extended
EXTERIOR VIEW
Under

7
3: Insert and tighten by hand 2
screws located on the left and right
of the blade. Check alignment and
tighten with screwdriver until mount-
ing plate is securely placed on door.
TIP: when installing screws by hand, turn screws clockwise several turns then
counterclockwise one turn to ensure smooth threading and no cross threading.
4: Use the key to ensure deadbolt locks and
unlocks smoothly(no binding or rubbing).
IMPORTANT: when finished, leave the dead-
bolt extended and remove the key before
proceeding to the next step.
2: Align and secure mounting plate with
adhesive strips. Guide connection cables
through the hole and secure to the lower
left notched hole.
1: Check interior mounting plate (D)
alignment to your door hole before
securing with adhesive strips.
G
(2X)
INSTALLING INTERIOR ASSEMBLY (F)
Step 3
G
Remove key when finished
Leave deadbolt extended

8
Lockly Secure Pro comes with a pre-wired door sensors consisting of two parts:
Part (P) - Wired Sensor Part (Q) - Sensor Magnet
About door sensors
Door sensors provide real-time door condition status, such as the ability to verify if the
door is securely closed. It also sends push notifications to your phone whenever your
door opens and enables voice control with Amazon Alexa or Google assistant.
Removal of Sensor (optional)
There may be circumstances where the sensor cannot be installed because of molding/
door limitations or is not aesthetically desirable. The sensor wired to the lock is removable
by carefully pulling its connector from the circuit board. If removed, some features and
functionality will not be available, such as real-time condition status.
IMPORTANT: Gap must be less than 3/4” when installed.
When installed on door, the distance between the wired sensor and
sensor magnet must be less than 3/4” in order for the sensor to work.
If door frame is higher than door, add included foam pads to level
parts (P) and (Q) with each other as much as possible.
PREPARING DOOR SENSORS FOR INSTALLATION
Step 4
Do not mount (install) door sensors yet. You will install in step 7.
TIP: Lockly door sensors comes in Grey (PGA715) and Matte Black (PGA716) that
can be ordered through our customer hotline: [phone] or by email:
[email protected].

Right
or
Left
When installing the door sensors, make sure the
arrow on the wired sensor (P) aligns to the arrow
of the sensor magnet (Q) as close as possible.
The sensors need to be as close
to level as possible. If needed,
use the adhesive foam pad(s)
to adjust the height of the wired
sensor.
Sensors can be positioned on either left
or right side (see page 10).
2-3/4" (70mm)
2-3/8" (60mm)
3/4" (20mm)
Foam pad
(P) (Q)
9
PREPARING DOOR SENSORS FOR INSTALLATION
Step 4 continued

Insert form pad
The interior assembly comes with the pre-in-
stalled wired door sensor setup for a right
swing doors with 2 ¾" (70mm) backset*.
Trim excess part (P) for doors with 2 ⅜"
(60mm) backset as shown below.
For left swing doors, re-route the door
sensor
wire through the side channel. Pull
the
foam pad then re-insert to secure the
wire. Discard the excess part (e) for doors
with 2 ⅜" (60mm) backset as shown below:
*Backset = distance of the door edge to the center of the cross-bore door hole.
DO NOT INSTALL THE SENSORS YET
Pull foam pad
PREPARING DOOR SENSORS FOR INSTALLATION
(P)
10
Step 4 continued
Trim excess here for
2 ⅜" (60mm) backset*
3
2
1

NOTE: If you need to disconnect
the cable, make sure to press
the snap tab to release the plug
before carefully pulling it out.
Do not force, as this may result
in damaging the lock.
Plug the cable coming through mounting plate (D) into the interior assembly (F) as shown.
Tuck cable under eyelet hooks and route to the right on interior assembly (F).
INSTALLING THE INTERIOR ASSEMBLY (F)
11
Step 5
Plug into , match red side
of plug with red on socket - insert
tightly.
X
X
Y
Y

RESET
PROGRAM
Before placing the interior
assembly onto the mounting
plate, ensure the thumb turn
is vertical.
Place the interior assembly
against the mounting plate
and make sure the torque
blade is inserted to the thumb
turn shaft.
Secure the interior assembly
to mount platedoor with 2
screws.
Torque Blade Thumb turn shaft
I
2X
I
INSTALLING THE INTERIOR ASSEMBLY (F)
12
Step 5 continued
Align torque blade with thumb
turn shaft, make sure both are in
the vertical position.
RESET
PROGRAM
RESET
PROGRAM

13
INSTALLING BATTERIES
Step 6
1: With door open and deadbolt fully extended, place ribbon inside compartment and insert 4
batteries (note correct -/+ polarity).
2: After all batteries are installed, PRESS and HOLD the program button for 10S. The lock will auto-
matically start self-check (release program button once check starts). The self-check process
determines right or left swinging door and is very important to ensure correct installation. IMPORTANT :
if lock is not properly installed it will open and close repeatedly (refer to next page #3).
PRESS
& HOLD
123
4

14
INSTALLING BATTERIES
Step 6
3: Once self-check completes ensure the lock operates smoothly by manually locking and
unlocking the door using the thumb turn on the interior assembly. The deadbolt should operate
smoothly without any interference or binding. If necessary, repeat step 2 and ensure that (a)
the deadbolt was extended and (b) the torque blade was inserted vertically while the deadbolt
was extended.
4: Swipe your hand across the touch screen
keypad, the lock should close (lock). If deadbolt
bounces back or unlocks automatically it means
something is not installed correctly. Go back and
repeat step 2, same as above.
5. Once self-check is complete, install battery
cover (H), secure with screw on top (do not over
tighten).

LOCK SENSOR (P)
Install on the interior side only. If necessary, trim tab from sensor (P) for doors with 2-3/8"
(60mm) backset. Clean surface of door and doorframe, remove film from adhesive,
attach and secure close to door edge as shown.
2-3/4" ( 70mm)
2-3/8" ( 60mm)
(P)
15
INSTALLING THE DOORS SENSOR
Step 7
Make sure you have prepared the door sensors for installation, see step 4

NOTE: When properly installed, the Lockly logo blinks red when door opens and closes.
DOOR FRAME SENSOR (Q)
Manually retract deadbolt and close door. Dry fit sensor (Q) to door frame and check
for alignment. If needed, raise the height of the sensor to be more level with sensor (P)
by adding 1 or 2 of the included adhesive foam pads. Once satisfied both sensors are
as level as possible, remove film from adhesive and install with arrows aligned to each
other with less than a 3/4" gap between each sensor.
16
INSTALLING THE DOORS SENSOR
Step 7 continued
(Q)

Use the supplied door strike or use your existing as long as deadbolt operates smoothly
without binding or catching.
IMPORTANT: because doors and frames vary in design it may be necessary to
make slight adjustments to your strike plate and/or dust box in order to ensure
smooth deadbolt operation. This is very important. If the deadbolt is binding or
catching in any way the lock will sound an alarm (rapid beeping) indicating it
cannot close due to misalignment and/or excessive rubbing or binding.
17
INSTALLING STRIKE PLATE
Step 8
L
K(2X) N

DOWNLOAD LOCKLY APP
You have completed the Lockly physical lock installation. To enable live monitoring and
voice control with Google Assistant or Amazon Alexa, you will need to setup the included
Secure Link Wi-Fi hub and pair it with the Lockly Secure Pro deadbolt smart lock door
sensors.
Before connecting Secure Link Wi-Fi hub download the Lockly app on your smartphone. It’s
required to finish setup and to set (pair) the connection between hub and lock.
18
Step 9
Scan or visit
Lockly.com/app
